PROHEAT ® 2X PREMIER USER GUIDE 47A2, 17N4, 80R4 SERIES

IMPORTANT SAFETY INSTRUCTIONS www.BISSELL.com 800.237.7691 2 WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY: » Connect to a properly grounded outlet only. See grounding instructions. Do not modify the 3-prong grounded plug. » Do not leave appliance when it is plugged in. Unplug from outlet when not in use and before servicing. » Use indoors only. » Do not allow to be used as a toy. Close attention is necessary when used by or near children. » Do not use for any purpose other than described in this User’s Guide. Use only manufacturer’s recommended attachments. » Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, have it repaired at an authorized service center. » Always install float before any wet pick-up operation. » Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces. » Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. » Do not handle plug or appliance with wet hands. » Do not put any object into openings. Do not use with any opening blocked; keep openings free of dust, lint, hair, and anything that may reduce air flow. » Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts. » Turn off all controls before plug- ging or unplugging appliance. » Use extra care when cleaning on stairs. » Do not use to pick up flammable or combustible materials (lighter fluid, gasoline, kerosine, etc.) or use in areas where they may be present. » Do not use appliance in an enclosed space filled with vapors given off by oil base paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapors. » Do not use to pick up toxic material (chlorine bleach, ammonia, drain cleaner, etc.). » Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes. » Use only BISSELL cleaning products intended for use with this appliance to prevent internal component damage. See the Cleaning Fluid section of this guide. » Unplug before connecting TurboBrush Tool. » Do not immerse. Use only on surfaces moistened by the cleaning process. » Keep appliance on a level surface. » Do not carry the appliance while in use. READ ALL INSTRUCTIONS BEFORE USING YOUR DEEP CLEANER. When using an electrical appliance, basic precautions should be observed, including the following: This model is for household use only. Commercial use of this unit voids the manufacturer’s warranty. SAVE THESE INSTRUCTIONS FOR FUTURE USE WARNING Improper connection of the equipment-grounding conductor can result in a risk of electrical shock. Check with a qualified electrician or service person if you aren’t sure if the outlet is properly grounded. DO NOT MODIFY THE PLUG. If it will not fit the outlet, have a proper outlet installed by a qualified electrician. This appliance is designed for use on a nominal 120-volt circuit, and has a grounding attachment plug that looks like the plug in the illustration. Make certain that the appliance is connected to an outlet having the same configuration as the plug. No plug adapter should be used with this appliance. GROUNDING INSTRUCTIONS This appliance must be connected to a grounded wiring system. If it should malfunction or break down, grounding provides a safe path of least resistance for electrical current, reducing the risk of electrical shock. The cord for this appliance has an equipment-grounding conductor and a grounding plug. It must only be plugged into an outlet that is properly installed and grounded in accordance with all local codes and ordinances. Grounded Outlets Grounding Pin

Quick Start Guide www.BISSELL.com 800.237.7691 3 1. Make sure handle of machine is locked in upright position 2. Attach the cleaning tool to the end of the hose 3. Clean by pressing the trigger to spray solution onto the area to be cleaned 4. Slowly scrub the tool back and forth over the soiled surface 5. Tilt the tool forward and release spray trigger to suction liquid Before you begin cleaning Assembly 1. Move furniture to another area if cleaning an entire room 2. Remove large dirt and debris from carpet 3. Pre-treat spots & stains and heavy traffic areas (optional) 4. Fill the clean water tank 4a. Unlatch the top by lifting up on the latches on each side of the tank 4b. Remove the top 4c. Pour 5 ounces of formula into the heavy duty bladder (fill the included measuring cup twice). Fill the rest of the way with hot tap water (do not boil or microwave water). 4d. Re-attach top by lining up and securing the latches on the sides of the tank 5. Plug into outlet, and turn the power switch on NOTE: Heatwave Technology ® helps keep hot water hot while the machine is in use. Simply turn the machine on to activate Heatwave. Cleaning with attachments 1. Slide upper handle onto machine base 2. Screw 2 screws into the marked holes 3. Place upper hose rack onto back of upper handle, and secure with screw 4. Wrap power cord to the left and flex hose to the right of the upper hose rack 5. Attach tool to hose grip

Th for buying a BISSELL dp cleer We’re glad you purchased a BISSELL deep cleaner. Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. Your BISSELL deep cleaner is well made, and we back it with a limited three-year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Care department, so, should you ever have a problem, you’ll receive fast, considerate assistance. My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your BISSELL deep cleaner. Thanks again, from all of us at BISSELL. Mark J. Bissell Chairman & CEO Safety Instructions ........... 2 Quick Start Guide............ 3 Product View................ 5 Assembly ................... 6 Operations ............... 6-12 Maintenance & Care ......13-15 Troubleshooting ............ 16 Replacement Parts ......... 17 Accessories ................ 18 Warranty ................... 19 Consumer Care ............. 19 Product Registration ....... 20 » Deep cleaning stairs and high-traffic areas on a regular basis helps prolong carpet life. » Check upholstery stuffing before cleaning. Colored stuffing may bleed through the fabric when it becomes wet. » Before turning off the machine, suction up clean water to thoroughly rinse out the interior of the flex hose. Then, lift the cleaning tool and point it upwards to drain any remaining water into the dirty water/ collection tank. Tips www.BISSELL.com 800.237.7691 4

1 Spray Trigger 2 Extra Long Power Cord 3 Upper Handle 4 Flex Hose 5 Power Switch 6 Easy Carry Handle 7 Tank Carry Handle 8 Large Capacity 2-in-1 Water Tank 9 Surround Suction® 10 Easy To Remove Nozzle 11 EdgeSweep® Brushes 12 Lower Base 13 Upper Hose Rack 14 Lower Hose Rack 15 Handle Recline Pedal Product View www.BISSELL.com 800.237.7691 5 1 2 4 3 5 6 7 8 9 10 11 12 13 14 15

Your deep cleaner comes in three (four on select models) easy-to-assemble components: Upper Handle with Screws Lower Base Upper Hose Rack Upper Tool Holder (select models) The only thing you will need to assemble your cleaner is a Phillips head screwdriver. The only thing you will need to assemble your cleaner is a Phillips head screwdriver. 1. Slide upper handle onto lower handle. 2. Screw 2 screws into the marked holes (screws will be taped to handle). 3. Place upper hose rack onto back of upper handle, and secure with screw. 4. Wrap power cord and flex hose. Snap hose wand into hose clip on upper hose wrap. NOTE: Take care to wrap the hose in the right direction in order to make use of the hose clip. Make sure the hose is wrapped beginning from the back of the machine and wrapping toward the front. Deep cleaner assembly is now complete. Asmbly Operatis www.BISSELL.com 800.237.7691 WARNING Do not plug in your deep cleaner until you are familiar with all instructions and operating procedures. 6 Cleaning fluid Keep plenty of genuine BISSELL 2X formula on hand so you can clean and protect whenever it fits your schedule. Always use genuine BISSELL deep cleaning formulas. Non-BISSELL cleaning solutions may harm the machine and will void the warranty. *ONLY BISSELL Protects from future stains with Scotchgard™ Protector WARNING To reduce the risk of ﬁre and electric shock due to internal component damage, use only BISSELL cleaning ﬂuids intended for use with the deep cleaner. 4. 3a. 3b. 1. 2. Professional Deep Cleaning Pet Stain & Odor Deep Clean & Protect Allergen Cleansing Deep Clean + Oxy Hard Floor Solutions Pet Stain PreTreat Stain PreTreat Best for Out cleans all other formulas Removes tough pet stains and contains patented odor removal technology Deep cleans carpets and protects from future stains with Scotchgard™ Protector Helps remove pet & pollen allergens Permanently removes tough stains For use with the Bare Floor Tool (select models) Pretreat to help remove tough pet stains and odors Pretreat to penetrate and loosen tough stains 2X Concentrated X X X X X X Scotchgard™ Protection ® X X X

Before you clean 1. Move furniture to another area if cleaning an entire room (optional). 2. Pick up all loose dirt, debris, and pet hair before deep cleaning. It is recommended that you vacuum the area prior to deep cleaning. 3. Plan your cleaning route to leave an exit path. It is best to begin cleaning in the corner farthest from your exit. 4. Pretreating (optional) is recommended to improve cleaning effectiveness for heavily soiled carpet in high traffic areas such as entryways and hallways. BISSELL Stain Pretreat a. Spray the BISSELL Stain Pretreat formula onto heavy traffic areas, soiled areas, or stains. b. Allow to penetrate for at least 3 minutes. c. Clean as normal following the instructions on the next page. Machine Prep 1. Fill the 2-in-1 Water Tank. Remove the tank from the base of the machine by lifting up the tank carry handle. Carry like a bucket to the sink. 2. Unlatch the top of the tank from the bottom by lifting up on the tank latches on either side of the tank. 3. Pour 5 ounces of formula into the heavy duty bladder (fill the included measuring cup twice). Fill the rest of the heavy duty bladder with hot (140°F/60°C MAX) tap water. DO NOT BOIL OR MICROWAVE WATER. NOTE: Always use genuine BISSELL 2X formulas to maximize cleaning and for the safety of your machine. 4. Place the top of the tank back on the bottom and secure the latches on both sides. NOTE: Remember to secure the tank latches on either side of the tank and test to make sure they are secure before picking up the tank. Operatis www.BISSELL.com 800.237.7691 WARNING To reduce the risk of ﬁre and electric shock due to internal component damage, use only BISSELL cleaning ﬂuids intended for use with the deep cleaner. ATTENTION Some Berber carpets have a tendency to fuzz with wear. Repeated strokes in the same area with an ordinary vacuum or deep cleaner may aggravate this condition. Please see Stain Removal instructions on page 11. 7 1 2 3 4 5 6 7 8 9 1. 2. 3. 4.

Operatis Carpet cleaning 1. Plug into a proper outlet and push the on/off button located on the front of the handle. 2. Recline the handle by pressing on the lever at the back of the machine behind the 2-in-1 water tank. 3. Cleaning Strokes. While pressing the trigger, make one slow forward wet pass and another one back. Caution: Do not overwet. Take care not to run over loose objects or edges of area rugs. Stalling brush may result in premature belt failure. NOTE: Your machine is equipped with a circuit breaker that will automatically shut off the brush if a large or loose object is caught in the brush roll. If that happens, be sure to unplug your machine, remove the foreign object, and then plug the machine back in to reset the circuit breaker. 4. Release the trigger and make one slow forward and backward pass over the same area to remove any residual dirty water and aid in drying. Repeat cleaning passes until solution being pulled up appears clean. Continue passes without pressing the trigger until you can’t see any more water being pulled up. 1. 2. www.BISSELL.com 800.237.7691 8

Cleaning with attachments Your deep cleaner comes equipped with a hose and at least one attachment for cleaning stairs, upholstery, and more. 1. Important! If using to clean upholstery, check upholstery tags. 1. Check manufacturer’s tag before cleaning. “W” or “WS” on the tag means you can use your deep cleaner. If the tag is coded with an “X” or an “S” (with a diagonal stripe through it), or says “Dry Clean Only”, do not proceed with any deep cleaning machine. Do not use on velvet or silk. If manufacturer’s tag is missing or not coded, check with your furniture dealer. a. Check for colorfastness in an inconspicuous place. b. If possible, check upholstery stuffing. Colored stuffing may bleed through fabric when wet. c. Plan activities to allow upholstery time to dry. d. Pick up any loose dirt, debris and pet hair before deep cleaning. 2. Follow the instructions on page 7 for filling the 2-in-1 water tank. 3. The DeepClean Premier is designed with an automatic diverter. Simply lock the unit upright in order to clean with the hose. 4. Attach the cleaning tool to the end of the hose. 5. Plug in and turn on the power switch. 6. Clean by pressing the trigger to spray solution onto the area to be cleaned. Slowly move the tool back and forth over the soiled surface. Release the trigger to suction soiled water. Continue to clean in the area, working in small sections, until no more dirt can be removed. Rinse (optional) and suction as needed. Caution: Do not overwet. 7. Remove and rinse tools in clean, running water. Dry and replace on the end of the hose. 8. It is recommended that you suction clean water from a bowl to rinse out the hose. 9. Before replacing lift end of hose and stretch out to ensure all water is cleared from hose. 10. Wrap flex hose around the hose rack. 11. Empty 2-in-1 water tank and rinse out, following the instructions on page 10. Operatis 4. 9. WARNING To reduce the risk of injury, be extra careful when cleaning stairs. Make sure machine is secure and level. Adsdfdd ghg bvh cvbbj jkn hnbj jkvh gcghhjj jhffhl kllgh Manufacturer’s tag www.BISSELL.com 800.237.7691 9

Cleaning with the Stain Trapper tool (select models) Your deep cleaner may have come with a Stain Trapper tool. This tool is great for keeping messes out of the machine’s hose system. 1. Attach the Stain Trapper tool to the end of the hose. 2. Gently scrape up any semi-solids with a spoon or spatula. Do not use a knife or other utensil with sharp edges because it could damage the carpet or upholstery. 3. Follow instructions 3-6 on page 9 under “Cleaning with attachments”. NOTE: Do not fill the Stain Trapper tank above the FULL line. 4. To empty the Stain Trapper tool, rotate the small tank on the bottom of the tool to unlock it. NOTE: Be careful to keep the top of the tool facing upward or soiled water will spill out of the tank. 5. Dump dirty water into a sink or toilet and rinse the tank out with clean water. Replace the tank by lining up the “unlock” symbol with the small arrow on the tank and turning it to the “lock” symbol. 6. Clean the front of the tool by removing the plate over the suction path. Pull down on the bottom of the plate to remove. Run the tool and the plate under clean water to rinse taking care to remove all debris. Replace the front plate by sliding it back into place. Clean-up 1. Remove the tank from the base of the machine by lifting up on the tank carry handle. Carry like a bucket to a utility sink or outside where you will dispose of the dirty water. 2. Unlatch the top of the tank from the bottom by lifting up on the tank latches on either side of the tank. 3. Remove the top of the tank by lifting up on the handle. 4. Lift the bottom portion of the tank; pour out dirty water in the sink through the rectangular shaped opening in the corner of the tank. NOTE: You may notice hair & debris deposits on the carpet or in the tank that were loosened by the cleaning action. This debris should be picked up and thrown away. Check the red lint filter near the duct on the back of the machine base for debris and remove before continuing. 1. 3. 2. 4. Filter Operatis 6. 4. www.BISSELL.com 800.237.7691 10
