AUTOMATIC TRANSMISSION PARTS CATALOG ALTO PRODUCTS CORP. Alto Way • Atmore • AL • 36502 • USA • www.altousa.com Tel: 251.368.7777 • Fax: 251.368.7774 • sales@altousa.com • PARTES DE TRANSMISIONES AUTOMATICAS • AUTOMATIKGETRIEBETEILE • PIÈCES DE TRANSMISSIONS AUTOMATIQUES • PEÇAS PARA TRANSMISSÕES AUTOMÁTICAS • ЗАПЧАСТЕЙ АВТОМАТИЧЕСКИХ КОРОБОК ПЕРЕДАЧ

AUTOMOTIVE PARTS (See Bookmarks) SPECIAL FEATURES REFERENCE CODES A - 1980 F - 1985 L - 1990 S - 1995 Y - 2000 5 - 2005 B - 1981 G - 1986 M - 1991 T - 1996 1 - 2001 6 - 2006 C - 1982 H - 1987 N - 1992 V - 1997 2 - 2002 7 - 2007 C - 1983 J - 1988 P - 1993 W - 1998 3 - 2003 8 - 2008 E - 1984 K - 1989 R - 1994 X - 1999 4 - 2004 9 - 2009 Chrysler Transmission Codes Honda Transmission Codes Toyota Transmission Tag Numbers Alto Transmission Series Chart Alto Part Number Codes Glossary of Terms: English to Spanish GM Transmission Codes Miscellaneous Transmission CVT & Dual Shaft Gear Transfer Case Listings (shown in bookmarks) Differential Listings (shown in bookmarks) Antique Section Domestic Manufacturers Asian & European Manufacturers Unless otherwise specified, years expressed in this catalog refer to the model year of the vehicle. The VIN is found on a sticker located on the driver's door and on a metal plate located at the bottom of the driver's side front windshield. MODEL YEAR IDENTIFICATION Automatic Transmission Parts Catalog 2011 Use the chart below to identify the model year represented by the tenth character of the VIN (Vehicle Identification Number). Hardware Chemicals What's New in our 2010 Catalog? Vehicle Index

What's New in Our 2011 Catalog? GENERAL MOTORS YEAR GENERAL MOTORS YEAR 195000 6L80E, 6L90E 2006-ON 196000 6T70, 6T75 6 SPEED 2007-ON 201000 6L50E, CTS, SRX, STS 2007-ON 204000 6T40, 6T45 2008-ON 205000 2ML70 2007-ON ALLISON YEAR 149000 B500 500P 500R 1995 ON 149000 B500, 500P, 500R 1995-ON FORD YEAR 183000 6R60 2006-ON 183000 6R80 2007-ON 196000 6F, 6F55 6 SPEED 2007-ON 204000 6F35 2009-ON 193000 CVT CFT-30 2005-ON 206000 6R140 2011-ON CHRYSLER YEAR 77000 62TE 2008-ON 128000 68RFE 2007-ON AISIN WARNER / BORG WARNER YEAR 129000 TF60-SN, 09G 2003-ON 185000 TR60-SN 2004-ON 187000 AW80-40LS, AW81-40LE GM DAEWOO 2004-ON 197000 AWF21, TF80-SC, AF40-6, AM6, AW6A-EL 2005-ON HYUNDAI YEAR 191000 JF405E 2003-ON MAZDA YEAR 39000 RC4AEL, JR405E 2004-ON MERCEDES YEAR MERCEDES YEAR 189000 722.9 2004-ON 76000 722.8 2004-ON NISSAN YEAR 181000 RE0F06A CVT 1996-ON 181000 RE0F09A CVT 2003-ON 174000 RE7R01A, JR710E 2009-ON SATURN YEAR SATURN YEAR 172000 MDRA 2WD, MDPA 4WD VUE 2004-ON SUBARU YEAR 135000 5EAT 5 SPEED 2005-ON TOYOTA YEAR 136000 U250E 2005-ON 127000 U540E 2002-ON 173000 A750E 750F 2005 ON 173000 A750E, 750F 2005-ON 199000 U660E 2007-ON ZF 143000 ZF6HP19 2004-ON 183000 ZF6HP26 2002-ON

Abbreviations & Ordering Notes ORDERING NOTES Super Kits - Add "SK" to Master Kit item number. Super Kits include Overhaul Kit, Friction/Steel Module and Band, Filter, Modulator, Bushing Kit, Washer Kit (subject to availability). Farpak® - Add "F" to Gasket item number. Red Eagle® Grooved Friction Clutches - Add "WF" for Waffle Groove or "PL" for Parallel Line Groove to Red Eagle Friction item number. For Grooving charge and Min. qty. contact Customer Service. ABBREVIATION TERM ABBREVIATION TERM 2wd 2 Wheel Drive KOL Kolene® 4wd 4 Wheel Drive LRG Large BND Band OD Outer Diameter BLK Black OEI Original Equipment Improvement™ BRK Brake OEM Original Equipment Manufacturer CRB Carbonite® PL Parallel Line Grooved DIR Direct PLNI Parallel Line Non-Intersecting Grooved DR Drive REV Reverse FLT Filter RR Rear F/D Forward/Direct FRT Front RWD Rear Wheel Drive F/R Front/Rear SAD Single Adjustable Diaphragm FWD Front Wheel Drive SB Sunburst Grooved GSK Gasket SEL Selective GOV Governor SML Small GRN Green SMOOTH Not Grooved HEG Hi-Energy Graphitic TURB Turbulator Holes HP Hi-Performance W/ With ID Inside Diameter W/O Without INT Intermediate WF Waffle Grooved DISCLAIMER This catalog has b een pr oduced using the most up to da te inf ormation av ailable at the time of pr oduction. While the utmost care has been u sed to compile this information, we assume no responsibility for any errors, omissions, or the misapplication s supplied to us. N ot all parts listed in this catalo g are stocked and are listed for reference only. Reference numbers and/or OEM numbers are listed solely for identification purposes, some numbers change frequently. Please check with your sales representative for more up to date information. MADE IN U.S.A. All Friction and Steel plates are m anufactured by Alto Products Corp. in the USA. Overhau l kits may contain contents not of USA origin . Other th an Friction and Steel plates, t here are no representations made a s t o country of origin. For country of origin on a specific item, contact your sales representative. TRADEMARKS Red Eagle ®, Carbonite®, PowerPack®, and D rumSaver® are all registe red trademar ks of ALTO PRODUC TS CORP. KEVLAR® is a register ed trademark of E.I. Dupont Corporation. KOLENE® is a registered trademark of Kolene Corporation. SHIFT KIT®, TRANSGO® Reprogramming Kit™ are registered trademarks of Transgo. COPYRIGHT Printed in the USA – All Rights Reserv ed. No part of th is publication may be reproduced, stored in a retr ieval system, or tr ansmitted in any form or by any means; elec tronic, mechanic al, phot ocopying, recordi ng or otherwise without the express written consent of ALTO PRODUCTS CORP. ©2011 ALTO PRODUCTS CORP

ACURA MODEL YEAR ENGINE TRANS 2.2CL 1996-97 L4, 2.2L A6VA 2.3CL 1998-99 L4, 2.3L B6VA 3.2TL 2001-03 V6, 3.2L B7WA 2.5TL 1995-98 L5, 2.5L M1WA 3.5RL 1996-04 V6, 3.5L M5DA Integra 1986-87 L4, 1.6L CA Integra 1988-89 L4, 1.6L PI 3.0CL 1996-99 V6, 3.0L M7ZA Integra 1990 L4, 1.8L RO Integra 1991-93 L4, 1.8L MPRA Integra 1994-99 L4, 1.8L MP7A, SP7A, S4XA Integra 2000-On L4, 1.8L SKWA 3.2CL 2000-03 V6, 3.2L MGFA, BGFA Legend 1986-87 V6, 2.5L G4 Legend 1988-89 V6, 2.7L L5 Legend 1990 V6, 2.7L PL5X Legend 1991-95 V6, 3.2L MPYA 3.2TL 1996-98 V6, 3.2L M5HA MDX 2001-02 V6, 3.5L MGHA, BGHA MDX 2003-04 V6, 3.5L MDKA MDX 2005-06 V6, 3.5L BDKA MDX 2007-08 V6, 3.7L BYFA 3.2TL 1999 V6, 3.2L B7VA NSX 1991-05 V6, 3.0L M9RA RDX 2007-On L4, 2.3L BWEA RL 2005-09 V6, 3.5L MJBA RL 2009-On V6, 3.7L TBA RSX 2002-06 L4, 2.0L MRMA 3.2TL 2000 V6, 3.2L M7WA SLX 1996-99 V6, 3.2L 4L30E TL 2004-08 V6, 3.2L BDGA TL Type S 2007-On V6, 3.5L BDHA TSX 2004-08 L4, 2.4L MCTA TSX 2009-On L4, 2.4L MM7A Vigor 1992-95 L5, 2.5L MPWA ALFA ROMEO MODEL YEAR ENGINE TRANS 159 2005-On 1.9D, 2.4D, 3.2L AWF21, AF40, TF-80SC 164 1990-95 V6, 3.0L ZF4HP18Q 166 2004-06 AW55-50SN 2000 1971-76 ZF3HP12 2000 Milano 164 1976-78 ZF3HP22 2000 Milano 164 1984-93 ZF4HP22 Brera 2007-On AWF21, AF40, TF-80SC Spider 2007-On AWF21, AF40, TF-80SC AM GENERAL MODEL YEAR ENGINE TRANS H2 2002-07 V8, 6.0L 4L65E H2, SUV, SUT 2007-On V8, 6.2L 6L80E H3, X, ALPHA 2005-On 3.5, 3.7. 5.3L 4L60E H3T 2009-On 3.7L 4L60E H3T ALPHA 2009-On 5.3L 4L70E H4 2010-On 3.6L 4L60E Hummer (H1) 1991-93 3L80E Hummer (H1) 1993-On 4L80E AMERICAN MOTORS CORP (AMC) MODEL YEAR ENGINE TRANS Alliance 1983-87 MB1 Ambassador 1963-71 BWT35 VEHICLE INDEX
