2010-2011 Victory Vision Tour & Tour ABS Service & Repair Manual

SPECIFICATIONS / GAUGE / AUDIO 1.1 CHAPTER 1 SPECIFICATIONS / GAUGE / AUDIO 1 GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 SERVICE RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 SAFETY INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4 GENERAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5 2008 - 2009 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5 2010 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.7 VEHICLE LOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9 VEHICLE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10 VEHICLE IDENTIFICATION NUMBER (VIN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10 MODEL NUMBER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10 VIN NUMBER / MANUFACTURER LABEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11 ENGINE NUMBER LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11 VECI / NECI / TIRE INFORMATION LABELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11 KEY IDENTIFICATION NUMBER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11 PUBLICATIONS & TECHNICAL LITERATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12 PUBLICATION PART NUMBERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12 MATERIAL SAFETY DATA SHEET (MSDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12 REFINISHING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.13 VICTORY TOUCH-UP & REFINISHING PAINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.13 VICTORY DETAIL & FINISH RESTORER KITS AND PRODUCTS . . . . . . . . . . . . . . . 1.13 PAINTING TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.13 PAINT COLORS BY MODEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.14 PAINT COLOR CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.16 BREAK IN PERIOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17 EMISSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.18 SPECIAL SERVICE TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.19 TRANSPORTING, ELEVATING, AND SECURING THE MOTORCYCLE . . . . . . . . . . . 1.22 INSTRUMENTATION / CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.23 CLOCK, GEAR POSITION, TRIP ODOMETER, TEMPERATURE, ODOMETER . . . . . 1.25 CHANGING INFORMATION DISPLAY UNITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 CONSOLE MOUNTED SWITCHES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 HAND GRIP HEATER SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 HAZARD SWITCH (EMERGENCY FLASHERS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 DRIVING LAMP SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 INDICATOR LAMPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.27 SEAT HEATER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28 LEFT HANDLEBAR SWITCH, MODE BUTTON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28 HEADLAMP HIGH / LOW BEAM SWITCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28 WINDSHIELD ADJUSTMENT SWITCH (MOTORIZED) . . . . . . . . . . . . . . . . . . . . . . . . 1.28 MANUAL WINDSHIELD ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.29 TURN SIGNAL SWITCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.29 CLUTCH LEVER & STARTER INTERLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.29 RIGHT HANDLEBAR CONTROLS, ENGINE STOP SWITCH, STARTER BUTTON . . 1.30 AUDIO / COM / CRUISE CONTROL BUTTONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.30 MIRRORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.30 LINKED BRAKE SYSTEM / ABS BRAKE SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.30 FRONT BRAKE LEVER REACH ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.31 FOOT CONTROL ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.31 FUEL DOOR, FUEL CAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32 GLOVE / STORAGE COMPARTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32 SADDLEBAGS, TRUNK OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.33 © 2009 Polaris Sales Inc.

1.2 SPECIFICATIONS / GAUGE / AUDIO RADIO / AUDIO SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.34 RADIO / AUDIO SYSTEMS OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.34 RADIO FREQUENCIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.34 MAIN USER INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.34 LEFT HAND CONTROLS / REAR PASSENGER CONTROL . . . . . . . . . . . . . . . . . . . . 1.35 AUDIO SYSTEM POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.35 VOLUME CONTROL / AUDIO MUTE / AUDIO VOLUME / PASSENGER VOLUME . . 1.36 AUDIO SOURCE SELECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.37 AUDIO TUNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.38 MEMORY PRESETS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.38 AUDIO MODE MENUS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.38 BASS, TREBLE, FADER, EXTERNAL SPEAKER SETTING, AVC . . . . . . . . . . . . . . . . 1.39 CB HEADSET VOLUME CONTROLS / CB HEADSET ENT MODE* . . . . . . . . . . . . . . 1.40 ICOM VOLUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.40 TUNING (SEEK / SCAN MODES) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.40 RADIO DATA SYSTEM (RDS) AUX MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.41 XM DISPLAY / XM TUNE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.41 XM CATEGORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.42 NOAA WEATHER BAND (WB OR WX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.42 CB RADIO / ICOM SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.43 CB RADIO FCC RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.43 HEADSET USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.43 GETTING STARTED / CB CHANNELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.43 PUSH-TO-TALK (PTT) / SQUELCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.44 CB RADIO VOLUME SETTING (DRIVER / PASSENGER) . . . . . . . . . . . . . . . . . . . . . . 1.45 CB LO/DX* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.45 CB FREQUENCIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.46 ICOM SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.46 VOX BREAK SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.46 ICOM VOLUME SETTING (DRIVER / PASSENGER) . . . . . . . . . . . . . . . . . . . . . . . . . . 1.47 HEADSET RECEPTACLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.47 AUX / IPOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.48 GETTING STARTED / AUX INPUT CABLE / INPUT CABLE SETUP . . . . . . . . . . . . . . 1.48 IPOD USE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.48 AUX MODE (2010) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.49 IPOD PLAY LISTS / IPOD TUNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.49 XM RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.50 ABOUT XM RADIO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.50 XM READY LEGAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.50 XM READY SUBSCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.50 GETTING STARTED - XM RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.50 XM RADIO RECEPTION / XM RADIO SPECIFIC MENU OPTIONS . . . . . . . . . . . . . . . 1.51 XM RADIO SETTINGS / XM CATEGORY SELECTION . . . . . . . . . . . . . . . . . . . . . . . . 1.51 XM CHANNEL SELECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.52 NAV MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.52 BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.52 TIPS FOR OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.52 GETTING STARTED / CHANGING AUX MODE TO NAV MP3. . . . . . . . . . . . . . . . . . . 1.53 CD CHANGER (2008-2009) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.54 REFERENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.55 SAE TAP DRILL SIZES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.55 METRIC TAP DRILL SIZES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.55 DECIMAL EQUIVALENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.55 FAHRENHEIT TO CELSIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.56 MEASUREMENT CONVERSION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.56 © 2009 Polaris Sales Inc.

1.3 SPECIFICATIONS / GAUGE / AUDIO 1 GENERAL INFORMATION TRADEMARKS The following are REGISTERED trademarks of Polaris Industries Inc.: VICTORY MOTORCYCLES, VICTORY, VICTORY PERFORMANCE, VICTORY VISION, NESS SIGNATURE SERIES VICTORY VISION, FREEDOM, POLARIS; POLARIS THE WAY OUT; VEGAS; VEGAS JACKPOT; HAMMER; KINGPIN; NESS SIGNATURE SERIES VEGAS JACKPOT. Polaris acknowledges the following products mentioned in this manual: LOCTITE, is a registered trademark of the Henkel Corporation DUNLOP, is a registered trademark of the Dunlop Tire Corporation. STA-BIL, is a registered trademark of Gold Eagle NYOGEL, trademark of Gold Eagle FLUKE, registered trademark of the Fluke Corporation XM, a registered trademark of XM  Satellite Radio, Inc. SERVICE RULES In order to perform service work efficiently and prevent costly errors, technicians should read the text in this manual and familiarize themselves with the procedures before beginning. Notes, Cautions and Warnings have been included for clarification of text and safety concerns. Knowledge of mechanical theory, tool use and shop procedures are necessary to perform some procedures in this manual safely and correctly. Use only genuine Victory service parts, including fasteners that require replacement if removed. Do NOT substitute fasteners or hardware. Cleanliness of parts and tools as well as the work area is of primary importance. Dirt and foreign matter will cause damage to precision parts. Clean the motorcycle before beginning service. Clean all parts before installing. If difficulty is encountered in removing or installing a component, look to see if a cause for the difficulty can be found. If it is necessary to tap the part into place, use a soft face hammer and tap lightly. Always follow torque specifications as outlined throughout this manual. Incorrect torquing may lead to serious machine damage or in the case of steering, driveline, and chassis components, can result in loss of control during operation of the motorcycle, which may result in severe personal injury or death. If a torquing sequence is indicated for nuts, bolts or screws of a certain component, start all fasteners and hand tighten. Following the method and sequence indicated, tighten evenly to the specified torque value. When removing nuts, bolts or screws from a component with several fasteners, loosen them all about 1/4 turn before removing them to prevent distortion of that component. Replace all oil seals, sealing washers, gaskets, and O-rings with new ones during assembly. Be sure the mating surfaces for the gasket are clean and smooth to avoid leaks and maintain specified tolerances. Some procedures require removal of retaining rings or clips. Removal can weaken and deform these parts, therefore, they should always be replaced with new parts. When installing new retaining rings and clips, use care not to expand or compress them beyond what is required for installation. Victory lubricants and greases have been specially formulated to provide maximum performance and protection when applied properly. In some applications, warranty coverage may be void if improper lubricants are used. Parts requiring grease should be cleaned thoroughly and fresh grease applied before reassembly. Deteriorating grease loses lubricity and may contain abrasive foreign matter. Always replace locking hardware such as lock nuts or lock washers, fasteners that have pre-applied locking agent, or any other fasteners as noted in this service manual with genuine Victory hardware from an authorized Victory dealer. Working with batteries can be hazardous. Review all battery warnings and cautions. © 2009 Polaris Sales Inc.

1.4 SPECIFICATIONS / GAUGE / AUDIO SAFETY INFORMATION Understanding Safety Labels & Instructions READ AND BECOME FAMILIAR WITH ALL WARNING AND CAUTION SYSMBOLS AND STATEMENTS LISTED BELOW AND IN THE TEXT OF THIS MANUAL BEFORE YOU BEGIN WORK. This is the safety alert symbol. When you see this symbol on the vehicle or in this manual, be alert to the potential for personal injury. Your safety is involved! Indicates a hazardous situation, which, if not avoided, could Indicates a situation, which, if not avoided, could result in Gasoline is extremely flammable and explosive  Always stop the engine and refuel outdoors or in a  Do not smoke or allow open flames or sparks in or  Do not overfill the tank. Do not fill the tank neck above  If you get gasoline in your eyes or if you swallow  If you spill gasoline on your skin or clothing,  Never start the engine or let it run in an enclosed area. damage to the motorcycle. NOTICE: under certain conditions. well ventilated area. near the area where refueling is performed or where gasoline is stored. the fuel tank insert. Leave air space to allow for fuel expansion. gasoline, see your doctor immediately. Never try to syphon gasoline using mouth suction. immediately wash it off with soap and water and change clothing. Engine exhaust fumes are poisonous and can cause loss of consciousness or death in a short time. Improper repairs or service can create The engine and exhaust components on this The engine exhaust from this product contains chemicals known to cause cancer, birth defects or other reproductive harm. unsafe conditions that may cause severe personal injury or death. product become very hot during operation and remain so for a period of time after the engine is stopped. Never run the engine in an enclosed area Modifications to this motorcycle not approved Brake fluid is poisonous. KEEP OUT OF REACH OF CHILDREN. without a properly functioning exhaust gas evacuation system connected to the product. by Victory may cause loss of performance, excessive emissions, and make the machine unsafe for use. Wear insulated protection for hands and Brake fluid is poisonous. Do not ingest or Battery electrolyte is poisonous. It contains Brake fluid will damage plastic, painted and rubber parts. Protect arms or wait until hot components have cooled sufficiently before working on the product. allow brake fluid to contact eyes. Always wear eye protection when working with brake fluid. sulfuric acid. Serious burns can result from contact with skin, eyes or clothing. NOTICE these surfaces whenever the brake system is being serviced. result in death or serious injury. Indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury. Care should be taken to be sure the motorcycle will not tip or fall while elevated. Severe personal injury or death could occur if the motorcycle tips or falls. © 2009 Polaris Sales Inc.

1.5 SPECIFICATIONS / GAUGE / AUDIO 1 GENERAL SPECIFICATIONS 2008 - 2009 Vision Street / Vision Tour / 10th Anniversary Vision / NSS Vision Specifications Specifications may change with the addition of custom order options and / or accessories. Polaris Sales Inc. reserves the right without prior notice to discontinue at any time at its discretion any of the items herein or change specifications or designs without incurring any obligation to the customer. C A P A C I T I E S & D I M E N S I O N S 2008-2009 VICTORY VISION Models Oil Capacity 5.0 Qt. (4.75 ltr) (Approximately 4.5 qts. or 4.25 ltr at oil & filter change) Fuel Capacity 6.0 US Gal (22.7 ltr) (1.0 U.S. gal / 3.8 ltr reserve) Fuel Type / Octane Minimum Premium Unleaded / 91 Octane Dry Weight Street: 809 lbs (367 kg) / Tour: 849 lbs (385 kg) Wet Weight Street: 844 lbs (383 kg) / Tour: 889 lbs (403 kg) Gross Vehicle Weight Rating Street: 1349 lbs. (612 kg) / Tour: 1414 lbs. (641 kg) Gross Axle Weight Rating Refer to Manufacturer Information label on vehicle Maximum Load Subtract Wet Weight from GVWR. Never exceed GVWR* Overall Length Street: 103.5 in (262.9 cm) / Tour: 104.9 in (266.5 cm) Overall Width 45.2 in (114.7 cm) Overall Height 58.5 (148.5 cm) Seat Height 26.5 in (67.3 cm) Ground Clearance 5.8 in (14.8 cm) Passenger Capacity 1 Wheelbase 65.7 in (166.9 cm) Rake / Trail 29 Degrees / 5.4 in. (13.7 cm) E N G I N E Engine Type Victory Freedom  V-Twin Engine Configuration 50 o SOHC V-Twin 4 Stroke Engine Displacement 1731cc / 106 cubic inch 6 speed (106 / 6 engine) Engine Cooling System Air / Oil Compression Ratio 9.4:1 Compression Pressure 210 - 225 psi (1448 - 1551 kPa) Valve Train 4 Valves per cylinder. Hydraulic Lifters & Cam Chain Adjusters (No Adjustment) Bore x Stroke 101 x 108 mm Starter Electric / Direct Drive Fuel System / Throttle Body Bore Size Closed Loop Sequential Electronic Fuel Injection / Dual Bore 45 mm Exhaust System Type 2-1-2 Split Dual Exhaust With Crossover Lubrication System Wet Sump Spark Plug Type (Gap) NGK DCPR6E (.032 in. / .8 mm) Dry Weight (Engine Approximate) 265 lbs. (120 Kg) B R A K E S Brake Type (Front / Rear) Disc / Disc Front Brake Dual Floating Disc / 3 Piston Calipers Rear Brake Linked, Single Floating Disc / 2 Piston Caliper © 2009 Polaris Sales Inc.

1.6 SPECIFICATIONS / GAUGE / AUDIO 2008-2009 Vision Street / Vision Tour / 10th Anniversary / NSS Vision Specifications (cont.) Specifications may change with the addition of custom order options and / or accessories. Polaris Sales Inc. reserves the right without prior notice to discontinue at any time at its discretion any of the items herein or change specifications or designs without incurring any obligation to the customer. D R I V E S Y S T E M 2008 - 2009 VICTORY VISION Models Transmission Type Manual, 6 Speed Overdrive, Constant Mesh Clutch Type Wet, Multi-Plate Diaphragm Spring Primary Drive Type Wet, Gear Drive w/ Torque Compensator Primary Reduction Ratio 1.5:1 Final Drive Type / Belt Width / Final Drive Ratio Carbon Fiber Reinforced Belt / 28mm / 2.12:1 Gear Shift Pattern 1 Down, 5 Up Internal Gear Ratios 1st 3.15:1 2nd 2.03:1 3rd 1.53:1 4th 1.24:1 5th 1:1 6th .84:1 S U S P E N S I O N Front Wheel (Size / Type) Cast or Billet / 3.00 x 18 (inch) Rear Wheel (Size / Type) Cast or Billet 5.00 x 16 (inch) Front Tire Dunlop Elite 3 (130/70R18) 63H Radial Rear Tire Dunlop Elite 3 (180/60R16) 80H Radial Minimum Tread Depth .063 in. (1.6mm) Front Type 45mm (TYPE 1) Telescopic Cartridge Fork Front Travel 5.1 in. (13 cm) Front Tube Diameter 43 mm (1.7 in.) Rear Shock Type Single, Monotube Air Adjustable Shock Rear Swingarm Type Cast Aluminum with Rising Rate Linkage Rear Travel (inches) 4.7 in (12 cm) L I G H T S Headlamp High / Low: H-4 55/60W Driving Lamp (Std / HID) HS1 35W / D1R 35W Turn / Brake / Tail Light 3157 27 / 9w License Plate / Trunk Running Light W5W 5w Courtesy Light (Trunk, if equipped) 6411 10W Fog Lamp (If equipped) 35W Alternator / Battery 50 amp max output / 12V 18AH 310 CCA F U S E S Left Fuse Panel Ignition 10 amp circuit breaker Headlight 20 amp circuit breaker Gauges 5 amp fuse Radio 25 amp fuse Secondary Lighting 20 amp fuse Horn 20 amp fuse Turn Signal / Brake 20 amp fuse Right Fuse Panel Engine 15 amp circuit breaker Windshield (Electric) 20 amp fuse Fuel Pump / Ignition Coil 15 amp fuse Chassis 20 amp fuse © 2009 Polaris Sales Inc.

1.7 SPECIFICATIONS / GAUGE / AUDIO 1 2010 VICTORY VISION Tour / Tour ABS / 8-Ball / NSS Vision Specifications Specifications may change with the addition of custom order options and / or accessories. Polaris Sales Inc. reserves the right without prior notice to discontinue at any time at its discretion any of the items herein or change specifications or designs without incurring any obligation to the customer. C A P A C I T I E S & D I M E N S I O N S VICTORY VISION TOUR / TOUR ABS VICTORY VISION 8-BALL / NESS Oil Capacity 5.0 Qt. (4.75 ltr) (Approximately 4.5 qts. or 4.25 ltr at oil & filter change) Fuel Capacity 6.0 US Gal (22.7 ltr) (1.0 U.S. gal / 3.8 ltr reserve) Fuel Type / Octane Minimum Premium Unleaded / 91 Octane Dry Weight TOUR: 852 lbs (387 kg) TOUR ABS: 869 lbs (394 kg) 8-BALL / NESS: 800 lbs (363 kg) Wet Weight TOUR: 892 lbs (405 kg) TOUR ABS: 909 lbs (412 kg) 8-BALL / NSS: 840 lbs (381 kg) Gross Vehicle Weight Rating (GVWR) 1414 lbs. (641 kg) Gross Axle Weight Rating FRONT AXLE 513 lbs. (233 kg) Gross Axle Weight Rating REAR AXLE 901 lbs. (409 kg) Maximum Load (See page 1.9 for more information) TOUR: 522 lbs (237 kg) TOUR ABS: 505 lbs (229 kg) 8-BALL / NESS: 574 lbs (260 kg) Overall Length 104.9 in (266.5 cm) 8-Ball / NESS: 103.5 in (262.9 cm) Overall Width 45.2 in (114.7 cm) Overall Height 58.5 (148.5 cm) 56.2 (142.7 cm) Seat Height 26.5 in (67.3 cm) 24.5 in (62.2 cm) Ground Clearance 5.8 in (14.8 cm) 4.8 in (12.2 cm) Passenger Capacity 1 1 Wheelbase 65.7 in (166.9 cm) Rake / Trail 29 Degrees / 5.4 in. (13.7 cm) E N G I N E Engine Type Victory Freedom  V-Twin Engine Configuration 50 o SOHC V-Twin 4 Stroke Engine Displacement 1731cc / 106 cubic inch 6 speed (106 / 6 engine) Engine Cooling System Air / Oil Compression Ratio 9.4:1 Compression Pressure 210 - 225 psi (1448 - 1551 kPa) Valve Train 4 Valves per cylinder. Hydraulic Lifters & Cam Chain Adjusters (No Adjustment) Bore x Stroke 101 x 108 mm Starter Electric / Direct Drive Fuel System / Throttle Body Bore Size Closed Loop Sequential Electronic Fuel Injection / Dual Bore 45 mm Exhaust System Type 2-1-2 Split Dual Exhaust With Crossover Lubrication System Wet Sump Spark Plug Type (Gap) NGK DCPR6E (.032 in. / .8 mm) Dry Weight (Engine Approximate) 265 lbs. (120 Kg) B R A K E S Brake Type (Front / Rear) Disc / Disc Front Brake Dual Floating Disc / 3 Piston Calipers (2010 - ABS if equipped) Rear Brake Linked, Single Floating Disc / 2 Piston Caliper (2010 - ABS if equipped) © 2009 Polaris Sales Inc.

1.8 SPECIFICATIONS / GAUGE / AUDIO 2010 VICTORY VISION Tour / Tour ABS / 8-Ball / NSS Vision Specifications (cont.) Specifications may change with the addition of custom order options and / or accessories. Polaris Sales Inc. reserves the right without prior notice to discontinue at any time at its discretion any of the items herein or change specifications or designs without incurring any obligation to the customer. D R I V E S Y S T E M 2010 VICTORY VISION Models Transmission Type 6 Speed Constant Mesh With True Overdrive Clutch Type Wet, Multi-Plate Diaphragm Spring Primary Drive Type Wet, Gear Drive w/ Torque Compensator Primary Reduction Ratio 1.5:1 Final Drive Type / Belt Width / Final Drive Ratio Carbon Fiber Reinforced Belt / 28mm / 2.12:1 Gear Shift Pattern 1 Down, 5 Up Internal Gear Ratios 1st 3.15:1 2nd 2.03:1 3rd 1.53:1 4th 1.24:1 5th 1:1 6th .84:1 Reverse 2009-2010 Only. Motorized Reverse (if equipped) See Electrical Chapter 19 S U S P E N S I O N Front Wheel (Type / Size) Cast or Billet / 3.00 x 18 (inch) Rear Wheel (Type / Size) Cast or Billet / 5.00 x 16 (inch) Front Tire Dunlop Elite 3 (130/70R18) 63H Radial Rear Tire Dunlop Elite 3 (180/60R16) 80H Radial Minimum Tread Depth .063 in. (1.6mm) Front Type 45mm (TYPE 1) or (46MM TYPE 2) Conventional Telescopic Cartridge Fork Front Travel 5.1 in. (13 cm) Front Tube Diameter 46 mm (1.81 in.) Rear Shock Type Single, Monotube Air Adjustable Shock Rear Swingarm Type Cast Aluminum with Rising Rate Linkage Rear Travel (inches) 4.7 in (12 cm) [8-Ball & Ness - 3.5 in. (9.0 cm)] L I G H T S Headlamp High / Low: H-4 55/60W Driving Lamp (Std / HID) HS1 35W / D1R 35W Turn / Brake / Tail Light 3157 27/ 7w License Plate / Trunk Running Light W5W 5w Courtesy Light (Trunk, if equipped) 6411 10W Fog Lamp (If equipped) 35W Alternator / Battery 50 amp max output / 12V 18AH 310 CCA / Yuasa YTX20HL F U S E S Left Fuse Box Ignition 10 amp circuit breaker Headlight 20 amp circuit breaker Gauges (Instruments) 5 amp fuse Radio 25 amp fuse Secondary Lighting 20 amp fuse Horn 20 amp fuse Turn Signal / Brake 20 amp fuse Right Fuse Box Engine 15 amp circuit breaker Windshield (Electric) 20 amp fuse Fuel Pump / Ignition Coil 15 amp fuse Chassis 20 amp fuse ABS Fuse (if equipped) (2) 30A © 2009 Polaris Sales Inc.

1.9 SPECIFICATIONS / GAUGE / AUDIO 1 VEHICLE LOADING GROSS VEHICLE WEIGHT RATING (GVWR) The maximum load capacity of your motorcycle is the maximum weight you may add to your motorcycle without exceeding the GVWR. This capacity is determined by calculating the difference between your motorcycle’s gross vehicle weight rating and the wet weight. Refer to the specification section of this manual or the Manufacturing Information / VIN label on the motorcycle frame for model-specific information. Refer to Information label section in this manual (page 1.11) for location on the motorcycle. When determining the weight you will be adding to your motorcycle, and to ensure you do not exceed the maximum load capacity, include the following: • operator body weight • passenger body weight • weight of all riders’ apparel and items in or on apparel • weight of any accessories and their contents • weight of any additional cargo on the motorcycle WARNING Exceeding the gross vehicle weight rating of your motorcycle can reduce stability and handling and could cause loss of control. NEVER exceed the gross vehicle weight rating of your motorcycle. © 2009 Polaris Sales Inc.

1.10 SPECIFICATIONS / GAUGE / AUDIO VEHICLE INFORMATION VEHICLE IDENTIFICATION NUMBER (VIN) See “VIN NUMBER / MANUFACTURER LABEL” on page 1.11. for location on the vehicle. MODEL NUMBER See “VIN NUMBER / MANUFACTURER LABEL” on page 1.11. for location on vehicle. *5VPSB36D0A2000000* SAE-assigned World Manufacturing Identifier Type: B = Standard C = Custom D = Deluxe / Tour Serial Number Engine Size: 1 = 1507 cc 2 = 1634 cc Engine HP: 6 = 78-94 Check Digit (May be a number or a letter) Model Year: 8 = 2008 Plant/ Line Code S = Sport 3 = 1731 cc 9 = 2009 A = 2010 W = ABS Series: C = Canada D = Domestic (49 State) L = California U = United Kingdom A = Australia E = Europe Chassis: See chassis designators listed under Model Number (below) V10SD36DAP Engine Size: 1 = 1507 cc 2 = 1634 cc Engine HP: 6 = 78-94 P = Premium Model VICTORY Model Year: 08 = 2008 Color Indicator (Premium package equipped as Type: B = Standard C = Custom D = Deluxe / Tour S = Sport 3 = 1731 cc specified for model. T = Top Premium Model (Premium package and additional upgrades as specified for model) 09 = 2009 10 = 2010 Example: 2010 - T designates ABS W = ABS Series: C = Canada D = Domestic (49 State) L = California U = United Kingdom A = Australia E = Europe Chassis: A = Vegas 8-Ball C = Kingpin H = Hammer B = Hammer 8-Ball S = Victory Vision V = Victory Vision 8-Ball P = Kingpin 8-Ball L = Vegas Low, 2010 Vegas X = Jackpot D = Cross Country E = Cross Roads K = Kingpin Low, 2009 © 2009 Polaris Sales Inc.
