1.1
SPECIFICATIONS
CHAPTER 1
SPECIFICATIONS
1
340 CLASSIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.2
500 CLASSIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4
550 CLASSIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.6
600 CLASSIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8
700 CLASSIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10
500 INDY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12
SUPERSPORT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.14
340 INDY TOURING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16
TRAIL TOURING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.18
600 EDGE TOURING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20
700 TOURING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.22
WIDETRAK LX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24
500 XC SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26
600 HO STANDARD FUSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28
600 HO DRAGON FUSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.30
700 FUSION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32
900 FUSION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.34
600 HO SWITCHBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.36
900 SWITCHBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.38
TRAIL RMK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.40
600 HO RMK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.42
700 RMK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.44
900 RMK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.46
1.2
SPECIFICATIONS
340 CLASSIC
MODEL S06ND3AS
Table 1-1: Engine
Engine type Fuji
Engine displacement 339cc
Bore in/mm 2.45/62.3
Stroke in/mm 2.19/55.6
Piston to cylinder clearance in/
mm
.003-.005/.076-.127
Piston ring end gap .008-.014/.20-.35
Operating RPM±200 7000
Idle RPM±200 1600
Clutch engagement RPM ±200 4100
Table 1-2: Fuel Delivery
Type VM30SS
Main Jet 170
Pilot Jet 35
Jet Needle/Clip position 5DP13/3
Needle Jet O-6 (169)
Throttle gap under cutaway
in/mm
.240/6.1
Throttle slide cutaway 2.5AL
Valve seat 1.5Viton
Starter jet 1.5
Pilot air jet 2.5
Fuel screw setting N/A
Air screw setting 1.5
Recommended fuel octane
(R+M/2)
87 NonOxy/89 Oxy Min
Table 1-3: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -25_F/<-35_C
-30_F to -10_F/-34_C to -23_C
-15_F to +5_F/-26_C to -15_C
0_F to +20_F/-18_C to -7_C
+15_F to +35_F/-9_C to +2_C
+30_F to +50_F/-1_C to +10_C
+45_F to +65_F/+7_C to +18_C
>+60_F/>+16_C
0-600
(0-2000)
185
#4
180
#3
170
#3
170
#3
165
#3
160
#3
155
#3
150
#3
600-1200
(2000-4000)
175
#3
170
#3
160
#3
160
#3
155
#3
150
#3
140
#2
140
#2
1200-1800
(4000-6000)
165
#3
160
#3
155
#3
150
#3
145#
3
140
#2
130
#2
130
#2
1800-2400
(6000-8000)
155
#3
150
#3
140
#3
135
#3
135
#2
130
#2
120
#1
120
#1
2400-3000
(8000-10000)
145
#3
140
#3
130
#2
130
#2
125
#2
120
#1
110
#1
110
#1
3000-3700
(10000-12000)
135
#3
130
#2
120
#2
115
#2
115
#1
110
#1
100
#1
100
#1
Table 1-4: Clutching
Altitude meters
(feet)
Drive Clutch (P-85) Driven Clutch (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-900
(0-3000)
10
Black-
2287
Red/
Black
S36ER 16:41-72
900-1800
(3000-6000)
10-M
Blue
Black-
2287
Red/
Black
S36ER 16:41-72
1800-2700
(6000-9000)
10MW
Black-
2287
Red/
Black
S36ER 16:41-72
2700-3700
(9000-12000)
10MR
Black-
2287
Red/
Black
S36ER 16:41-72
Drive clutch bolt torque 50 ft-lbs(69Nm)
Table 1-5: Belt
Belt part number 3211078
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-6: Chaincase
Center distance in/cm 7.92/20.1
Reverse type PERC
1.3
SPECIFICATIONS
Table 1-7: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l N/A
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-8: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm .82/2.1
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.375-.5/1-1.3
Table 1-9: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041932
IFS spring rate
lbs-in/kg-mm
100/1.79
IFS Spring pre-load in/mm .625/16
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-10: Rear Suspension
Suspension type Edge
Front track shock (FTS) Arvin/7041939
FTS Spring Rate
lbs-in/kg-mm
200/3.58
FTS pre-load Fixed
Rear track shock Fox/7042120*
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-11: Torsion spring
Torsion spring PNs
(LH/RH)
7041629/7041630
Torsion spring diameter in/mm .359/9.12
Torsion spring tail angle 77_
Table 1-12: Dimensions
Width in/cm 48/122
Length in/cm 113/287
Height in/cm 48/122
Est dry weight lb/kg 517/234.7
Table 1-13: Electrical
Ignition timing 26.5_@3000RPM
Spark plug gap in/mm .028/.71
Spark plug NGK BR8ES
Voltage regulator/output 240watt
Magneto pulse 6
CDI marking CU7245
1.4
SPECIFICATIONS
500 CLASSIC
MODEL S06ND4BS
Table 1-14: Engine
Engine type Fuji
Engine displacement 488cc
Bore in/mm 2.83/72
Stroke in/mm 2.36/60
Piston to cylinder clearance in/
mm
.0035-.0049/.090-.125
Piston ring end gap .0079-.016/.20-.40
Operating RPM±200 7800
Idle RPM 1600
Clutch engagement RPM ±200 4000
Table 1-15: Fuel Delivery
Type TM38
Main Jet 360
Pilot Jet 40
Jet Needle/Clip position 9DFY1-54/2
Needle Jet P-2(825)
Throttle gap under cutaway
in/mm
.078/2.0
Throttle slide cutaway 2
Valve seat 1.5 Viton
Starter jet 145
Pilot air jet 0.9
Fuel screw setting 1.5
Air screw setting N/A
Recommended fuel octane
(R+M/2)
Min 87 NonOxy/89 Oxy
Min
Table 1-16: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -30_F/<-34_C
-30_F to +10_F/-34_C to -23_C
-10_F to +10_F/-23_C to -12_C
+10_F to +30_F/-12_C to -1_C
+30_F to +50_F/-1_C to +10_C
>50_F />+10_C
0-600
(0-2000)
390
#4
370
#3
360
#3
360
#2
340
#2
320
#2
600-1200
(2000-4000)
370
#3
350
#3
340
#2
320
#2
310
#2
300
#2
1200-1800
(4000-6000)
350
#3
330
#3
320
#2
300
#2
290
#2
270
#1
1800-2400
(6000-8000)
320
#3
310
#3
300
#2
380
#2
370
#1
250
#1
2400-3000
(8000-10000)
300
#3
290
#2
270
#2
260
#1
240
#1
230
#1
3000-3700
(10000-12000)
280
#2
270
#2
250
#1
240
#1
220
#1
210
#1
Table 1-17: Clutching
Altitude meters
(feet)
Drive Clutch (P-85) Driven Clutch (P-85)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-900
(0-3000)
10-M5 Gold Black
36 D
Button #2
21:40-74
900-1800
(3000-6000)
10-M
Blue
Gold Black
36 D
Button #2
21:40-74
1800-2700
(6000-9000)
10 MW
Dark
Blue/
White
Black
36 D
Button #2
21:40-74
2700-3700
(9000-12000)
10M Red
Dark
Blue/
White
Black
36 D
Button #2
21:40-74
Drive clutch bolt torque 50 ft-lbs(69Nm)
Table 1-18: Belt
Belt part number 3211078
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-19: Chaincase
Center distance in/cm 7.92/20.1
Reverse type Mechanical
1.5
SPECIFICATIONS
Table 1-20: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l 4.8/4.5
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-21: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm 1/2.5
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.875-.1.13/2.2-2.9
Table 1-22: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041918
IFS spring rate
lbs-in/kg-mm
100/1.79
IFS Spring pre-load in/cm 1/2.54
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-23: Rear Suspension
Suspension type Edge M-10
Front track shock (FTS) Fox/7042224*
FTS spring rate lbs-in/kg-
mm
160/2.86
FTS pre-load in/mm .90/23
Rear track shock (RTS) Fox/7042216*
RTS Springs 7041935-7041936
RTS Spring Rate lbs-in/kg-
mm
185 VAR-1000/3.3-17.9
RTS spring installed length
in/cm
10.5/25.4
Rear travel in/cm 14/35.6
* notes that shock is rebuildable
Table 1-24: Dimensions
Width in/cm 48/122
Length in/cm 113/287
Height in/cm 48/122
Est dry weight lb/kg 471/213.8
Table 1-25: Electrical
Ignition timing 26_@3000
Spark plug gap in/mm .028/.71
Spark plug Champion RN3C
Voltage regulator/output 200watt
Magneto pulse 2
CDI marking IU2212
1.6
SPECIFICATIONS
550 CLASSIC
MODEL S06ND5BS
Table 1-26: Engine
Engine type Fuji
Engine displacement 544cc
Bore in/mm 2.87/73
Stroke in/mm 2.56/65
Piston to cylinder clearance in/
mm
.0045-.0053/.11-.13
Piston ring end gap .016-.022/.40-.55
Operating RPM±200 7000
Idle RPM 1600
Clutch engagement RPM ±200 3800
Exhaust valve spring N/A
Table 1-27: Fuel Delivery
Type VM34
Main Jet 280 PTO/270 MAG
Pilot Jet 40
Jet Needle/Clip position 6BGY41/3
Needle Jet Q-4 (480)
Throttle gap under cutaway
in/mm
.250/6.35
Throttle slide cutaway 3
Valve seat 1.5 Viton
Starter jet 1.5
Pilot air jet 2.5
Fuel screw setting N/A
Air screw setting .75
Recommended fuel octane
(R+M/2)
87 NonOxy/89 Oxy Min
Table 1-28: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -30_F/<-34_C
-30_F to +10_F/-34_C to -23_C
-10_F to +10_F/-23_C to -12_C
+10_F to +30_F/-12_C to -1_C
+30_F to +50_F/-1_C to +10_C
>50_F />+10_C
0-600
(0-2000)
300/290
#4
290/280
#3
280/270
#3
270/260
#3
260/250
#3
250/240
#2
600-1200
(2000-4000)
290/280
#3
270/260
#3
260/250
#3
250/240
#3
240/230
#3
230/220
#2
1200-1800
(4000-6000)
270/260
#3
260/250
#3
250/240
#3
240/230
#2
230/220
#2
220/210
#2
1800-2400
(6000-8000)
250/240
#3
240/230
#3
230/220
#2
220/210
#2
210/200
#1
200/190
#1
2400-3000
(8000-10000)
240/230
#3
230/220
#2
220/210
#2
200/190
#2
190/180
#1
180/170
#1
3000-3700
(10000-12000)
220/210
#2
210/200
#2
200/190
#2
190/180
#1
180/170
#1
170/160
#1
Jetting listed as PTO/MAG
Table 1-29: Clutching
Altitude meters
(feet)
Drive Clutch (P-85) Driven Clutch (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-900
(0-3000)
10-62
Dark
Blue/
White
Red/Blue S40 ER 19:39- 72
900-1800
(3000-6000)
10-60
Dark
Blue/
White
Red/Blue S40 ER 19:39- 72
1800-2700
(6000-9000)
10-60
Dark
Blue/
White
Red/Blue S40 ER 19:39- 72
2700-3700
(9000-12000)
10-58
Dark
Blue/
White
Red/Blue S40 ER 19:39- 72
Drive clutch bolt torque 50 ft-lbs(69Nm)
Table 1-30: Belt
Belt part number 3211078
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-31: Chaincase
Center distance in/cm 7.92/20.1
Reverse type PERC
1.7
SPECIFICATIONS
Table 1-32: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l N/A
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-33: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm .82/2.1
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.375-.5/1-1.3
Table 1-34: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041932
IFS spring rate
lbs-in/kg-mm
100/1.79
IFS spring installed length
in/cm
9.81/24.9
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-35: Rear Suspension
Suspension type Edge
Front track shock (FTS) Arvin/7041939
FTS Spring rate
lbs-in/kg-mm
100/1.79
FTS Installed length Fixed
Rear track shock Fox/7042129*
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-36: Torsion spring
Torsion spring PNs
(LH/RH)
7041629/7041630
Torsion spring diameter in/mm .359/9.12
Torsion spring tail angle 77_
Table 1-37: Dimensions
Width in/cm 48/122
Length in/cm 113/287
Height in/cm 48/122
Est dry weight lb/kg 489/222
Table 1-38: Electrical
Ignition timing
27_@3000
14_@6500
Spark plug gap in/mm .028/.71
Spark plug NGK BR9ES
Voltage regulator/output 240watt
Magneto pulse 6
CDI marking CU7242
1.8
SPECIFICATIONS
600 CLASSIC
MODEL S06ND6ES
Table 1-39: Engine
Engine type Liberty
Engine displacement 599
Bore in/mm 3.04/77.25
Stroke in/mm 2.52/64
Piston to cylinder clearance in/
mm
.0045-.0059/.115-.149
Piston ring end gap .014-.020/.0356-.508
Operating RPM±200 8100
Idle RPM 1200
Clutch engagement RPM ±200 4000
Exhaust valve spring Green/Yellow
Table 1-40: Fuel Delivery
Type TM38
Main Jet 440
Pilot Jet 45
Jet Needle/Clip position 9DFH7-60/3
Needle Jet P-8
Throttle gap under cutaway
in/mm
.079/2
Throttle slide cutaway 2.5
Valve seat 1.5
Starter jet 140
Pilot air jet N/A
Fuel screw setting 2.5
Air screw setting 1
Recommended fuel octane
(R+M/2)
87 Min. NonOxy
Table 1-41: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -25_F/<-35_C
-30_F to -10_F/-34_C to -23_C
-15_F to +5_F/-26_C to -15_C
0_F to +20_F/-18_C to -7_C
+15_F to +35_F/-9_C to +2_C
+30_F to +50_F/-1_C to +10_C
+45_F to +65_F/+7_C to +18_C
>+60_F/>+16_C
0-600
(0-2000)
480
#4
460
#4
440
#3
430
#3
420
#3
400
#3
390
#2
380
#2
600-1200
(2000-4000)
450
#4
430
#4
420
#4
410
#3
400
#3
380
#2
360
#2
350
#2
1200-1800
(4000-6000)
420
#4
400
#4
390
#3
380
#3
370
#2
350
#2
330
#2
320
#2
1800-2400
(6000-8000)
400
#4
380
#3
360
#2
350
#2
340
#2
330
#2
310
#2
300
#2
2400-3000
(8000-10000)
370
#3
350
#2
340
#2
330
#2
320
#2
300
#2
280
#2
370
#2
3000-3700
(10000-12000)
340
#2
330
#2
310
#2
300
#2
290
#2
270
#1
260
#1
250
#1
When using non oxygenated fuel with a research octane
Number (RON) of greater than 93, decrease the main jet
number on the above chart by 30.
Table 1-42: Clutching
Altitude meters
(feet)
Drive Clutch (P-85) Driven Clutch (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-900
(0-3000)
10-58
Dark
Blue/
White
Red/Blue
58/42-36
ER
23:39-74
900-1800
(3000-6000)
10-56
Dark
Blue/
White
Red/Blue
58/42-36
ER
23:39-74
1800-2700
(6000-9000)
10-54
Dark
Blue/
White
Red/Blue
58/42-36
ER
23:39-74
2700-3700
(9000-12000)
10
Dark
Blue/
White
Red/Blue
58/42-36
ER
22:39-74
Drive clutch bolt torque 50 ft-lbs(69Nm)
Table 1-43: Belt
Belt part number 3211080
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
1.9
SPECIFICATIONS
Table 1-44: Chaincase
Center distance in/cm 7.92/20.1
Reverse type PERC
Table 1-45: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l 5.6/5.3
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-46: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm 1/2.5
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.875-1.13/2.2-2.9
Table 1-47: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041918
IFS spring rate
lbs-in/kg-mm
90-180/1.6-3.2
IFS Spring installed length
in/cm
9.5/24.1
Front vertical travel in/cm 10.25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-48: Rear Suspension
Suspension type Edge M-10
Front track shock (FTS) Fox/7042224*
FTS spring rate in-lbs/kg-
mm
160/2.86
FTS pre-load in/mm .90/23
Rear track shock (RTS) Fox/7042216*
RTS Springs 7041935-7041936
RTS Spring Rate
lbs-in/kg-mm
185 VAR-1000/3.3-17.9
RTS spring installed length
in/cm
10.5/25.4
Rear travel in/cm 14/35.6
* notes that shock is rebuildable
Table 1-49: Dimensions
Width in/cm 47.25/120
Length in/cm 113/287
Height in/cm 48/122
Est dry weight lb/kg 497/255.6
Table 1-50: Electrical
Ignition timing 24_@3500RPM
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
Voltage regulator/output 280watt
Magneto pulse 6
CDI marking 4010830
1.10
SPECIFICATIONS
700 CLASSIC
MODEL S06PD7HS
Table 1-51: Engine
Engine type Liberty
Engine displacement 755
Bore in/mm 3.05/77.5
Stroke in/mm 3.15/80
Piston to cylinder clearance in/
mm
.0045-.0074/.114-.188
Piston ring end gap .014-.020/.35-.50
Operating RPM ±200 7600
Idle RPM 1700
Clutch engagement RPM ±200 3700
Exhaust valve spring Purple
Table 1-52: Fuel Delivery
Type Cleanfire
Throttle body size in/mm 2.0/51
Fuel pressure psi/bar 116/8
Recommended fuel octane
(R+M/2)
91
Table 1-53: Idle TPS voltage setting
Altitude meters/feet Voltage ±.01v
0-1800(0-6000) .93
1800-2700(6000-9000) .95
> 2700 (>9000) .97
Table 1-54: Clutching
ALTITUDE
meters
(feet)
DRIVE CLUTCH (P-85) DRIVEN CLUTCH (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-72
Dark Blue /
White
Red/Black
62/42-46
ER
23:39-76
600-1200
(2000-4000)
10-72
Dark Blue /
White
Red/Black
62/42-46
ER
23:39-76
1200-1800
(4000-6000)
10-70
Dark Blue /
White
Red/Black
62/42-46
ER
23:39-76
1800-2400
(6000-8000)
10-68
Black /
Green
Red/Black
62/38-36
ER
22:40-76
2400-3000
(8000-10000)
10-66
Black /
Green
Red/Black
62/38-36
ER
20:41-76
3000-3600
(10000-12000)
10-64
Black /
Green
Red/Black
62/38-36
ER
20:41-76
Drive clutch bolt torque 96 ft-lbs (130Nm)
Table 1-55: Belt
Belt part number 3211080
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
Table 1-56: Chaincase
Center distance in/cm 8.373/21.27
Reverse type PERC
Table 1-57: Fluids and capacities
Fuel gal/l 9.2/34.8
Oil qts/l 3/2.8
Coolant qts/l 6.7/6.3
Chaincase oz/ml 11/325.3
Brake fluid type DOT 4
Table 1-58: M-10 Track
Width in/cm 15/38
Length in/cm 128/325
Lug height in/cm 1.25/3.2
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
7/8” - 1 1/8” (2.2 - 2.9cm)
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$31.99
Viewed 42 Times Today
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$31.99
This is the complete factory service repair workshop manual for the 2006 Polaris Snowmobile. The manual has easy-to-read text sections with top quality diagrams and instructions, making it useful for both professional mechanics and DIY enthusiasts. It covers every single detail on the machine and provides step-by-step instructions based on the complete disassembly of the machine.
Models Covers:
- 2006 Polaris 340 Classic
- 2006 Polaris 500 Classic
- 2006 Polaris 500 Indy
- ... (and more models)
Service Repair Manual Covers:
- Specifications
- General Information
- Maintenance
- Carburetion
- Cleanfire Fuel Injection
- Engines
- Clutching
- Final Drive
- Brake System
- Front Suspension and Steering
- Rear Suspensions
- Chassis and Hood
- Electrical Systems
- Wire Diagram
- And More...
File Format: .PDF
Compatibility: All Versions of Windows & Mac
Language: English
Requirements: Adobe Reader & Win
No waiting, all pages are printable. This manual is a cost-effective way to keep your vehicle working properly and is great to have.
