Jun 1 2007
PARTS CATALOG
imageCLASS MF4150/
MF4140/MF4122/MF4120/i-
SENSYS MF4150/MF4140/
MF4120
PREFACE
This Parts Catalog contains listings of parts used
Diagrams are provided with the listings to aid the service technician in identifying clearly, the
item to be orderd.
Whenever ordering parts, consult this Parts Catalog for all of the information pertaining to each
item. Be sure to include, in the Parts Request, the full item description, the item part number,
and the quantity.
COPYRIGHT (C) 1999 CANON INC.
Use of this manual should be
strictly supervised to avoid
disclosure of confidential
information.
Contents
NUMERICAL INDEX
imageCLASS MF4150/MF4140/MF4122/MF4120/i-SENSYS MF4150/
MF4140/MF4120(Numerical Index) ................................................... 1-1
imageCLASS MF4150/MF4140/MF4122/MF4120/i-SENSYS MF4150/
MF4140/MF4120(Parts Catalog)
A ASSEMBLY LOCATION DIAGRAM ...................................... 2-1
001 ACCESSORIES ..................................................................... 2-2
100 EXTERNAL COVERS, PANELS, ETC. ................................. 2-3
101 INTERNAL COMPONENTS 1 ............................................... 2-6
102 INTERNAL COMPONENTS 2 ............................................... 2-8
103 INTERNAL COMPONENTS 3 ............................................. 2-10
104 BASE PLATE ASS'Y ............................................................ 2-13
310 PAPER PICK-UP ASS'Y ...................................................... 2-15
400 READER ASS'Y ................................................................... 2-17
810 FIXING ASS'Y ...................................................................... 2-19
A10 ADF ASS'Y (MF4150/4130) ................................................. 2-21
1-1
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO
NUMERICAL INDEX
imageCLASS MF4150/MF4140/MF4122/MF4120/i-SENSYS MF4150/MF414
FC5-4820-000 100 - 13
FC6-5204-000 100 - 1
FC6-5210-000 102 - 5
FC6-5210-000 103 - 22
FC7-3544-000 A10 - 1
FC7-3548-000 A10 - 10
FC7-3549-000 A10 - 2
FC7-3553-000 400 - 12
FC7-3554-000 100 - 4
FC7-3557-000 810 - 1
FC7-3558-000 101 - 1
FC7-3561-010 100 - 6
FC7-3566-010 100 - 7
FC7-3573-000 100 - 27
FC7-3596-000 100 - 23
FC7-3597-000 100 - 24
FC7-3598-000 100 - 25
FC7-3615-000 400 - 1
FC7-3616-000 400 - 2
FC7-3623-000 400 - 3
FC7-3630-000 400 - 4
FC7-3637-000 A10 - 8
FC7-3638-000 100 - 11
FC7-3639-000 100 - 18
FC7-3641-000 810 - 2
FC7-3642-000 810 - 3
FC7-3643-000 810 - 4
FC7-3644-000 810 - 5
FC7-3645-000 810 - 6
FC7-3646-000 102 - 7
FC7-3647-000 103 - 20
FC7-3648-000 100 - 9
FC7-3649-000 100 - 10
FC7-3652-000 810 - 7
FC7-3653-000 103 - 21
FC7-3656-000 100 - 19
FC7-3657-000 100 - 20
FC7-3666-000 102 - 4
FC7-3679-000 101 - 2
FC7-3690-000 103 - 8
FC7-3700-000 102 - 2
FC7-3702-000 A10 - 9
FC7-3710-000 100 - 11
FC7-3711-000 100 - 11
FC7-3712-000 100 - 11
FC7-3713-000 400 - 5
FC7-3714-000 100 - 12
FC7-3726-000 100 - 26
FC7-3727-000 101 - 17
FC7-3728-000 100 - 13
FC7-3729-000 100 - 14
FC7-3741-000 A10 - 1
FC7-3742-000 A10 - 2
FC7-3743-000 100 - 6
FC7-3744-000 100 - 7
FC7-3751-000 100 - 15
FC7-3752-000 100 - 15
FC7-3753-000 100 - 15
FC7-3764-010 100 - 29
FC7-3765-000 102 -
FC7-3766-000 100 -
FC7-3767-000 102 -
FC7-3788-000 100 - 28
FC7-3813-000 310 - 11
FC7-3817-000 100 - 30
FC7-3827-000 100 -
FK2-1311-000 101 - 13
FK2-1313-000 101 - 12
FK2-1314-000 101 - 14
FK2-1316-000 101 - 16
FK2-1317-000 101 - 15
FK2-2869-000 400 - 6
FK2-3049-000 103 - 48
FK2-3492-000 101 - 9
FK2-3494-000 101 - 9
FK2-3502-000 101 - 9
FK2-3506-000 103 - 39
FK2-3508-000 310 - 1
FK2-3510-000 103 - 11
FK2-3516-000 400 - 7
FK2-3517-000 400 - 8
FK2-3698-000 103 - 5
FK2-3699-000 103 - 5
FK2-3702-000 103 - 42
FK2-3703-000 103 - 42
FK2-3704-000 103 - 42
FK2-4389-000 001 - 4
FK2-4390-000 101 - 18
FK2-4391-000 001 - 3
FK2-4558-000 001 - 1
FK2-4560-000 001 - 1
FK2-4561-000 001 - 7
FK2-4647-000 001 - 1
FK2-5232-000 101 -
FK2-5233-000 001 - 1
FK2-5790-000 103 - 42
FL2-5620-000 100 - 3
FL2-5621-000 400 - 9
FL2-5626-000 100 - 2
FL2-5629-000 101 - 3
FM2-8861-000 A10 - 4
FM2-8862-000 A10 - 5
FM2-8864-000 A10 - 6
FM2-8865-000 A10 - 7
FM2-8867-000 400 -
FM2-8868-000 400 - 10
FM2-8869-000 100 - 21
FM2-8870-000 100 - 16
FM2-8871-000 310 -
FM2-8872-000 310 - 2
FM2-8874-000 101 - 6
FM2-8876-000 104 - 1
FM2-8877-000 104 - 2
FM2-8879-000 103 - 12
FM2-8882-000 102 - 3
FM2-8883-000 100 - 17
FM2-8884-010 102 - 13
FM2-8885-000 810 - 8
FM2-8890-000 810 -
FM2-8891-000 810 -
FM2-8892-000 810 -
FM2-8897-000 100 - 21
FM2-8898-000 100 - 21
FM2-8899-000 100 - 21
FM2-8900-000 100 - 21
FM2-8901-000 100 - 21
FM2-8902-000 100 - 21
FM2-8903-000 100 - 21
FM2-8904-000 100 - 21
FM2-8905-000 100 - 21
FM2-8906-000 100 - 21
FM2-8907-000 100 - 5
FM2-8908-000 100 - 22
FM2-8910-000 104 - 3
FM2-8911-000 310 - 3
FM2-8912-000 101 - 5
FM2-8913-000 400 -
FM2-8914-000 101 - 7
FM2-8915-000 810 - 9
FM2-8916-000 810 - 9
FM2-8917-000 810 - 9
FM2-8918-000 100 - 21
FM2-8919-000 100 - 21
FM2-8920-000 100 - 21
FM2-8922-000 100 - 21
FM2-8923-000 100 - 8
FM2-8924-000 100 - 8
FM2-9907-000 102 - 6
FM2-9909-000 102 - 12
FM2-9910-000 101 - 8
FM2-9911-000 101 - 8
FM2-9912-000 101 - 8
FM2-9914-000 101 - 10
FM2-9916-000 101 - 11
FM2-9925-000 103 - 49
FM2-9926-000 103 - 50
1-2
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO
NUMERICAL INDEX
imageCLASS MF4150/MF4140/MF4122/MF4120/i-SENSYS MF4150/MF414
FM2-9929-000 103 - 51
FM3-0255-000 810 - 10
FM3-2185-000 103 - 5
FM3-2186-000 103 - 5
FU5-1804-000 102 - 9
FU5-1805-000 102 - 10
FU6-2254-000 103 - 27
FU6-2255-000 103 - 28
FU6-2255-000 310 - 14
FU6-2875-000 810 - 11
FU7-0538-000 103 - 29
FU7-0539-000 103 - 30
FU7-0540-000 103 - 31
FU7-0541-000 103 - 23
FU7-0542-000 103 - 32
FU7-0543-000 103 - 33
FU7-0544-000 103 - 25
FU7-0545-000 103 - 34
FU7-0546-000 103 - 40
FU7-0547-000 103 - 41
HB1-4978-000 001 - 5
HC1-2012-000 001 - 6
HC1-2034-000 001 - 2
HH2-2824-000 103 - 43
HK1-0544-000 103 - 46
HK1-0547-000 103 - 44
HK1-0550-000 103 - 45
HK1-0559-000 103 - 47
NPN 001 -
NPN 100 -
NPN 101 -
NPN 102 -
NPN 103 -
NPN 104 -
NPN A10 -
RA0-1019-000 103 - 1
RA0-1172-000 103 - 18
RC1-1953-000 103 - 2
RC1-1954-000 103 - 3
RC1-1955-000 103 - 4
RC1-1957-000 103 - 6
RC1-1959-000 103 - 7
RC1-1960-000 310 - 4
RC1-1990-000 310 - 5
RC1-1993-000 310 - 6
RC1-1994-000 310 - 7
RC1-1999-000 102 - 1
RC1-2012-000 310 - 8
RC1-2040-000 310 - 9
RC1-2041-000 310 - 10
RC1-2043-000 310 - 12
RC1-2044-000 310 - 13
RC1-2066-000 810 - 12
RC1-2067-000 810 - 13
RC1-2079-000 810 - 14
RC1-2097-000 810 - 15
RC1-2098-000 810 - 16
RC1-2139-000 810 - 17
RC1-3579-000 103 - 26
RC1-5550-000 310 - 15
RC1-5551-000 310 - 16
RC1-5552-000 310 - 17
RC1-5553-000 310 - 18
RC1-5572-000 810 - 18
RK2-0777-000 103 - 24
RL1-0266-000 310 - 19
RL1-0268-000 310 - 20
RM1-2046-000 310 - 21
RU5-0174-000 103 - 14
RU5-0175-000 103 - 15
RU5-0176-000 103 - 16
RU5-0179-000 103 - 19
RU5-0180-000 310 - 22
RU5-0312-000 103 - 35
RU5-0313-000 103 - 36
RU5-0314-000 103 - 37
RU5-0315-000 103 - 38
RU5-0503-000 103 - 10
RU5-0505-000 103 - 13
RU5-0506-000 103 - 17
RU5-0523-000 810 - 19
RU5-2178-000 810 - 20
RU5-2492-000 102 - 11
XA9-0476-000 400 - 11
XA9-0476-000 A10 - 3
XA9-1420-000 101 - 4
XA9-1495-000 102 - 14
XA9-1495-000 103 - 9
XA9-1495-000 104 - 4
XA9-1501-000 102 - 8
XA9-1503-000 310 - 23
XB2-8300-609 810 - 501
XB4-5401-000 400 - 501
XB4-5401-009 101 - 501
XB4-5401-009 310 - 501
XB4-5401-009 A10 - 501
XB4-7300-807 100 - 501
XB4-7300-807 A10 - 502
imageCLASS MF4150/MF4140/
MF4122/MF4120/i-SENSYS MF4150/
MF4140/MF4120(Parts Catalog)
imageCLASS MF4150
Satera MF4150
i-SENSYS MF4150
imageCLASS MF4140
i-SENSYS MF4140
120V TW F14-9201-000 KVU
120V US F14-9231-000 JVM
120V CND/LTN F14-9231-000 KVT
230V AUS F14-9241-000 KVY
230V ASIA F14-9241-000 KVZ
230V CHN F14-9251-000 STC
230V KOR F14-9261-000 STD
100V JP F14-9211-000 JVP
230V EU1 F14-9291-000 JVN
230V EU2 F14-9291-000 KVW
230V EU3 F14-9291-000 KVX
230V AUS F14-9242-000 STW
230V EU1 F14-9292-000 JVQ
Satera MF4130
imageCLASS MF4122
imageCLASS MF4120
Satera MF4120
i-SENSYS MF4120
230V EU2 F14-9292-000 STE
230V EU3 F14-9292-000 STF
100V JP F14-9213-000 JVR
230V ASIA F14-9244-000 SUB
230V CHN F14-9254-000 SUC
230V CHN wo
MZ
F14-9255-000 SUD
230V KOR F14-9264-000 SUE
100V JP F14-9214-000 JVT
230V EU1 F14-9294-000 JVS
230V EU2 F14-9294-000 STZ
