PARTS CATALOG
LBP3000/3000B/2900/2900i/
2900B
PREFACE
This Parts Catalog contains listings of parts used
Diagrams are provided with the listings to aid the service technician in identifying clearly, the
item to be orderd.
Whenever ordering parts, consult this Parts Catalog for all of the information pertaining to each
item. Be sure to include, in the Parts Request, the full item description, the item part number,
and the quantity.
COPYRIGHT (C) 1999 CANON INC.
Use of this manual should be
strictly supervised to avoid
disclosure of confidential
information.
Contents
NUMERICAL INDEX
LBP3000/3000B/2900/2900i/2900B(Numerical Index) ...................... 1-1
LBP3000/3000B/2900/2900i/2900B(Parts Catalog)
A ASSEMBLY LOCATION DIAGRAM ...................................... 2-1
001 DISK UNIT ............................................................................. 2-2
100 EXTERNAL COVERS ............................................................ 2-4
101 INTERNAL COMPONENTS 1 ............................................... 2-6
102 INTERNAL COMPONENTS 2 ............................................... 2-9
103 INTERNAL COMPONENTS 3 ............................................. 2-11
104 BASE PLATE ASS'Y ............................................................ 2-14
310 PAPER PICK-UP ASS'Y ...................................................... 2-16
810 FIXING ASS'Y ...................................................................... 2-19
1-1
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO
NUMERICAL INDEX
LBP3000/3000B/2900/2900i/2900B(Numerical Index)
FC1-4820-000 100 - 6
NPN 001 -
NPN 100 -
NPN 101 -
NPN 102 -
NPN 103 -
NPN 104 -
RA0-1019-000 103 - 1
RA0-1060-000 101 - 9
RC1-1953-000 103 - 2
RC1-1954-000 103 - 3
RC1-1955-000 103 - 4
RC1-1956-000 103 - 5
RC1-1957-000 103 - 6
RC1-1959-000 103 - 7
RC1-1960-000 310 - 1
RC1-1964-000 103 - 8
RC1-1987-000 104 - 1
RC1-1989-000 310 - 2
RC1-1990-000 310 - 3
RC1-1993-000 310 - 4
RC1-1994-000 310 - 5
RC1-1996-000 310 - 6
RC1-1999-000 102 - 1
RC1-2005-000 101 - 2
RC1-2007-000 102 - 2
RC1-2012-000 310 - 7
RC1-2029-000 310 - 19
RC1-2039-000 310 - 8
RC1-2040-000 310 - 9
RC1-2041-000 310 - 10
RC1-2042-000 310 - 11
RC1-2043-000 310 - 12
RC1-2044-000 310 - 13
RC1-2049-000 310 - 14
RC1-2061-000 310 - 15
RC1-2066-000 810 - 1
RC1-2067-000 810 - 2
RC1-2069-000 810 - 3
RC1-2070-000 810 - 4
RC1-2079-000 810 - 5
RC1-2097-000 810 - 7
RC1-2098-000 810 - 8
RC1-2098-000 810 - 8
RC1-2101-000 810 - 9
RC1-2102-000 810 - 10
RC1-2103-000 810 - 11
RC1-2106-020 101 - 3
RC1-2108-000 810 - 6
RC1-2116-020 102 - 3
RC1-2117-000 103 - 9
RC1-2120-000 102 - 4
RC1-2121-020 102 - 5
RC1-2135-000 810 - 12
RC1-2139-000 810 - 13
RC1-3004-000 100 - 6
RC1-5521-000 101 - 2
RC1-5570-000 810 - 21
RC1-5571-000 810 - 6
RC1-5875-000 100 - 8
RC1-6194-000 100 - 1
RC1-6199-000 100 - 9
RC1-6214-000 100 - 12
RC1-6215-000 100 - 7
RC1-6217-000 100 - 6
RC1-6218-000 100 - 1
RC1-6221-000 100 - 8
RC1-6223-000 103 - 10
RC1-6223-000 103 - 24
RC1-6979-000 101 - 19
RC1-6980-000 101 - 20
RH9-1015-000 101 - 12
RH9-1162-000 101 - 12
RH9-1163-000 101 - 13
RH9-1164-000 101 - 12
RH9-1166-000 101 - 12
RH9-1168-000 101 - 12
RH9-1168-000 101 - 12
RH9-1169-000 101 - 12
RH9-1170-000 101 - 12
RH9-1170-000 101 - 12
RH9-1170-000 101 - 12
RK2-0107-000 101 - 4
RK2-0108-000 310 - 16
RK2-0778-000 310 - 16
RK2-0799-000 101 - 4
RK2-1025-000 001 - 1
RK2-1026-000 001 - 1
RK2-1027-000 001 - 1
RK2-1136-000 001 - 1
RK2-1137-000 001 - 1
RK2-1258-000 001 - 1
RK2-1259-000 001 - 1
RK2-1260-000 001 - 1
RK2-1261-000 001 - 1
RK2-1262-000 001 - 1
RK2-1302-000 101 - 18
RK2-1848-000 001 - 1
RL1-0266-000 310 - 17
RL1-0268-000 310 - 18
RL1-0269-000 101 - 1
RL1-0270-000 810 - 14
RL1-0274-000 103 - 11
RL1-0275-000 104 - 2
RL1-0905-000 100 - 2
RL1-0908-000 100 - 5
RL1-0909-000 100 - 5
RM1-0171-000 102 - 6
RM1-0634-000 103 - 12
RM1-0640-000 104 - 5
RM1-0641-000 310 -
RM1-0642-000 310 - 20
RM1-0644-000 310 - 21
RM1-0645-000 310 - 22
RM1-0647-020 101 - 5
RM1-0648-000 101 - 6
RM1-0650-040 810 - 15
RM1-0651-020 810 - 16
RM1-0656-040 810 - 15
RM1-0658-000 101 - 7
RM1-0660-000 810 -
RM1-0661-000 810 -
RM1-0806-050 102 - 7
RM1-0807-040 101 - 8
RM1-0808-040 101 - 8
RM1-0809-000 101 - 10
RM1-0810-000 101 - 11
RM1-2051-000 810 - 15
RM1-2052-020 810 - 15
RM1-2086-000 810 -
RM1-2087-010 810 -
RM1-2091-020 310 -
RM1-2092-000 810 - 16
RM1-2093-000 101 - 7
RM1-2312-000 101 - 10
RM1-2313-000 101 - 11
RM1-2314-000 102 - 7
RM1-2315-000 101 - 8
RM1-2316-000 101 - 8
RM1-2317-000 810 - 22
RM1-2391-000 100 - 4
RM1-2393-000 100 - 3
RM1-2395-000 104 - 3
RM1-2397-000 104 - 4
RM1-2399-000 100 - 3
RM1-2401-000 100 - 3
RM1-3125-000 103 - 25
RM1-3126-000 103 - 25
RM1-3956-000 102 - 6
RM1-4087-000 103 - 25
RM1-4087-000 103 - 25
RM1-4088-000 103 - 25
RM1-4088-000 103 - 25
RM1-4737-000 100 - 3
RM1-4738-000 100 - 3
RU5-0173-000 103 - 13
1-2
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO
NUMERICAL INDEX
LBP3000/3000B/2900/2900i/2900B(Numerical Index)
RU5-0174-000 103 - 14
RU5-0175-000 103 - 15
RU5-0176-000 103 - 16
RU5-0177-000 103 - 17
RU5-0178-000 103 - 18
RU5-0179-000 103 - 19
RU5-0180-000 310 - 23
RU5-0185-000 810 - 18
RU5-0186-000 810 - 19
RU5-2173-000 103 - 20
RU5-2174-000 103 - 21
RU5-2174-000 310 - 24
RU5-2177-000 102 - 8
RU5-2178-000 810 - 20
VD7-1791-002 101 - FU101
VD7-3111-002 101 - FU101
XA9-1420-000 101 - 14
XA9-1420-000 102 - 9
XA9-1469-000 100 - 10
XA9-1469-000 103 - 22
XA9-1469-000 103 - 26
XA9-1495-000 101 - 15
XA9-1495-000 102 - 10
XA9-1495-000 103 - 23
XA9-1495-000 104 - 6
XA9-1500-010 100 - 11
XA9-1500-010 102 - 11
XA9-1503-000 310 - 25
XB2-6400-607 101 - 17
XB2-8300-609 810 - 17
XB4-5401-009 101 - 16
XB4-5401-009 310 - 26
LBP3000/3000B/2900/2900i/
2900B(Parts Catalog)
LBP3000
100V R72-8544-
000
LLJA
120V R72-8554-
000
JLHA
220V R72-8558-
000
KMXA EUR/UK/ASIA/AU
220V R72-8558-
000
LMCA000001- ASIA
220V R72-8558-
000
LMDA000001- GB
220V R72-8558-
000
LMEA000001- AU
220V R72-8568-
000
KMYA CN
100V R72-8624-
000
LPCA
120V R72-8634-
000
LPDA
220V EUR R72-8638-
000
LPEA
220V ASIA R72-8638-
000
LPGA
220V DE R72-8638-
000
LPHA
220V AU R72-8638-
000
LPJA
220V R72-8648-
000
LPFA000001- CN
LBP2900
LBP2900i
LBP2900B
LBP3000B
220V R72-8658-
000
KMKA EUR/UK/ASIA/AU
220V R72-8658-
000
LMLA000001- GB 12
220V R72-8658-
000
LMMA000001- ASIA 12
220V R72-8658-
000
LMNA000001- AU 12
220V CN R72-8668-
000
LMPA CN
220V R72-8678-
000
LPLA000001- GB 12
220V R72-8678-
000
LPMA000001- ASIA 12
220V R72-8678-
000
LPNA000001- AU 12
220V CN R72-8688-
000
LPPA CN
230V R72-9048-
000
LSFA000001-
230V R72-9388-
000
LXLA EUR
100V R72-9384-
000
MABA
