Detroit Diesel Series 60 EGR Technical Manual

The Series 60 EGR Technician's Guide is designed for qualified service technicians familiar with Detroit Diesel electronically controlled (DDEC) diesel engines. It aims to enhance understanding of the EGR system for improved diagnosis of a Series 60® EGR system.

This manual should be used alongside the DDEC III/IV Single ECM Troubleshooting Guide and the DDEC V Single ECM Troubleshooting Guide.

APPLICABLE MODELS :

• Detroit Diesel Series 60 EGR

TABLE OF CONTENTS :

• 1 INTRODUCTION
• 2 COMPONENTS
• 3 MODES
• 4 CODES
• 5 DDEC IV TESTING
• 6 DDDL/SNAPSHOTS
• 7 SNAPSHOT EXAMPLES
• 8 DDEC V COMPONENTS
• 9 DDEC V CODES
• 10 DDEC V TESTING
• APPENDIX A: LIST OF ACRONYMS
• APPENDIX B: DDEC IV WIRING SCHEMATICS
• APPENDIX C: ENGINE DIAGNOSTIC QUESTIONNAIRE
• APPENDIX D: SERVICE INFORMATION LETTERS

Compatible: Windows & Mac

Language: English

Requirements: Reader

Total pages: 135

This manual contains specifications, diagrams, actual real photo illustrations, and schemes. In addition to space savings, the advantage of having files instead of a hard-printed manual is the ability to use the Search feature in Acrobat to find specific information and print out the exact pages needed.

→ All pages are printable, allowing for easy access in the garage or workshop.

→ This Manual is compatible with all versions of Windows PC OS, MAC OS, and Linux OS.

→ A compression utility is needed to extract it first if located in the archive (e.g. 7- ).
