YAMAHA GeneratorS EF12000E EF12000DE EF12000DEX EF1300TE SRM

EF12000E[50Hz, 220V] EF12000DE[60Hz, 120/240V] [For U.S.A.] EF12000DEX[60Hz, 120/240V] [For CANADA] EF13000TE[50Hz, 220/380V] SERVICE MANUAL 7UX-28197-E1 310139

FOREWORD This manual was written by the Yamaha Motor Company primarily for use by Yamaha dealers and their qualified mechanics. It is not possible to put an entire mechanic’s edu- cation into one manual, so it is assumed that persons using this book to perform mainte- nance and repairs on Yamaha generators have a basic understanding of the mechani- cal precepts and procedures inherent to gen- erator repair technology. Without such knowl- edge, attempted repairs or service to this model may render it unfit for use and/or unsafe. Yamaha Motor Company Ltd. is continually striving to further improve all models manu- factured by Yamaha. Modifications and sig- nificant changes in specifications or procedures will be forwarded to all Authorized Yamaha dealers and will, where applicable, appear in future editions of this manual. HOW TO USE THIS MANUAL PARTICULARLY IMPORTANT INFORMATION This material is distinguished by the follow- ing notation. The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS IN- VOLVED! Failure to follow WARNING instructions could result in severe injury or death to the machine operator, a bystander, or a person in- specting or repairing the machine. CAUTION: A CAUTION indicates special precautions that must be taken to avoid damage to the machine. NOTE: A NOTE provides key information to make procedures easier or clearer. MANUAL FORMAT The procedures in this manual are organized in a sequential, step-by-step format. The information has been compiled to provide the mechanic with an easy to read, handy refer- ence that contains comprehensive explana- tions of all disassembly, repair, assembly, and inspection operations. In this revised format, the condition of a faulty component will precede an arrow symbol and the course of action required will follow the symbol, e.g., • Bearings Pitting/damage → Replace. EXPLODED DIAGRAM Each chapter provides exploded diagrams before each disassembly section for ease in identifying the correct disassembly and assembly procedures. EF12000E (50Hz, 220V) EF12000DE (60Hz, 120/240V) EF12000DEX (60Hz, 120/240V) EF13000TE (50Hz, 220/380V) SERVICE MANUAL ©2002 by Yamaha Motor Co., Ltd. 1st Edition, November 2002 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. WARNING
