2005 Sea-Doo 3D RFI Operator's Guide

2 19 0 0 0 3 6 4 Includes Safety, Vehicle and Maintenance Information Operator’s Guide 20053D TM RFI TM

This Operator’s Guide utilizes the following symbols to emphasize particular information:  The Safety Alert Symbol indicates a potential personal injury hazard.  WARNING Indicates a potentially hazardous situation which, if not avoided, could result in serious injury or death. CAUTION: Denotes an instruction which, if not followed, could severely damage vehicle components. Indicates supplementary information needed to fully complete an instruction.  WARNING For your safety, understand and follow all the safety precautions and instructions contained in this Operator’s Guide, the Safety Videocassette and the on-product labels. Failure to do so can result in SEVERE INJURY OR DEATH. Keep this Operator’s Guide in a waterproof bag with the vehicle at all times. This Operator’s Guide and the Safety Videocassette should remain with the vehicle at the time of sale. Knight’s Spray-Nine † is a trademark of Korkay System Ltd GTX † is a trademark of Castrol Ltd. Used under license The following is a non-exhaustive list of trademarks that are the property of Bombardier Recreational Products Inc. or its affiliates: XP-S TM Mineral Injection Oil GTI TM Sea-Doo LK TM XP-S TM Synthetic 2–stroke Oil O.P.A.S. TM XP ® Sea-Doo Synthetic Grease Rotax TM 4–TEC TM DESS TM RFI TM 3D TM Sea-Doo ® O.T.A.S. TM Printed in Canada. (smo2005-001 en SH) ®™Trademarks of Bombardier Recreational Products Inc. or its affiliates. ©2005 Bombardier Recreational Products Inc. and BRP US Inc. All rights reserved. * Trademark of Bombardier Inc. used under license.

FOREWORD The Operator's Guide has been pre- pared to acquaint the owner/operator with this personal watercraft and its various controls, maintenance and safe riding instructions. It is indis- pensable for the proper use of the product and should be kept in a waterproof bag with the watercraft at all times. Make sure you read and understand the content of the Operator's Guide. For any questions pertaining to the warranty and its application, consult the WARRANTY section in this guide, and/or an authorized Sea-Doo dealer. In USA, products are distributed by BRP US Inc. In Canada, products are distributed by Bombardier Recreation- al Products Inc. (collectively “BRP”). The information and components/system descriptions contained in this guide are correct at the time of writ- ing. BRP however, maintains a policy of continuous improvement of its products without imposing upon itself any obligation to install them on products previously manufactured. Because of its ongoing commitment to product quality and innovation, BRP reserves the right at any time to dis- continue or change specifications, de- signs, features, models or equipment without incurring obligation. The illustrations in this document show the typical construction of the different assemblies and may not represent the full detail or exact shape of the parts. However, they represent parts that have the same or similar function. It is understood that this guide may be translated into another language. In the event of any discrepancy, the English version shall prevail. Specifications are given in the SI metric system with the SAE U.S. equiva- lent in parenthesis. Where precise ac- curacy is not required, some conver- sions are rounded off for easier use. A Shop Manual can be obtained for complete service, maintenance and more repair information. The use of LEFT (port) and RIGHT (starboard) indications in the text, al- ways refers to driving position (when sitting on watercraft). Furthermore, in the marine industry, FRONT is referred to BOW and REAR as STERN.    1. Left (port) 2. Right (starboard) ______________________ 1

TABLE OF CONTENTS SAFETY INFORMATION INTRODUCTION ...................................................................... 8 SAFETY CHECK LIST................................................................. 9 General ............................................................................. 9 GETTING UNDERWAY .............................................................. 10 To Wear ........................................................................... 10 Helmets ........................................................................... 12 To Bring ........................................................................... 12 To Do .............................................................................. 13 OPERATION .......................................................................... 14 Collision Avoidance .............................................................. 14 Safe Riding ....................................................................... 14 Maneuverability of the Watercraft ............................................. 15 OPERATING RULES ................................................................. 16 Remember these Rules of the Road .......................................... 16 WEB SITES ........................................................................... 17 LOCATION OF THE IMPORTANT LABELS ....................................... 19 VEHICLE INFORMATION REGISTRATION NUMBER LOCATION ........................................... 26 IDENTIFICATION NUMBERS....................................................... 27 Hull ................................................................................ 27 Engine ............................................................................. 27 CONTROLS/INSTRUMENTS/EQUIPMENTS.................................... 28 CONTROLS/INSTRUMENTS/EQUIPMENTS FUNCTIONS ................... 30 1) Safety Lanyard (engine cut-off cord) ........................................ 30 2) Handlebar ...................................................................... 31 3) Handlebar Adjuster ........................................................... 31 4) Throttle Lever ................................................................. 32 5) Engine Start/Stop Button ..................................................... 32 6) Indicator Light Cluster ........................................................ 33 7) Steering Pole .................................................................. 33 8) Fuel Tank Cap ................................................................. 34 9) Engine Cover Latch ........................................................... 34 10) Oil Injection Reservoir Cap ................................................. 36 11) Air Intake Opening .......................................................... 37 12) Bow and Stern Eyelets ..................................................... 37 13) Boarding Pads ............................................................... 37 14) Rear Platform ................................................................ 37 15) Cooling System Bleed Outlet .............................................. 38 2 _______________________

16) Flushing Connector .......................................................... 38 17) Bilge Drain Plugs ............................................................ 38 18) Jet Pump Nozzle............................................................. 38 19) VTS Adjuster (if so equipped) .............................................. 39 20) Jet Pump Water Intake ..................................................... 39 21) Fuses ......................................................................... 39 22) Battery ........................................................................ 39 23) Rear Access Cover .......................................................... 40 24) Automatic Bilge Pump ...................................................... 40 25) “Moto” Seat Release Button (if so equipped)............................ 40 26) “Moto” Seat Post Receiver ................................................ 44 27) “Moto” Seat Post Release Lever (if so equipped) ....................... 44 28) Kart Seat Lever (if so equipped)............................................ 44 29) Steering Pole Retainer (if so equipped) ................................... 45 LIQUIDS ............................................................................... 47 Fueling Procedure ............................................................... 47 Recommended Fuel ............................................................. 47 Recommended Oil ............................................................... 47 Oil Injection System ............................................................. 48 BREAK-IN PERIOD ................................................................... 49 10-Hour Inspection .............................................................. 49 PRE-OPERATION CHECKS ......................................................... 50 Hull ................................................................................ 51 Jet Pump Water Intake .......................................................... 51 Bilge ............................................................................... 51 Water Flow in Cooling System (only when temperature is below or close to freezing point) .................................................................... 51 Battery ............................................................................ 52 Fuel Tank and Oil Reservoir ..................................................... 52 Engine Compartment ............................................................ 52 Steering System ................................................................. 52 Steering Pole ..................................................................... 52 Throttle System .................................................................. 52 VTS (Variable Trim System) (if so equipped)................................... 52 Safety Lanyard and Engine Start/Stop Button ................................ 52 Optional Configurations ......................................................... 53 OPERATING INSTRUCTIONS ...................................................... 54 Principle of Operation ........................................................... 54 Boarding the Watercraft ......................................................... 57 Starting............................................................................ 59 Riding ............................................................................. 60 Rough Water or Poor Visibility Operation ..................................... 62 Crossing Waves .................................................................. 62 Stopping/Docking ................................................................ 62 Beaching .......................................................................... 63 Shutting Off the Engine ......................................................... 63 ______________________ 3

POST-OPERATION CARE ........................................................... 64 General Care ..................................................................... 64 Additional Care for Foul Water or Salt Water ................................. 64 Cooling System Flushing and Engine Internal Lubrication ................... 64 Anticorrosion Treatment......................................................... 66 SPECIAL PROCEDURES ............................................................ 67 Monitoring System .............................................................. 67 Engine Overheating.............................................................. 67 Jet Pump Water Intake and Impeller Cleaning................................ 67 Capsized Watercraft ............................................................. 68 Submerged Watercraft .......................................................... 68 Water-Flooded Engine ........................................................... 68 Fuel-Flooded Engine ............................................................. 69 Towing the Watercraft on the Water........................................... 69 Low-Charge Battery Condition ................................................. 70 MAINTENANCE INFORMATION Engine Emissions Information .................................................. 72 General ............................................................................ 73 MAINTENANCE CHART ............................................................ 74 Periodic Inspection .............................................................. 74 MAINTENANCE ...................................................................... 77 Lubrication ........................................................................ 77 Throttle Cable Inspection ....................................................... 78 Fuel Injection System ........................................................... 78 Fuel and Oil Filters ............................................................... 78 Steering Alignment .............................................................. 78 Steering Pole ..................................................................... 78 Handlebar and Adjuster Operation ............................................. 79 “Moto” Seat (if so equipped) ................................................... 79 Kart Seat (if so equipped) ....................................................... 79 O.T.A.S. TM System............................................................... 80 VTS Adjustment (if so equipped) ............................................... 80 Vacuum Bailer Pick-Ups ......................................................... 80 Fuses .............................................................................. 81 General Inspection and Cleaning ............................................... 82 TRAILERING, STORAGE AND PRESEASON PREPARATION ................. 84 Trailering .......................................................................... 84 Storage............................................................................ 85 Preseason Preparation .......................................................... 90 Preseason Preparation Chart ................................................... 91 4 _______________________

TROUBLESHOOTING ............................................................... 93 SPECIFICATIONS .................................................................... 98 INTERNATIONAL SYSTEM METRIC INFORMATION ........................ 101 ABBREVIATIONS USED IN THIS MANUAL ................................... 102 WARRANTY BRP NORTH AMERICA LIMITED WARRANTY: 2005 SEA-DOO ® 3D TM RFI TM PERSONAL WATERCRAFT ...................................................... 105 CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT FOR MODEL-YEAR 2005 SEA-DOO ® 3D TM RFI TM PERSONAL WATERCRAFT WITH RFI TM ENGINES. ................................................................... 109 BRP INTERNATIONAL LIMITED WARRANTY: 2005 SEA-DOO ® 3D TM RFI TM PERSONAL WATERCRAFT ....................................................... 113 PRIVACY INFORMATION ......................................................... 116 CHANGE OF ADDRESS/OWNERSHIP ......................................... 117 ______________________ 5

6 _______________________

SAFETY INFORMATION ____________ SAFETY INFORMATION ____________ 7

INTRODUCTION Congratulations, you are now the proud owner of a Sea-Doo personal watercraft. You have selected one of the most popular watercraft on water. Your Sea-Doo ® personal watercraft (PWC) can provide you and your family or friends the opportunity to fully enjoy the natural beauty and excitement of the world’s waterways. Welcome to fun on water! With this new enjoyment and free- dom however comes the responsibility of safety for yourself, the people you lend your watercraft to, and other water users. Please follow all safety instructions and operate your watercraft with care. Be sure every operator of your watercraft fully under- stands the controls and operation of it and the importance of courteous, re- sponsible riding. Each operator has a responsibility to ensure the safety of other water users. Some of the information contained in this safety section may be new to you while other information may be com- mon sense or obvious. Irrespective, we want you to have a safe, pleasur- able riding experience, so please take a few minutes of your time to com- pletely read this short safety section. Although the mere reading of such information does not eliminate the hazard, the understanding and application of the information will promote the correct use of the watercraft. Failure to follow the instructions of this safety section may result in severe injury or death. This safety section is for initial refer- ence and its content is therefore limited. section It should be read in con- junction with the rest of this Opera- tor’s Guide, the safety videocassette and the on-product warning/caution labels. It is also strongly recommended that operators obtain further information concerning “Boating Rules” from a local Coast Guard Auxiliary, Power- boat Squadron or other local boating authorities. Many states or provinces have re- quirements regarding boating safety and competence certificates. BRP strongly recommends that any watercraft operator completes a safety and competence boating course. Check with your local Coast Guard or Power Sail Squadron in your area for course availability. Some boating safety information can be obtained from the Boating Safe- ty/Regulation Web sites listed at the end of this safety section. Regulations concerning boating are modified from time to time. It is ad- visable to periodically check the local regulations wherever you plan to operate your watercraft. We encourage you to have an Annu- al Safety Inspection of your personal watercraft. Please contact your dealer for further details. Finally, we urge you to visit your dealer regularly for regular and safety maintenance and for any accessories you may require. Have fun and...Bon Voyage. 8 ____________ SAFETY INFORMATION ___________
