OUTBOARD MOTOR NSF6A3Z/8A3/9.8A3 OWNER’S OPERATING MANUAL No.003N11082-9

ENOM00001-0 READ THIS MANUAL BEFORE USING THE OUTBOARD MOTOR. FAILURE TO FOLLOW THE INSTRUCTIONS AND SAFETY PRECAUTIONS IN THIS MANUAL CAN RESULT IN SERIOUS INJURY OR DEATH. KEEP THIS MANUAL IN A SAFE LOCATION FOR FUTURE REFERENCE. Copyright © 2009-2012 Nissan Marine Co., Ltd. All rights reserved. No part of this manual may be repro- duced or transmitted in any from or by any means without the express written permission of Nissan Marine Co., Ltd.

3 YOUR NISSAN MARINE OUTBOARD MOTOR ENOM00002-0 OWNER REGISTRATION AND IDENTIFICATION Upon purchasing this product, be sure that the WARRANTY CARD is correctly and com- pletely filled out and mailed to the addressee noted there on. This WARRANTY CARD identifies you as the legal owner of the product and serves as your warranty registration. TO THE EXTENT PERMITTED BY APPLICABLE LAW, YOUR OUTBOARD MOTOR WILL NOT BE COVERED BY THE APPLICABLE LIMITED WARRANTY, IF THIS PROCEDURE IS NOT FOLLOWED. ENOM00003-0 PRE-DELIVERY CHECK Be sure that the product has been checked by an authorized NISSAN MARINE dealer before you take delivery. ENOM00004-0 Limited Warranty Please refer to the NISSAN MARINE outboard motor Limited warranty provided to you with this product, the terms and conditions of which, as amended from time to time, are incorporated by reference into the manual.

4 ENOM00005-0 Serial Number In the space below, please record the outboard motor’s serial number (indicated both on the lower motor cover and on the cylinder block). The serial number will be needed in the event of theft or to quickly identifying the outboard motor type. Serial Number: ENOM00006-0 To You, Our Customer Thank you for selecting a NISSAN MARINE outboard motor. You are now the proud owner of an excellent outboard motor that will service you for many years to come. This manual should be read in its entirety and the inspection and maintenance procedures described later in this manual should be followed carefully. Should a problem arise with the outboard motor, please follow the troubleshooting procedures listed at the end of this manual. If the problem persists, contact an authorized NISSAN MARINE service shop or dealer. We hope you will enjoy your outboard motor and wish you good luck in your boating adventures. NISSAN MARINE

GENERAL SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 1. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2. NAMES OF PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 3. LOCATIONS OF WARNING LABELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 4. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 1. Mounting the outboard motor on boat . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 2. Installing the remote control devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 3. Installing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 5. PRE-OPERATING PREPARATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 1. Recommended gasoline types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 2. Low permeation fuel hose requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 EQUIPPED FOR UNITED STATES AND CANADA MODEL 3. EPA pressurized portable fuel tank requirements . . . . . . . . . . . . . . . . . . . 29 EQUIPPED FOR UNITED STATES AND CANADA MODEL 4. EPA approval primer valve/hose assembly . . . . . . . . . . . . . . . . . . . . . . . . 29 EQUIPPED FOR UNITED STATES AND CANADA MODEL 5. Recommended engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 6. Altitude adjustment kit requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 7. Break-In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 8. Engine oil warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 9. ESG (A device preventing over revolution). . . . . . . . . . . . . . . . . . . . . . . . . 32 6. ENGINE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Before starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 1. Filling the fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 2. Feeding the fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 3. Starting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 4. Warming up the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 5. Forward and reverse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 6. Stopping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 7. Trim angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 8. Tilt up, tilt down and shallow water operation . . . . . . . . . . . . . . . . . . . . . . 49 9. Shallow water operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 7. REMOVING AND CARRYING THE OUTBOARD MOTOR. . . . . . . . . . . . . . 54 1. Removing the outboard motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 2. Carrying the outboard motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 3. Storing the outboard motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 8. TRAILERING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 9. ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 1. Steering friction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 2. Throttle grip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 3. Remote Control Lever Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 4. Trim Tab Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 10. INSPECTION AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 CONTENTS

1. Daily Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 2. Periodic Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 3. Off-season storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 4. Pre-season check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 5. Motor submerged in water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70 6. Cold weather precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 7. Checking after striking underwater object . . . . . . . . . . . . . . . . . . . . . . . . . 71 11. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 12. TOOL KIT AND SPARE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 13. OPTIONAL ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 14. PROPELLER TABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

7 GENERAL SAFETY INFORMATION 1. SPECIFICATIONS 2. NAMES OF PARTS 3. LOCATIONS OF WARNING LABELS 4. INSTALLATION 5. PRE-OPERATING PREPARATIONS 6. ENGINE OPERATION 7. REMOVING AND CARRYING THE OUTBOARD MOTOR 8. TRAILERING 9. ADJUSTMENT 10. INSPECTION AND MAINTENANCE 11. TROUBLESHOOTING 12. TOOL KIT AND SPARE PARTS 13. OPTIONAL ACCESSORIES 14. PROPELLER TABLE INDEX

8 GENERAL SAFETY INFORMATION ENOM00007-0 NOTICE: DANGER/WARNING/CAUTION/Note Before installing, operating or otherwise handling your outboard motor, be sure to thoroughly read and understand this Owner’s Manual and carefully follow all of the instructions. Of particular importance is information preceded by the words “DANGER,” “WARNING,” “CAUTION,” and “Note.” Always pay special attention to such information to ensure safe operation of the outboard motor at all times. ENOW00001-0 Failure to observe will result in severe personal injury or death, and possibly property damage. ENOW00002-0 Failure to observe could result in severe personal injury or death, or property damage. ENOW00003-0 Failure to observe could result in personal injury or property damage. ENON00001-0 Note This instruction provides special information to facilitate the use or maintenance of the outboard motor or to clarify important points. ENOM0008-0 EMERGENCY STOP SWITCH The Emergency Stop Switch will stall the outboard motor when the stop switch tether is pulled off. This stop switch tether can be attached to the operator of the outboard motor to minimize or prevent injuries from the propeller in case the operator falls overboard. We highly recommend use of the Emergency Stop Switch tether. ENOW00004-0 Accidental activation of the Emergency Stop Switch (such as the tether being pulled out in heavy seas) could cause passengers to lose their balance and even fall overboard, or it could result in loss of power in heavy seas, strong currents, or high winds. Loss of control while mooring is another potential hazard. To minimize accidental activation of the Emergency Stop Switch, the 500 mm (20 inch.) stop switch tether is coiled and can extended to a full 1300 mm (51 inch.). DANGER WARNING CAUTION WARNING

GENERAL SAFETY INFORMATION 9 ENOM00009-0 SAFE OPERATION OF BOAT As the operator/driver of the boat, you are responsible for the safety of those aboard and those in other boat around yours, and for following local boating regulations. You should be thoroughly knowledgeable on how to correctly operate the boat, outboard motor, and accessories. To learn about the correct operation and maintenance of the outboard motor, please read through this manual carefully. It is very difficult for a person standing or floating in the water to take evasive action should he or she see a power boat heading in his/her direction, even at a slow speed. Therefore, when your boat is in the immediate vicinity of people in the water, the outboard motor should be shifted to neutral and shut off. ENOW00005-0 SERIOUS INJURY IS LIKELY IF A PERSON IN THE WATER MAKES CONTACT WITH A MOV- ING BOAT, GEAR HOUSING, PROPELLER, OR ANY SOLID DEVICE RIGIDLY ATTACHED TO A BOAT OR GEAR HOUSING. ENOM00010-0 SERVICING, REPLACEMENT PARTS & LUBRICANTS We recommend that only an authorized service shop perform service or maintenance on this outboard motor. Be sure to use genuine parts, genuine lubricants, or recommended lubricants. ENOM00011-0 MAINTENANCE As the owner of this outboard motor, you should be acquainted with correct maintenance procedures. It is the operator’s responsibility to perform all safety checks and to ensure that all lubrication and maintenance instructions are complied with for safe operation. Please comply with all instructions concerning lubrication and maintenance. You should take the engine to an authorized dealer or service shop for periodic inspection at the pre- scribed intervals. Correct periodic maintenance and proper care of this outboard motor will reduce the chance of problems and limit overall operating expenses. ENOM00012-0 MOUNTING Outboard motor mounting must be performed by trained service person(s) using lift or hoist with sufficient capacity. WARNING

10 SPECIFICATIONS ENOM00501-0 *: with manual Remark: Specifications subject to change without notice. 6A3Z (Available in specific region) Item MODEL MF EF EP Overall Length mm (in) 975 (38.4) 590 (23.2) Overall Width mm (in) 354 (13.9) 320 (12.6) Overall Height S·L·UL mm (in) 1035 (40.7) 1162 (45.7) 1289 (50.7) Transom Height S·L·UL mm (in) 435 (17.1) 562 (22.1) 689 (27.1) Weight S kg (lb) 37.0 (81.5) — L kg (lb) 38.0 (84.0) 41.0 (90.5) UL kg (lb) 39.5 (87.0) — Output kW (ps) 4.4 (6) Max. Operating Range rpm 5000–6000 Idle Speed in Forward Gear rpm 900 Idle Speed in Neutral Gear rpm 950 Engine Type 4-Stroke Number of Cylinder 2 Bore × Stroke mm (in) 55 × 44 (2.17 × 1.73) Piston Displacement mL (Cu in) 209 (12.8) Exhaust System Through hub exhaust Cooling System Water cooling Engine Lubrication Trochoid pump Startring System Manual Electric starter motor* Ignition System Flywheel Magneto C.D. ignition Spark Plug NGK DCPR6E Trim Position 6 3 Engine Oil mL (fl.oz.) NMMA FC-W certified 10W-30 or API SF, SG, SH, SJ, SL or SM, 10W-30/40, Approx. 800 (27) Gear Oil mL (fl.oz.) Genuine Gear Oil or API GL5, SAE #80-90, Approx. 320 (10.8) Fuel Unleaded regular gasoline : Pump posted 87 Octane (research octane rating of 91) Fuel Tank Capacity L (US gal) 12 (3.17) Gear Reduction Ratio 2.08 (13 : 27) Emission Control System EM (Engine modification) Operator Sound Pressure (ICOMIA 39/94) dB (A) 77.2 Hand Vibration Level (ICOMIA 38/94) m/sec2 2.2 —
