2008-2012 EZGO RXV Electric Golf Cars Service & Repair Manual

RXV ELECTRIC SERVICE & REPAIR ISSUED JANUARY 2008 REVISED APRIL 2009 605975 Downloaded from www.Manualslib.com manuals search engine

(NOTES, CAUTIONS AND WARNINGS CONTINUED ON INSIDE OF BACK COVER) For any questions on material contained in this manual, contact an authorized representative for clarification. Read and understand all labels located on the vehicle. Always replace any damaged or missing labels. On steep hills it is possible for vehicles to coast at greater than normal speeds encountered on a flat surface. To prevent loss of vehicle control and possible serious injury, speeds should be limited to no more than the maximum speed on level ground. See GENERAL SPECIFICATIONS. Limit speed by applying the service brake. Catastrophic damage to the drivetrain components due to excessive speed may result from driving the vehicle above specified speed. Damage caused by excessive speed may cause a loss of vehicle control, is costly, is considered abuse and will not be covered under warranty. Use extra caution when towing the vehicle(s). Do not tow a single vehicle at speeds in excess of 12 mph (19 kph). Do not tow more than three vehicles at a time. Do not exceed 5 mph (8 kph) while towing multiple vehicles. Towing the vehicle at above the recommended speed may result in personal injury and/or damage to the vehicle and other property. Vehicles equipped with the AC Drive motor must be towed with the Run-Tow switch, located under the passenger seat, in the ‘Tow’ position. If the vehicle is to be used in a commercial environment, signs similar to the ones illustrated should be used to warn of situations that could result in an unsafe condition Be sure that this manual remains as part of the permanent service record should the vehicle be resold. NOTES, CAUTIONS AND WARNINGS WASH HANDS AFTER HANDLING! Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to cause cancer and reproductive harm. BATTERY WARNING WASH HANDS AFTER HANDLING! WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to cause cancer and reproductive harm. BATTERIES CONTAIN LEAD AND RELATED PARTS ! < 14˚ 25% DO NOT DRIVE ACROSS SLOPES IN EXCESS OF 14˚ Throughout this guide NOTE, CAUTION and WARNING will be used. A NOTE indicates a condition that should be observed. A CAUTION indicates a condition that may result in damage to the vehicle. A WARNING indicates a hazardous condition that could result in severe injury or death. Please observe these NOTES, CAUTIONS and WARN- INGS; be aware that servicing a vehicle requires mechanical skill and a regard for conditions that could be hazardous. Improper service or repair may damage the vehicle or render it unsafe. Battery posts, terminals and related accessories contain lead and lead compounds. Wash hands after handling. SAFETY Downloaded from www.Manualslib.com manuals search engine

Page i Repair and Service Manual SERVICE AND REPAIR MANUAL ELECTRIC POWERED GOLF CARS & PERSONAL VEHICLES RXV FLEET GOLF CAR RXV FREEDOM GOLF CAR RXV SHUTTLE 2+2 STARTING MODEL YEAR 2008 E-Z-GO Division of TEXTRON, Inc. reserves the right to make design changes without obligation to make these changes on units previously sold and the information contained in this manual is subject to change without notice. E-Z-GO Division of TEXTRON, Inc. is not liable for errors in this manual or for incidental or consequential damages that result from the use of the material in this manual. TO CONTACT US NORTH AMERICA: TECHNICAL ASSISTANCE & WARRANTY PHONE: 1-800-774-3946, FAX: 1-800-448-8124 SERVICE PARTS PHONE: 1-888-GET-EZGO (1-888-438-3946), FAX: 1-800-752-6175 INTERNATIONAL: SALES PHONE: 001-706-798-4311, FAX: 001-706-771-4609 E-Z-GO DIVISION OF TEXTRON, INC., 1451 MARVIN GRIFFIN ROAD, AUGUSTA, GEORGIA USA 30906-3852 Downloaded from www.Manualslib.com manuals search engine

Page ii Repair and Service Manual This vehicle has been designed and manufactured in the United States of America (USA) as a ‘World Vehicle’. The Standards and Specifications listed in the following text originate in the USA unless otherwise indicated. The use of non Original Equipment Manufacturer (OEM) approved parts may void the warranty. Overfilling batteries may void the warranty. BATTERY PROLONGED STORAGE All batteries will self discharge over time. The rate of self discharge varies depending on the ambient temperature and the age and condition of the batteries. A fully charged battery will not freeze in winter temperatures unless the temperature falls below -75° F (-60° C). For winter storage, the batteries must be clean, fully charged and disconnected from any source of electrical drain. The battery charger and the controller are both sources of electrical drain. Unplug the battery charger DC plug from the vehicle receptacle. On PDS vehicles, disconnect the controller from the battery set by selecting the ‘TOW/ MAINTENANCE’ position on the RUN-TOW/MAINTENANCE SWITCH located under the passenger seat. As with all electric vehicles, the batteries must be checked and recharged as required or at a minimum of 30 day intervals. GENERAL INFORMATION Downloaded from www.Manualslib.com manuals search engine

Page iii Repair and Service Manual TABLE OF CONTENTS TITLE PAGE SAFETY ....................................................................................................................... Inside Covers MODELS ........................................................................................................................................... i GENERAL INFORMATION ............................................................................................................... ii SAFETY INFORMATION ................................................................................................................. v TITLE SECTION GENERAL INFORMATION & ROUTINE MAINTENANCE .............................................................. A SAFETY ........................................................................................................................................... B BODY ............................................................................................................................................... C WHEELS AND TIRES ...................................................................................................................... D ELECTRONIC SPEED CONTROL (AC MOTOR) ............................................................................ E FRONT SUSPENSION .................................................................................................................... F MOTOR & MOTOR BRAKE ............................................................................................................ G BATTERIES & CHARGING .............................................................................................................. H BATTERY CHARGER ....................................................................................................................... I BRAKES........................................................................................................................................... J ELECTRICAL COMPONENTS & WIRING....................................................................................... K REAR SUSPENSION ....................................................................................................................... L REAR AXLE .................................................................................................................................... M WEATHER PROTECTION ............................................................................................................... N TROUBLESHOOTING .................................................................................................................... O LIGHTNING PROTECTION & GROUNDING .................................................................................. P SPECIFICATIONS........................................................................................................................... Q Downloaded from www.Manualslib.com manuals search engine

Page iv Repair and Service Manual TABLE OF CONTENTS Notes: Downloaded from www.Manualslib.com manuals search engine

SAFETY INFORMATION Page v Repair and Service Manual Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings This manual has been designed to assist the owner-operator in maintaining the vehicle in accordance with procedures developed by the manufacturer. Adherence to these procedures and troubleshooting tips will ensure the best possible service from the product. To reduce the chance of personal injury and/or property damage, the following instructions must be carefully observed: GENERAL Many vehicles are used for a variety of tasks beyond the original intended use of the vehicle; therefore it is impossible to anticipate and warn against every possible combination of circumstances that may occur. No warnings can take the place of good common sense and prudent driving practices. Good common sense and prudent driving practices do more to prevent accidents and injury than all of the warnings and instructions combined. The manufacturer strongly suggests that the owner-operator read this entire manual pay- ing particular attention to the CAUTIONS and WARNINGS contained therein. It is further recommended that employ- ees and other operators be encouraged to do the same. If you have any questions, contact your closest representative or write to the address on the back cover of this publi- cation, Attention: Custome Care Department. E-Z-GO Division of Textron reserves the right to make design changes without obligation to make these changes on units previously sold and the information contained in this manual is subject to change without notice. E-Z-GO Division of Textron is not liable for errors in this manual or for incidental or consequential damages that result from the use of the material in this manual. This vehicle conforms to the current applicable standard for safety and performance requirements. These vehicles are designed and manufactured for off-road use. They do not conform to Federal Motor Vehicle Safety Standards and are not equipped for operation on public streets. Some communities may permit these vehicles to be operated on their streets on a limited basis and in accordance with local ordinances. With electric powered vehicles, be sure that all electrical accessories are grounded directly to the battery (-) post. Never use the chassis or body as a ground connection. Refer to GENERAL SPECIFICATIONS for vehicle seating capacity. Never modify the vehicle in any way that will alter the weight distribution of the vehicle, decrease its stability or increase the speed beyond the factory specification. Such modifications can cause serious personal injury or death. Modifications that increase the speed and/or weight of the vehicle will extend the stopping distance and may reduce the stability of the vehicle. Do not make any such modifications or changes. The manufacturer pro- hibits and disclaims responsibility for any such modifications or any other alteration which would adversely affect the safety of the vehicle. Vehicles that are capable of higher speeds must limit their speed to no more than the speed of other vehicles when used in a golf course environment. Additionally, speed should be further moderated by the environmental conditions, terrain and common sense. GENERAL OPERATION Always use the vehicle in a responsible manner and maintain the vehicle in safe operating condition. Always read and observe all warnings and operation instruction labels affixed to the vehicle. Always follow all safety rules established in the area where the vehicle is being operated. Downloaded from www.Manualslib.com manuals search engine

Page vi SAFETY INFORMATION Repair and Service Manual Read all of Section B and this section before attempting any procedure. Pay particular attention to all Notes, Cautions and Warnings. B Always reduce speed to compensate for poor terrain or conditions. Always apply service brake to control speed on steep grades. Always maintain adequate distance between vehicles. Always reduce speed in wet areas. Always use extreme caution when approaching sharp or blind turns. Always use extreme caution when driving over loose terrain. Always use extreme caution in areas where pedestrians are present. MAINTENANCE Always maintain your vehicle in accordance with the manufacturer’s periodic service schedule. Always ensure that mechanics performing repairs are trained and qualified to do so. Always follow the manufacturer’s directions if you do any maintenance on your vehicle. Be sure to disable the vehicle before performing any maintenance. Disabling includes removing the key from the key switch and removal of a battery wire. Always insulate any tools used within the battery area in order to prevent sparks or battery explosion caused by short- ing the battery terminals or associated wiring. Remove the batteries or cover exposed terminals with an insulating material. Always check the polarity of each battery terminal and be sure to rewire the batteries correctly. Always use specified replacement parts. Never use replacement parts of lesser quality. Always use recommended tools. Always determine that tools and procedures not specifically recommended by the manufacturer will not compromise the safety of personnel nor jeopardize the safe operation of the vehicle. Always support the vehicle using wheel chocks and safety stands. Never get under a vehicle that is supported by a jack. Lift the vehicle in accordance with the manufacturer’s instructions. Never attempt to maintain a vehicle in an area where exposed flame is present or persons are smoking. Always be aware that a vehicle that is not performing as designed is a potential hazard and must not be operated. The manufacturer cannot anticipate all situations, therefore people attempting to maintain or repair the vehicle must have the skill and experience to recognize and protect themselves from potential situations that could result in severe personal injury or death and damage to the vehicle. Use extreme caution and, if unsure as to the potential for injury, refer the repair or maintenance to a qualified mechanic. Always test drive the vehicle after any repairs or maintenance. All tests must be conducted in a safe area that is free of both vehicular and pedestrian traffic. Always replace damaged or missing warning, caution or information labels. Always keep complete records of the maintenance history of the vehicle. Downloaded from www.Manualslib.com manuals search engine

SAFETY INFORMATION Page vii Repair and Service Manual Read all of Section B and this section before attempting any procedure. Pay particular attention to all Notes, Cautions and Warnings. B B VENTILATION Hydrogen gas is generated in the charging cycle of batteries and is explosive in concentrations as low as 4%. Because hydrogen gas is lighter than air, it will collect in the ceiling of buildings necessitating proper ventilation. Five air exchanges per hour is considered the minimum requirement. Never charge a vehicle in an area that is subject to flame or spark. Pay particular attention to natural gas or propane gas water heaters and furnaces. Always use a dedicated circuit for each battery charger. Do not permit other appliances to be plugged into the receptacle when the charger is in operation. Chargers must be installed and operated in accordance with charger manufacturers recommendations or applicable electrical code (whichever is more restrictive). Downloaded from www.Manualslib.com manuals search engine

Page viii Repair and Service Manual Notes: SAFETY INFORMATION Read all of Section B and this section before attempting any procedure. Pay particular attention to all Notes, Cautions and Warnings. Downloaded from www.Manualslib.com manuals search engine
