Samsung UN60D6000 UN55D6000 UN46D6000 UN40D6000 UN32D6000 Service Manual

5. Wiring Diagram 5-1. Wiring Diagram For common Function T-CON Main Board Speaker IP Board CN201 CN1601 Speaker CM803 CNI802 CN1201 CN301 5-1 5. Wiring Diagram

5-2. Connector For common CN1405_FHD (to Panel) 1 N.C(HVS for LCD) 42 Ch1[0]- 2 LUT_SELECT1 43 GND 3 TCON_EEPROM_WP 44 GND 4 BLACK_INS_SYNC 45 GND 5 TCON_RESET 46 N.C. 6 NC 47 Panel_VCC 7 NC 48 Panel_VCC 8 SDA_I(for 49 Panel_VCC 9 WP(EEPROM) 50 Panel_VCC 10 LUT_SELECT0 51 Panel_VCC 11 3D_ENABLE 52 GND 12 SCL_I(for 53 Ch2[0]- 13 GND 54 Ch2[0]+ 14 Ch3[4]+ 55 Ch2[1]- 15 Ch3[4]- 56 Ch2[1]+ 16 Ch3[3]+ 57 Ch2[2]- 17 Ch3[3]- 58 Ch2[2]+ 18 GND 59 GND 19 Ch3CLK+ 60 Ch2CLK- 20 Ch3CLK- 61 Ch2CLK+ 21 GND 62 GND 22 Ch3[2]+ 63 Ch2[3]- 23 Ch3[2]- 64 Ch2[3]+ 24 Ch3[1]+ 65 Ch2[4]- 25 Ch3[1]- 66 Ch2[4]+ 26 Ch3[0]+ 67 GND 27 Ch3[0]- 68 Ch4[0]- 28 GND 69 Ch4[0]+ 29 Ch1[4]+ 70 Ch4[1]- 30 Ch1[4]- 71 Ch4[1]+ 31 Ch1[3]+ 72 Ch4[2]- 32 Ch1[3]- 73 Ch4[2]+ 33 GND 74 GND 34 Ch1CLK+ 75 Ch4CLK- 35 Ch1CLK- 76 Ch4CLK+ 36 GND 77 GND 37 Ch1[2]+ 78 Ch4[3]- 38 Ch1[2]- 79 Ch4[3]+ 39 Ch1[1]+ 80 Ch4[4]- 40 Ch1[1]- 81 Ch4[4]+ 41 Ch1[0]+ 82 GND CN602(to HDMI1) 1 HDMI1_RX2+ 10 HDMI1_RXCLK+ 2 GND 11 GND 3 HDMI1_RX2- 12 HDMI1_RXCLK- 4 HDMI1_RX1+ 13 HDMI_CEC 5 GND 14 GND 6 HDMI1_RX1- 15 HDMI1_DDC_SCL 7 HDMI1_RX0+ 16 HDMI1_DDC_SDA 8 GND 17 GND 9 HDMI1_RX0- 18 HDMI1_5V CN603(to HDMI2) 1 HDMI2_RX2+ 10 HDMI2_RXCLK+ 2 GND 11 GND 3 HDMI2_RX2- 12 HDMI2_RXCLK- 4 HDMI2_RX1+ 13 HDMI_CEC 5 GND 14 GND 6 HDMI2_RX1- 15 HDMI2_DDC_SCL 7 HDMI2_RX0+ 16 HDMI2_DDC_SDA 8 GND 17 GND 9 HDMI2_RX0- 18 HDMI2_5V CN604(to HDMI3) 1 HDMI3_RX2+ 10 HDMI3_RXCLK+ 2 GND 11 GND 3 HDMI3_RX2- 12 HDMI3_RXCLK- 4 HDMI3_RX1+ 13 HDMI_CEC 5 GND 14 GND 6 HDMI3_RX1- 15 HDMI3_DDC_SCL 7 HDMI3_RX0+ 16 HDMI3_DDC_SDA 8 GND 17 GND 9 HDMI3_RX0- 18 HDMI3_5V CN601(to HDMI4) 1 HDMI4_RX2+ 10 HDMI4_RXCLK+ 2 GND 11 GND 3 HDMI4_RX2- 12 HDMI4_RXCLK- 4 HDMI4_RX1+ 13 HDMI_CEC 5 GND 14 GND 6 HDMI4_RX1- 15 HDMI4_DDC_SCL 7 HDMI4_RX0+ 16 HDMI4_DDC_SDA 8 GND 17 GND 9 HDMI4_RX0- 18 HDMI4_5V 5-2 5. Wiring Diagram

CN402(to PC Sound) 1 GND 4 PC_SL_IN 2 PC_SR_IN 5 NC 3 PC_SL_IN CN301(to Speaker) 1 R+ 3 L+ 2 R- 4 L- CN303(to Optical Jack) 1 VCC 3 GND 2 SPDIF_OUT CN1502(to Side USB1) 1 USB0_VCC_PW 3 USB_DP 2 USB0_DM 4 GND CN1501(to Side USB2) 1 USB2_VCC_PW 3 USB2_DP 2 USB2_DM 4 GND CN1505(to Side USB3) 1 USB3_VCC_PW 3 USB3_DP 2 USB3_DM 4 GND CN802(to Monitor OUT) 1 GND 4 HP_ID 2 NC 5 GND 3 HP_SR 6 HP_SL CN501(to Component1/AV1) 1 GND 6 GND 2 COMP1_Y 7 IDENT_COMP1 3 COMP1_PB 8 COMP_AV1_SL_IN 4 IDENT_COMP_AV1 9 COMP_AV1_SR_IN 5 COMP1_PR CN401(to Function/IR) 1 IR 5 MSDA_A5V 2 GND 6 WAKE 3 A3.3V_PW 7 LED_STB 4 MSCL_A5V 8 NC CN201(to Power Board) 1 B5V_PW 11 B13V_PW 2 SW_POWER 12 B13V_PW 3 B5V_PW 13 B13V_PW 4 A5V_PW 14 PWM_DIMMING 5 GND 15 GND 6 GND 16 PWM_DIMMING_ CPLD2 7 B18VS_PW 17 OVD_ON 8 GND 18 PWM_DIMMING_ CPLD3 9 B18VS_PW 19 OVD_LEVEL 10 SW_INVERTER 20 PWM_DIMMING_ CPLD4 5-3 5. Wiring Diagram

5-3. Connector Functions Connector Functions CN201 CN802 Supply power from SMPS to Main Board. CN1401 CN505 The LVDS signal transfered from Main Board to Panel. 5-4. Cables For common Use Main-SMPS Main-Tcon Code 32" BN39-01267E (250mm) 40" BN39-01267N (225mm) 46" BN39-01267N (225mm) 55" BN39-01267E (250mm) 32" BN96-12723J 40" BN96-12723L 46" BN96-12723M 55" BN96-12723N Photo 5-4 5. Wiring Diagram
