2005 DYNA MODELS SERVICE MANUAL Part Number 99481-05 Section 1: Maintenance Section 2: Chassis Section 3: Engine Section 4: Fuel System Section 5: Starter Section 6: Drive Section 7: Transmission Section 8: Electrical Section 9: Fuel Injection Appendix ELECTRICAL DIAGNOSTICS Part Number 99496-05 Section 1: Starting & Charging Section 2: Instruments Section 3: TSM & TSSM Section 4: Engine Management (Carbureted) Section 5: Engine Management (EFI) Section 6: Wiring

SUBJECT PAGE NO. 1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1.2 Fuel and Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5 1.3 Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6 1.4 Engine Oil and Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9 1.5 Battery Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11 1.6 Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15 1.7 Bleeding Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17 1.8 Brake Pads and Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18 1.9 Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21 1.10 Primary Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23 1.11 Primary Chaincase Lubricant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25 1.12 Clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-27 1.13 Transmission Lubricant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-29 1.14 Rear Belt Deflection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-30 1.15 Rear Belt and Sprockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-32 1.16 Suspension Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-34 1.17 Steering Head Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-37 1.18 Front Fork Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-38 1.19 Spark Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-39 1.20 Air Cleaner Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-40 1.21 Cable and Chassis Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-42 1.22 Throttle Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-43 1.23 Enrichener: Carbureted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-44 1.24 Idle Speed/Ignition Timing: Carbureted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-45 1.25 Fuel Supply Valve Filter: Carbureted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-46 1.26 Engine Mounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-48 1.27 Headlamp Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-49 1.28 Critical Fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-51 1.29 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-52 1.30 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-54 T ab le Of Contents MAINTENANCE 1

2005 Dyna: Maintenance 1-1 HOME GENERAL 1.1 SERVICING A NEW MOTORCYCLE 1WARNING Always follow the listed service and maintenance recommendations, since they affect the safe operation of the motorcycle and the personal welfare of the rider. Failure to follow recommendations could result in death or serious injury. Service operations to be performed before customer delivery are specified in the applicable model year PREDELIVERY AND SETUP MANUAL. The performance of new motorcycle initial service is required to keep warranty in force and to ensure proper emissions sys- tems operation. After a new motorcycle has been driven its first 1000 miles (1600 km), and at every 5000 mile (8000 km) interval thereaf- ter, have a Harley-Davidson dealer perform the service operations listed under 1.3 MAINTENANCE SCHEDULE. SAFE OPERATING MAINTENANCE CAUTION ● Do not attempt to retighten engine head bolts. Retightening can cause engine damage. ● During the initial 1000 mile (1600 km) break-in period, use only Harley-Davidson 20W50 engine oil. Failure to use the recommended oil will result in improper break-in of the engine cylinders and piston rings. A careful check of certain equipment is necessary after peri- ods of storage, and frequently between regular service intervals, to determine if additional maintenance is required. Check: 1. Tires for abrasions, cuts and correct pressure. 2. Secondary drive belt for proper tension and condition. 3. Brakes, steering and throttle for responsiveness. 4. Brake fluid level and condition. Hydraulic lines and fittings for leaks. Also, check brake pads and rotors for wear. 5. Cables for fraying, crimping and free operation. 6. Engine oil and transmission fluid levels. 7. Headlamp, passing lamp, tail lamp, brake lamp and turn signal operation. SHOP PRACTICES Repair Notes NOTE ● General maintenance practices are given in this section. ● Repair = Disassembly/Assembly. ● Replace = Removal/Installation. All special tools and torque values are noted at the point of use. All required parts or materials can be found in the appropriate PARTS CATALOG. Safety Safety is always the most important consideration when performing any job. Be sure you have a complete understanding of the task to be performed. Use common sense. Use the proper tools. Protect yourself and bystanders with approved eye protection. Don’t just do the job – do the job safely. Removing Parts Always consider the weight of a part when lifting. Use a hoist whenever necessary. Do not lift heavy parts by hand. A hoist and adjustable lifting beam or sling are needed to remove some parts. The lengths of chains or cables from the hoist to the part should be equal and parallel and should be posi- tioned directly over the center of the part. Be sure that no obstructions will interfere with the lifting operation. Never leave a part suspended in mid-air. 1WARNING Always check the capacity rating and condition of hoists, slings, chains or cables before use. Failure to do so could lead to an accident which could result in death or serious injury. Always use blocking or proper stands to support the part that has been hoisted. If a part cannot be removed, verify that all bolts and attaching hardware have been removed. Check to see if any parts are in the way of the part being removed. When removing hoses, wiring or tubes, always tag each part to ensure proper installation. Cleaning If you intend to reuse parts, follow good shop practice and thoroughly clean the parts before assembly. Keep all dirt out of parts; the unit will perform better and last longer. Seals, fil- ters and covers are used in this vehicle to keep out environ- mental dirt and dust. These items must be kept in good condition to ensure satisfactory operation. Clean and inspect all parts as they are removed. Be sure all holes and passages are clean and open. After cleaning, cover all parts with clean lint-free cloth, paper or other material. Be sure the part is clean when it is installed.

1-2 2005 Dyna: Maintenance HOME Always clean around lines or covers before they are removed. Plug, tape or cap holes and openings to keep out dirt, dust and debris. Always verify cleanliness of blind holes before assembly. Tightening a screw with dirt, water or oil in the hole can cause castings to crack or break. Disassembly and Assembly Always assemble or disassemble one part at a time. Do not work on two assemblies simultaneously. Be sure to make all necessary adjustments. Recheck your work when finished. Be sure that everything is done. Operate the vehicle to perform any final check or adjustments. If all is correct, the vehicle is ready to go back to the customer. REPAIR AND REPLACEMENT PROCEDURES Hardware and Threaded Parts Install helical thread inserts when inside threads in castings are stripped, damaged or not capable of withstanding specified torque. Replace bolts, nuts, studs, washers, spacers and small common hardware if missing or in any way damaged. Clean up or repair minor thread damage with a suitable tap or die. Replace all damaged or missing lubrication fittings. Use Teflon pipe sealant on pipe fitting threads. Wiring, Hoses and Lines Replace hoses, clamps, electrical wiring, electrical switches or fuel lines if they do not meet specifications. Instruments and Gauges Replace broken or defective instruments and gauges. Replace dials and glass that are so scratched or discolored that reading is difficult. Bearings Anti-friction bearings must be handled in a special way. To keep out dirt and abrasives, cover the bearings as soon as they are removed from the package. Wash bearings in a non-flammable cleaning solution. Knock out packed lubricant inside by tapping the bearing against a wooden block. Wash bearings again. Cover bearings with clean material after setting them down to dry. Never use compressed air to dry bearings. Coat bearings with clean oil. Wrap bearings in clean paper. Be sure that the chamfered side of the bearing always faces the shoulder (when bearings installed against shoulders). Lubricate bearings and all metal contact surfaces before pressing into place. Only apply pressure on the part of the bearing that makes direct contact with the mating part. Always use the proper tools and fixtures for removing and installing bearings. Bearings do not usually need to be removed. Only remove bearings if necessary. Bushings Do not remove a bushing unless damaged, excessively worn or loose in its bore. Press out bushings that must be replaced. When pressing or driving bushings, be sure to apply pressure in line with the bushing bore. Use a bearing/bushing driver or a bar with a smooth, flat end. Never use a hammer to drive bushings. Inspect the bushing and the mated part for oil holes. Be sure all oil holes are properly aligned. Gaskets Always discard gaskets after removal. Replace with new gaskets. Unless otherwise instructed, never use the same gasket twice. Be sure that gasket holes match up with holes in the mating part. But be aware that sections of a gasket may be used to seal passages. Lip Type Seals Lip seals are used to seal oil or grease and are usually installed with the sealing lip facing the contained lubricant. Seal orientation, however, may vary under different applica- tions. Seals should not be removed unless necessary. Only remove seals if required to gain access to other parts or if seal damage or wear dictates replacement. Leaking oil or grease usually means that a seal is damaged. Replace leaking seals to prevent overheated bearings. Always discard seals after removal. Do not use the same seal twice. O-Rings (Preformed Packings) Always discard O-rings after removal. Replace with new O- rings. To prevent leaks, lubricate the O-rings before installation. Apply the same type of lubricant as that being sealed. Be sure that all gasket, O-ring and seal mating surfaces are thoroughly clean before installation.

2005 Dyna: Maintenance 1-3 HOME Gears Always check gears for damaged or worn teeth. Lubricate mating surfaces before pressing gears on shafts. Shafts If a shaft does not come out easily, check that all nuts, bolts or retaining rings have been removed. Check to see if other parts are in the way before using force. Shafts ﬁtted to tapered splines should be very tight. If shafts are not tight, disassemble and inspect tapered splines. Dis- card parts that are worn. Be sure tapered splines are clean, dry and free of burrs before putting them in place. Press mating parts together tightly. Clean all rust from the machined surfaces of new parts. Part Replacement Always replace worn or damaged parts with new parts. CLEANING Part Protection Before cleaning, protect rubber parts (such as hoses, boots and electrical insulation) from cleaning solutions. Use a grease-proof barrier material. Remove the rubber part if it cannot be properly protected. Cleaning Process Any cleaning method may be used as long as it does not result in parts damage. Thorough cleaning is necessary for proper parts inspection. Strip rusted paint areas to bare metal before repainting. Rust or Corrosion Removal Remove rust and corrosion with a wire brush, abrasive cloth, sand blasting, vapor blasting or rust remover. Use bufﬁng cro- cus cloth on highly polished parts that are rusted. Bearings Clean open bearings by soaking them in a petroleum cleaning solution. Never use a solution that contains chlorine. Let bearings stand and dry. Do not dry using compressed air. Do not spin bearings while they are drying. TOOL SAFETY Air Tools ● Always use approved eye protection equipment when performing any task using air-operated tools. ● On all power tools, use only recommended accessories with proper capacity ratings. ● Do not exceed air pressure ratings of any power tools. ● Bits should be placed against work surface before air hammers are operated. ● Disconnect the air supply line to an air hammer before attaching a bit. ● Never point an air tool at yourself or another person. ● Protect bystanders with approved eye protection. Wrenches ● Never use an extension on a wrench handle. ● If possible, always pull on a wrench handle and adjust your stance to prevent a fall if something lets go. ● Never cock a wrench. ● Never use a hammer on any wrench other than a STRIK- ING FACE wrench. ● Discard any wrench with broken or battered points. ● Never use a pipe wrench to bend, raise or lift a pipe. Pliers/cutters/prybars ● Plastic- or vinyl-covered pliers handles are not intended to act as insulation; don’t use on live electrical circuits. ● Don’t use pliers or cutters for cutting hardened wire unless they were designed for that purpose. ● Always cut at right angles. ● Don’t use any prybar as a chisel, punch or hammer.

1-4 2005 Dyna: Maintenance HOME Hammers ● Never strike one hammer against a hardened object, such as another hammer. ● Always grasp a hammer handle firmly, close to the end. ● Strike the object with the full face of the hammer. ● Never work with a hammer which has a loose head. ● Discard hammer if face is chipped or mushroomed. ● Wear approved eye protection when using striking tools. ● Protect bystanders with approved eye protection. Punches/Chisels ● Never use a punch or chisel with a chipped or mushroomed end; dress mushroomed chisels and punches with a file. ● Hold a chisel or a punch with a tool holder if possible. ● When using a chisel on a small piece, clamp the piece firmly in a vise and chip toward the stationary jaw. ● Wear approved eye protection when using these tools. ● Protect bystanders with approved eye protection. Screwdrivers ● Don’t use a screwdriver for prying, punching, chiseling, scoring or scraping. ● Use the right type of screwdriver for the job; match the tip to the fastener. ● Don’t interchange POZIDRIV ® , PHILLIPS ® or REED AND PRINCE screwdrivers. ● Screwdriver handles are not intended to act as insulation; don’t use on live electrical circuits. ● Don’t use a screwdriver with rounded edges because it will slip – redress with a file. Ratchets and Handles ● Periodically clean and lubricate ratchet mechanisms with a light grade oil. Do not replace parts individually; ratchets should be rebuilt with the entire contents of service kit. ● Never hammer or put a pipe extension on a ratchet or handle for added leverage. ● Always support the ratchet head when using socket extensions, but do not put your hand on the head or you may interfere with the action of its reversing mechanism. ● When breaking loose a fastener, apply a small amount of pressure as a test to be sure the ratchet’s gear wheel is engaged with the pawl. Sockets ● Never use hand sockets on power or impact wrenches. ● Select the right size socket for the job. ● Never cock any wrench or socket. ● Select only impact sockets for use with air or electric impact wrenches. ● Replace sockets showing cracks or wear. ● Keep sockets clean. ● Always use approved eye protection when using power or impact sockets. Storage Units ● Don’t open more than one loaded drawer at a time. Close each drawer before opening up another. ● Close lids and lock drawers and doors before moving storage units. ● Don’t pull on a tool cabinet; push it in front of you. ● Set the brakes on the locking casters after the cabinet has been rolled to your work.

2005 Dyna: Maintenance 1-5 HOME FUEL AND OIL 1.2 FUEL 1WARNING Use care when refueling. Pressurized air in fuel tank can force gasoline to escape through filler tube. Gasoline is extremely flammable and highly explosive, which could result in death or serious injury. (00029a) 1WARNING Avoid spills. Slowly remove filler cap. Do not fill above bot- tom of filler neck insert, leaving air space for fuel expan- sion. Secure filler cap after refueling. Gasoline is extremely flammable and highly explosive, which could result in death or serious injury. (00028a) Use a good quality leaded or unleaded gasoline (91 pump octane or higher). Pump octane is the octane number usually shown on the gas pump. GASOLINE BLENDS CAUTION Using gasoline that has an alcohol additive, such as methanol, may cause fuel system rubber components’ failure and/or engine damage. Harley-Davidson motorcycles were designed to give the best performance using unleaded gasoline. Some fuel suppliers sell gasoline/alcohol blends as a fuel. The type and amount of alcohol added to the fuel is important. ● DO NOT USE GASOLINES CONTAINING METHANOL. Using gasoline/methanol blends will result in starting and driveability deterioration and damage to critical fuel system components. ● ETHANOL is a mixture of 10% ethanol (Grain alcohol) and 90% unleaded gasoline. Gasoline/ethanol blends can be used in your motorcycle if the ethanol content does not exceed 10%. ● REFORMULATED OR OXYGENATED GASOLINES (RFG): “Reformulated gasoline” is a term used to describe gasoline blends that are specifically designed to burn cleaner than other types of gasoline. Your motorcycle will run normally using this type of gas. You may find that some gasoline blends adversely affect the starting, driveability or fuel efficiency of your bike. If you expe- rience one or more of these problems, we recommend you try a different brand of gasoline or gasoline with a higher octane rating. ENGINE OIL Use the proper grade of oil for the lowest temperature expected before the next oil change. If it is necessary to add oil and Harley-Davidson oil is not available, use an oil certified for diesel engines. Acceptable diesel engine oil designations include: ● CF ● CF-4 ● CG-4 ● CH-4 The preferred viscosities for the diesel engine oils, in descending order, are: ● 20W-50 ● 15W-40 ● 10W-40 At the first opportunity, see a Harley-Davidson dealer to change back to 100 percent Harley-Davidson oil. See 1.4 ENGINE OIL AND FILTER for all service information. WINTER LUBRICATION Combustion in an engine produces water vapor. During starting and warm-up in cold weather, especially in freezing temperatures, the vapor condenses to water before the crankcase is hot enough to exhaust it through the breather system. If the engine is run long enough for the crankcase to become thoroughly heated, the water returns to vapor and is then exhausted. An engine used for only short trips, and seldom allowed to thoroughly warm up, accumulates increasing amounts of water in the oil pan. Water mixed with oil forms a sludge that causes accelerated engine wear. In freezing temperatures, the water becomes slush or ice, which may clog oil lines and result in engine failure. Always change the engine oil more often in winter. If the engine is used for short runs, change the oil even more frequently. The farther below freezing the temperature drops the more often the oil should be changed.

1-6 2005 Dyna: Maintenance HOME MAINTENANCE SCHEDULE 1.3 Table 1-1. Regular Service Intervals For Dyna Models ITEM SERVICED PROCEDURE 1000 mi 1600 km 5000 mi 8000 km 10,000 mi 16,000 km 15,000 mi 24,000 km 20,000 mi 32,000 km 25,000 mi 40,000 km NOTES Engine oil and filter Replace X X X X X X Oil lines and brake system Inspect for leaks X X X X X X 1 Air cleaner Inspect, service as required X X X X X X Tires Check pressure, inspect tread X X X X X X Wheel spokes Check tightness X X X 1, 4 Primary chaincase lubricant Replace X X X X X X Transmission lubricant Replace X X X X X X Clutch Check adjustment X X X X X X 1 Primary chain Check adjustment X X X X X X Rear belt and sprockets Inspect, adjust belt X X X X X X 1 Throttle, brake, enrichener and clutch controls Check, adjust and lubricate X X X X X X 1, 4 Jiffy stand Inspect and lubricate X X X 1 Fuel valve, lines and fittings Inspect for leaks X X X X X X 1, 4 Fuel tank filter screen Clean (EFI: replace) X 1 Brake fluid Check levels and condition X X X X X X Brake pads and discs Inspect for wear X X X X X X Spark plugs Inspect X X X X Replace X X Electrical equipment and switches Check operation X X X X X X Engine idle speed Check adjustment X X X X X X 1 Front fork oil Replace X 1 Steering head bearings Adjust and lubricate X X X 1, 2 Rear fork bearings Repack every 30,000 mi (48,000 km) if applicable 1 Critical fasteners Check tightness X X X 1 Engine mounts and stabilizer links Inspect X X 1 Battery Check battery and clean connections 3 Road test Verify component and system functions X X X X X X NOTES: 1. Should be performed by an authorized Harley-Davidson dealer, unless you have the proper tools, service data and are mechanically qualified. 2. Disassemble, lubricate and inspect every 30,000 miles (48,000 km). 3. Perform annually. 4. Not all vehicles are equipped with enrichener, fuel valve or spoke wheels. Consult appropriate topic in service manual.

2005 Dyna: Maintenance 1-7 HOME Table 1-2 Quick Reference Maintenance Chart ITEM SERVICED SPECIFICATION DATA Engine oil and filter Drain plug torque 14-21 ft-lbs (19.0-28.5 Nm) Oil capacity 3 qt. (2.4 L) Filter Hand tighten 1/2-3/4 turn after gasket contact Chrome filter part number 63798-99 Black filter part number 63731-99 Primary chain tension Deflection with cold engine 5/8-7/8 in. (15.9-22.3 mm) Deflection with hot engine 3/8-5/8 in. (9.5-15.9 mm) Chain tensioner nut torque 21-29 ft-lbs (28.5-39.3 Nm) Primary chain inspection cover torque 84-108 in-lbs (9.5-12.2 Nm) Primary chain lubricant Lubricant capacity 26 oz. (768.9 ml) Primary chaincase drain plug torque 36-60 in-lbs (4.1-6.8 Nm) Clutch adjustment Free play at adjuster screw 1/2-1 turn Adjuster screw locknut torque 72-120 in-lbs (8.1-13.6 Nm) Free play at hand lever 1/16-1/8 (1.6-3.2 mm) Clutch inspection cover torque 84-108 in-lbs (9.5-12.2 Nm) Transmission lubricant Lubricant level Dipstick at FULL with motorcycle level and filler plug resting on threads Lubricant capacity 20-24 oz (591.5-709.8 ml) Transmission drain plug torque 14-21 ft-lbs (19.0-28.5 Nm) Filler plug torque 25-75 in-lbs (2.8-8.5 Nm) Tire condition and pressure Pressure for solo rider Front: 30 psi (207 kPA) Rear: 36 psi (248 kPA) Pressure for rider and passenger Front: 30 psi (207 kPA) Rear: 40 psi (276 kPA) Wear Replace tire if 1/32 in. (0.8 mm) or less of tread pattern remains Wheel spokes Spoke nipple torque 40-50 in-lbs (4.5-5.6 Nm) Brake fluid reservoir level D.O.T. hydraulic brake fluid part numbers 99902-77 (12 oz.) 99901-77 (gal) Proper fluid level 1/8 in. (3.2 mm) below gasket surface Master cylinder reservoir cover torque 6-8 in-lbs (0.7-0.9 Nm) Brake pad linings and discs Minimum brake pad thickness 0.04 in. (1.02 mm) Minimum brake disc thickness See stamp on side of disc
