Indmar Diagnostic Trouble Code Fault Descriptions

Indmar Products 2008 All Rights Reserved 21 Draft Rev. A-Jan. 2008 7 Diagnostic Trouble Code Fault Descriptions LDGCP and MGCP header pins are in standard font, HDGCP and MDGCP header pins are in italicized parentheses (##). 7.1 SPN & FMI to DTC Conversion Table Indmar DTCConfigurations SPN FMI DTC Code Description 29 3 DTC 2128 FPP2 voltage high 29 4 DTC 2127 FPP2 voltage low 51 3 DTC 123 TPS1 voltage high 51 4 DTC 122 TPS1 voltage low 51 0 DTC 221 TPS1-2 higher than expected 51 1 DTC 121 TPS1-2 lower than expected 51 7 DTC 2112 Unable to reach higher TPS 51 7 DTC 2111 Unable to reach lower TPS 51 31 DTC 2135 TPS1/2 simultaneous voltages out-of-range 84 8 DTC 502 Roadspeed input loss of signal 91 3 DTC 2122 FPP1 voltage high 91 4 DTC 2123 FPP1 voltage low 91 16 DTC 2126 FPP1-2 higher than expected 91 18 DTC 2121 FPP1-2 lower than expected 91 31 DTC 1121 FPP1/2 simultaneous voltages out-of-range (redundancy lost) 91 19 DTC 1630 J1939 ETC message receipt loss 100 1 DTC 524 Oil pressure low 100 1 DTC 524 Oil pressure sender low pressure 100 0 DTC 521 Oil pressure sender high pressure 100 3 DTC 523 Oil pressure sender high voltage 100 4 DTC 522 Oil pressure sender low voltage 102 3 DTC 238 TIP/TOP high voltage 102 4 DTC 237 TIP/TOP low voltage 102 0 DTC 234 Boost control overboost failure 102 1 DTC 299 Boost control underboost failure 102 2 DTC 236 TIP/TOP active 105 3 DTC 113 IAT voltage high 105 4 DTC 112 IAT voltage low 105 15 DTC 111 IAT higher than expected stage 1 105 0 DTC 127 IAT higher than expected stage 2 106 16 DTC 108 MAP pressure high 106 4 DTC 107 MAP voltage low 108 0 DTC 2229 BP pressure high 108 1 DTC 129 BP pressure low 110 3 DTC 118 ECT voltage high 110 4 DTC 117 ECT voltage low 110 15 DTC 116 ECT higher than expected stage 1 110 0 DTC 217 ECT higher than expected stage 2

Indmar Products 2008 All Rights Reserved 22 Draft Rev. A-Jan. 2008 168 15 DTC 563 Vbat voltage high 168 17 DTC 562 Vbat voltage low 515 16 DTC 1111 RPM above fuel rev limit level 515 0 DTC 1112 RPM above spark rev limit level 628 13 DTC 601 Microprocessor failure - FLASH 629 31 DTC 606 Microprocessor failure - COP 629 31 DTC 1612 Microprocessor failure - RTI 1 629 31 DTC 1613 Microprocessor failure - RTI 2 629 31 DTC 1614 Microprocessor failure - RTI 3 629 31 DTC 1615 Microprocessor failure - A/D 629 31 DTC 1616 Microprocessor failure - Interrupt 630 12 DTC 604 Microprocessor failure - RAM 636 2 DTC 336 CRANK input signal noise 636 8 DTC 16 Crank and/or cam could not synchronize during start 636 4 DTC 337 Crank signal loss 639 12 DTC 1626 CAN-J1939 Tx fault 639 12 DTC 1627 CAN-J1939 Rx fault 645 4 DTC 2618 Tach output ground short 645 3 DTC 2619 Tach output short to power 651 5 DTC 261 Injector 1 open or short to ground 651 6 DTC 262 Injector 1 coil shorted 652 5 DTC 264 Injector 2 open or short to ground 652 6 DTC 265 Injector 2 coil shorted 653 5 DTC 267 Injector 3 open or short to ground 653 6 DTC 268 Injector 3 coil shorted 654 5 DTC 270 Injector 4 open or short to ground 654 6 DTC 271 Injector 4 coil shorted 655 5 DTC 273 Injector 5 open or short to ground 655 6 DTC 274 Injector 5 coil shorted 656 5 DTC 276 Injector 6 open or short to ground 656 6 DTC 277 Injector 6 coil shorted 657 5 DTC 279 Injector 7 open or short to ground 657 6 DTC 280 Injector 7 coil shorted 658 5 DTC 282 Injector 8 open or short to ground 658 6 DTC 283 Injector 8 coil shorted 695 9 DTC 1629 J1939 TSC1 message receipt loss 701 3 DTC 1511 AUX analog Pull-Up 1 high voltage 701 4 DTC 1512 AUX analog Pull-Up 1 low voltage 702 3 DTC 1513 AUX analog Pull-Up 2 high voltage 702 4 DTC 1514 AUX analog Pull-Up 2 low voltage 703 3 DTC 1517 AUX analog Pull-Up 3 high voltage 703 4 DTC 1518 AUX analog Pull-Up 3 low voltage 710 3 DTC 1515 AUX analog Pull-Down 1 high voltage 710 4 DTC 1516 AUX analog Pull-Down 1 low voltage 723 4 DTC 342 Loss of CAM input signal 723 2 DTC 341 CAM input signal noise 731 4 DTC 327 Knock1 sensor open or not present 731 2 DTC 326 Knock1 excessive or erratic signal 920 4 DTC 1641 Buzzer control ground short 920 5 DTC 1642 Buzzer open

Indmar Products 2008 All Rights Reserved 23 Draft Rev. A-Jan. 2008 920 3 DTC 1643 Buzzer control short to power 1079 3 DTC 643 Sensor supply voltage 1 high 1079 4 DTC 642 Sensor supply voltage 1 low 1079 31 DTC 1611 Sensor supply voltage 1 and 2 out-of-range 1080 3 DTC 653 Sensor supply voltage 2 high 1080 4 DTC 652 Sensor supply voltage 2 low 1110 31 DTC 1625 J1939 shutdown request 1192 3 DTC 1131 WGP voltage high 1192 4 DTC 1132 WGP voltage low 1213 4 DTC 1644 MIL control ground short 1213 5 DTC 650 MIL open 1213 3 DTC 1645 MIL control short to power 1268 5 DTC 2300 Spark coil 1 primary open or short to ground 1268 6 DTC 2301 Spark coil 1 primary shorted 1269 5 DTC 2303 Spark coil 2 primary open or short to ground 1269 6 DTC 2304 Spark coil 2 primary shorted 1270 5 DTC 2306 Spark coil 3 primary open or short to ground 1270 6 DTC 2307 Spark coil 3 primary shorted 1271 5 DTC 2309 Spark coil 4 primary open or short to ground 1271 6 DTC 2310 Spark coil 4 primary shorted 1272 5 DTC 2312 Spark coil 5 primary open or short to ground 1272 6 DTC 2313 Spark coil 5 primary shorted 1273 5 DTC 2315 Spark coil 6 primary open or short to ground 1273 6 DTC 2316 Spark coil 6 primary shorted 1274 5 DTC 2318 Spark coil 7 primary open or short to ground 1274 6 DTC 2319 Spark coil 7 primary shorted 1275 5 DTC 2321 Spark coil 8 primary open or short to ground 1275 6 DTC 2322 Spark coil 8 primary shorted 1321 4 DTC 616 Start relay ground short 1321 5 DTC 615 Start relay coil open 1321 3 DTC 617 Start relay coil short to power 1323 11 DTC 1311 Cylinder 1 misfire detected 1323 31 DTC 301 Cylinder 1 emissions/catalyst damaging misfire 1324 11 DTC 1312 Cylinder 2 misfire detected 1324 31 DTC 302 Cylinder 2 emissions/catalyst damaging misfire 1325 11 DTC 1313 Cylinder 3 misfire detected 1325 31 DTC 303 Cylinder 3 emissions/catalyst damaging misfire 1326 11 DTC 1314 Cylinder 4 misfire detected 1326 31 DTC 304 Cylinder 4 emissions/catalyst damaging misfire 1327 11 DTC 1315 Cylinder 5 misfire detected 1327 31 DTC 305 Cylinder 5 emissions/catalyst damaging misfire 1328 11 DTC 1316 Cylinder 6 misfire detected 1328 31 DTC 306 Cylinder 6 emissions/catalyst damaging misfire 1329 11 DTC 1317 Cylinder 7 misfire detected 1329 31 DTC 307 Cylinder 7 emissions/catalyst damaging misfire 1330 11 DTC 1318 Cylinder 8 misfire detected 1330 31 DTC 308 Cylinder 8 emissions/catalyst damaging misfire 1347 5 DTC 628 Fuel-pump high-side open or short to ground 1347 6 DTC 629 Fuel-pump high-side short to power 1348 4 DTC 628 Fuel pump relay control ground short

Indmar Products 2008 All Rights Reserved 24 Draft Rev. A-Jan. 2008 1348 5 DTC 627 Fuel pump relay coil open 1348 3 DTC 629 Fuel pump relay coil short to power 1485 4 DTC 686 Power relay ground short 1485 5 DTC 685 Power relay coil open 1485 3 DTC 687 Power relay coil short to power 3050 11 DTC 420 Catalyst inactive on gasoline (Bank 1) 3051 11 DTC 430 Catalyst inactive on gasoline (Bank 2) 3217 5 DTC 134 EGO1 open / lazy 3227 5 DTC 154 EGO2 open / lazy 3256 5 DTC 140 EGO3 open / lazy 3266 5 DTC 160 EGO4 open / lazy 3673 3 DTC 223 TPS2 voltage high 3673 4 DTC 222 TPS2 voltage low 4236 0 DTC 1155 Closed-loop gasoline bank1 high 4236 1 DTC 1156 Closed-loop gasoline bank1 low 4237 0 DTC 171 Adaptive-learn gasoline bank1 high 4237 1 DTC 172 Adaptive-learn gasoline bank1 low 4238 0 DTC 1157 Closed-loop gasoline bank2 high 4238 1 DTC 1158 Closed-loop gasoline bank2 low 4239 0 DTC 174 Adaptive-learn gasoline bank2 high 4239 1 DTC 175 Adaptive-learn gasoline bank2 low 520197 4 DTC 332 Knock2 sensor open or not present 520197 2 DTC 331 Knock2 excessive or erratic signal 520199 11 DTC 2120 FPP1 invalid voltage and FPP2 disagrees with IVS (redundancy lost) 520199 11 DTC 2125 FPP2 invalid voltage and FPP1 disagrees with IVS (redundancy lost) 520199 11 DTC 1122 FPP1/2 do not match each other or IVS (redundancy lost)
