INDEX Handler with telescopic boom Telelift 3713 SX (From serial n. 09944 to serial n. 16244) SERVICE MANUAL Code 57.4402.9200 - 1 st Edition 10/2006 English Edition Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX TELELIFT 3713 SX Intentionally blank page  Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX  TELELIFT 3713 SX SERVICE MANUAL Code 57.4402.9200 - 1 st Edition 10/2006 Number: .................................... Consigned to: ................................................................................................................................ DECLARATION I, the undersigned.......................................................................................................................... declare that I have received the Service manual for TEREXLIFT lifts series Telelift 3713 SX. Copies consigned: n° ...... on paper n° ...... on CD-Rom The undersigned is obliged to use the manual in their workshop, without disclosing the information in the same in any way, to unauthorised workshops and third parties in general, and not to photocopy or reproduce this manual or parts of the same in any way without the prior written authorisation of TEREXLIFT to do so. If business relations between the undersigned and TEREXLIFT should come to an end, the undersigned is obliged to return the copies received without charges for TEREXLIFT. Yours sincerely Date ............................ For acceptance The consignee Company stamp and signature of the Legal representative ........................................... ........................................... Copy to return stamped and signed for acceptance by the Legal representative of the company receiving the copies of the manual. Courtesy of Crane.Market

Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX SERVICE MANUAL Code 57.4402.9200 - 1 st Edition 10/2006 Number: .................................... Consigned to: ................................................................................................................................ DECLARATION I, the undersigned.......................................................................................................................... declare that I have received the Service manual for TEREXLIFT lifts series Telelift 3713 SX. Copies consigned: n° ...... on paper n° ...... on CD-Rom The undersigned is obliged to use the manual in their workshop, without disclosing the information in the same in any way, to unauthorised workshops and third parties in general, and not to photocopy or reproduce this manual or parts of the same in any way without the prior written authorisation of TEREXLIFT to do so. If business relations between the undersigned and TEREXLIFT should come to an end, the undersigned is obliged to return the copies received without charges for TEREXLIFT. Yours sincerely Date ............................ For acceptance The consignee Company stamp and signature of the Legal representative ........................................... ...........................................  TELELIFT 3713 SX Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX Revision Revised pages Notes Issued by No. Date 1 10-2006 Publication 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 TELELIFT 3713 SX LIST OF REVISED PAGES 4 Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX MANUAL CONTENTS INTRODUCTION Sect. 1 SAFETY RULES Sect.  TECHNICAL SPECIFICATIONS Sect.  SCHEDULED MAINTENANCE INSPECTIONS Sect. 4 SCHEDULED MAINTENANCE PROCEDURES Sect. 5 TROUBLESHOOTING Sect. 6 SCHEMES Sect. 7 REPAIR PROCEDURES 5 TELELIFT 3713 SX GENERAL INDEX Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX Machine denomination Literature valid up to serial number Telelift 3713 SX 11321 TELELIFT 3713 SX SERIAL NUMBER IDENTIFICATION 6 Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX i TELELIFT 3713 SX INTRODUCTION INTRODUCTION Important Read, understand and obey the safety rules and operating instructions in the Telelift 71 SX Operator's Handbook before attempting any maintenance or repair procedure. This manual provides the machine owner and user with detailed information on the scheduled maintenance. It also provided qualifed service technicians with infromation on troubleshooting and repair procedures. Basic mechanical, hydraulic and electrical skills are required to perform most procedures. However, several procedures require specialized skills, as well as specifc tools and equipment. In these instances, we strongly recommend letting service and repair the machine at an authorized TEREXLIFT service center. Technical Publications No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means without prior written permission from TEREXLIFT srl. In pursuing a policy of constant quality improvement, TEREXLIFT srl reserves the right to make changes at any time and without undertaking to give prior notice; therefore, also this publication may be subject to modifcations. Contact Us http://www.terexlift.com e-mail: info@terexlift.it © Copyright 2006 TEREXLIFT srl - All rights reserved. Courtesy of Crane.Market

Document 57.4402.9200 - 1 st Edition 10/2006 INDEX TELELIFT 3713 SX INTRODUCTION ii DESCRIPTION OF THE MACHINE OPERATION The source of mechanical energy of this machine is a naturally aspirated diesel engine (1) model Perkins 1104C-44 with direct injection, water cooling, 4 cylinders, 63.5 kW power (86 HP) at 2400 rev/min., max torque of 302 Nm at 1400 rev./min. or, in alternative, a turbo.- compressed diesel engine model Perkins 1104C/44T, with direct injection, water cooling, 4 cylinders, 74.4 kW power (101 HP) at 2400 rev./min., max. torque of 412 Nm at 1400 rev./min. On the fywheel side of the engine, and connected to this engine by a Technodrive coupler complete with elastic joint and with a 1-to-1 ratio, there is Bosch- Rexroth closed-loop pump for hydrostatic drives, model A4VG71 () with adjustment valve of DA type. The max displacement of this swashplate pump is 71 cm 3 /rev. and the max calibration pressure is 420 bar. This pump is used to supply hydraulic power under form of pressure and fow rate which is then used for moving the machine. On the through-shaft of such drive pump there is a Casappa open-loop gear pump (with fxed displacement) (4) with priority valve integrated in the housing (1). The displacement of this pump is 43 cm 3 /rev. Its function is to provide hydraulic power, under form of pressure and fow rate, to the steering circuit of the machine (priority side) and to the circuit for the telescopic boom movements (secondary side). The assembly of the two pumps involves they have a rotation velocity equal to the speed of the diesel engine. A third Casappa open-loop gear pump (with fxed displacement) (5) with a displacement of 20 cm 3 /rev., is installed on the PTO of the engine located to the distribution side. This pump feeds the servo-assisted braking system (18) and the unused oil fow is delivered to the hydraulic geared motor Casappa (8) with a displacement of 20 cm 3 for the operation of the cooling fan mounted on the heat exchanger (9). Inside the motor housing, an anti-cavitation valve and a pressure limiting valve with bypass function set at 140 bar, are installed. The suction lines of the open-loop pumps (5) and (4) are protected by an immersed flter (7), placed inside the hydraulic fuid tank (11) whose capacity is 120 litres. Just upstream of the connection with the two suction lines mentioned above, there is a gate valve with ball valve which lets you cut out the hydraulic oil tank in order to perform maintenance interventions on the machine's hydraulic system. On the contrary, the drive pump () is protected by a cartridge flter (6), installed on the suction line of the booster pump. This pump is an integral part of the drive pump. The one-way valve (1) set at 2.5 bar protects the pump housing against high pressures and guarantees a certain circulation of the drain oil to the hydrostatic motor reducing, in this way, the temperature. From port “G” of the drive pump () low- pressure oil is taken (25-30 bar) and used for the anti- Courtesy of Crane.Market
