Sudco Velocity Stacks shown above
Precision machined aluminum, velocity stacks for Keihin FCR Carburetors.
Secure external screw mounting with a beautiful blue anodized finish.
Order by each
FCR Carb Size: Length: Color: Order No:
32-33mm 15mm Blue 020-250
30mm Blue 020-254
35-41mm 15mm Blue 020-252
“ Red 020-253
30mm Blue 020-256
“ Red 020-257
“ Polished 020-258
50mm Blue 020-260
“ Red 020-262
70mm Blue 020-266
“ Red 020-268
78. Spacing Collar #2 (cont’d)
021-158 N704-02050 50mm (option)
021-159 N704-02053 53mm (option)
021-160 N704-02068 68mm (option)
021-168 N704-02089 89mm (option)
79. Spacing Collar #3
021-171 N704-03071 71mm ZX7/10/11
021-173 N704-03077 77mm CB1,FZR750/1000
021-175 N704-03081 81mm CBR600, FZR400,
021-169 N704-03056 56mm FZR600, ZX6
021-170 N704-03060 60mm
021-172 N704-03065 65mm
021-174 N704-03068 68mm
021-176 N704-03089 89mm
80. Rubber Pipe
021-179 0804-985-0000 34mm CBR600,FZR400
FZR600, CB1,
ZX7/10/11
021-181 0804-990-0000 41mm ZX6
021-183 0804-992-0000 46mm FZR750/1000
021-180 0804-988-0000 31mm (option)
81. Air Vent Joint (Breather)
021-187 1077-826-7000 all (R1)
021-188 1077-806-7001 Dual Ducati
82. U-Ring Air Vent
021-097 W9353-65000 all
84. Fuel Joint (center)
021-191 1075-834-2000 CBR600,FZR400
FZR600, CB1,
ZX6, FZR750/1000
021-193 1075-836-2000 ZX7/10/11
85. O-Ring, Fuel T-Joint
018-755 W9351-13057 all
88. Rubber Pipe (R.L.)
021-197 0804-991-0000 45mm CBR600, CB1,
FZR400/600
021-199 0804-437-0001 50mm ZX6
021-201 0804-991-0000 60mm FZR750/1000 (R.L/Ctr)
GSX-R750 93-95
021-203 0804-991-0000 70mm ZX7/10/11
021-202 0804-444-0000 40mm (option)
89. Fuel T-Joint
018-751 1077-804-7000 CBR600, CB1,
FZR400/600
ZX6/10/11
86-92 GSXR
018-753 1077-803-7000 FZR750/1000
Liq. Cool GSXR
021-251 1074-848-2100 Singles downdraft
021-190 1077-834-2100 Dual Ducati
90. Step Screw Comp.
021-099 1034-837-2100 all
021-531 1034-837-2501 13.25”
91. Washer, Stop Screw
021-101 0301-078-1200 all
92. Coil Spring, Stop Screw
021-103 1300-112-2000 all
100. Screw, Bracket
021-105 0136-804-1100 all
103. Main Air Jet 99101-393-nnn
(See chart on pg. 206)
121. Float Bowl
021-107 1050-863-2100 #3 “D” w/ center pull
#2 “D” w/ right pull
021-261 1050-882-2100 #3 “H” w/ center pull
021-261 1050-882-2100 #2 “H” w/ right pull
122. O-Ring, Drain Bolt
021-109 W9351-19145 all
123. Drain Bolt
021-111 1018-804-2000 all
124. Rubber Pipe
021-201 0804-437-0001 60mm ZX6/7/10/11
021-209 0804-986-0000 70mm CBR600, CB1
FZR750/1000
021-210 0804-987-0000 80mm (option)
125. Adapters - see chart on pg. 180
126. Velocity Stacks shown below
*Sold Individually
021-113 1130-806-7002 28-33mm Blue (50mm)
021-114 1130-807-7000 35-41mm Blue (50mm)
021-115 1130-808-7000 35-41mm Red
(35mm Long)
127. Rubber Cap, T-Joint
018-759 1028-808-7000 all
128. Clip, Rubber Cap
018-761 W9535-55000 all
129. Air Cleaner Adapter - See chart on pg. 178-179
130. O-Ring, Air Cleaner Adapter
021-439 FCR 35-41 all
170
