Edgewater 170CC Owners Manual

170CC 170 Center Console OWNER ASSISTANCE MANUAL Revised April 2014

170CC SPECIFICATIONS LENGTH: 16’10” (4.8m) BEAM: 7’3” (2.2m) DRAFT (boat only): 12” (30.5cm) BOAT WEIGHT: 1700lbs (771kg) WEIGHT CAPACITY: 1350lbs (612kg) PERSON CAPACITY: 6 PERSON WEIGHT: 805lbs (365.1kg) FUEL CAPACITY: 30gal (98.42L) TRANSOM HEIGHT: S-20 MAX POWER: 115hp (86kw) COCKPIT DEPTH: 21” (53.3cm) COCKPIT AREA: 44sq/ft (4m²) APPROX LENGTH ON TRAILER: 22’ (6.7m) BRIDGE CLEARANCE: W/OUT TOP 5’ 4” (1.6m) W/SUNTOP 6’ 5” (2.0m) FLOTATION: UNSINKABLE LEVEL HULL DEADRISE: 18° U.S. Coast Guard CE Maximum Capacities 6 PERSONS OR 510kg 6 PERSONS OR 805 LBS 86kw MAX POWER 1350 LBS PERSONS, MOTORS, GEAR C RATING 115 H.P. MOTOR

Owner’s Manual 170CC REVISED April 2014

2 Dear EdgeWater 170CC owner: Congratulations on purchasing one of the finest small boats ever built. It has been constructed with care from the finest available materials. At EdgeWater we take great pride in the quality and craftsmanship that goes into each boat, large or small. We believe you’ll have many years of enjoyment from your new EdgeWater and thank you for entrusting your leisure time to one of our fine products. This manual has been assembled to help you learn more about your new boat and increase your enjoyment of it. Your EdgeWater has been built for a “Lifetime on the Water”. Boat safe and boat smart, we wish you many years of boating pleasure. Sincerely, Peter Truslow President EdgeWater Powerboats

3 Service Information Please fill out the information below completely. It will help us in assisting you in the event your EdgeWater needs service. Customer Name ______________________________________________________________________ Address _____________________________________________________________________________ City __________________________________________ State Zip Phone _________________________Cell _____________________Business _____________________ E-mail Address _______________________________________________________________________ Dealer Name _________________________________________________________________________ Address _____________________________________________________________________________ City ___________________________________________ State ______ Zip ______________ Phone _________________________________________ Fax __________________________________ Purchase Date __________________________________ Engine Make/Model ____________________ Delivery Date ___________________________________ Engine Serial # _________________________ Hull Number __DMA______________________________ Ignition Key # ___________________________ EdgeWater Power Boats, LLC. reserves the right to make alterations in the standard and optional equipment without incurring obligation to those boats already having been built. Every effort has been made to ensure that the information in this manual accurately describes vessels being built at the date of printing.

4 Table of Contents Chapter 1 General Information ................................................................. 6 1.1 General ..............................................................................................................................6 1.2 Owner / Operator Responsibilities ...................................................................................... 6 Chapter 2 Helm Control Systems ............................................................. 7 2.1 General ..............................................................................................................................7 2.2 Steering System................................................................................................................. 7 2.3 Engine Throttle and Shift Controls...................................................................................... 7 Chapter 3 Propulsion System................................................................... 8 3.1 General ..............................................................................................................................8 3.2 Engine Cooling System ......................................................................................................9 3.3 Propellers ..........................................................................................................................9 3.4 Engine Power Tilt and Trim .............................................................................................. 10 3.5 Engine Instrumentation ................................................................................................... 10 Chapter 4 Fuel System ............................................................................ 12 4.1 General ............................................................................................................................ 12 4.2 Fuel Fill ............................................................................................................................ 12 4.3 Fuel Vent ......................................................................................................................... 12 4.4 Fueling ............................................................................................................................. 12 4.5 Fuel System Maintenance ................................................................................................ 13 4.6 Fuel Filters ....................................................................................................................... 13 Chapter 5 Electrical System ................................................................... 13 5.1 General ............................................................................................................................ 13 5.2 Accessory Panel Switches ............................................................................................... 13 5.3 Electrical System Maintenance ........................................................................................ 14 Chapter 6 Raw Water & Freshwater Systems........................................ 14 6.1 General ............................................................................................................................ 14 6.2 Livewell Operation............................................................................................................ 14 6.3 High Pressure Washdown ................................................................................................ 15 6.4 Freshwater System .......................................................................................................... 15 6.5 Water Systems Maintenance..............................................................................................15 Chapter 7 Drainage System ................................................................... 16 7.1 General ............................................................................................................................ 16 7.2 Drain System Maintenance .............................................................................................. 16 7.3 Cockpit Drains.................................................................................................................. 16 7.4 Transom Bilge .................................................................................................................. 16

5 7.5 Locker Drains .....................................................................................................................17 Chapter 8 Safety Equipment ................................................................... 17 8.1 Required Safety Equipment ............................................................................................ 17 8.2 Suggested Safety Equipment - Inshore ............................................................................ 18 8.3 Suggested Safety Equipment – Offshore ......................................................................... 18 Chapter 9 Safe Operation ....................................................................... 19 9.1 Pre-Cruise Check List ......................................................................................................19 9.2 Basic Rules of the Road ................................................................................................... 20 9.3 Safe Operation ................................................................................................................. 21 9.4 Towing or Being Towed.................................................................................................... 21 9.5 Stopping the Boat............................................................................................................. 22 9.6 Docking ............................................................................................................................ 22 9.7 After Operation ............................................................................................................... 22 9.8 Trailering Your Boat ......................................................................................................... 23 9.9 Launching Your Boat ........................................................................................................23 9.10 Retrieving Your Boat ......................................................................................................24 Chapter 10 Routine Maintenance ........................................................... 23 10.1 Exterior Hull and Deck...................................................................................................23 10.2 Engine............................................................................................................................ 26 Chapter 11 Exterior Equipment .............................................................. 26 11.1 Swim Platform (optional) ................................................................................................ 26 Chapter 12 Seasonal Maintenance ......................................................... 27 12.1 Engine............................................................................................................................ 27 12.2 Hull................................................................................................................................. 27 12.3 Storage .......................................................................................................................... 27 12.4 Trailer............................................................................................................................. 27 Appendix .................................................................................................... 28

6 1/General Information 1.1 General The EdgeWater 170CC is a semi-custom fishing vessel designed to be powered by a single outboard engine. 1.2 Owner / Operator Responsibilities Registration Registering your boat is important to you. Federal Law requires that all powered, undocumented vessels be registered in their state of principal use. Contact the appropriate agency in your local state to obtain specific registration information. Reporting Boating Accidents All boating accidents must be reported to the proper authorities in the state which the accident occurred. If someone dies or disappears as a result of the recreational boating accident, it must be reported immediately, with a formal report being made within 48 hours. If there is damage of more than $500, or if the boat is completely lost, a formal report must be made within 10 days. Questions regarding accidents may be directed to the Boating Safety Hotline, 800-368-5647. Education Whether or not you are an experienced boater, attending a Boating Education Course can be beneficial. If you are inexperienced, it is the best, safest way to begin your life on the water. If you are an experienced boater, it’s always good to sharpen your skills. Required Equipment The U.S. Coast Guard requires certain equipment on each boat. In addition, they also set minimum equipment and safety standards. For more detailed requirement information, obtain “Federal Requirements And Safety Tips For Recreational Boats”, by contacting the Boating Safety Hotline, 800-368-5647. Some states and local agencies require equipment that is not required by the U.S. Coast Guard. Your local agency or dealer can provide specific information regarding these non- standard requirements.

7 2/Helm Control Systems 2.1 General The helm station is the control center for the boat. The main control systems are the engine throttle/shift controls and the steering system. These provide the operator the ability to control speed, direction, boat trim, and attitude. Each manufacturer provides manuals on the operation and use of their systems. 2.2 Steering System General The manual which comes with your steering system provides specific information on your steering system. The standard hydraulic steering system has two main components: a helm assembly and hydraulic cylinder. Turning the helm, which pumps fluid in the hydraulic hoses, activates the hydraulic cylinder and causes the motor to turn. The helm acts as both pump and reservoir. Please see diagram in the manual’s appendix for a visual representation of this system. While running at slow speeds, most boats tend to wander slightly back and forth. Keeping the wheel in the center without overcompensating for the slight wandering will prevent over steering and reduce the tendency to wander. Steering System Maintenance Routine system inspection should occur regularly. Cables, hoses, linkage and helm assemblies should be inspected for wear, corrosion, cracking, or deterioration. Cleaning and light grease should be applied to all exposed metal parts and other damaged or deteriorated parts should be replaced as soon as possible. 2.3 Engine Throttle and Shift Controls Refer to the engine manual supplied with your engine for specific information on your controls. The ones depicted are those supplied by Yamaha. There are three major components of the engine throttle and shift controls: handles, throttle cable, shift cable. Throttle and shift cables are push-pull and are connected to the fuel system (carburetor or fuel injection) and the other to the shift rod linkage. By moving the handles forward and back, the operator engages the cables thus controlling the amount of fuel being used and the gear selector for forward, neutral and reverse. Careful use of the controls provides smooth, responsive and safe operation.

8 Do not bring the throttle back abruptly to stop the boat unless it is an emergency. Allow time for the engine RPM to come down to idle before shifting to reverse or severe gearbox damage could occur. PLEASE REFER TO YOUR ENGINE OWNER’S MANUAL FOR FURTHER OPERATIONAL PROCUDURES FOR YOUR OUTBOARD. Engine Stop Switch This device is designed to prevent the operator falling overboard while the engine remains running. The engine stop switch lanyard should always be worn by the operator, while the boat is in motion. Pulling the lanyard from the control will stop the engine. If the engine will not crank properly, the lanyard may not be properly attached to the engine stop switch. Do not use the engine stop switch to stop the boat unless it is an emergency as it may impair your ability to quickly re-start the engine. **NOTE** Each ignition key has a 3 digit number stamped on it. Please record this number for future reference on the service information page in the front of this manual. 3/Propulsion System 3.1 General Your new EdgeWater 170CC is designed to be powered by a single outboard motor. Most 2- cycle outboards currently use an automatic system to mix the oil with the gasoline before the engine uses it. On a 170CC equipped with a 2-cycle engine, the oil tank is maintained in the crankcase. Make sure this tank always has a sufficient amount of the recommended 2-cycle oil for your cruise, plus some reserve. 4-cycle engines require oil be maintained in the crankcase also. Always check the crankcase oil level before each day’s run. Always follow the manufacturer’s recommendations and use only the recommended oil types. Don’t attempt to service your outboard or any of its components unless you are thoroughly familiar with its operation and dangers. Many of the moving part components are exposed and can pose an extreme danger to anyone unfamiliar with their operation. Always leave the servicing to a qualified technician. Each manufacturer provides manuals designed to assist you in the proper operation and maintenance of your new engine. Follow their guidance and schedules for proper operation of your new engine. With a modern outboard there is little to do as long as proper maintenance is performed, in accordance with the manufacturer’s recommendations. If the boat is to be kept in saltwater for an extended period, electrolysis and marine growth can become a problem. When leaving your boat in salt water overnight or for an extended period, tilt the engine as high out of the water as possible. This will decrease the possibility of marine growth on the outside of the engine, as well as reduce the potential of marine growth compromising the cooling water inlets in the lower unit, which can cause overheating.
