Mitsubishi Transmissions Service & Repair Manual
Lifetime Access
Lifetime Access
Description
Mitsubishi Transmissions Service & Repair Manual
Models covered:
| Transmission Type | Front-Wheel Drive (F) | Rear-Wheel Drive (R) | Van/Commercial (V) | Global Market (W) | Other |
|---|---|---|---|---|---|
| 3-Speed Manual | - | - | - | - | - |
| 4-Speed Manual | F4M21 | R4M21 | - | - | - |
| 5-Speed Manual | F5M21, F5M22, F5M31, F5M33, F5MR1, F5M42, F5MR3, F5M41, F5M51 | R5M21, R5M3 | V5M21, V5MT1, V5M3 | W5M31, W5M33, W5MG1, W5M42 | - |
| 6-Speed Manual | - | - | - | W6MG1 | - |
| Other Manual | - | - | - | - | KM182 |
| 3-Speed Automatic | F3A2 | - | - | - | - |
| 4-Speed Automatic | F4A2, F4A3, F4A4, F4A5 | R4AW2, R4AW3, R4A51 | V4AW2, V4AW3, V4AW4, V4A51 | W4A3 | - |
| 5-Speed Automatic | - | - | V5A51 | - | - |
The Mitsubishi Transmissions Service & Repair Manual provides comprehensive technical documentation for the entire range of Mitsubishi gearboxes, from the early F3A2 three-speed automatic to advanced six-speed units like the W6MG1. This reference covers an extensive lineup of manual and automatic transmissions across multiple applications, including front-wheel drive, rear-wheel drive, and commercial vehicle configurations.
Each transmission type includes detailed disassembly and reassembly procedures with critical specifications for clearances, end play measurements, and proper bearing preload settings. The manual provides complete valve body overhaul instructions for automatic units, shift linkage adjustment procedures for manual transmissions, and synchronizer inspection criteria across all models. Specialized procedures for clutch pack service, planetary gear set inspection, and differential carrier maintenance ensure proper operation and extended service life.
The technical content includes model-specific troubleshooting flowcharts, pressure test specifications, and component bench testing procedures essential for proper diagnosis and repair. From basic maintenance of the F5M21 five-speed manual to complete rebuilding of the sophisticated V5A51 five-speed automatic, this manual delivers factory-correct specifications and service procedures without the dealership service department costs.
Printable: Yes
Language: English
Compatibility: Pretty much any electronic device, incl. PC & Mac computers, Android and Apple smartphones & tablet, etc.
Requirements: Adobe Reader (free)
