1 E Owner’s manual DUCATI 748R

3 E Hearty welcome among Ducati fans! Please accept our best compliments for choosing a Ducati motorcycle. We think you will ride your Ducati motorcycle for long journeys as well as short daily trips. Ducati Motor Holding S.p.A wishes you smooth and enjoyable riding. We are steadily doing our best to improve our “Technical Assistance” service. For this reason, we recommend you to strictly follow the indications given in this manual, especially for motorcycle running-in. In this way, your Ducati motorbike will surely give you unforgettable emotions. For any servicing or suggestions you might need, please contact our authorized service centres. Enjoy your ride! Ducati Motor Holding S.p.A. declines any liability whatsoever for any mistakes incurred in drawing up this manual. The information contained herein is valid at the time of going to print. Ducati Motor Holding S.p.A. reserves the right to make any changes required by the future development of the above-mentioned products. For your safety, as well as to preserve the warranty, reliability and worth of your motorcycle, use original Ducati spare parts only. Warning This manual forms an integral part of the motorcycle and - if the motorcycle is resold - must always be handed over to the new owner.

4 E TABLE OF CONTENTS General 6 Warranty 6 Symbols 6 Useful information for safe riding 7 Carrying the max load allowed 8 Identification data 9 Controls 10 Position of motorcycle controls 10 Instrument panel 11 Keys 12 Key-operated ignition switch and steering lock 12 Left switch 13 Clutch lever 14 Cold start button 15 Right switch 15 Throttle twistgrip 16 Front brake lever 16 Rear brake pedal 17 Gear change pedal 17 Adjustment of gear change and rear brake pedals 18 Main components and devices 20 Location 20 Tank filler plug 21 Seat catch and helmet hook 22 Side stand 23 Steering damper 24 Front fork adjusters 25 Shock absorber adjusters 27 Changing motorcycle track alignement 28 Directions for use 29 Running-in recommendations 29 Pre-ride checks 30 Starting the engine 31 Moving off 33 Braking 33 Stopping the motorcycle 34 Parking 34 Refueling 35 Tool kit and accessories 36 Main maintenance operations 37 Removing the fairing 37 Cleaning and changing air filters 39 Checking the coolant level 40 Checking brake and clutch fluid level 41 Checking brake pads for wear 42 Lubricating cables and joints 43 Throttle cable adjustment 43 Charging the battery 44 Adjusting headstock angle 45

5 E Chain tension inspection 46 Chain lubrication 46 Replacing bulbs 47 Beam setting 51 Rear view mirror adjustment 51 Tubeless tyres 52 Checking engine oil level 54 Cleaning and replacing the spark plugs 55 Cleaning the motorcycle 56 Storing the bike away 56 Important notes 56 Technical data 57 Performance data 57 Overall dimensions 57 Weights 57 Top-ups 58 Engine 59 Timing system 59 Spark plugs 59 Brakes 60 Transmission 61 Frame 62 Wheels 62 Tyres 62 Suspensions 63 Available colours 63 Electric system 63 Routine maintenance record 68

6 E GENERAL Warranty In your own interest, and in order to guarantee product reliability, you are strongly advised to refer to a Ducati Dealer or Authorized Workshop for any servicing requiring particular technical expertise. Our highly skilled staff have access to the implements required to perform any servicing job at best, using Ducati original spare parts only as the best guarantee for full interchangeability, smooth running and long life. All Ducati motorcycles come with a “Warranty Card”. However, warranty does not apply to the motorcycles used in competitions. No motorcycle part may be tampered with, altered, or replaced with parts other than original Ducati spare parts during the warranty period, or the warranty will be automatically invalidated. Symbols Ducati Motor Holding S.p.A. advises you to read this manual carefully so as to become familiar with your motorcycle. In case of any doubts, please call a Ducati Dealer or Authorized Workshop. The information contained herein will prove useful on your trips - and Ducati Motor Holding S.p.A. wishes you smooth, enjoyable riding - and will help you keep the performance of your motorcycle unchanged for a long time. Warning Failure to comply with these instructions may put you at risk and lead to severe injury or death. Important Possibility of damaging the motorcycle and/or its components. Note Additional information concerning the job being carried out. The terms right and left are referred to the motorcycle viewed from the riding position.

7 E Useful information for safe riding Warning Read this section before riding your motorcycle. Accidents are frequently due to inexperience. Always make sure you have your licence with you when riding; you need a valid licence to be entitled to ride your motorcycle. Do not lend your motorcycle to inexperienced riders or who do not hold a valid licence. Always wear a safety helmet. Wear proper clothing, with no loose items or accessories that may become tangled in the controls or limit your zone of vision. Never start or run the engine indoors. Exhaust gases are poisonous and may lead to loss of consciousness or even death within a short time. Keep your feet on the footpegs when the motorcycle is in motion. Always hold the handlebars firmly with both hands so you will be ready for sudden changes of direction or in the road surface. Ride within the law and observe national and local rules. Always respect speed limits where these are posted. However, always adjust your speed to the visibility, road and traffic conditions you are riding in. Always signal your intention to turn or pull to the next lane in good time using the suitable turn indicators. Be sure you are clearly visible and do not ride within the blind spot of vehicles ahead. Be very careful when tackling road junctions, or when riding in the areas near exits from private grounds, car parks or on slip roads to access motorways. Always turn off the engine when refueling. Be extremely careful not to spill gasoline on the engine or on the exhaust pipe when refueling. Do not smoke when refueling. While refueling, you may inhale noxious gasoline vapors. Should any gasoline drops be spilled on your skin or clothing, immediately wash with soap and water and change your clothing. Always remove the key when you leave your motorcycle unattended. The engine, exhaust pipes, and mufflers stay hot for a long time. Park your motorcycle where no one is likely to hit it and use the side stand. Never park on uneven or soft ground or your motorcycle may fall over.

8 E Carrying the maximum load allowed Your motorcycle is designed for long-distance riding, carrying the maximum load allowed in full safety. Even weight distribution is critical to preserving safety features and avoiding trouble when performing sudden manoeuvres or riding on bumpy roads. Information about carrying capacity The total weight of the motorcycle in running order including rider, luggage and additional accessories should not exceed 310 Kg. Arrange your luggage or heavy accessories in the lowest possible position and close to motorcycle centre. Be sure to secure the luggage to the supports provided on the motorcycle as firmly as possible. Improperly secured luggage may affect stability. Never fix bulky or heavy objects to the handlebar or to the front mud guard as this would affect stability and cause danger. Do not insert any objects you may need to carry into the gaps of the frame as these may foul moving parts. Make sure the tyres are inflated to the proper pressure indicated at page 52 and that they are in good condition.

Identification data All Ducati motorcycles have two identification numbers, for frame (fig. 1.1) and engine (fig. 1.2). Frame number Engine number Note These numbers identify the motorcycle model and are required when ordering spare parts. This exclusive model has been produced in a limited series. Each motorcycle is identified by a serial number etched on a silver plate fixed to steering head. 9 E fig. 1.2 fig. 1.1

10 E CONTROLS Warning This section details the position and function of all the controls you need to drive your motorcycle. Be sure to read this information carefully before you use the controls. Position of motorcycle controls (fig. 2) 1) Instrument panel. 2) Key-operated ignition switch and steering lock. 3) Left switch. 4) Clutch lever. 5) Cold start button. 6) Right switch. 7) Throttle twistgrip. 8) Front brake lever. 9) Gear change pedal. 10) Rear brake pedal. fig. 2
