PA-28 AND PA-28R
CHEROKEE
PARTS CATALOG
CARD 1 OF 4
PA-28-140 PA-28-180
PA-28-150 PA-28-235
PA 28-160 PA-28R-180
PA-28R-200
PIPER AIRCRAFT CORPORATION
(PART NUMBER 753 582)
1A1
AEROFICHE EXPLANATION
The Parts Catalog information incorporated in this set of Aerofiche cards has been arranged in accordance with the
general specifications of Aerofiche adopted by the General Aviation Manufacturer’s Association.
Conversion of Aerofiche alpha/numeric code numbers:
First number is the Aerofiche card identifier.
Letter is the horizontal line reference per card.
Second number is the vertical line reference per card.
Example: 2-J16 = Aerofiche card number two of given set, Grid location J16.
To aid in locating the various sections and related information desired, the following is provided:
A complete Catalog Table of Contents is given at Grid 1A8 of Aerofiche card number 1 of this set. Each additional
card in this set will have a Table of Contents for all sections on that particular card. This table will start at Grid A3.
REVISIONS
The information compiled in this Aerofiche Parts Catalog will be kept current by revisions distributed periodically.
These revisions will supersede all previous revisions and will be complete Aerofiche card replacements and shall super-
sede Aerofiche cards of the same number in the set.
Current revisions to this PA-28 and PA-28R Parts Catalog issued August 16,1973 are as follows:
753 582 (PR750815)....................................................................................Dated August 1975
753 582 (PR460430)........................................................................................Dated April 1976
753 582 (PR760831)....................................................................................Dated August 1976
753 582 (PR770304) .....................................................................................Dated March 1977
753 582 (PR770715) ........................................................................................Dated July 1977
753 582 (PR780908) .............................................................................Dated September 1978
753 582 (PR790405)........................................................................................Dated April 1979
753 582 (PR800520) ........................................................................................Dated May 1980
753 582 (IR860226) ..................................................................................Dated February 1986 (Interim change)
753 582 (IR950215) ..................................................................................Dated February 1995 (Interim change)
PIPER PARTS CATALOG
INTERIM REVISION: FEBRUARY 1995 PA-28 & PA-28R
1A2
INTERIM CHANGE
Figures 13 and 14 of card 1, and Figures 56, 64, 65,
and 76 of card 3 have been revised. There are no other
changes included in this interim change revision.
Please discard your current cards 1 and 3 and replace
them with the revised ones. DO NOT DISCARD CARDS
2 AND 4.
INTRODUCTION
The illustrated Parts Catalog is designed to provide simple but positive identification of replacement parts for the Piper “CHEROKEE”
Model PA-28 and PA-28R manufactured by the Piper Aircraft Corporation of Vero Beach, Florida,
NOTE: UNDER NO CIRCUMSTANCES SHALL THIS CATALOG BE USED FOR RIGGING AND INSTALLATION PURPOSES.
It is suggested that this catalog be thoroughly studied to determine its arrangement prior to its utilization.
1. The catalog is divided into eleven (11) major sections described as follows:
a. Section I to X inclusive contains all replacement parts for the complete airplane. Each section is subdivided and each division
includes an illustration and a parts listing.
b. Section Xl is the Miscellaneous Group. This group includes a listing of the Optional Equipment Kits, Repair Kits and Special
Tools
2. The following is a brief explanation of the column in the parts Listing:
a. The “FIGURE AND INDEX” column indicates the illustration figure number and its part index number EXAMPLE (2-1), the 2 is
the figure number and the 1 is the index number. The figure number appears only at the top of each parts listing page or at the beginning of
each new parts listing.
b. The “PART NUMBER” column contains the identifying number of the replacement part and the part number must be shown on
all Parts Orders.
c. The “CODE” column is for the purpose of indicating special use of the part. An explanation of the Ietter code used is shown
below each listing
ALL PARTS CODED WITH A “W” MUST BE PURCHASED FROM
PIPER AIRCRAFT CORPORATION, LOCK HAVEN, PENNA
ALL PARTS NOT CODED WITH A “W” MUST BE PURCHASED FROM
PIPER AIRCRAFT CORPORATION, VERO BEACH, FLORIDA
d. The “NOMENCLATURE” column indicates the part name. The name must be shown on all Parts Orders.
e. The “NO REQ.” (Number Required) column represents the total quantity of parts used per aircraft per figure when the part is not
indented and the quantity of parts used per assembly when the part is indented. The symbol “AR” listed in the coIumn means “As Required”.
Identification Example: Indentations of listings in the “Nomenclature coIumn” indicates “assemblies” and “components” or “parts”, in
order of their indentations.
EXAMPLE
Figure
and Part NO SERIAL NUMBERS
Index Number Code NOMENCLATURE Req. AFFECTED
Number
DOOR ASSEMBLY - Baggage compartments
• FRAME ASSEMBLY - Baggage compartment door
•• HINGE ASSEMBLY - Baggage door
•• CLIP - Baggage door spring
This listing is interpreted as foIIows:
If the DOOR ASSEMBLY (not indented) is ordered, it will include the three items listed under that item,
If the FRAME ASSEMBLY (indented one space) is ordered, it will include the two items listed under the sub-assembly.
If you want only a HINGE ASSEMBLY or CLIP, you order only that item
f. The “SERIAL NUMBERS AFFECTED” column indicates the part application by airplane serial number.
PIPER PARTS CATALOG
REVISED: AUGUST 1976 PA-28 & PA-28R
1A3
3. The “ATTACHING PARTS” such as nuts, bolts, screws, etc., that are available as commercial hardware items, are not generally sup-
plied by the Piper Aircraft Corporation. The catalog lists for your convenience, those attaching parts required for main assemblies and in stal-
lation. The identifying number for these parts appear after the part name.
4, All items of Optional Equipment are contained in the parts list in their proper sequence and sections The items were not marked
optional, since they are fuIIy identified by their descriptions.
HOW TO IDENTIFY A PART
IF YOU KNOW WHAT IT LOOKS LIKE
AND KNOW WHERE IT IS LOCATED
1. Refer to Figure 1 to determine the Section number in which the part is used.
2. Refer to the Table of Contents and locate the section. Note the figure number that illustrate the various subgroups of this main section.
a. Select the figure title you think might continue the part you wish to identify and proceed to the grid (page) specified.
3. Find the part on the illustration and note the index number.
NOTE If you don’t find the part on this illustration, try another figure in this group.
4. Refer to the “Figure and Index Number” in the Parts Listing for complete description of the part.
HOW TO ORDER PARTS
In ordering parts for your Piper Airplanes, observe the following instructions which will aid in your getting the right parts required without
delay:
a. Place your order with the distributor or dealer for your territory, since parts are available only through our distributor organization.
b. Always specify the model and serial number of your airplane.
c. Always specify Part Number, Name, type and quantity required.
d. Specify the method of shipment - freight, express, parcel post, air express, air freight, or air parceI post. Where the nature of the ship-
ment requires it or when no instructions are given, we reserve the right to ship the most suitable way.
GENERAL INFORMATION
a. Shortages
All orders are checked and rechecked before leaving our Shipping Department. A packing slip is enclosed with the shipment and claims
for errors or shortages must be made within the (3) days after receipt of orders.
b. Returned Goods
No material should be returned to us without first securing our written permission. Material sent in without notice will be held at the
owner’s risk for thirty (30) days and will then be disposed of as we see fit.
Transportation charge must be PREPAID on returned goods or the shipment will be refused.
c. Transportation Liabilities
The Piper Aircraft Corporation cannot be held liable for damages to Parts in transit from the factory. If a shipment is received in a dam-
aged condition, have the delivery man or Transportation Company make a notation of the damage and file your claim with the Carrier. In case
of concealed damage, do not attempt to remove the part from the shipping container, or endeavor to repair the damage, but call the Carrier
and have his Claim Agent inspect the damage before filing your claim with the Carrier.
PIPER PARTS CATALOG
REVISED: AUGUST 1976 PA-28 & PA-28R
1A4
PA-28 AND PA-28R SERIAL NUMBER INFORMATION
The following information should be kept in mind when ordering from this catalog:
a. The serial numbers of the aircraft covered by this Part Catalog are as follows:
(1) Serial numbers of the 1961 PA-28-150 and PA-28-160 Models are 28-1 to 28-84 inclusive.
(2) Serial numbers of the 1962 PA-28-150 and PA-28-160 Models are 28-85 to 28-670 inclusive.
(3) Serial numbers of the 1963 PA-28-150 and PA-28-160 Cherokee “B” Models are 28-725 to 28-1760 inclusive.
(4) Serial numbers of the PA-28-180 Cherokee “B” Models are 28-671 to 28-1760 inclusive.
(5) Serial numbers of the PA-28-150, PA-28-160 and PA-28-180 Cherokee “C” Models are 28-1761 to 28-4377 inclusive.
(6) Serial numbers of the PA-28-180 Cherokee “D” Models are 284378 to 28-5600 inclusive.
(7) Serial numbers of the PA-28-180 Cherokee “E” Model- are 28-5601 to 28-5869 inclusive.
(8) Serial numbers of the PA-28-180 Cherokee “F” Models are 28-7105001 to 28-7105244 inclusive.
(9) Serial numbers of the PA-28-180 Cherokee “G” Models are 28-7205001 to 28-7205328 inclusive.
(10) Serial numbers of the 1973 PA-28-180 Cherokee Models are 28-7305001 to 28-7305611 inclusive, and 28-E13. (SEE NOTE)
(11) Serial numbers of the 1974 PA-28-180 Cherokee Models are 28-7405001 to 28-7405290 inclusive.
(12) Serial numbers of the 1975 PA-28-180 Cherokee Models are 28-7505001 to 28-7505261 inclusive.
(13) Serial numbers of the PA-28-140 Models are 28-20002 to 28-24999 inclusive.
(14) Serial numbers of the PA-28-140 Cherokee “B” Models are 28-25000 to 28-26400 inclusive.
(15) Serial numbers of the PA-28-140 Cherokee “C” Models are 28-26401 to 28-26956 inclusive.
(16) Serial numbers of the PA-28-140 Cherokee “D” Models are 28-7125001 to 28-7125651 inclusive.
(17) Serial numbers of the PA-28-140 Cherokee “E” Models are 28-7225001 to 28-7225612 inclusive.
(18) Serial numbers of the 1973 PA-28-140 Cherokee Models are 28-7325001 to 28-7325684 inclusive.
(19) Serial numbers of the 1974 PA-28-140 Cherokee Model are 28-7425001 to 28-7425454 inclusive.
(20) Serial numbers of the 1975 PA-28-140 Cherokee Models are 28-7525001 to 28-7525350 inclusive
(21) Serial number of the 1976 PA-28-140 Cherokee Models are 28-7625001 to 28-7625234 inclusive.
(22) Serial numbers of the 1977 PA-28-140 Cherokee Models are 28-7725001 to 28-7725290 inclusive,
(23) Serial numbers of the PA-28-235 Models are 28-10003 to 28-10719 inclusive,
(24) Serial numbers of the PA-2B-235 Cherokee “B” Models are 28-10720 to 28-11039 inclusive.
(25) Serial numbers of the PA-28-235 Cherokee “C” Model are 28-11040 to 28-11300 inclusive.
(26) Serial numbers of the PA-28-235 Cherokee “D” Models are 28-11301 to 28-11393 inclusive.
(27) Serial numbers of the PA-28-235 Cherokee “E” Models are 28-7110001 to 28-7110042 inclusive.
(28) Serial numbers of the PA-28-235 Cherokee “F” Models are 28-7210001 to 28-7210033 inclusive.
(29) Serial numbers of the 1973 PA-28-235 Cherokee Models are 28-7310001 to 28-7310187 inclusive, and 28-E11. (SEE NOTE)
(30) Serial numbers of the 1974 PA-28-235 Cherokee Models are 28-7410001 to 28-7410120 inclusive.
(31) Serial numbers of the 1975 PA-28-235 Cherokee Models are 28-7510001 to 28-7510145 inclusive.
(32) Serial numbers of the 1976 PA-28-235 Cherokee Models are 28-7610001 to 28-7610206 inclusive.
(33) Serial numbers of the 1977 PA-28-235 Cherokee Models are 28-7710001 to 28-7710089 inclusive.
NOTE: PA-28-180 with serial number 28-E13 and PA-28-235 with serial number 28-E11 are not
referenced in the various Parts Lists throughout this catalog.
PA-28-180 with serial number 28-E13 is to be serviced the same as serial number 28-7305001.
PA-28-235 with serial number 28-E11 is to be serviced the same as serial number 28-7310001.
PIPER PARTS CATALOG
REVISED: SEPTEMBER 1978 PA-28 & PA-28R
1A5
PA-28 AND PA-28R SERIAL NUMBER INFORMATION (cont. )
(34) Serial numbers of the PA-28R-180 Cherokee Models are 28R-30005 to 28R-30481 inclusive, and 28R-30483
to 28R-31279 inclusive.
(35) Serial number of the PA-28R-180 Cherokee "B" Models are 28R-7130001 to 28R-7130019 inclusive.
(36) Serial numbers of the PA-28R-200 Cherokee Models are 28R-30482, 28R-35001 to 28R-35830 inclusive.
(37) Serial numbers of the PA-28R-200 Cherokee "B" Models are 28R-7135001 to 28R-7135238 inclusive.
(38) Serial number of the PA-28R-200 Cherokee "II" Models are 28R-7235001 to 28R-7235330 inclusive
(39) Serial numbers of the 1973 PA-28R-200 Cherokee "II" Models are 28R-7335001 to 28R-7335455 inclusive,
(40) Serial numbers of the 1974 PA-28R-200 Cherokee "II" Models are 28R-7435001 to 28R-7435331 inclusive.
(41) Serial numbers of she 1975 PA-28R-200 Cherokee "I" Models are 28R-7535001 to 28R-7535303 inclusive.
(42) Serial numbers of the 1976 PA-28R-200 Cherokee "II" Models are 28R-7635001 to 28R-7635545 inclusive.
PIPER PARTS CATALOG
REVISED: SEPTEMBER 1978 PA-28 & PA-28R
1A6
STANDARD PAINT CHART
MFG. PIPER PART NUMBER
NO. QUART GALLON
EXTERIOR
ENAMEL
Daytona J-9545 751 700 751 701
Bahama Blue H-9170 751 714 751 715
Phoenix W-3557 754 718 754 719
Portland Green W-3558 754 724 754 725
Pontiac Red W-3665 754 716 754 717
El Paso Brown (Metallic W-8433 754 737 754 738
Tampa Green (Metallic W-8427 754 739 754 740
Newport Blue (MetaIIic) W-8430 754 741 754 742
ACRYLIC LACQUER
Pontiac Red B-7943 4175 592 1175 592
Tampa Green B-5430 4175 360 1175 360
Newport Blue B-5501 4175 434 1175 434
Monterey Maroon (base coat) K-2789 4175 441 1175 441
Monterey Maroon (top coat) B-5480 4175 437 1175 437
Juneau White B-7784-A 4175 657 1175 657
LakeIand Blue B-5440 4175 433 1175 433
Orlando Green B-5490 4175 361 1175 361
Mocha Tan B-5450 4175 627 1175 627
Denver Brown (base coat K-2790 4175 299 1175 299
Denver Brown (top coat) B-5460 4175 409 1175
Madrid Red B-5511 4175 593 1175
Dakota Black H-6117-R 4175 373 1175 373
Beaumont Blue B-5530 4175 435 1175 435
Bahama Blue B-9170 4175 436 1175 436
Bimini Turquoise B-9915 4175 438 1175 438
Nassau Turquoise B-9914 4175 439 1175 439
Reno Gold B-9916 4175 345 1175 345
Lincoln Gray B-7919 4175 362 1175 362
Dallas Yellow Y-5783 4175 701 1175 701
Ocala Orange (base coat) P-7946 4175 499 1175 499
OcaIa Orange (top coat) C-2065-A 4175 500 1175 500
PoIar Gray Y-6100-R 4175 341 1175 341
Las Vegas Gold G-2124-A 4175 332 1175 332
Avocado G-2352 4175 331 1175 331
Thinner B-5408-B 4179 102 1179 402
PIPER PARTS CATALOG
REVISED: MAY 1980 PA-28 & PA-28R
1A7
TABLE OF CONTENTS
FIGURE NUMBER FIGURE TITLE GRID NUMBER
1 View of Complete Airplane .................................................................................................. 1A15
SECTION l
WING GROUP
2 Wing Installation (PA-28-140/150/160/180/235, PA-28R-180/200) ...................................... 1A16
3 Wing Leading Edge Assembly (PA-28-140/150/160/180/235, PA-28R-180/200) ................ 1A21
4 Wing Trailing Edge Assembly (PA-28-140/150/160/180/235) .............................................. 1B1
5 Wing Trailing Edge Assembly (PA-28R-180/200) ................................................................ 1B4
6 Aileron Assembly (PA-28-140/150/160/180/235, PA-28R-180/200) .................................... 1B7
7 Flap Assembly ..................................................................................................................... 1B9
SECTION II
FUSELAGE GROUP
8 Complete Fuselage (PA-28-140, PA-28-150/160/180 - S/N 28-1 to 28 4377 incl.,
PA-28-235 - S/N 28-10003 to 28-11039 incl.) ...................................................................... 1B12
9 Complete Fuselage (PA-28-180 - S/N 28-4378 to 28-7505261 incl., PA-28-235
S/N 28-1 1040 and up, PA-28R-180 - S/N 28R-30005 to 28R-30481 incl., 28R-30483
to 28R-7130019 incl. PA-28R-200 - S/N 28R-30482, 28R-35001 and up) ........................... 1C1
10 Upper Forward Cockpit Assembly (PA-28-140/ 150/ 160/ 180/235) .................................... 1C14
11 Upper Forward Cockpit Assembly (PA-28R-180/200) ......................................................... 1D1
12 Upper Center Cockpit Assembly .......................................................................................... 1D6
13 Lower Forward Cockpit Assembly ........................................................................................ 1E1
14 Lower Aft Cockpit Assembly ................................................................................................ 1E14
15 FuseIage Aft Section ............................................................................................................ 1E18
16 Instrument Panel Installation (PA-28-140 - S/N 28-20002 to 28-24999 incl.,
PA-28-150/160/180 - S/N 28-1 to 28-4377 incl., PA-28-235 - S/N 28-10003 to
28-1 1039 incl.) ..................................................................................................................... 1F1
17 Instrument Panel Installation (PA-28-140 - S/N 28-25000 and up, PA-28-180 - S/N
28-4378 and up, PA-28-235 - S/N 28-11040 and up, PA-28R-180 - S/N 28R-30005
to 28R-30481 incl., 28R-30483 to 28R-7130019 incl., PA-28R-200 - S/N 28R-30482,
28R-35001 and up) ............................................................................................................... 1F8
18 Vacuum System Installation (PA-28-1 40 - S/N 28-20002 to 28-24999 incl.,
PA-28-150/160/180 - S/N 28-1 to 28-4377 incl., PA-28-235 - S/N 28-10003 to
28-1 1039 incl.) ..................................................................................................................... 1G6
19 Vacuum System Installation (PA-28-180 - S/N 28-4378 to 28-5121 28-5123 to
28-5129, 28-5180 to 28-5227 incl.., PA-28R-180 - S/N 28R-30005 to 28R-30481
incl.., 28R-30483 to 28R-30878 incl.) .................................................................................. 1G11
19A Vacuum System Installation (PA-28-140 - S/N 28-25000 to 28-26956 incl. ,
PA-28-180 - S/N 28-5122, 28-5130 to 28-5179 incl. , 28-5228 to 28-5869 incl. ,
PA-28-235 - S/N 28-11040 to 28-11393 incl. , PA-28R-180 - S/N 28R-30879 to
28R-31279 incl., PA-28R-200 - S/N 28R-30482, 28R-35001 to 28R-35830 incI.) ............... 1G13
19B Vacuum System Installation (PA-28-140 - S/N 28-7125001 and up, PA-28-180 - S/N
28-7105001 and up, PA-28-235 - S/N 28-7110001 and up, PA-28R-180 - S/N
28R-7130001 and up, PA-28R-200 - S/N 28R-7135001 and up) ........................................ 1G15
20 Pitot-Static System Installation (PA-28-140 - S/N 28-20002 to 28-24999 incl.,
PA-28-150/160/180 - S/N 28-1 to 28-4377 incl. , PA-28-235 - S/N 28-10003 to
28-11039 incl. ) ..................................................................................................................... 1G18
PIPER PARTS CATALOG
REVISED: MAY 1980 PA-28 & PA-28R
1A8
TABLE OF CONTENTS
FIGURE NUMBER FIGURE TITLE GRID NUMBER
SECTION II (cont.)
FUSELAGE GROUP
21 Pitot-Static System Installation (PA-28-140 - S/N 28-25000 and up, PA-28-180
S/N 28-4378 and up, PA-28-235 - S/N 28-11040 and up, PA-28R-180 - S/N
28R-30005 to 28R-30481 incl., 28R-30483 and up, PA-28R-200 - S/N 28R-30482,
28R-35001 and up) .............................................................................................................. 1G22
22 Fuselage Enclosure Installation (PA-28-140 - S/N 28-20002 to 28-7225612 incl.,
PA-28-150/160/180 - S/N 28-1 to 28-4377 incl., PA-28-235 - S/N 28-10003 to
28-1 1039 incl.) . ................................................................................................................... 1H1
22A Fuselage Enclosure Installation (PA-28-235 - S/N 28-11040 to 28-7210033 incl.) .............. 1H7
23 Fuselage Enclosure Installation (PA-28-180 - S/N 28-4378 to 28-7205328 incl.
PA-28R-180 - S/N 28R-30005 to 28R-30481 incl., 28R-30483 to 28R-7130019 incl.,
PA-28R-200 - S/N 28R-30482, 28R-35001 to 28R-7235330 incI.) ...................................... 1H10
23A Fuselage Enclosure Installation (PA-28-180 - S/N 28-7305001 and up, PA-28-235 S/N
28-7310001 and up, PA-28R-200 - S/N 28R-7335001 and up) ........................................... 1H14
23B Fuselage Enclosure Installation (PA-28-140 - S/N 28-7325001 and up) .............................. 1H21
24 Cabin and Baggage Door Installation (PA-28-140 - S/N 28-20002 to 28-7625030
incl., PA-28-150/160/180 - S/N 28-1 to 28-7505261 incl., PA-28-235 - S/N
28-10003 to 28-7610020 incl., PA-28R-180, PA-28R-200 - S/N 28R-30482,
28R-35001 to 28R-7635017 incI.) ........................................................................................ 1I1
24A Cabin and Baggage Door Installation (PA-28-140 - S/N 28-7625031 and up,
PA-28-235 - S/N 28-7610021 and up, PA-28R-200 - S/N 28R-7635018 and up) ................ 1J4
25 Cockpit Finishing Installation (PA-28-150/160/180 - S/N 28-1 to 28-4377 incl.,
PA-28-235 - S/N 28-1003 to 28-11039 incl. ........................................................................ 1J9
26 Cockpit Finishing Installation (PA-28-140) ........................................................................... 1K1
27 Cockpit Finishing Installation (PA-28-180 - S/N 28-4378 and up, PA-28R-180 - S/N
28R-30005 to 28R-30481 incl. 28R-30483 and up, PA-28R-200 - S/N 28R-30482,
28R-35001 and up) ............................................................................................................... 2A6
27A Cockpit Finishing Installation (PA-28-235 - S/N 28-11040 and up) ...................................... 2B17
27B Window Curtains Installation (PA-28-235 - S/N 28-7710001 and up, PA-28R-200 S/N
28R-7635504 and up)........................................................................................................... 2C9
28 Seats Installation (PA-28-140 - S/N 28-20002 to 28-26956 incl., PA-28-150/160/180 S/N
28-1 to 28-5869 incl. PA-28-235 - S/N 28-10003 to 28-11393 incl. , PA-28R-1 80 S/N
28R-30005 to 28R-30481 incl., 28R-30483 to 28R-31279 incl., PA-28R-200 - S/N
28R-30482, 28R-35001 to 28R-31279 incl.) ......................................................................... 2C11
28A Seats Installation (PA-28-140 - S/N 28-7125001 and up, PA-28-180 - S/N
28-7105001 and up, PA-28-235 - S/N 28-7110001 and up, PA-28R-180 - S/N
28R-7130001 and up PA-28R-200 - S/N 28R-7135001 and up) ......................................... 2D3
28B Vertically Adjustable Front Seat Assembly (PA-28-140 - S/N 28-26401 to 28-7325684
incl. , PA-28-180 - S/N 28-5601 to 28-7205328 incl., PA-28-235 - S/N 28-11301 to
28-7210033 incl., PA-28R-180 - S/N 28R-31251 to 28R-7130019 incl., PA-28R-200 - S/N
28R-35601 to 28R-7135238 incl.) ........................................................................................ 2E1
28C Vertically Adjustable Front Seat Assembly (PA-28-140 - S/N 28-7425061 and up,
PA-28-180 - S/N 28-7405035 and up, PA-28-235 - S/N 28-7410027 and up,
PA-28R-200 - S/N 28R-7435035 and up) ............................................................................. 2E5
29 Rear Seat Installation (PA-28-140)....................................................................................... 2E11
30 Cabin Heat, Defroster and Fresh Air System (PA-28-140 - S/N 28-20002 to 28-24999
incl. , PA-28-150/160/180 - S/N 28-1 to 28-1760 incl.) ........................................................ 2E14
31 Cabin Heat Defroster and Fresh Air System (PA-28-235 - S/N 28-10003 to 28-11039
incl. , PA-28-150/160/180 - S/N 28-1761 to 28-4377 incl. ................................................... 2E19
PIPER PARTS CATALOG
REVISED: MAY 1980 PA-28 & PA-28R
1A9
TABLE OF CONTENTS
FIGURE NUMBER FIGURE TITLE GRID NUMBER
SECTION II (cont.)
FUSELAGE GROUP
31A Cabin Heat and Defroster Installation (PA-28-180 - S/N 28-4378 and up, PA-28-235 -
S/N 28-11040 and up) ......................................................................................................... 2F1
31B Cabin Heat and Defroster Installation (PA-28-140 - S/N 28-25000 and up) ........................ 2F7
32 Cabin Heat and Defroster Installation (PA-28R-180/200) . .................................................. 2F10
32A Air Conditioning Compressor, Refrigerant Lines and Alternator Installation (PA-28-140
S/N 28-25001, 28-7125472 and up, PA-28-180 - S/N 28-5653, 28-7205092 and up,
PA-28R-200- S/N 28R-7235001 and up) .............................................................................. 2F15
32B Air Conditioning Duct and Evaporator Installation (PA-28-140 - S/N 28-25001,
28-7125472 and up, PA-28-180 - S/N 28-5653 28-7205092 and up. PA-28R-200 S/N
28R-7235001 and up)........................................................................................................... 2F20
32C Air Conditioning Condenser Installation (PA-28-140 - S/N 28-25001, 28-71 25472
and up PA-28-180 - S/N 28-5653, 28-7205092 and up PA-28R-200 - S/N
28R-7235001 and up)........................................................................................................... 2G1
32D Cabin Overhead Air Vent Installation (PA-28-140 - S/N 28-26401 to 28-7325684
incl., PA-28-180 - S/N 28-5601 to 28-730561 1 incl., PA-28-235 - S/N 28-1 1 301 to
28-7310187 incl., PA-28R-180 - S/N 28R-31251 to 28R-7130019 incl., PA-28R-200 S/N
28R-35601 to 28R-7335455 incl.) ........................................................................................ 2G5
32E Fresh Air Ventilation Installation (PA-28-140 - S/N 28-7425001 and up, PA-28-180 -
S/N 28-7405001 and up, PA-28-235 - S/N 28-7410001 and up PA-28R-200 - S/N
28R-7435001 and up) .......................................................................................................... 2G7
SECTION III
CHASSIS GROUP
33 Nose Gear Installation (PA-28-140/150/160/180/235) ......................................................... 2G12
33A Nose Gear Strut Assembly (PA-28-140/150/160/180/235) .................................................. 2G18
34 Nose Gear Installation (PA-28R-180/200) ............................................................................ 2H1
35 Nose Gear Assembly (PA-28R-180/200) ............................................................................. 2H6
36 Nose Wheel Assembly (Cleveland) ...................................................................................... 2H10
36A Nose Wheel Assembly (McCauley) (PA-28-140/150/160/180/235) .................................... 2H12
36B Nose Wheel Assembly (McCauley) (PA-28R-180/200) ....................................................... 2H14
37 Main Gear Installation (PA-28-140/150/160/180/235) ......................................................... 2H16
38 Main Gear Installation (PA-28R-180/200) ............................................................................ 2H21
39 Main Gear Assembly (PA-28R-180/200) ............................................................................. 2I1
40 Main Wheel Assembly .......................................................................................................... 2I4
41 Brake Assembly ................................................................................................................... 2l7
42 Landing Gear Door Installation (PA-28R-180/200) ............................................................... 2l10
43 Main and Nose Wheel Fairing Installation (PA-28-140/150/160/180/235) .......................... 2I13
44 Main Landing Gear Strut Fairing Installation (PA-28-140/150/160/180/235) ........................ 2J1
45 Hand Brake Installation (PA-28-150/160 - S/N 28-1 to 28-250 incl.) ................................... 2J3
46 Hand Brake Installation (PA-28-150/160 - S/N 28-251 and up, PA-28-140/180/235) .......... 2J6
47 Hand Brake Installation (PA-28R-180/200) .......................................................................... 2J11
48 Toe Brake Installation, .......................................................................................................... 2J14
48A Toe Brake Master Cylinder Installation ................................................................................ 2J18
49 EDO Float Installation (PA-28S-180 - S/N 28S-671 to 28S-7205328 incI.) .......................... 2J21
PIPER PARTS CATALOG
REVISED: MAY 1980 PA-28 & PA-28R
1A10
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$36.99
1961-1970 Piper Cherokee PA-28 Parts Catalog
Viewed 25 Times Today
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$36.99
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
Description
This manual is the manufacturer's official 634-page parts catalog for a Piper PA-28 Cherokee - part number 753-582. It covers the following models:
- PA-28-140
- PA-28-150
- PA-28-160
- PA-28-180
- PA-28-235
- PA-28R-180
- PA-28R-200
The serial numbers of the aircraft covered by this parts catalog are as follows:
- Serial numbers of the 1961 PA-28-150 and PA-28-160 models are 28-1 to 28-84 inclusive.
- Serial numbers of the 1962 PA-28-150 and PA-28-160 models are 28-85 to 28-670 inclusive.
- Serial numbers of the 1963 PA-28-150 and PA-28-160 Cherokee "B" models are 28-725 to 28-1760 inclusive.
- Serial numbers of the PA-28-180 Cherokee "B" models are 28-671 to 28-1760 inclusive.
- Serial numbers of the PA-28-150, PA-28-160, and PA-28-180 Cherokee "C" models are 28-1761 to 28-4377 inclusive.
- Serial numbers of the PA-28-180 Cherokee "D" models are 28-4378 to 28-5600 inclusive.
- Serial numbers of the PA-28-180 Cherokee "E" models are 28-5601 to 28-5869 inclusive.
- Serial numbers of the PA-28-180 Cherokee "F" models are 28-7105001 to 28-7105244 inclusive.
- Serial numbers of the PA-28-180 Cherokee "G" models are 28-7205001 and up.
- Serial numbers of the PA-28-140 models are 28-20002 to 28-24999 inclusive.
- Serial numbers of the PA-28-140 Cherokee "B" models are 28-25000 to 28-26400 inclusive.
- Serial numbers of the PA-28-140 Cherokee "C" models are 28-26401 to 28-26956 inclusive.
- Serial numbers of the PA-28-140 Cherokee "D" models are 28-7125001 to 28-7125651 inclusive.
- Serial numbers of the PA-28-140 Cherokee "E" models are 28-7225001 and up.
- Serial numbers of the PA-28-235 models are 28-10003 to 28-10719 inclusive.
- Serial numbers of the PA-28-235 Cherokee "B" models are 28-10720 to 28-11039 inclusive.
- Serial numbers of the PA-28-235 Cherokee "C" models are 28-11040 to 28-11300 inclusive.
- Serial numbers of the PA-28-235 Cherokee "D" models are 28-11301 to 28-11393 inclusive.
- Serial numbers of the PA-28-235 Cherokee "E" models are 28-7110001 to 28-7110042 inclusive.
- Serial numbers of the PA-28-235 Cherokee "F" models are 28-7210001 and up.
- Serial numbers of the PA-28R-180 Cherokee models are 28-30005 to 28-30481 inclusive, and 28-30483 to 28-31279 inclusive.
- Serial numbers of the PA-28R-180 Cherokee "B" models are 28-7130001 to 28-7130019 inclusive.
- Serial numbers of the PA-28R-200 Cherokee models are 28-30482, 28-35001 to 28-35830 inclusive.
- Serial numbers of the PA-28R-200 Cherokee "B" models are 28-7135001 to 28-7135238 inclusive.
- Serial numbers of the PA-28R-200 Cherokee "11" models are 28-7235001 and up.
This manual is clear and written in a way so that just about anybody can follow it. It is bookmarked, so you can find what you need to know quickly. Just click on the bookmark, and that page comes up. The manual is also searchable; just type in what you are looking for, and that page will come up. It can be viewed on any computer, as well as zoomed and printed. An excellent reference source for your home, repair shop, or business.
Assurance that the airplane is in an airworthy condition is the sole responsibility of the owner. The pilot in command is responsible for determining that the airplane is safe for flight and for remaining within the operating limitations of the airplane. While some manuals may appear similar for the same make and model of aircraft, each manual is unique and contains specific information about a particular aircraft, such as the equipment installed and weight and balance information. Information you can count on!
Why pay big bucks to have someone else print it for you? Print what you need when you need it! Save a tree, buy digitally! We have thousands of airplane and engine manuals - please email us about any you might need! Their manuals have you searching endlessly for what you need.
