1800 YRM 1247 General
General
DRY BRAKE SYSTEM
NOTE: The dry brake system is used only on lift truck
models
• GLC40, 45, 55VX; GLC55SVX; (GC/GLC080, 100,
120VX; GC/GLC080, 100VXBCS; GC/GLC120SVX;
GC/GLC120VXPRS) (E818)
• GLP/GDP40VX5/VX6; GLP/GDP45SVX5, GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (F813, G813, H813)
This section has service procedures for the dry brake
system. The dry brake system includes the following
parts: master cylinder and parking brake system (see
Figure 1) and brake shoes and wheel cylinders (see
Figure 6).
WET BRAKE SYSTEM
NOTE: The wet brake system is used on all lift truck
models covered in this YRM.
The wet brake system in this section includes the follow-
ing parts: master cylinder and parking brake system.
See Figure 2 for lift truck models
• GLC40, 45, 55VX; GLC55SVX; (GC/GLC080, 100,
120VX; GC/GLC080, 100VXBCS; GC/GLC120SVX;
GC/GLC120VXPRS) (E818)
See Figure 3 for lift truck models
• GLC/GDC60VX, GLC/GDC70VX, (GC/GLC/
GDC135VX, GC/GLC/GDC155VX) (C879, D879,
E879, F879)
• GLP/GDP60VX, GLP/GDP70VX (GP/GLP/
GDP135VX, GP/GLP/GDP155VX) (C878, D878,
E878)
See Figure 4 for lift truck models
• GLP/GDP80VX, GLP/GDP80VX9, GLP/GDP90VX
(GLP/GDP170VX, GLP/GDP175VX36, GLP/
GDP190VX) (A909, B909)
See Figure 5 for lift truck models
• GLP/GDP40VX5/VX6; GLP/GDP45SVX5, GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX ) (F813, G813, H813)
The wet disc brakes are a component of the wet brake
drive axle. The brake discs are located inside the plan-
etary carrier housing at each end of the drive axle. For
the removal, assembly and installation procedures see:
1. PARK BRAKE HANDLE ASSEMBLY
2. ADJUSTMENT KNOB
3. PARK BRAKE CABLES
4. INCHING/BRAKE PEDAL
5. MASTER CYLINDER AND BOOSTER
6. BRAKE ASSEMBLY
7. BRAKE POSITION SENSOR (RIGHT-HAND
SIDE)
Figure 1. Dry Brake System
Drive Axle and Differential Assembly Repair, (Wet
Brake) 1400 YRM 1246 for lift truck models
• GLC40, 45, 55VX; GLC55SVX; (GC/GLC080, 100,
120VX; GC/GLC080, 100VXBCS; GC/GLC120SVX;
GC/GLC120VXPRS) (E818)
• GLP/GDP40VX5/VX6; GLP/GDP45SVX5, GLP/
GDP45VX6, GLP/GDP50-55VX (GP/GLP/GDP080,
090, 100, 110, 120VX) (F813, G813, H813)
1
