2100 Maxum Cuddy 2003 17 18 19 20 27 30 33 2 34 31 32 25 24 22 28 29 23 26 10 11 12 6 15 15 9 13 14 17 16 1 2 3 4 5 6 7 8 36 35 21 37 06/01/2004 6 COCKPIT

2100 Maxum Cuddy 2003 COCKPIT 1727320 1 ELECTRICAL,PNL ASSY GAUGE GAS SLVR N/DEPTH 1718853 2 DRINK HOLDER, DUAL STACK TTNIUM 1727464 3 ELECTRICAL,PNL ASSY SW W/INSERT TTNIUM 1323625 4 STEERING, HELM MECHANICAL ASSY BACK-MNT W/BZL 1705283 STEERING FITTINGS, WEDGE KIT 20 DEGREE 1719238 DECAL, MAXUM-03 CHR/BLK DRIPMOLD STEERNG WHL 1727216 STEERING WHEEL, TTNIUM MAXUM-03 N/CTR PAD 1727220 STEERING WHEEL, CTR PAD CVR TTNIUM 1694325 5 CONTROL, SHIFTER COMMANDER 4000 I/O 1706286 6 RAIL, GRAB 20"X 1" ELLIPSE SS 1718147 7 TRIM, JUMPSEAT SLOT ARCW 1717323 8 STEREO, AM/FM/CD PLAYER FOR HULL #'S A35NG AND LWR 1718786 STEREO, AM/FM/CD PLAYER FOR HULL #'S A36NG AND UP 1705522 9 SPEAKER, DUAL CONE 6.5" FOR HULL #'S A35NG AND LWR 1440536 SPEAKER, DUAL CONE EXT 6.5" W/CVR FOR HULL #'S A36NG AND UP 1718192 10 DOOR, CUDDY ENTR 1/2"ACRY ARCW 1702357 DOOR HARDWARE, HINGE PADDLE 2 SHORT 1 LONG 1718254 11 THRESHOLD, HDPE 1/2" ENTR BROW MOLDED ARCW 1702372 12 DOOR HARDWARE, LATCH COVERED 1718193 13 TRIM, LINER ABS 1/8" ARCW CTR 1718194 14 TRIM, LINER ABS 1/8" ARCW PRT 1705929 15 RAIL, GRAB 11"X 1" ELIPSE W/STUDS SS 1706431 16 LATCH, SLAM PLAS WHT SNAPPY 1718255 DOOR, HDPE B/B 1/2" TTNIUM 1701355 17 HANDLE, ENG HATCH CVR LIFT HANDLE 126862 18 VENT, LOUVERED DRAIN/HORN CVR 2.5" SS 1702325 19 HINGE, BUTTERFLY CHR 2"X 3"X 6 HOLE 132340 20 LATCH, FLUSH D-RING N/LOCK BLK 1750546 2100SC 03,LAM ASSY,SKI LCKR HATCH 1737609 21 LABEL, STICKER NMMA CAP 2100SC-03 1750693 22 2100SC 03,UPH ASSY,PRT TRNSM CLOSEOUT DOOR 1750694 23 2100SC 03,UPH ASSY,STB TRNSM CLOSEOUT DOOR 1701355 24 HANDLE, ENG HATCH CVR LIFT HANDLE 1701709 25 CATCH, F/HATCH HINGE WHT 1701735 26 HINGE, ALUM 1/2" DBL BUTTERFLY 1750547 27 2100SC 03,LAM ASSY,MTRBX 1692262 UPHOLSTERY, KIT SOUND FOAM 1702036 28 DOOR HARDWARE, SOFT LATCH W/CATCH 1705875 29 HINGE, BREAKAWAY 3X3 REMOVEABLE PIN 1706422 30 HINGE, 5 3/8"X 1.5" SS 1750548 31 2100SC 03,LAM ASSY,MTRBX DOOR 1718809 MOLDING, D-SEAL ARCW 1701725 32 HINGE, CHROME 2"X 2" BUTT 132340 33 LATCH, FLUSH D-RING N/LOCK BLK 1706427 METAL AND PLASTICS, CATCH FOR MTR BX 1701310 34 TRIM EDGE, 7/16" SCR 8 FOOT 1706140 35 LABEL, STICKER QUALIFIED OPERATOR 1703581 36 LABEL, STICKER EMERGENCY SHUT DOWN 1703698 37 LABEL, STICKER DO NOT BOARD FOREDECK NOT SHOWN 1699344 LABEL, STICKER WARNING VENTILATE 1701413 TRIM EDGE, T-TRIM 11/16" WHT 1701595 BUMPER, GLASS DOOR 1701802 LABEL, STICKER BATT INSTALLATION COMPL 1702191 DRAIN, FITTING 1/4" ID 1702192 NUT, JAM PLAS 1/2" (FOR 1702191) 1702930 TRIM EDGE, 1/2" WHT 1/2" BLK BULB F/ V-BERTH DOOR OPENING 1703805 LABEL, STICKER WARNING FLAMMABLE LIQUID STRG 1703969 LABEL, STICKER OVERLAM FOR CAP LABEL 1705524 LABEL, STICKER SUN LNG WARNING 1718385 FIRE EXTINGUISHER, FIRE PORT FLUSH ARCW 1719237 DECAL, MAXUM-03 CHR/BLK DRIP MOLD OWNERS PACKET 1692836 MANUAL, OWNER 1742430 MANUAL, OWNERS SUPPLMNT MAXUM-03 SPORT BOATS 06/01/2004 7
