KTM 950 Adventure Engine Repair Manual

950/990 ADVENTURE 990 SUPER DUKE 950 SUPERMOTO 950 SUPER ENDURO REPARATURANLEITUNG MANUALE DI RIPARAZIONE MANUEL DE RÉPARATION MANUAL DE REPARACIÓN ART.NR.: 3.206.044-E REPAIRMANUAL2003-2007

REPAIRMANUAL2003-2007 950/990 ADVENTURE 990 SUPER DUKE 950 SUPERMOTO 950 SUPER ENDURO KTM Group Partner

1 SERVICE-INFORMATIONS 2 GENERAL INFORMATION 3 REMOVING AND REFITTING ENGINE 4 DISASSEMBLING ENGINE 5 SERVICING INDIVIDUAL COMPONENTS 6 ASSEMBLING ENGINE 7 ELECTRICAL / INJECTION 8 FUEL SYSTEM 9 TROUBLE SHOOTING 10 CHASSIS 11 TECHNICAL SPECIFICATIONS 12 PERIODIC MAINTENANCE SCHEDULE 13 WIRING DIAGRAMS 14 15 16

Remove page (s) Replace by page (s) Insert page (s) after page 5-2 to 5-5 5-2 to 5-5 11-1 11-1 11-6 to 11-13 11-6 to 11-13 11-18 to 11-19 11-18 to 11-19 13-1 to 13-6 13-1 to 13-6 13-35 to 13-44 13-35 to 13-44 13-63 to 13-72 13-63 to 13-72 13-89 to 13-98 13-89 to 13-98 13-117 to 13-125 13-117 to 13-125 I MPORTANT I NFORMATION /U PDATING INSTRUCTIONS To be able to continue using the existing loose-leaf repair instructions, simply print the following pages and insert them in the existing repair instructions: 1,3,7,9,13,71-74,211-218,223,224,253-258,287-296,315-324,341-350,369-378 KTM REPAIR MANUAL IN LOOSE-LEAF FORM STORING THE REPAIR MANUAL IN THE BINDER – Put the index into the binder. – Put the front page of the repair manual (210x297 mm) into the transparent pocket provided for this purpose on the outside of the binder. – Put the spine label (170x45 mm) into the transparent pocket provided for this purpose on the spine of the binder. – Put the summary list of contents (150x297 mm) into the transparent pocket provided for this purpose on the inside of the binder or insert this page on the beginning of the manual. – Then insert the individual chapters of the manual between the sheets of the index according to the page number printed in the right bottom corner of each page. Example: page no. 3-5; 3 = chapter 3; 5 = page 5 All pages with a page number that begins with the digit 3, for example, must be put under the index heading „Chapter 3“. – Index sheets that have not been marked with a certain chapter are for your personal convenience. The respective headings can be entered in the list of contents.

E XPLANATION - U PDATING Edition: 02/2007 3.206.009-E Repair Manual LC8 Basicversion Modelyear 2003 4/2003 3.206.016-E Updating of Rep.Manual 3.206.009-E Modelyear 2004 (Engine number with first digit “4“) 11/2003 3.206.025-E Updating of Rep.Manual 3.206.009-E Modelyear 2005 (Engine number with first digit “5“) 01/2005 3.206.035-E Updating of Rep.Manual 3.206.009-E Modelyear 2005/06 (Engine number with first digit “5“ and “6”) 01/2006 3.206.044-E Updating of Rep.Manual 3.206.009-E Modelyear 2007 (Engine number with first digit “7“) 02/2007 technical details, technical data, technical specifications, wiring diagrams
