© Panasonic Corporation 2011 Unauthorized copy-
ing and distribution is a violation of law.
OrderNo.PTW1104504CE
Automatic Bread Maker
Model No. SD-ZB2502BXE
Chassis
Product Color Black
Destination Belgium
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions ----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
3 Location of Controls and Components ------------------- 4
4 Operating Instructions------------------------------------------ 6
5 Troubleshooting Guide ----------------------------------------16
6 Disassembly and Assembly Instructions ---------------25
7 Wiring Connection Diagram ---------------------------------42
8 Exploded View and Replacement Parts List -----------44
2
1 Safety Precautions
3
2 Specifications
Power supply 230 V -50 HZ
Power consumed 550 W
Capacity (Strong flour) max.600g min.300g
(Dry Yeast) max.7.5g min.2.25g
Capacity of raisin nut dispenser max.150g raisins
Timer Digital timer (up to 13 hours)
Protective device Self-resetting motor protector (Open:230°F)
Dimensions (H × W × D) approx. 38.2cm × 25.6cm × 38.9cm
Weight approx. 7.8kg
Accessories (Included) Measuring cup, Measuring spoon
4
3 Location of Controls and Components
5
6
4 Operating Instructions
4.1. Befor Use
7
4.2. How to Use
8
9
10
