2016 Nautique Ski 200 open bow/200 closed bow - Sport 200 Owners Manual

SKI NAUTIQUE 200 - CLOSED BOW SPORT NAUTIQUE 200 - OPEN BOW SKI NAUTIQUE 200 - OPEN BOW

i Dear Nautique Owner, Welcome to the Nautique Family! For over 90 years, Nautique has been dedicated to providing our customers and their families with the finest inboard boats available. It’s our passion to create the best performing boats in the industry. Boats that allow you to escape the routine of everyday life. Our customers don’t just own a Nautique, they live the Nautique life. Your boat has been built with the best material and workmanship available, a legacy handed down from our founder. Our wealth of experience gives us the edge in innovation, quality and performance. We have the most dedicated and loyal employees in the industry. Hands down. Every day, our employees do more than just punch a clock; they take personal pride in every boat that comes down the line. Review this Owner’s Manual for your boat. We have assembled this manual to inform you about your Nautique and educate you further on boating. Please pay particular attention to the safety statements labeled as DANGER, WARNING, CAUTION and NOTICE. These statements alert you to possible safety hazards to avoid so you can have a safer boating experience. There are also many tips and tricks on care and maintenance sprinkled throughout the manual. Boating is very important to us and we would like you to enjoy many years of boating in your Nautique. By purchasing a Nautique, you have taken the first step in trading your old lifestyle for a new one. Now that you own a Nautique, life as you know it will never be the same. Enjoy the Nautique Life. The Nautique Team Trust in the Lord with all thine heart; and lean not unto thine own understanding. In all thy ways acknowledge him, and he shall direct thy paths. Proverbs 3:5-6 P/N 160055

ii Record Important Information In addition to this manual, your Nautique boat is supplied with component manufacturer information such as instructions, warranties or other important information. Read these materials carefully since improper operation and maintenance can void the warranty and jeopardize personal safety. Safeguard information about your Nautique boat, by recording the Hull Identification Number (HIN) and the model of your boat, and the model and serial numbers of your engine/transmission and trailer, if applicable. Your HIN is located on the top right side of the transom, above the water line. The U.S. Coast Guard requires that your HIN be permanently affixed and remain on the top right side of the transom. The first two digits refer to the country of manufacture (U.S.). The next three digits represent the manufacturer, Nautique Boat Company, Inc. (CTC). The next five digits are the boat’s serial number. The next digit is a letter from “A” where “A” = January through “L” where “L” = December, designating the month the boat was made. The last three digits represent the last digit of the year the boat was built and the final two digits of the boat model year. A boat built in July 2006 is actually a 2007 model boat. Example: A boat with “607” as the last digits indicates the boat was built in 2006, but it is a 2007 model boat. Hull HIN ___________________________________________________________ Date Purchased _________________________________________________ Dealer/Phone __________________________________________________ Ignition Key Number ____________________________________________ Registration Number/State _______________________________________ Engine Model Number _________________________________________________ Serial Number __________________________________________________ Trailer Model Number _________________________________________________ Serial Number __________________________________________________ Accessory Model Number _________________________________________________ Serial Number __________________________________________________ The identification numbers are important! Keep a copy of these numbers stored in a safe place off the boat. In case of theft, damage, etc., report these numbers to the local authorities, your insurance agent and your Nautique dealer.

iii Boater’s Checklist For improved safety and enjoyment, check each of these items: Check Before You Launch Your Boat: • Read both the engine and the boat operator manuals. • Drain plug (Securely in place?) • Propeller Condition (Prop nut tight and secured, no cracked or bent blades, prop turns freely?) • Steering System (Working smoothly and properly, self locking nuts in place?) • Battery (Fully charged, cable terminals clean and tight?) • Capacity Plate (Are you overloaded?) • Weather conditions (Safe to go out?) • Fuel and Oil (Sufficient for trip, check bilge area for gas odor, no leaks?) • Hoses and Connectors (No leaks or damage?) • Electrical Equipment (Lights, horn, pumps, etc.?) • Safety Equipment (Fire extinguisher, bailer, paddle, anchor and line, mooring lines, signaling device, tool kit, first aid kit, first aid manual?) • Personal Flotation Devices for all occupants • Float Plan submitted to Responsible Person (Verbal or written?) Check Before You Start Your Engine: • Fuel (Sufficient for trip, check bilge area for gas odor?) • Control Lever in Neutral • Capacity Plate (Are you overloaded?) • Personal Flotation Devices for all occupants • Seating (Everyone in proper place?) • Engine Stop Switch and Lanyard (Operational and securely fastened?) • No one in water near boat • Keep firm and continuous grip on steering wheel • Engine Cooling Water Valve open

iv Restricted Areas Before boating, check with Local, State and Federal authorities to identify restricted areas. Because of the threat of terrorism, the U.S. Coast Guard has and will continue to implement strict limits on watercraft near U.S. Navy and Coast Guard ships and other potential targets. Proposition 65 Emission Control Warranty Information The engine in your Nautique boat meets the strict requirements set forth by the California Air Resources Board (CARB). The engine has a special environmental tag and the boat has this label affixed to it. The tag and the label are required by the California Air Resources Board (CARB). The label has 1, 2, 3 or 4 stars. The label MUST be affixed to the boat, if the boat is operated in the state of California and/or bordering waters. CORC013 KC-0206-B A wide variety of components used on this vessel contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm. EXAMPLES INCLUDE: TO AVOID HARM: Engine and generator exhaust. Engine and generator fuel, and other liquids such as coolants and oil, especially used motor oil. Cooking fuels. Cleaners, paints and substances used for vessel repair. Waste materials that result from wear of vessel components. Lead from battery terminals and from other sources such as ballast or fishing sinkers. Keep away from engine, generator and cooking fuel exhaust fumes. Wash area thoroughly with soap and water after handling the substances above. California Health & Safety Code 25249.5-.13

v Boating Terminology * An easy way to remember PORT side from STARBOARD side is “PORT” and “LEFT” both have four letters. Product Improvement Because of our policy of continuous product improvement, the illustrations used in this manual may not look the same as on your boat and are intended only as representative reference views. Some illustrations may also show optional accessories which may or may not be available for your boat. Many optional accessories can only be installed at the time the boat is manufactured and cannot be installed by your dealer. Your dealer will be happy to provide details on installing accessories. CORC001 BOW DRAFT FREEBOARD GUNWALE STERN WATERLINE AFT FORWARD HELM BEAM TRANSOM LENGTH OVERALL (LOA) STARBOARD SIDE PORT SIDE

vi Welcome.....................................i Record Important Information...............................ii Boater’s Checklist ....................iii Restricted Areas .......................iv Proposition 65 ..........................iv Emission Control Warranty Information ..............................iv Boating Terminology................v Product Improvement ..............v Boating Safety ......................1-1 Introduction...........................1-1 About this Owner’s Manual ................................1-2 Signal Words and Symbols Used In This Manual .........1-3 Basic Safety Rules ..................1-4 Pre-operation Check List – Before Leaving the Dock ..............................1-5 Precautions While Underway ............................1-7 Safety While Maintaining the Vessel ..........................1-10 Owner Responsibility and Boating Education...............1-12 Important Safety Information ......................1-12 Responsibilities of Boat Owner and Operators ......1-12 Registration.......................1-13 Insurance ..........................1-13 Boating Safety Education Opportunities ...................1-14 Operation by Minors and Licensing ...................1-15 Safety and Required Equipment ...........................1-15 Navigation Lights .............1-16 Emergency Safety Lanyard .............................1-16 Personal Flotation Devices...............................1-18 Fire Extinguisher ..............1-20 Horn or Whistle ...............1-20 Bilge Pump(s)...................1-21 Visual Distress Signals ......1-21 Recommended Safety Equipment ........................1-22 General Boating Safety Topics ...................................1-23 Safe Speed.........................1-23 Passenger Safety ...............1-23 Carbon Monoxide Safety .................................1-24 Proper Loading ................1-27 Weighting Your Boat During Watersport Activities ............................1-28 Visibility from the Helm ...1-30 Boating Under the Influence ...........................1-31 Product Misuse .................1-32 Reporting Accidents ........1-32 Rendering Assistance .......1-32 Hazardous Conditions .....1-33 Environmental Concerns ...........................1-34 On Product Warning Labels ....................................1-37 Warning Labels & Locations ...........................1-37 Basic Rules of the Road ......1-50 Table of Contents

vii Boating Regulations .........1-50 Encountering Another Vessel .................................1-51 Aids to Navigation ............1-55 Night Running .................1-61 Watersports Safety ...............1-64 Hand Signals.....................1-66 Towed Person Safety Responsibilities .................1-66 Additional Precautions for Towed Skier/Rider ....1-68 Tow Line Guidelines........1-70 Fallen Skier or Rider........1-71 Develop WATER SENSE ..1-72 Emergency Procedures .......1-77 Explosion and Fire ...........1-77 Swamping and Flooding..1-78 Capsizing ...........................1-79 Staying Afloat ....................1-79 Collisions ...........................1-79 Grounding ........................1-80 Person Overboard ............1-80 Drowning ..........................1-81 Medical Emergency..........1-81 Operation Failure.............1-81 Towing...............................1-81 200-OB, 200-CB, 200-V.........2-1 Specifications .........................2-1 200-OB, 200-CB ..................2-1 200-V ....................................2-1 200 Nautique Dash Pod and Console ...................................2-3 200-OB, 200-CB Team Dash Pod and Console ...................2-5 Keys .........................................2-5 200-V Team Dash Pod and Console ...................................2-7 Keypad ....................................2-9 200 Open Bow Deck Layout ...................................2-10 200 Closed Bow Deck Layout ...................................2-12 200 V-Drive Deck Layout ....2-14 200-OB Seating Area ...........2-16 200-CB Seating Area............2-17 200-V Seating Area ..............2-18 Standard and Optional Equipment ...........................2-19 Controls and Indicators .......3-1 Steering ..................................3-1 Hydro-Gate™ Control and SportShift™............................3-2 Shifter/Throttle.....................3-4 Emergency Stop Switch .....3-5 Nautique Dash Pod ...............3-6 Gauges .................................3-6 Speedometer Calibration ..3-8 Control Switches.................3-8 12-Volt Port .......................3-11 Nautique Digital Cruise ................................3-12 Team Dash Pod ...................3-15 Keypad...............................3-15 Switches .............................3-20 Nautique LINC 2.0 ..............3-22 Product Information........3-22 Basic Navigation Features .............................3-23 Quick Access Key Features .............................3-24 Nautique LINC 2.0 – River Mode .................................3-44 Nautique LINC 2.0 – River Mode in Integrated Zero Off 3 Event...............3-52 MENU Options ................3-55

viii LINC 2.0 General Troubleshooting Guide ...3-63 Standard Equipment ...........3-64 Watersports Tow Point ....3-64 Tow Rope Attachment – Center................................3-65 Tow Rope Attachment – Tower Pylon ......................3-66 Bow Features - Open Bow Only ...........................3-67 Driver’s Seat Adjustment........................3-68 Rearview Mirror Adjustment........................3-69 Observer’s Seat .................3-70 200 Engine Box Cover/ Lifting/Removal ...............3-71 Walk-Thru Windshield Opening/Latching...........3-72 Dash Storage .....................3-72 Boarding Platform ...........3-73 Engine Cooling Water Intake Valve ......................3-75 Battery Disconnect Switch ................................3-76 Nautique Electrical System................................3-76 Rudder Remote Lube ......3-76 Fuel Tank ..........................3-77 Optional Equipment ...........3-78 Folding Instructions for Flight Control Tower ® ......3-78 Bimini Top........................3-80 Battery Charger ................3-81 Optional Accessories ...........3-81 Stereo Systems ..................3-81 Boat Systems ........................4-1 Fuel System ............................4-1 200-OB, 200-CB ..................4-2 200-V ....................................4-3 Ballast Tanks and Bilge System .....................................4-4 Ballast Tank Valves – 200-V ....................................4-5 Port and Starboard Ballast Tanks – 200-V .........4-6 Bilge System – 200-OB, 200-CB, 200-V......................4-7 12-Volt System – 200-OB, 200-CB ....................................4-8 12-Volt System – 200-V Only ........................................4-9 Cockpit Heater System – Optional ...............................4-10 Getting Underway ................5-1 Safety Checklist ......................5-1 Safety Equipment ..................5-2 Fueling ....................................5-2 Gasoline Containing Alcohol ................................5-3 When Fueling .....................5-4 After Fueling .......................5-5 Boarding .................................5-5 Boat Planing...........................5-5 Pre-Operation Checks ...........5-6 Flooded Engine ................5-11 Break In Procedure..........5-13 Propeller Selection...........5-13 Shifting .................................5-14 Steering ................................5-14 Stopping ...............................5-15 Docking ................................5-15 Running................................6-1 Hydro-Gate™..........................6-1 Maneuvering Techniques .....6-2
