ZF Tractor Transmission T-7336 PS Workshop Manual

Order No.: 5871 970 002 ZF – TRACTOR TRANSMISSION T-7336 PS ZF Passau GmbH Donaustr. 25 - 71 D- 94034 Passau

REPAIR MANUAL for the ZF – TRACTOR TRANSMISSION T-7336 PS I M P O R T A N T N O T E: The great variety of ZF units compels a restriction of the Disassembly and Assembly Manuals to a current ZF production unit. Technical development of the ZF units as well as extensions concerning the design possibilities may require differing steps, which can be carried out by qualified Specialists without greater difficulties with the help of the Perspective Illustrations in the corresponding Spare Parts Lists. The described Disassembly and Assembly Manual is based on the design level of a ZF production unit at the time of preparation of the Repair Manual. The ZF Passau GmbH reserve the right to replace the present Disassembly and Assembly Manual by a successional edition without advance notice. Upon request, the ZF Passau GmbH will advise what edition is the latest one. ATTENTION: For the Installation as well as for the commissioning of the unit, the Instructions and Specifications of Vehicle Manufacturer have to be observed! For information about the Operation, Maintenance and Description, see the corresponding ZF Operating Instructions. ZF Passau GmbH Donaustr. 25 - 71 D - 94034 Passau Abt.: ASDM / Section : ASDM Nachdruck auch auszugsweise ohne die Genehmigung der ZF Passau GmbH nicht gestattet! Copyright ZF Passau GmbH! Copying even partially not permitted! Reproduction même par extrait est interdite! Technische Änderungen vorbehalten! With the reserve of technical modifications! Sous reserve de modifications techniques! 1.Auflage / 1st Edition 2004/05

Repair Manual Off-Road Transmissions and Axle Systems Division 5871 970 002 0/1 PREFACE This documentation has been developed for the skilled Serviceman, trained by the ZF Passau for the Repair and Maintenance operations on ZF-Units. Treated is a ZF-Serial product according to the design stage of the date of Edition. However, due to further technical developments of the product, the repair of the unit at your disposal could require different steps as well as other adjustment and testing specifications. Therefore, we recommend to commit your ZF-Product to Masters and to Servicemen, whose practical and theoretical training is constantly completed to the actual situation in our Training School. The Service Stations, established by the ZF Friedrichshafen all over the world, offer you: 1. Constantly trained personnel 2. Prescribed installations, e.g. Special Tools 3. Genuine ZF-Spare Parts according to the latest phase of development Here, all operations are carried out for you with utmost care and reliability. Repair operations carried out by ZF-Service Stations, are covered additionally within the terms of the actual contractual conditions, by the ZF-Warranty. Damages caused by inappropriate or inexpert work, carried out by personnel foreign to ZF, and after- expenditures eventually arising from it, are excluded from this contractual responsibility. This applies also in case of a renouncement of Genuine ZF-Spare Parts. ZF Passau GmbH Service Department

Repair Manual Off-Road Transmissions and Axle Systems Division 5871 970 002 0/2 GENERAL The Service Manual covers all work required for dismantling and the pertaining installation. When repairing the axle, ensure utmost cleanliness and that the work is carried out in an expert-like manner. The axle should only be disassembled for renewing damaged parts. Covers and housing parts installed with seals must be loosened by slight blows with a plastic mallet after screws and nuts have been removed. For removing parts being in tight contact with the shaft such as antifriction bearings, bearing races, and similar, use suitable pulling devices. Dismantling and mounting work must be carried out at a clean working place. Use the special tools developed for this purpose. Prior to the re-installation of the parts, clean the contact surfaces of housings and covers from the residues of old seals. Remove burrs, if any, or similar irregularities with an oil stone. Clean housings and locking covers with a suitable detergent, in particular corners and angles. Damaged parts or parts heavily worn down must be renewed. Here, the expert must assess, whether parts such as antifriction bearings, thrust washers etc. subjected to normal wear during operation, can be installed again. Parts such as sealing rings, lock plates, split pins etc. must generally be renewed. Radial sealing rings with worn down or torn sealing lip must also be renewed. Particularly ensure that no chips or other foreign bodies remain in the housing. Lube oil bores and grooves must be checked for unhindered passage. All bearings must be treated with operating oil prior to installing them: REFE- RENCE: For heating up parts such as bearings, housings etc., only a heating furnace or an electric drier is permitted to be used! Parts fitted in heated state have to be installed subsequently after cooling down to ensure a perfect contact! CAUTION When assembling the transmission, absolutely observe the indicated torque limits and adjustment data. Screws and nuts must be tightened according to the enclosed standard table, unless otherwise specified. In view of the risk of functional failures in the control unit, the use of liquid sealing agents is not permitted. by no means. Lined plates with organic friction linings (e.g. paper linings) must not be washed (negative effect on lining adhesion). They are only allowed to be dry-cleaned (leather cloth). For the installation of circlips and retaining rings it must be observed that slots are located exactly. DANGER When using detergents, observe the instructions given by the manufacturer regarding handling of the respective detergent.

Repair Manual Off-Road Transmissions and Axle Systems Division 5871 970 002 0/3 Structure of the Repair Manual The structure of this Repair Manual reflects the sequence of the working steps for completely disassembling the dismantled transmission. Dismantling and installing as well as the disassembly and assembly of a main group are always summarized in one chapter. Special tools required for performing the respective repair work are listed in the text as well as in the Chapters “W” (List of Special Tools) and “WB” (Illustrated Tables). Important information on industrial safety Generally, the persons repairing ZF-units are responsible on their own for the industrial safety. The observation of all valid safety regulations and legal impositions is the pre-condition for avoiding damage to persons and to the product during maintenance and repair works. Persons performing repair works must familiarize themselves with these regulations. The proper repair of these ZF-products requires the employment of suitably trained and skilled staff. The repairer is obliged to perform the training. The following safety references are used in the present Repair Manual: CAUTION Serves as reference to special working procedures, methods, information, the use of auxiliaries etc... in this repair manual. DANGER Is used, if lacking care can lead to personal injury or damage the product. ___________________________________________________ REFE- RENCE Prior to starting the checks and repair works, thoroughly study the present instructions. CAUTION: Illustrations, drawings and parts do not always represent the original; the working procedure is shown. The illustrations, drawings, and parts are not drawn to scale; conclusions regarding size and weight must not be drawn (not even within one representation). The works must be performed according to the description. REFE- RENCE: After the repair works and the checks, the expert staff must convince itself that the product is properly functioning again. !

Repair Manual Off-Road Transmissions and Axle Systems Division 5871 970 002 0/4 VERGLEICHSTABELLE FÜR MASSEINHEITEN CONVERSION TABLE TABLEAU DE CONVERSION 25,40 mm 1 kg ( Kilogramm ) 9,81 Nm ( 1 kpm ) 1,356 Nm ( 0,138 kpm ) 1 kg / cm 1 bar ( 1,02 kp/cm 2 ) 0,070 bar ( 0,071 kp/cm 2 ) 1 Liter 4,456 Liter 1 Liter 3,785 Liter 1609,344 m 0° C ( Celsius ) 0 ° C ( Celsius ) = = = = = = = = = = = = = = 1 in ( inch) 2,205 lb ( pounds ) 7,233 lbf x ft ( pound force foot) 1 lbf x ft ( pound force foot ) 5,560 lb / in ( pound per inch ) 14,233 psi (pound force per square inch lbf/in 2 ) 1 psi ( lbf/in 2 ) 0,264 Gallon ( Imp. ) 1 Gallon ( Imp. ) 0,220 Gallon ( US ) 1 Gallon ( US ) 1 Mile ( Landmeile ) + 32° F ( Fahrenheit ) 273,15 Kelvin

Repair Manual Off-Road Transmissions and Axle Systems Division 5871 970 002 0/5 BEZEICHNUNG DER GESETZLICHEN EINHEITEN DENOMINATION OF STANDARD DIMENSIONS DENOMINATION DES DIMENSIONS STANDARDISEES Hinweis : längenbezogene Maße in kg/m; flächenbezogene maße in t/m 2 Note : linear density in kg/m; areal density in t/m 2 Nota : Densité linéaire en kg/m; Densité superficielle en t/m 2 Begriff Unit Unité Formelzeichen Formula Sign Symbole Neu Alt New Old Nouveau Vieu Umrechnung Conversion Conversion Bemerkungen Note Nota Masse Mass Mass m kg (Kilogramm) kg Kraft Force Force F N (Newton) kp 1 kp = 9,81 N Arbeit Work Travail A J (Joule) kpm 0,102kpm = 1J = 1Nm Leistung Power Puissance P KW (Kilowatt) PS (DIN) 1 PS = 0,7355 KW 1 KW = 1,36 PS Drehmoment Torque Couple T Nm (Newtonmeter) kpm 1 kpm = 9,81 Nm T (Nm) = F (N) . r (m) Kraftmoment Moment (Force) Moment (Force) M Nm (Newtonmeter) kpm 1 kpm = 9,81 Nm M (Nm) = F (N) . r (m) Druck (Über-) Pressure (Overpress) Pression (Sur-) pü bar atü 1,02 atü = 1,02 kp/cm 2 = 1 bar = 750 torr Drehzahl Speed Nombre de Tours n min -1

Repair Manual Off-Road Transmissions and Axle Systems Division 5871 970 002 0/6 TORQUE LIMITS FOR SCREWS (IN Nm) TO ZF-STANDARD 148 Friction value : μ total= 0.12 for screws and nuts without after-treatment, as well as phophatized nuts. Tightened by hand ! Torque limits, if not especially indicated, can be taken from the following list: Metric ISO-Standard Thread DIN 13, Page 13 Size 8.8 10.9 12.9 M4 2.8 4.1 4.8 M5 5.5 8.1 9.5 M6 9.5 14 16.5 M7 15 23 28 M8 23 34 40 M10 46 68 79 M12 79 115 135 M14 125 185 215 M16 195 280 330 M18 280 390 460 M20 390 560 650 M22 530 750 880 M24 670 960 1100 M27 1000 1400 1650 M30 1350 1900 2250 M33 1850 2600 3000 M36 2350 3300 3900 M39 3000 4300 5100 Metric ISO-Fine Thread DIN 13, Page 13 Size 8.8 10.9 12.9 M 8 x 1 24 36 43 M 9 x 1 36 53 62 M 10 x 1 52 76 89 M 10 x 1.25 49 72 84 M 12 x 1.25 87 125 150 M 12 x 1.5 83 120 145 M 14 x 1.5 135 200 235 M 16 x 1.5 205 300 360 M 18 x 1.5 310 440 520 M 18 x 2 290 420 490 M 20 x 1.5 430 620 720 M 22 x 1.5 580 820 960 M 24 x 1.5 760 1100 1250 M 24 x 2 730 1050 1200 M 27 x 1.5 1100 1600 1850 M 27 x 2 1050 1500 1800 M 30 x 1.5 1550 2200 2550 M 30 x 2 1500 2100 2500 M33 x 1.5 2050 2900 3400 M 33 x 2 2000 2800 3300 M 36 x 1.5 2700 3800 4450 M 36 x 3 2500 3500 4100 M 39 x 1.5 3450 4900 5700 M 39 x 3 3200 4600 5300

Repair Manual Off-Road Transmissions and Axle Systems Division LIST OF SPECIAL TOOLS FOR DIS- AND REASSEMBLY TRACTOR TRANSAXLE T–7336 PS 2094 009 003 Disassembly Chapter/Fig Reassembly Chapter/Fig. Designation and Use Part No. 5871 970 002 W/1 1/01 1/07 Assembly truck cpl. with tilting device # Holding fixture # Support # To mount the complete transmission, rear axle housing and the axle trumpet respectively on the assembly truck. 5870 350 000 5870 350 117 5870 350 125 1/05 7/94 10/09 Lifting chain 3-strand Dis- and reassembly aid for removal and installation of the complete rear axle and rear axle trumpets respectively. To be used in combination with eyebolts DIN 580 M16 = 0636 804 001 5870 281 047 1/12 10/7 Adjusting screws M16 Dis- and reassembly aid for separation and assembly of the complete transmission with the rear axle housing. 5870 204 023 2/06 2/10 6/02 9/38 Adjusting screws M 8 Dis- and reassembly aid for removal and installation of the complete valve housing / F/R shift control. Gasket and intermediate sheet on the pump housing. 5870 204 011 2/26 9/43 Adjusting screws M 10 Dis- and reassembly aid for removal and installation of the complete pump housing – F/R shift control. 5870 204 007 2/26 3/04 Pry bar set 1 Set = 2 Pcs. Universal use. To separate housing components, flanges and shafts. To press off the brake- from the rear axle housing 5870 345 065 2/28_3/10 3/16_3/22 3/26_3/29 3/44_5/32 6/21_7/74 7/82_7/82 8/25_8/49 Set of external pliers A1-A2-A3-A4 Universal use. To unsnap and snap in externally clamping retaining rings. 5870 900 015

Repair Manual Off-Road Transmissions and Axle Systems Division LIST OF SPECIAL TOOLS FOR DIS- AND REASSEMBLY TRACTOR TRANSAXLE T–7336 PS 2094 009 003 Disassembly Chapter/Fig Reassembly Chapter/Fig. Designation and Use Part No. 5871 970 002 W/2 2/29 Two-armed puller Opening 120 mm Universal use. To pull off the ball bearing from the bearing bracket. 5870 970 002 3/04 Adjusting screws M 16 Dis- and reassembly aid for removal and installation of the complete cover from the transmission housing. 5870 204 023 3/07 Rapid grip # To pull off the bearing inner ring 32012X = 0750 117 505 from the input gear 2094 359 046. To be used in combination with: Basic device 5873 011 014 5873 001 000 3/08_3/18 3/19_3/21 3/24_3/47 Gripping insert # To pull off the bearing inner ring 30 210X = 0750 117 656 from the input shaft splitter group . To be used in combination with: Basic device 5873 001 038 5873 001 000 3/11 3/27 3/39 7/85 8/25 8/50 8/92 Pressing bush # To preload the compression springs 0732 041 183 in the disc carrier splitter group. To preload the set of cup springs 0501 314 521 on the FA and powershift clutch . 5870 506 117 3/13 3/29 3/41 Clamping pliers To lift the piston 2094 359 004 out of the disc carrier splitter group. 5870 900 007 3/14 3/30 3/42 Internal extractor Countersupport Universal use. To remove the needle bearing 0750 115 365 from the disc carrier splitter group. 5870 300 005 5870 300 003
