DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 1 Rev. 2.1, 22.10.2008 Deutz-Code / SPN / Fehlername ...............................Seite 11 / 107 / AirFltSysReac .................................................... 3 12 / 91 / APP1.................................................................... 3 14 / 91 / APPPwm.............................................................. 3 15 / 91 / APPPwmPer ........................................................ 4 16 / 108 / APSCD .............................................................. 4 17 / 729 / ArHt1.................................................................. 4 18 / 730 / ArHt2.................................................................. 5 19 / 676 / ArHtCD_NoLd.................................................... 5 20 / 676 / ArHtCD_RlyErr .................................................. 5 22 / 168 / BattCD ............................................................... 6 23 / 168 / BattCDSysReac ................................................. 6 24 / 523561 / BIPCyl1 ........................................................ 6 25 / 523562 / BIPCyl2 ........................................................ 7 26 / 523563 / BIPCyl3 ........................................................ 7 27 / 523564 / BIPCyl4 ........................................................ 7 28 / 523565 / BIPCyl5 ........................................................ 8 29 / 523566 / BIPCyl6 ........................................................ 8 30 / 523567 / BIPCyl7 ........................................................ 8 31 / 523568 / BIPCyl8 ........................................................ 9 32 / 102 / BPSCD .............................................................. 9 33 / 102 / BPSCDSysReac ................................................ 9 37 / 111 / CLSCDSysReac .............................................. 10 38 / 1323 / CmbChbMisfire1 ............................................ 10 39 / 1324 / CmbChbMisfire2 ............................................ 10 40 / 1325 / CmbChbMisfire3 ............................................ 11 41 / 1326 / CmbChbMisfire4 ............................................ 11 42 / 1327 / CmbChbMisfire5 ............................................ 11 43 / 1328 / CmbChbMisfire6 ............................................ 12 44 / 1450 / CmbChbMisfire7 ............................................ 12 45 / 1451 / CmbChbMisfire8 ............................................ 12 46 / 1322 / CmbChbMisfireMul ........................................ 13 47 / 1346 / CmbChbSysReac .......................................... 13 48 / 1109 / CoEngShOffDemIgr ....................................... 13 52 / 1072 / CRERCD ....................................................... 14 53 / 1081 / CSLpCD......................................................... 14 54 / 704 / CTLpCD........................................................... 14 55 / 110 / CTSCD ............................................................ 15 Deutz-Code / SPN / Fehlername............................... Seite 56 / 110 / CTSCDSysReac .............................................. 15 57 / 701 / Dummy1CD_Max ............................................. 15 58 / 701 / Dummy1CD_Min .............................................. 16 59 / 701 / Dummy1CD_SigNpl ......................................... 16 60 / 702 / Dummy2CD_Max ............................................. 16 61 / 702 / Dummy2CD_Min .............................................. 17 62 / 702 / Dummy2CD_SigNpl ......................................... 17 69 / 2791 / EGRCD_Max ................................................. 17 70 / 2791 / EGRCD_Min .................................................. 18 71 / 2791 / EGRCD_SigNpl.............................................. 18 72 / 2791 / EGRCDIntEGR .............................................. 18 74 / 923 / EngCDTrqCalcOut ........................................... 19 75 / 190 / EngMBackUp ................................................... 19 76 / 190 / EngMCaS1....................................................... 19 77 / 190 / EngMCrS1........................................................ 20 78 / 190 / EngMOfsCaSCrS ............................................. 20 79 / 190 / EngPrtSysReacFOC ........................................ 20 80 / 190 / EngPrtSysReacORC........................................ 21 81 / 703 / ESLpCD ........................................................... 21 82 / 1074 / ExFlCD........................................................... 21 83 / 975 / FanCD.............................................................. 22 85 / 1639 / FanCDEval ..................................................... 22 86 / 523602 / FanCDSysReac ......................................... 22 87 / 97 / FlFCD................................................................. 23 89 / 97 / FlFCD_WtLvl ...................................................... 23 90 / 94 / FlPSCD .............................................................. 23 91 / 94 / FlPSCDSysReac ................................................ 24 94 / 523239 / FrmMngDecV1 ........................................... 24 95 / 523240 / FrmMngFunModCtl .................................... 24 106 / 523212 / FrmMngTOEngPrt .................................... 25 110 / 523216 / FrmMngTOPrHtEnCmd............................ 25 112 / 523218 / FrmMngTORxCCVS ................................ 25 113 / 523604 / FrmMngTORxEngTemp........................... 26 117 / 523238 / FrmMngTOSwtOut ................................... 26 118 / 523222 / FrmMngTOTCO1 ..................................... 26 120 / 523605 / FrmMngTOTSC1AE................................. 27 121 / 523606 / FrmMngTOTSC1AR................................. 27 Deutz-Code / SPN / Fehlername ............................... Seite 122 / 523607 / FrmMngTOTSC1DE ................................ 27 123 / 523608 / FrmMngTOTSC1DR................................ 28 124 / 523609 / FrmMngTOTSC1PE ................................ 28 125 / 898 / FrmMngTOTSC1TE ...................................... 28 126 / 520 / FrmMngTOTSC1TR ...................................... 29 127 / 523610 / FrmMngTOTSC1VE ................................ 29 128 / 523611 / FrmMngTOTSC1VR ................................ 29 131 / 523500 / FrmMngTxTO .......................................... 30 133 / 174 / FTSCD........................................................... 30 134 / 174 / FTSCDSysReac ............................................ 30 136 / 523618 / GOTSCD ................................................. 31 137 / 523619 / GOTSCDSysReac ................................... 31 138 / 29 / HdThrt ............................................................. 31 139 / 1638 / HOTSCD ..................................................... 32 140 / 1638 / HOTSCDSysReac ....................................... 32 141 / 523617 / HWEMonCom.......................................... 32 142 / 630 / HWEMonEEPROM........................................ 33 143 / 523612 / HWEMonRcyLocked ............................... 33 144 / 523612 / HWEMonRcySuppressed ........................ 33 145 / 523612 / HWEMonRcyVisible ................................ 34 146 / 523612 / HWEMonUMaxSupply ............................. 34 147 / 523612 / HWEMonUMinSupply .............................. 34 149 / 105 / IATSCD ......................................................... 35 150 / 105 / IATSCDSysReac ........................................... 35 153 / 523350 / InjVlvBnk1A ............................................. 35 154 / 523351 / InjVlvBnk1B ............................................. 36 155 / 523352 / InjVlvBnk2A ............................................. 36 156 / 523353 / InjVlvBnk2B ............................................. 36 157 / 523354 / InjVlvChipA .............................................. 37 158 / 523355 / InjVlvChipB .............................................. 37 159 / 651 / InjVlvCyl1A .................................................... 37 160 / 651 / InjVlvCyl1B .................................................... 38 161 / 652 / InjVlvCyl2A .................................................... 38 162 / 652 / InjVlvCyl2B .................................................... 38 163 / 653 / InjVlvCyl3A .................................................... 39 164 / 653 / InjVlvCyl3B .................................................... 39 165 / 654 / InjVlvCyl4A .................................................... 39

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 2 Rev. 2.1, 22.10.2008 Deutz-Code / SPN / Fehlername ...............................Seite 166 / 654 / InjVlvCyl4B .................................................... 40 167 / 655 / InjVlvCyl5A .................................................... 40 168 / 655 / InjVlvCyl5B .................................................... 40 169 / 656 / InjVlvCyl6A .................................................... 41 170 / 656 / InjVlvCyl6B .................................................... 41 171 / 657 / InjVlvCyl7A .................................................... 41 172 / 657 / InjVlvCyl7B .................................................... 42 173 / 658 / InjVlvCyl8A .................................................... 42 174 / 658 / InjVlvCyl8B .................................................... 42 175 / 523370 / InjVlvErrDet.............................................. 43 176 / 523615 / MeUnCD_ADC ........................................ 43 177 / 523615 / MeUnCDNoLoad ..................................... 43 178 / 523615 / MeUnCDSCBat........................................ 44 179 / 523615 / MeUnCDSCGnd ...................................... 44 182 / 2634 / MnRly1_SCB ............................................... 44 183 / 2634 / MnRly1_SCG............................................... 45 184 / 523420 / Montr........................................................ 45 186 / 2634 / MRlyCD ....................................................... 45 187 / 563 / MRlyCDMnRly2 ............................................. 46 188 / 2634 / MRlyCDMnRly3 ........................................... 46 189 / 523450 / MSSCD1.................................................. 46 190 / 523451 / MSSCD2.................................................. 47 191 / 523452 / MSSCD3.................................................. 47 192 / 639 / NetMngCANAOff ........................................... 47 193 / 1231 / NetMngCANBOff ......................................... 48 194 / 1235 / NetMngCANCOff ......................................... 48 195 / 705 / OPLpCD ........................................................ 48 196 / 100 / OPSCD .......................................................... 49 197 / 100 / OPSCD1 ........................................................ 49 198 / 100 / OPSCDSysReacHi ........................................ 49 199 / 100 / OPSCDSysReacLo........................................ 50 200 / 1237 / OSwCD........................................................ 50 201 / 175 / OTSCD .......................................................... 50 203 / 175 / OTSCDSysReac ............................................ 51 208 / 523470 / PRVMon .................................................. 51 209 / 157 / RailCD ........................................................... 51 210 / 157 / RailCDOfsTst ................................................. 52 Deutz-Code / SPN / Fehlername............................... Seite 211 / 523613 / RailMeUn0 ............................................... 52 212 / 523613 / RailMeUn1 ............................................... 52 213 / 523613 / RailMeUn2 ............................................... 53 214 / 523613 / RailMeUn3 ............................................... 53 215 / 523613 / RailMeUn4 ............................................... 53 216 / 523613 / RailMeUn7 ............................................... 54 218 / 523490 / SOPTst..................................................... 54 219 / 1079 / SSpMon1 ..................................................... 54 221 / 1080 / SSpMon2 ..................................................... 55 222 / 523601 / SSpMon3 ................................................. 55 223 / 677 / StrtCDHS ....................................................... 55 224 / 677 / StrtCDLS ........................................................ 56 225 / 624 / SysLamp ........................................................ 56 226 / 158 / T15CD............................................................ 56 227 / 523550 / T50CD...................................................... 57 228 / 523550 / TPUMon ................................................... 57 232 / 84 / VSSCD1........................................................... 57 235 / 523600 / WdCom .................................................... 58 236 / 523470 / PRVMonSysReac .................................... 58 237 / 523006 / APPCDSwtnSel........................................ 58 238 / 523007 / FrmMng_TORxEngPress ......................... 59 239 / 523008 / MplCtl ....................................................... 59 240 / 98 / OLSCD............................................................. 59 241 / 98 / OLSCDSysReacHi ........................................... 60 242 / 107 / ADPSCDAna.................................................. 60 243 / 98 / OLSCDSysReacLo .......................................... 60 244 / 523009 / PrvMonWear ............................................ 61 245 / 523010 / RailMeUn8 ............................................... 61 246 / 523650 / FlSys_FLPFMSysReac ............................ 61 247 / 523651 / FlSys_FTSFMSysReac............................ 62 248 / 523652 / FlSys_FlushStateEngineOff ..................... 62 249 / 523653 / FlSys_RapeOilHeatEx ............................. 62 250 / 523654 / FrmMngDieselLvl ..................................... 63 251 / 523655 / FrmMngFuelTemp.................................... 63 252 / 523656 / FrmMngLowPressureDiesel ..................... 63 253 / 523657 / FrmMngRapeOilIn.................................... 64 254 / 523658 / FrmMngRapeOilLvl .................................. 64 Deutz-Code / SPN / Fehlername ............................... Seite 255 / 523659 / FrmMngRapeOilVlv1 ............................... 64 256 / 523660 / FrmMngRapeOilVlv2 ............................... 65 257 / 523661 / FrmMngRapeOilVlv3 ............................... 65 258 / 523662 / FrmMngRapeOilVlv4 ............................... 65 259 / 523663 / FrmMngRapeOilVlv5 ............................... 66 260 / 523664 / FrmMngSTIN1RX .................................... 66

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 3 Rev. 2.1, 22.10.2008 11 / 107 / AirFltSysReac Error description AIR FILTER COND. Air filter differential pressure: the pressure difference of the intake air between the filter inlet and outlet calculated by ECU is above the target range and the ECU activates a system reaction Error codes DEUTZ-Errorcode: 11 BlinkCode (short-long-short): 1 - 3 - 6 SPN: 107 possible FMI: 0: data valid, but above normal working area 12. Errormode not identifiable 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Pressure loss above target range with system reaction, air filter clogged or defective, sensor not working, connection cable demaged Take actions for error repair Check airfilter and if necessary clean or renew it, check cabling, check air filter and if necessary replace the filter component, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning or Warning and power reduction Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 2 Measurement @ errortime: actual value 12 / 91 / APP1 Error description THROTTLE 1 Analog accelerator pedal sensor 1 or double accelerator pedal sensor: the voltage measured by ECU is out of the target range or the calculated pedal position is implausible compared with the position of the second pedal Error codes DEUTZ-Errorcode: 12 BlinkCode (short-long-short): 2 - 2 - 6 SPN: 91 possible FMI: 3: Voltage to high or short circuit to +Ubatt 4: Voltage to low or short circuit to -Ubatt 12. Errormode not identifiable 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Voltage outside target range, signal implausible compared to signal of redundant pedal (analog pedal 1), sensor defective, connection cable demaged Take actions for error repair Check cabling, check accelator pedal sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning, switching to substitute value correspond to Priority-Chain or Limp Home Behaviour error lamp: permanent light Selfhealing: no Signal Priority: 4 Measurement @ errortime: actual value 14 / 91 / APPPwm Error description THROTTLE 1 Digital accelerator pedal sensor (PWM): the signal received by ECU is defective or implausible or the pulse-duty factor is out of the target range Error codes DEUTZ-Errorcode: 14 BlinkCode (short-long-short): 2 - 2 - 2 SPN: 91 possible FMI: 8: unusual frequency, pulse or period. 8: unusual frequency, pulse or period. 2: data stream is defective 8: unusual frequency, pulse or period. Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Duty cycle outside target range, signal erroneous or implausible (pedal 1), sensor defective, onnection cable demaged Take actions for error repair Check cabling, check accelator pedal sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning, switching to substitute value correspond to Priority-Chain or Limp Home Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 4 Measurement @ errortime: actual value

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 4 Rev. 2.1, 22.10.2008 15 / 91 / APPPwmPer Error description THROTTLE 1 digital accelerator pedal sensor (PWM): the frequence of the signal received by ECU is out of the target range Error codes DEUTZ-Errorcode: 15 BlinkCode (short-long-short): 2 - 2 - 2 SPN: 91 possible FMI: 8: unusual frequency, pulse or period. 8: unusual frequency, pulse or period. 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Pulse frequency outside target range (pedal 1), sensor defective, connection cable demaged Take actions for error repair Check cabling, check accelator pedal sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning, switching to substitute value correspond to Priority-Chain or Limp Home Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 4 Measurement @ errortime: actual value 16 / 108 / APSCD Error description BAROMETRIC PRESS. Ambient air pressure sensor (in ECU): the voltage measured by ECU is out of the target range or the calculated ambient air pressure is implausible compared with the charge air pressure Error codes DEUTZ-Errorcode: 16 BlinkCode (short-long-short): 2 - 9 - 2 SPN: 108 possible FMI: 3: Voltage to high or short circuit to +Ubatt 4: Voltage to low or short circuit to -Ubatt 12. Errormode not identifiable 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Ambient air pressure sensor defective, ECU defective Take actions for error repair Change ECU other error properties System reaction: Warning, substitute value (0,85bar) Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 4 Measurement @ errortime: default value 17 / 729 / ArHt1 Error description AIR HEATER RELAY Air heater relay: the current drain measured by ECU is out of the target range Error codes DEUTZ-Errorcode: 17 BlinkCode (short-long-short): 2 - 6 - 3 SPN: 729 possible FMI: 3: Voltage to high or short circuit to +Ubatt 4: Voltage to low or short circuit to -Ubatt 5: current to low or broken wire 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Cable break or short circuit at EDC output, relay defective, connection cable demaged Take actions for error repair Check cabling, if sensor not working, check relay and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning, shutoff output Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 2 Measurement @ errortime: shut off value

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 5 Rev. 2.1, 22.10.2008 18 / 730 / ArHt2 Error description AIR HEATER VALVE Air heater magnet valve: the current drain measured by ECU is out of the target range Error codes DEUTZ-Errorcode: 18 BlinkCode (short-long-short): 2 - 6 - 3 SPN: 730 possible FMI: 3: Voltage to high or short circuit to +Ubatt 4: Voltage to low or short circuit to -Ubatt 5: current to low or broken wire 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Cable break or short circuit, valve defective, connection cable demaged Take actions for error repair Check valve and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 2 Measurement @ errortime: shut off value 19 / 676 / ArHtCD_NoLd Error description AIR HEATER Air heater relay: the ECU detects no switching operation at the input of a readback process Error codes DEUTZ-Errorcode: 19 BlinkCode (short-long-short): 2 - 6 - 3 SPN: 676 possible FMI: 12. Errormode not identifiable 4: Voltage to low or short circuit to -Ubatt 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Relay energized, but no feedback on sense line, relay defective or wrong wired, preheat component defective, connection cable demaged Take actions for error repair Check cabling of preheat component, if relay not working,check relay and if necessary replace it, check preheat component and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning Behaviour error lamp: permanent light Selfhealing: no Signal Priority: 3 Measurement @ errortime: setpoint for output status 20 / 676 / ArHtCD_RlyErr Error description AIR HEATER Air heater relay: the ECU detects an implausible signal at the input of a readback process Error codes DEUTZ-Errorcode: 20 BlinkCode (short-long-short): 2 - 6 - 3 SPN: 676 possible FMI: 5: current to low or broken wire 2: data stream is defective 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Relay not energized, but working voltage on sense line, relay defective (can not disconnect or switch off), preheat component defective, connection cable demaged Take actions for error repair Check cabling of preheat component, if relay not working,check relay and if necessary replace it, check preheat component and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning Behaviour error lamp: permanent light Selfhealing: no Signal Priority: 3 Measurement @ errortime: setpoint for output status

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 6 Rev. 2.1, 22.10.2008 22 / 168 / BattCD Error description BATTERY VOLTAGE Battery voltage: the voltage measured by ECU is out of the target range Error codes DEUTZ-Errorcode: 22 BlinkCode (short-long-short): 3 - 1 - 8 SPN: 168 possible FMI: 0: data valid, but above normal working area 1: data valid, but below normal working area 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Voltage below target range, battery defective, too high power supply voltage, too high contact resistance, wiring demaged, energie system overloaded, parametering inaccurate, ECU defective Take actions for error repair Check LIMA?, ECU, cabling, contact resistance, safety fuses, too high load in energy system, check battery and if necessary replace it, check battery pole and if necessary clean it, check connection cable and if necessary repair or replace it, check volta other error properties System reaction: Warning, substitute value, dependent upon supply voltage (12V, 24V) Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value 23 / 168 / BattCDSysReac Error description BATTERY VOLTAGE Battery voltage: the voltage measured by ECU is out of the target range; the ECU activates a system reaction Error codes DEUTZ-Errorcode: 23 BlinkCode (short-long-short): 3 - 1 - 8 SPN: 168 possible FMI: 2: data stream is defective 2: data stream is defective 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Above target range with system reaction, too high power supply voltage, parametering inaccurate, ECU defective Take actions for error repair Check dataset of calibration of working voltage for application, check LIMA? Check voltage of generator, check the parameters and if necessary correct them, replace ECU other error properties System reaction: Warning Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 4 Measurement @ errortime: actual value 24 / 523561 / BIPCyl1 Error description INJECT. PERIOD ZYL.1 Begin of injection of cylinder 1: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 24 BlinkCode (short-long-short): 5 - 3 - 1 SPN: 523561 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 1), magnet valve or injection pump defective Take actions for error repair Check magnetic valve or injection pump and if necessary change them other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 7 Rev. 2.1, 22.10.2008 25 / 523562 / BIPCyl2 Error description INJECT. PERIOD ZYL.2 Begin of injection of cylinder 2: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 25 BlinkCode (short-long-short): 5 - 3 - 2 SPN: 523562 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 2), magnet valve or injection pump defective Take actions for error repair Check magnetic valve or injection pump and if necessary change them other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value 26 / 523563 / BIPCyl3 Error description INJECT. PERIOD ZYL.3 Begin of injection of cylinder 3: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 26 BlinkCode (short-long-short): 5 - 3 - 3 SPN: 523563 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 3), magnet valve or injection pump defective Take actions for error repair Check magnetic valve or injection pump and if necessary change them other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value 27 / 523564 / BIPCyl4 Error description INJECT. PERIOD ZYL.4 Begin of injection of cylinder 4: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 27 BlinkCode (short-long-short): 5 - 3 - 4 SPN: 523564 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 4), magnet valve or injection pump defective Take actions for error repair d other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 8 Rev. 2.1, 22.10.2008 28 / 523565 / BIPCyl5 Error description INJECT. PERIOD ZYL.5 Begin of injection of cylinder 5: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 28 BlinkCode (short-long-short): 5 - 3 - 5 SPN: 523565 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 5), magnet valve or injection pump defective Take actions for error repair Check magnetic valve or injection pump and if necessary change them other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value 29 / 523566 / BIPCyl6 Error description INJECT. PERIOD ZYL.6 Begin of injection of cylinder 6: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 29 BlinkCode (short-long-short): 5 - 3 - 6 SPN: 523566 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 6), magnet valve or injection pump defective Take actions for error repair Check magnetic valve or injection pump and if necessary change them other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value 30 / 523567 / BIPCyl7 Error description INJECT. PERIOD ZYL.7 Begin of injection of cylinder 7: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 30 BlinkCode (short-long-short): 5 - 3 - 7 SPN: 523567 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 7), magnet valve or injection pump defective Take actions for error repair Check magnetic valve or injection pump and if necessary change them other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 9 Rev. 2.1, 22.10.2008 31 / 523568 / BIPCyl8 Error description INJECT. PERIOD ZYL.8 Begin of injection of cylinder 8: the ECU can not identify the magnet valve or the injection pump with the measured value of current drain at the begin of the injection Error codes DEUTZ-Errorcode: 31 BlinkCode (short-long-short): 5 - 3 - 8 SPN: 523568 possible FMI: 2: data stream is defective 2: data stream is defective 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Value outside target range or missing (cylinder 8), magnet valve or injection pump defective Take actions for error repair Check magnetic valve or injection pump and if necessary change them other error properties System reaction: No function at the moment/ Allocation check cylinder! Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 3 Measurement @ errortime: actual value 32 / 102 / BPSCD Error description CHARGE AIR PRESS. Charge air pressure sensor: the measured voltage of sensor by ECU is out of the target range; the calculated charge air pressure is implausible or the received value via CAN is defective Error codes DEUTZ-Errorcode: 32 BlinkCode (short-long-short): 2 - 2 - 3 SPN: 102 possible FMI: 3: Voltage to high or short circuit to +Ubatt 4: Voltage to low or short circuit to -Ubatt 2: data stream is defective 2: data stream is defective Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Cable break or short circuit, sensor defective, onnection cable demaged Take actions for error repair Check cabling, if LDF6T sensor not working, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Warning, substitute value Behaviour error lamp: permanent light Selfhealing: yes Signal Priority: 4 Measurement @ errortime: default value 33 / 102 / BPSCDSysReac Error description CHARGE AIR PRESS. Charge air pressure: the charge air pressure calculated by ECU is above the target range; the ECU activates a system reaction Error codes DEUTZ-Errorcode: 33 BlinkCode (short-long-short): 2 - 2 - 3 SPN: 102 possible FMI: 2: data stream is defective 2: data stream is defective 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light oder blinking. Entry in errormemory. Possible reason for error Outside target range with system reaction, air system demaged, sensor defective, onnection cable demaged Take actions for error repair Check air system, inspect air system and if necessary repair it, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Advice: BPSCD_stSysReacReq Behaviour error lamp: permanent light oder blinking Selfhealing: yes Signal Priority: 4 Measurement @ errortime: actual value

DTC-List Diagnosis- and Errorcodes referrenced ECU-Software P490_: 220, 310, 501 P491_: 220, 310, 400, 501 P492_: 213 P513_: 214, 300 DEUTZ AG, TE-CE, Fi Seite 10 Rev. 2.1, 22.10.2008 37 / 111 / CLSCDSysReac Error description ENG COOLANT LEVEL Coolant level: the coolant level calculated by ECU is underneath the allowed minimum Error codes DEUTZ-Errorcode: 37 BlinkCode (short-long-short): 2 - 3 - 5 SPN: 111 possible FMI: 1: data valid, but below normal working area 1: data valid, but below normal working area 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light oder blinking. Entry in errormemory. Possible reason for error Outside target range with system reaction, cooling system untight, sensor defective, onnection cable demaged Take actions for error repair Check coolant level, check cabling, inspect cooling system and if necessary repair it, check sensor and if necessary replace it, check connection cable and if necessary repair or replace it other error properties System reaction: Advice: CLSCD_stSysReacReq Behaviour error lamp: permanent light oder blinking Selfhealing: no Signal Priority: 3 Measurement @ errortime: actual value 38 / 1323 / CmbChbMisfire1 Error description MISFIRE CYL. 1 Misfire at cylinder 1: the number of the misfire detected by ECU is out of the allowed limit value Error codes DEUTZ-Errorcode: 38 BlinkCode (short-long-short): 2 - 4 - 1 SPN: 1323 possible FMI: 12: Defective component 12. Errormode not identifiable 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Misfire detected (cylinder 1), magnet valve or injection pump defective, fuel system defective, motor engineering demaged Take actions for error repair Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it other error properties System reaction: Behaviour error lamp: permanent light Selfhealing: no Signal Priority: 0 Measurement @ errortime: actual value 39 / 1324 / CmbChbMisfire2 Error description MISFIRE CYL. 2 Misfire at cylinder 2: the number of the misfire detected by ECU is out of the allowed limit value Error codes DEUTZ-Errorcode: 39 BlinkCode (short-long-short): 2 - 4 - 1 SPN: 1324 possible FMI: 12: Defective component 12. Errormode not identifiable 12. Errormode not identifiable 12. Errormode not identifiable Errordetection Errorlamp shows permanent light. Entry in errormemory. Possible reason for error Misfire detected (cylinder 2), magnet valve or injection pump defective, fuel system defective, motor engineering demaged Take actions for error repair Check magnetic valve or injection pump and if necessary replace them, check fuel system and if necessary repair it, check motor engineering and if necessary repair it other error properties System reaction: Behaviour error lamp: permanent light Selfhealing: no Signal Priority: 0 Measurement @ errortime: actual value
