2008-Onwards Victory Vision Street Tour Service & Repair Manual

2008 VICTORY VISION STREET / TOUR SERVICE MANUAL PN 9921254 FOREWORD This manual is designed primarily for use by Victory service technicians in a properly equipped shop and should be kept available for reference in the shop area. All references to left and right side of the motorcycle are from the operator's perspective when seated in a normal riding position. Some procedures outlined in this manual require a sound knowledge of mechanical theory, tool use, and shop procedures in order to perform the work safely and correctly. Technicians should read the text and be familiar with the service procedures before starting the work. Certain procedures will require the use of special tools. Use only the proper tools as specified. This manual includes procedures for maintenance, component identification and repair, along with service specifications for the above model motorcycles. Comments or suggestions about this manual may be directed to: Service Publications Dept. @ Polaris Sales Inc. 2100 Hwy 55 Medina Minnesota 55340. © Copyright 2007 Polaris Sales Inc. All information contained within this publication is based on the latest product information at the time of publication. Due to constant improvements in the design and quality of production components, some minor discrepancies may result between the actual vehicle and the information presented in this publication. Depictions and/or procedures in this publication are intended for reference use only. No liability can be accepted for omissions or inaccuracies. Any reprinting or reuse of the depictions and/or procedures contained within, whether whole or in part, is expressly prohibited. Printed in U.S.A.

TRADEMARKS The following are Registered Trademarks of Polaris Sales Inc.: Freedom Hammer Hammer S Vegas Jackpot Victory Vision Ness Signature Series Vegas Jackpot Polaris Sales Inc. acknowledges the following products mentioned in this manual: Loctite, Registered Trademark of the Henkel Corporation Nyogel, Registered Trademark of Wm. F. Nye Co. FLEXLOC, Registered Trademark of SPS Technologies Fluke, Registered Trademark of John Fluke Mfg. Co. Mity-Vac, Registered Trademark of Neward Enterprises, Inc. STA-BIL, Registered Trademark of Gold Eagle Torx, Registered Trademark of Textron Dunlop, Registered Trademark of Dunlop Tire Corporation. Some Victory publications can be downloaded from www.polarisindustires.com, purchased from www.purepolaris.com or purchased through a Victory dealer.

SPECIFICATIONS / GAUGE / AUDIO CHAPTER 1 SPECIFICATIONS / GAUGE / AUDIO 1 1.1 GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 SERVICE RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.3 SAFETY INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4 UNDERSTANDING SAFETY LABELS & INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . 1.4 GENERAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5 VEHICLE LOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.7 GROSS VEHICLE WEIGHT RATING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.7 LOADING EXAMPLES FOR GROSS VEHICLE WEIGHT RATING (GVWR) . . . . . . . . . 1.7 VEHICLE INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8 VEHICLE IDENTIFICATION NUMBER (VIN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8 MODEL NUMBER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.8 VIN NUMBER / MANUFACTURER LABEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9 LABEL LOCATION (VECI, NECI, ENGINE NUMBER, TIRE INFORMATION) . . . . . . . . 1.9 KEY IDENTIFICATION NUMBER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.9 PUBLICATIONS & TECHNICAL LITERATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10 MATERIAL SAFETY DATA SHEET (MSDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.10 BREAK IN PERIOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.11 EMISSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12 SPECIAL SERVICE TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.13 TRANSPORTING, ELEVATING, AND SECURING THE MOTORCYCLE . . . . . . . . . . . 1.16 REFERENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17 SAE TAP DRILL SIZES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17 METRIC TAP DRILL SIZES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17 DECIMAL EQUIVALENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.17 FAHRENHEIT TO CELSIUS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.18 MEASUREMENT CONVERSION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.18 INSTRUMENTATION / CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.19 IGNITION KEY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.19 IGNITION SWITCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.19 INSTRUMENT CLUSTER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 SPEEDOMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 TACHOMETER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 FUEL GAUGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 VOLT METER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 INDICATOR LAMP DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 INFORMATION DISPLAY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 CLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21 GEAR POSITION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21 TRIP ODOMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21 TEMPERATURE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21 ODOMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.21 TO CHANGE DISPLAY UNITS (MILES TO KILOMETERS) . . . . . . . . . . . . . . . . . . . . . 1.21 CONSOLE MOUNTED SWITCHES (GRIP HEATER / HAZARD / DRIVING LAMP). . . 1.22 NEUTRAL, GEAR POSITION, & HIGH BEAM INDICATOR LAMPS . . . . . . . . . . . . . . 1.23 SEAT HEATER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24 LEFT HANDLEBAR SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24 MODE BUTTON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24 HEADLAMP HIGH / LOW BEAM SWITCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.24 WINDSHIELD ADJUSTMENT SWITCH (MOTORIZED) . . . . . . . . . . . . . . . . . . . . . . . . 1.24 MANUAL WINDSHIELD ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25 TURN SIGNAL SWITCH. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25

SPECIFICATIONS / GAUGE / AUDIO 1.2 TURN SIGNAL MONMENTARY FEATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25 CLUTCH LEVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25 STARTER INTERLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.25 RIGHT HANDLEBAR CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 ENGINE STOP SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 ENGINE STARTER BUTTON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 MIRRORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 LINKED BRAKE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.26 FRONT BRAKE LEVER REACH ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.27 FOOT CONTROL ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.27 FUEL DOOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28 FUEL CAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28 GLOVE COMPARTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.28 SADDLEBAGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.29 TRUNK OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.29 RADIO / AUDIO SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.30 RADIO / AUDIO SYSTEMS OPERATION / FREQUENCIES / USER INTERFACE . . . 1.30 LEFT-HAND CONTROL, LOWER & UPPER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.31 REAR PASSENGER CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.31 SYSTEM POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.31 VOLUME CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32 AUDIO MUTE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32 AUDIO VOLUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32 PASSENGER VOLUME. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.32 SELECTING AUDIO SOURCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.33 SOURCE ACTIVATION (AM/FM, WB, AUX, IPOD, XM, CD CHANGER): . . . . . . . . . . 1.33 SOURCE ACTIVATION MW (MEDIUM WAVE), LW (LONG WAVE): . . . . . . . . . . . . . . 1.33 AUDIO TUNING, MEMORY PRESETS, SUB MENU ACCESS . . . . . . . . . . . . . . . . . . 1.34 BASS, TREBLE, FADER SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.35 EXTERNAL SPEAKERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.35 AUTOMATIC VOLUME CONTROL (AVC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.35 CB HEADSET ENT MODE, ICOM VOLUME, CB VOLUME . . . . . . . . . . . . . . . . . . . . . 1.36 TUNING (SEEK / SCAN MODES) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.36 CB LO/DX / XM DISPLAY* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.36 NOAA WEATHER BAND (WB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.37 CB RADIO / ICOM SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.37 GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.37 ADJUSTING CHANNELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.38 PUSH-TO-TALK (PTT). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.38 SQUELCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.39 CB RADIO VOLUME SETTING (DRIVER)* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.39 CB RADIO VOLUME SETTING (PASSENGER)* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.39 CB LO/DX, FREQUENCIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.40 ICOM SYSTEM (VOX BREAK SETTING, DRIVER AND PASSENGER VOLUME) . . . 1.41 HEADSET RECEPTACLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.42 AUX / IPOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.42 AUX / IPOD / INPUT CABLE / PLAY LISTS / TUNING . . . . . . . . . . . . . . . . . . . . . . . . . 1.43 XM SATELLITE RADIO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.44 XM SATELLITE RADIO / GETTING STARTED / ACTIVATING XM RADIO SERVICE 1.44 CD CHANGER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.45

SPECIFICATIONS / GAUGE / AUDIO 1 1.3 GENERAL INFORMATION TRADEMARKS The following are REGISTERED trademarks of Polaris Industries Inc.: POLARIS; POLARIS THE WAY OUT; VICTORY MOTORCYCLES; FREEDOM; VEGAS; VEGAS JACKPOT; HAMMER; KINGPIN; NESS SIGNATURE SERIES VEGAS JACKPOT. Polaris acknowledges the following products mentioned in this manual: LOCTITE, is a registered trademark of the Henkel Corporation DUNLOP, is a registered trademark of the Dunlop Tire Corporation. STA-BIL, is a registered trademark of Gold Eagle NYOGEL, trademark of Gold Eagle FLUKE, registered trademark of the Fluke Corporation SERVICE RULES In order to perform service work efficiently and prevent costly errors, technicians should read the text in this manual and familiarize themselves with the procedures before beginning. Notes, Cautions and Warnings have been included for clar- ification of text and safety concerns. Knowledge of mechanical theory, tool use and shop procedures are necessary to perform some procedures in this manual safely and correctly. Use only genuine Victory service parts, including fasteners that require replacement if removed. Do NOT substitute fasteners or hardware. Cleanliness of parts and tools as well as the work area is of primary importance. Dirt and foreign matter will cause damage to precision parts. Clean the motorcycle before beginning service. Clean all parts before installing. If difficulty is encountered in removing or installing a component, look to see if a cause for the difficulty can be found. If it is necessary to tap the part into place, use a soft face hammer and tap lightly. Always follow torque specifications as outlined throughout this manual. Incorrect torquing may lead to serious machine damage or in the case of steering, driveline, and chassis components, can result in loss of control during operation of the motorcycle, which may result in severe personal injury or death. If a torquing sequence is indicated for nuts, bolts or screws of a certain component, start all fasteners and hand tighten. Following the method and sequence indicated, tighten evenly to the specified torque value. When removing nuts, bolts or screws from a component with several fasteners, loosen them all about 1/4 turn before removing them to prevent dis- tortion of that component. Replace all oil seals, sealing washers, gaskets, and O-rings with new ones during assembly. Be sure the mating surfaces for the gasket are clean and smooth to avoid leaks and maintain specified tolerances. Some procedures require removal of retaining rings or clips. Removal can weaken and deform these parts, therefore, they should always be replaced with new parts. When installing new retaining rings and clips, use care not to expand or compress them beyond what is required for installation. Victory lubricants and greases have been specially formulated to provide maximum performance and protection when applied properly. In some applications, warranty coverage may be void if improper lubricants are used. Parts requiring grease should be cleaned thoroughly and fresh grease applied before reassembly. Deteriorating grease loses lubricity and may contain abrasive foreign matter. Always replace locking hardware such as lock nuts or lock washers, fasteners that have pre-applied locking agent, or any other fasteners as noted in this service manual with genuine Victory hardware from an authorized Victory dealer. Working with batteries can be hazardous. Review all battery warnings and cautions.

SPECIFICATIONS / GAUGE / AUDIO 1.4 SAFETY INFORMATION UNDERSTANDING SAFETY LABELS & INSTRUCTIONS READ AND BECOME FAMILIAR WITH ALL WARNING AND CAUTION SYSMBOLS AND STATEMENTS LISTED BELOW AND IN THE TEXT OF THIS MANUAL BEFORE YOU BEGIN WORK. This is the safety alert symbol. When you see this symbol on the vehicle or in this manual, be alert to the potential for personal injury. Your safety is involved! Indicates a hazardous situation, which, if not avoided, could Indicates a situation, which, if not avoided, could result in Gasoline is extremely flammable and explosive z Always stop the engine and refuel outdoors or in a z Do not smoke or allow open flames or sparks in or z Do not overfill the tank. Do not fill the tank neck above z If you get gasoline in your eyes or if you swallow z If you spill gasoline on your skin or clothing, z Never start the engine or let it run in an enclosed area. damage to the motorcycle. NOTICE: under certain conditions. well ventilated area. near the area where refueling is performed or where gasoline is stored. the fuel tank insert. Leave air space to allow for fuel expansion. gasoline, see your doctor immediately. Never try to syphon gasoline using mouth suction. immediately wash it off with soap and water and change clothing. Engine exhaust fumes are poisonous and can cause loss of consciousness or death in a short time. Improper repairs or service can create The engine and exhaust components on this The engine exhaust from this product contains chemicals known to cause cancer, birth defects or other reproductive harm. unsafe conditions that may cause severe personal injury or death. product become very hot during operation and remain so for a period of time after the engine is stopped. Never run the engine in an enclosed area Modifications to this motorcycle not approved Brake fluid is poisonous. KEEP OUT OF REACH OF CHILDREN. without a properly functioning exhaust gas evacuation system connected to the product. by Victory may cause loss of performance, excessive emissions, and make the machine unsafe for use. Wear insulated protection for hands and Brake fluid is poisonous. Do not ingest or Battery electrolyte is poisonous. It contains Brake fluid will damage plastic, painted and rubber parts. Protect arms or wait until hot components have cooled sufficiently before working on the product. allow brake fluid to contact eyes. Always wear eye protection when working with brake fluid. sulfuric acid. Serious burns can result from contact with skin, eyes or clothing. NOTICE these surfaces whenever the brake system is being serviced. result in death or serious injury. Indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury. Care should be taken to be sure the motorcycle will not tip or fall while elevated. Severe personal injury or death could occur if the motorcycle tips or falls.

SPECIFICATIONS / GAUGE / AUDIO 1 1.5 GENERAL SPECIFICATIONS Victory Vision ™ Street / Victory Vision ™ Tour Specifications All specifications are for standard Victory Vision ™ (Street or Tour) models. Specifications may change with the addition of custom order options and / or accessories. Polaris Sales Inc. reserves the right without prior notice to discontinue at any time at its discretion any of the items herein or change specifications or designs without incurring any obligation to the customer. * Maximum load capacity includes the weight of all additional accessories, options, cargo, rider with riding gear, and passenger with riding gear. See GVWR / loading information beginning on page 1.7. C A P A C I T I E S & D I M E N S I O N S 2008 Victory Vision ™ Street / Victory Vision ™ Tour Oil Capacity 5.0 Qt (4.75 ltr) (Approximately 4.65 qts.or 4.25 ltr at oil & filter change) Fuel Capacity 6.0 US Gal (22.7 ltr) (1.0 U.S. gal / 3.8 ltr reserve) Fuel Type / Octane Minimum Premium Unleaded / 92 Octane Dry Weight Street: 804 lbs (365 kg) / Tour: 849 lbs (385 kg) Wet Weight Street: 844 lbs (383 kg) / Tour: 889 lbs (403 kg) Gross Vehicle Weight Rating 1414 lbs. (641 kg) Gross Axle Weight Rating* Front: 513 lbs (233 kg) / Rear: 901 lbs (409 kg) Overall Length Street: 103.5 in (262.9 cm) / Tour: 104.9 in (266.5 cm) Overall Width 45.2 in (114.7 cm) Overall Height 58.5 (148.5 cm) Seat Height 26.5 in (67.3 cm) Ground Clearance 5.8 in (14.8 cm) Passenger Capacity 1 Wheelbase 65.7 in (166.9 cm) Rake / Trail 29 Degrees / 5.4 in. (13.7 cm) E N G I N E Engine Type Victory Freedom ® V-Twin Engine Configuration 50 o SOHC V-Twin 4 Stroke Engine Displacement 1737cc / 106 cubic-inch 6 speed (106/6 engine) Engine Cooling System Air / Oil Compression Ratio 9.4:1 Compression Pressure 185 - 225 psi (1275 - 1551 kPa) Valve Train 4 Valves per cylinder. Hydraulic Lifters & Cam Chain Adjusters (No Adjustment) Bore x Stroke 101 x 108 mm Starter Electric / Direct Drive Fuel System / Throttle Body Bore Size Closed Loop Sequential Electronic Fuel Injection / Dual Bore 45 mm Exhaust System Type 2-1-2 Split Dual Exhaust With Crossover Lubrication System Wet Sump Spark Plug Type (Gap) NGK DCPR6E (.032 - .036 in. / .8 - .9 mm) Dry Weight (Engine Approximate) 265 lbs. (120 Kg) B R A K E S Brake Type (Front / Rear) Disc / Disc Front Brake Dual Floating Disc / 3 Piston Calipers Rear Brake Linked, Single Floating Disc / 2 Piston Caliper

SPECIFICATIONS / GAUGE / AUDIO 1.6 Victory Vision ™ Street / Victory Vision ™ Tour Specifications (cont.) All specifications are for standard Victory Vision (Street or Tour) models. Specifications may change with the addition of custom order options and / or accessories. Polaris Sales Inc. reserves the right without prior notice to discontinue at any time at its discretion any of the items herein or change specifications or designs without incurring any obligation to the customer. D R I V E S Y S T E M 2008 Victory Vision ™ Street / Victory Vision ™ Tour Transmission Type Manual, 6 Speed Overdrive, Constant Mesh Clutch Type Wet, Multi-Plate Diaphragm Spring Primary Drive Type Wet, Gear Drive w/ Torque Compensator Primary Reduction Ratio 1.5:1 Final Drive Type / Belt Width / Final Drive Ratio Carbon Fiber Reinforced Belt / 28mm / 2.12:1 Gear Shift Pattern 1 Down, 5 Up Internal Gear Ratios 1st 3.15:1 2nd 2.03:1 3rd 1.53:1 4th 1.24:1 5th 1:1 6th .84:1 S U S P E N S I O N Front Wheel (Size / Type) Cast or Billet / 3.00 x 18 (inch) Rear Wheel (Size / Type) Cast or Billet 5.00 x 16 (inch) Front Tire Dunlop Elite 3 (130/70R18) 63H Radial Rear Tire Dunlop Elite 3 (180/60R16) 74H Radial Minimum Tread Depth .063 in. (1.6mm) Front Type 43mm Telescopic Cartridge Fork Front Travel 5.1 in. (13 cm) Front Tube Diameter 43 mm (1.7 in.) Rear Shock Type Single, Monotube Air Adjustable Shock Rear Swingarm Type Cast Aluminum with Rising Rate Linkage Rear Travel (inches) 4.7 in (12 cm) L I G H T S Headlamp High/Low: H-4 55/60W Driving Lamp (Std / HID) HS1 35W / D1R 35W Turn / Brake / Tail Light 3157 27/ 7w License Plate / Trunk Running Light W5W 5w Courtesy Light (Trunk, if equipped) 6411 10W Alternator / Battery 50 amp max output / 12V 18AH 310 CCA F U S E S Left Fuse Panel Ignition 10 amp circuit breaker Headlight 20 amp circuit breaker Gauges 5 amp fuse Radio 25 amp fuse Secondary Lighting 20 amp fuse Horn 20 amp fuse Turn Signal / Brake 20 amp fuse Right Fuse Panel Engine 15 amp circuit breaker Windshield (Electric) 20 amp fuse Fuel Pump / Ignition Coil 15 amp fuse Chassis 20 amp fuse Storage Volume Street: 3,370 Cubic Inch (55,224cc) Tour: 6,750 Cubic Inch (110,613cc) Colors Black / Supersteel Gray / Midnight Cherry

SPECIFICATIONS / GAUGE / AUDIO 1 1.7 VEHICLE LOADING GROSS VEHICLE WEIGHT RATING Gross Vehicle Weight Rating is the maximum allowable weight of the vehicle, including the total weight of the motorcycle, operator, and passenger. The motorcycle weight includes the weight of the motorcycle, all fluids, any accessories and their contents and /or mounting hardware, and any additional cargo on the motorcycle. The weight of the operator or passenger includes body weight, all apparel and objects in or on apparel. Refer to the examples below. Addition weight information is provided on the certification label, located under the rear console panel in front of the seat. LOADING EXAMPLES FOR GROSS VEHICLE WEIGHT RATING (GVWR) WARNING NEVER exceed the motorcycle’s Gross Vehicle Weight Rating (GVWR). Exceeding GVWR can reduce stability and handling and could cause loss of control. EXAMPLE 1: Victory Vision ™ with no accessories or cargo. GVWR = 1414 (641 kg) Item Weight Victory Vision ™ Street Victory Vision ™ Tour Motorcycle - with all fluids at full capacity 844 lbs (383 kg) 889 lbs (403 kg) Operator - with recommended riding apparel 220 lbs (100 kg) 220 lbs (100 kg) Passenger - with recommended riding apparel 155 lbs (70 kg) 155 lbs (70 kg) Total Weight 1219 lbs (553 kg) 1264 lbs (574 kg) EXAMPLE 2: Victory Vision ™ with cargo. GVWR = 1414 (641 kg) Item Weight Victory Vision ™ Street Victory Vision ™ Tour Motorcycle - with all fluids at full capacity 844 lbs (383 kg) 889 lbs (403 kg) Operator - with recommended riding apparel 220 lbs (100 kg) 220 lbs (100 kg) Passenger - with recommended riding apparel 155 lbs (70 kg) 155 lbs (70 kg) Total weight of cargo in saddlebags / trunk 9 lbs (4 kg) 15 lbs (7 kg) Total Weight 1228 lbs (557 kg) 1279 lbs (581 kg) EXAMPLE 3: Victory Vision ™ with cargo and accessories. GVWR = 1414 (641 kg) Item Weight Victory Vision ™ Street Victory Vision ™ Tour Motorcycle - with all fluids at full capacity 844 lbs (383 kg) 889 lbs (403 kg) Operator - with recommended riding apparel 220 lbs (100 kg) 220 lbs (100 kg) Passenger - with recommended riding apparel 155 lbs (70 kg) 155 lbs (70 kg) Total weight of cargo in saddlebags / trunk 9 lbs (4 kg) 15 lbs (7 kg) Total weight of accessory item & mounting hardware 7 lbs (3 kg) 7 lbs (3 kg) Total Weight 1219 lbs (553 kg) 1264 lbs (574 kg)

SPECIFICATIONS / GAUGE / AUDIO 1.8 VEHICLE INFORMATION VEHICLE IDENTIFICATION NUMBER (VIN) See “VIN NUMBER / MANUFACTURER LABEL” on page 1.9. for location on the vehicle. MODEL NUMBER See “VIN NUMBER / MANUFACTURER LABEL” on page 1.9. for location on vehicle. *5VPSB36D082000000* SAE-assigned World Manufacturing Identifier Type: B = Standard C = Custom D = Deluxe / Tour Series: C = Canada D = Domestic (49 State) L = California U = United Kingdom Serial Number Engine Size: 1 = 1507 cc 2 = 1634 cc Engine HP: 6 = 78-94 Check Digit (May be a number or a letter) Model Year: 8 = 2008, etc. Plant/ Line Code Chassis: A = 8-Ball C = Kingpin D = Ness Kingpin (05) E = Ness Vegas (05) G = Vegas H = Hammer N = Ness Vegas (04) S = Victory Vision ™ X = Jackpot B = NSS Vegas Jackpot S = Sport 3 = 1737 cc V08SD36DAP Chassis: A = 8-Ball C = Kingpin D = Ness Kingpin (05) E = Ness Vegas (05) G = Vegas Engine Size: 1 = 1507 cc 2 = 1634 cc Engine HP: 6 = 78-94 Series: C = Canada D = Domestic (49 State) L = California U = United Kingdom P = Premium Model Victory Model Year: 08 = 2008, etc. Color Indicator H = Hammer N = Ness Vegas (04) X = Jackpot B = Ness Jackpot (Premium package equipped as Type: B = Standard C = Custom D = Deluxe / Tour S = Sport 3 = 1737 cc S = Victory Vision ™ A = Black C = Midnight Cherry D = Supersteel Gray specified for model. T = Top Premium Model (Premium package and all available upgrades except billet wheels or as specified for model)
