Feb 20 2013
PARTS CATALOG
imageRUNNER ADVANCE
8205/8295/8285 Series
PREFACE
This Parts Catalog contains listings of parts used
Diagrams are provided with the listings to aid the service technician in identifying clearly, the
item to be orderd.
Whenever ordering parts, consult this Parts Catalog for all of the information pertaining to each
item. Be sure to include, in the Parts Request, the full item description, the item part number,
and the quantity.
COPYRIGHT (C) 1999 CANON INC.
Use of this manual should be
strictly supervised to avoid
disclosure of confidential
information.
Contents
NUMERICAL INDEX
imageRUNNER ADVANCE 8205/8295/8285 Series(Numerical Index) 1-1
imageRUNNER ADVANCE 8205/8295/8285 Series(Parts Catalog)
A1 ASSEMBLY LOCATION DIAGRAM ...................................... 2-1
A2 OPTION PARTS CATALOG LIST ......................................... 2-8
001 ACCESSOREIS ..................................................................... 2-9
100 EXTERNAL COVERS, PANELS, ETC. ............................... 2-11
101 INTERNAL COMPONENTS 1 ............................................. 2-16
102 INTERNAL COMPONENTS 2 ............................................. 2-19
103 INTERNAL COMPONENTS 3 ............................................. 2-21
104 INTERNAL COMPONENTS 4 ............................................. 2-23
105 INTERNAL COMPONENTS 5 ............................................. 2-25
106 INTERNAL COMPONENTS 6 ............................................. 2-27
107 INTERNAL COMPONENTS 7 ............................................. 2-30
108 MACHINE BOTTOM PLATE ................................................ 2-32
109 MACHINE REAR PLATE 1 .................................................. 2-33
110 MACHINE REAR PLATE 2 .................................................. 2-35
111 MACHINE REAR PLATE 3 .................................................. 2-37
112 FRONT COVER ASS'Y, LOWER ........................................ 2-39
113 RIGHT DOOR ASSEMBLY .................................................. 2-41
114 VERTICAL PATH ASSEMBLY ............................................ 2-43
130 FLAT CONTROL PANEL ASSEMBLY ................................ 2-44
135 UPRIGHT CONTROL PANEL ASSEMBLY ......................... 2-46
136 CONTROL PANEL ARM ASSEMBLY ................................. 2-49
140 POWER CORD TERMINAL ASS'Y ..................................... 2-51
250 MAIN DRIVE ASS'Y ............................................................. 2-55
260 V. PATH/CST. PICK-UP ASS'Y ........................................... 2-57
261 LEFT DECK PICK-UP DRIVE ASS'Y .................................. 2-58
270 DRUM DRIVE ASS'Y ........................................................... 2-60
271 DEVELOPING DRIVE ASS'Y .............................................. 2-61
280 DELIVERY REVERSE DRIVE ASS'Y .................................. 2-63
300 CASSETTE ASSEMBLY ...................................................... 2-64
301 CST. SIZE/REMNANT DETECT ASS'Y .............................. 2-67
302 DECK REMNANT DETECT ASS'Y ...................................... 2-68
303 CASSETTE SIZE DETECT ASS'Y ...................................... 2-69
304 PAPER STOCK ASS'Y, RIGHT ........................................... 2-70
305 PAPER STOCK ASS'Y, LEFT ............................................. 2-73
310 PAPER PICK-UP ASS'Y, RIGHT ......................................... 2-76
Contents
311 PAPER PICK-UP ASS'Y, LEFT ........................................... 2-79
312 MULTI TRAY ASS'Y ............................................................ 2-82
313 MULTI PAPER PICK-UP ASS'Y .......................................... 2-84
315 PRE-REGISTRATION GUIDE ASS'Y .................................. 2-87
330 FIXING/FEEDER DUPLEXING ASS'Y ................................ 2-88
331 FIXING/FEEDER FRAME ASS'Y ......................................... 2-94
332 REGISTRATION ASS'Y ....................................................... 2-98
333 DUPLEX. SIDE REG. SENSOR ASS'Y ............................. 2-100
334 E.T.B. CLEANING ASSEMBLY ......................................... 2-101
335 E.T.BELT ASSEMBLY ....................................................... 2-103
336 REVERSE CROSSMEMBER ASS'Y, LF. .......................... 2-105
350 OUTER PAPER DELIVERY ASS'Y ................................... 2-107
351 REVERSE PAPER DELIVERY ASS'Y ............................... 2-109
352 INNER PAPER DELIVERY ASS'Y ..................................... 2-113
460 LASER SCANNER UNIT ................................................... 2-115
510 PHOTO-SENSITIVE DRUM ASSEMBLY .......................... 2-116
550 1ST CORONA ASS'Y ........................................................ 2-118
570 PRE-TRANSFER CORONA ASS'Y ................................... 2-120
620 HOPPER ASS'Y ................................................................. 2-122
620A HOPPER ASS'Y ................................................................. 2-123
625 BUFFER ASS'Y ................................................................. 2-125
640 DEVELOPING ASS'Y ........................................................ 2-127
650 DEVELOPING RELEASE ASS'Y ....................................... 2-129
710 AP. KIT ASS'Y ................................................................... 2-131
711 DRUM CLEANING ASS'Y .................................................. 2-135
720 SEPARATION CLAW DRIVE ASSEMBLY ........................ 2-137
770 WASTE TONER FEED ASSEMBLY .................................. 2-139
810 FIXING ASS'Y .................................................................... 2-142
811 FIXING ASS'Y, UPPER ..................................................... 2-144
812 FIXING DRIVE ASS'Y ........................................................ 2-149
813 FIXING ENTRANCE GUIDE ASS'Y ................................... 2-151
814 FIXING EXIT GUIDE ASS'Y .............................................. 2-152
900 CONTROLLER BOX ASSEMBLY ..................................... 2-153
910 IH POWER SUPPLY PCB ASS'Y ...................................... 2-156
930 DC CONTROLLER PCB ASS'Y ......................................... 2-157
931 MAIN CONTROLLER PCB ASS'Y, 1 ................................. 2-158
932 MAIN CONTROLLER PCB ASS'Y, 2 ................................. 2-159
960 MAIN DRIVE DRIVER PCB ASS'Y .................................... 2-160
961 AC DRIVER PCB ASS'Y .................................................... 2-161
962 NOISE FILTER PCB ASSEMBLY ...................................... 2-162
963 DUPLEXING DRIVER PCB ASSEMBLY ........................... 2-163
964 FEED DRIVER PCB ASSEMBLY ...................................... 2-164
980 H.V. POWER SUPPLY ASS'Y ........................................... 2-165
T40 DEVICE PORT ASSEMBLY (EUR) ................................... 2-166
ZZA MECHANICAL STANDARD PARTS (HOW TO USE) ....... 2-167
Contents
ZZB MECHANICAL STANDARD PARTS (SCREWS) .............. 2-168
ZZC MECHANICAL STANDARD PARTS (BOLTS) .................. 2-175
ZZD MECHANICAL STANDARD PARTS (NUTS) .................... 2-176
ZZE MECHANICAL STANDARD PARTS (RETAINING RINGS) 2-177
1-1
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO
NUMERICAL INDEX
imageRUNNER ADVANCE 8205/8295/8285 Series(Numerical Index)
FA3-2473-000 720 - 1
FA3-2474-000 720 - 2
FA3-2475-000 720 - 3
FA3-2476-000 720 - 4
FA3-2477-000 720 - 5
FA3-2478-000 720 - 6
FA3-2483-000 720 - 7
FA4-1864-000 570 - 1
FA6-3071-020 811 - 1
FA9-3847-000 111 - 1
FA9-3943-000 720 - 9
FB1-6833-000 811 - 2
FB1-8581-000 313 - 1
FB1-8776-000 106 - 1
FB1-8776-000 811 - 3
FB2-6285-020 335 - 28
FB2-6872-000 711 - 1
FB2-7163-000 352 - 1
FB2-7219-030 811 - 4
FB2-7221-000 811 - 5
FB2-7230-000 811 - 6
FB2-7243-000 812 - 1
FB2-7867-030 112 - 1
FB2-8094-020 101 - 1
FB2-8299-000 720 - 10
FB2-8465-000 304 - 2
FB2-8465-000 305 - 2
FB4-1340-000 108 - 1
FB4-2007-000 310 - 1
FB4-2007-000 311 - 1
FB4-3687-000 550 - 18
FB4-3687-000 570 - 19
FB4-8012-020 710 - 1
FB4-8018-010 710 - 2
FB5-3625-000 104 - 10
FB5-5521-000 811 - 8
FB5-5530-000 814 - 1
FB5-6948-000 813 - 1
FB5-9104-010 710 - 3
FB6-2385-000 710 - 4
FB6-3150-000 813 - 2
FB6-3410-000 313 - 2
FB6-3456-000 312 - 1
FB6-3457-000 312 - 2
FB6-3459-000 312 - 3
FB6-3463-000 313 - 3
FB6-3464-000 313 - 15
FB6-3466-000 313 - 4
FB6-3467-000 313 - 5
FB6-3499-000 300 - 60
FB6-3499-000 304 - 4
FB6-3499-000 305 - 4
FB6-4937-000 312 - 17
FB6-6088-000 330 - 1
FB6-6088-000 710 - 6
FB6-6644-000 100 - 1
FC0-0205-000 101 - 38
FC0-2088-000 550 - 16
FC0-2089-000 550 - 17
FC0-2113-000 140 - 30
FC0-2131-000 350 - 2
FC0-2206-000 304 - 34
FC0-2206-000 305 - 34
FC0-2781-000 300 - 32
FC0-3223-000 570 - 26
FC0-4446-000 900 - 34
FC0-5153-000 130 - 1
FC0-5520-000 510 - 2
FC0-6856-000 130 - 2
FC0-6857-000 130 - 3
FC0-6861-000 130 - 4
FC0-6863-000 130 - 5
FC0-8737-000 310 - 13
FC0-8737-000 311 - 12
FC0-8803-000 135 - 1
FC0-8804-000 135 - 2
FC0-8805-000 135 - 3
FC0-8806-000 135 - 4
FC0-9151-000 100 - 28
FC0-9272-000 140 - 42
FC1-3975-020 331 - 1
FC1-3976-000 331 - 2
FC2-2121-000 106 - 2
FC5-1635-000 101 - 35
FC5-1766-000 510 - 1
FC5-1810-000 550 - 1
FC5-1810-000 570 - 2
FC5-1950-000 620 - 1
FC5-2051-000 331 - 46
FC5-2108-000 330 - 2
FC5-2179-000 313 - 6
FC5-2226-000 351 - 1
FC5-2261-000 336 - 1
FC5-2271-000 331 - 3
FC5-2286-000 811 - 9
FC5-2386-000 330 - 3
FC5-2524-000 310 - 2
FC5-2524-000 311 - 2
FC5-2526-000 310 - 3
FC5-2526-000 311 - 3
FC5-2528-000 310 - 4
FC5-2528-000 311 - 4
FC5-2537-010 310 - 6
FC5-2537-010 311 - 6
FC5-2538-000 310 - 7
FC5-2540-000 310 - 8
FC5-2540-000 311 - 7
FC5-2544-000 102 - 1
FC5-2547-000 310 - 9
FC5-2547-000 311 - 21
FC5-2548-000 310 - 10
FC5-2548-000 311 - 9
FC5-2573-000 310 - 11
FC5-2609-000 304 - 5
FC5-2609-000 305 - 5
FC5-2635-000 311 - 8
FC5-2638-000 311 - 10
FC5-2715-000 103 - 6
FC5-2715-000 105 - 1
FC5-2715-000 313 - 7
FC5-5078-000 313 - 8
FC5-5092-000 620 - 2
FC5-5145-000 813 - 4
FC5-5167-000 331 - 4
FC5-5170-000 330 - 4
FC5-6211-000 310 - 12
FC5-6211-000 311 - 11
FC5-6260-000 310 - 14
FC5-6287-000 331 - 5
FC6-1647-000 334 - 1
FC6-1968-000 330 - 5
FC6-2327-000 620A - 2
FC6-3230-000 620A - 3
FC6-3462-000 107 - 1
FC6-3494-000 812 - 24
FC6-3501-020 811 - 10
FC6-3592-000 811 - 11
FC6-3673-000 811 - 24
FC6-3762-000 304 - 6
FC6-3762-000 305 - 6
FC6-3763-000 304 - 7
FC6-3763-000 305 - 7
FC6-3808-000 811 - 13
FC6-3863-000 310 - 15
FC6-3863-000 311 - 13
FC6-4358-000 310 - 16
FC6-4358-000 311 - 14
FC6-6661-000 313 - 9
FC6-9029-000 270 - 1
FC6-9542-000 330 - 6
FC6-9782-000 351 - 2
FC6-9969-000 304 - 8
FC6-9969-000 305 - 8
FC7-0616-000 900 - 33
FC7-0658-000 811 - 14
FC7-4155-000 334 - 2
1-2
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO.
PARTS NUMBER
FIGURE
&
KEY NO
NUMERICAL INDEX
imageRUNNER ADVANCE 8205/8295/8285 Series(Numerical Index)
FC7-4302-000 106 - 35
FC7-5009-000 313 - 10
FC7-5845-000 310 - 22
FC7-5845-000 311 - 20
FC7-6972-000 331 - 6
FC7-7207-000 113 - 1
FC7-7207-000 313 - 12
FC7-7208-000 313 - 13
FC7-7208-000 331 - 7
FC7-7209-000 113 - 2
FC7-7209-000 114 - 1
FC7-7209-000 313 - 14
FC7-7800-000 811 - 15
FC8-0785-000 313 - 18
FC8-1844-000 100 - 3
FC8-1876-000 100 - 4
FC8-1877-000 100 - 5
FC8-2366-000 100 - 6
FC8-2367-000 100 - 7
FC8-2368-000 100 - 8
FC8-2369-000 100 - 64
FC8-2462-000 300 - 1
FC8-2463-000 300 - 2
FC8-2464-000 300 - 3
FC8-2466-000 300 - 4
FC8-2469-000 300 - 5
FC8-2470-000 300 - 6
FC8-2474-000 300 - 7
FC8-2475-000 300 - 8
FC8-2476-000 300 - 54
FC8-2477-000 300 - 9
FC8-2482-000 300 - 10
FC8-2484-000 300 - 11
FC8-2487-000 301 - 1
FC8-2495-000 300 - 12
FC8-2527-000 304 - 9
FC8-2527-000 305 - 9
FC8-2533-000 304 - 10
FC8-2533-000 305 - 10
FC8-2667-000 300 - 13
FC8-2668-000 300 - 14
FC8-2670-000 300 - 15
FC8-2671-000 300 - 16
FC8-2672-000 300 - 17
FC8-2697-000 114 - 2
FC8-2700-000 103 - 2
FC8-2708-000 312 - 4
FC8-2712-000 312 - 5
FC8-2713-000 312 - 6
FC8-2727-000 312 - 7
FC8-3782-000 114 - 3
FC8-4051-000 900 - 1
FC8-4964-010 300 - 18
FC8-4964-010 304 - 11
FC8-4964-010 305 - 11
FC8-4965-000 300 - 19
FC8-4967-000 300 - 20
FC8-4967-000 304 - 12
FC8-4967-000 305 - 12
FC8-4968-000 300 - 21
FC8-4968-000 304 - 13
FC8-4968-000 305 - 13
FC8-4987-000 300 - 22
FC8-4990-000 300 - 23
FC8-4994-000 300 - 24
FC8-4996-000 300 - 25
FC8-4997-000 300 - 26
FC8-5262-000 300 - 55
FC8-6109-000 100 - 11
FC8-6639-000 108 - 2
FC8-6976-000 106 - 37
FC8-6989-000 106 - 23
FC8-7023-000 900 - 3
FC8-7024-000 900 - 4
FC8-7026-000 107 - 2
FC8-7027-000 107 - 3
FC8-7033-000 100 - 12
FC8-7034-000 105 - 2
FC8-7038-000 105 - 3
FC8-7039-000 105 - 4
FC8-7053-000 550 - 2
FC8-7054-000 550 - 3
FC8-7074-000 711 - 4
FC8-7075-000 711 - 5
FC8-7083-000 710 - 45
FC8-7086-000 711 - 2
FC8-7093-000 710 - 8
FC8-7097-000 710 - 9
FC8-7098-000 710 - 10
FC8-7106-000 650 - 1
FC8-7107-000 650 - 2
FC8-7108-000 650 - 3
FC8-7109-000 650 - 15
FC8-7113-000 650 - 5
FC8-7125-000 271 - 1
FC8-7128-000 271 - 19
FC8-7139-000 620A - 4
FC8-7155-010 335 - 1
FC8-7156-010 335 - 2
FC8-7157-000 335 - 3
FC8-7158-000 335 - 4
FC8-7159-000 335 - 5
FC8-7160-000 335 - 6
FC8-7161-000 335 - 7
FC8-7162-000 335 - 8
FC8-7166-000 335 - 9
FC8-7171-000 330 - 7
FC8-7175-000 334 - 3
FC8-7192-010 330 - 8
FC8-7196-000 334 - 4
FC8-7200-000 330 - 10
FC8-7213-000 811 - 70
FC8-7235-000 812 - 2
FC8-7236-000 351 - 3
FC8-7236-000 812 - 3
FC8-7237-000 104 - 3
FC8-7244-000 812 - 4
FC8-7247-000 811 - 17
FC8-7251-000 811 - 18
FC8-7257-000 811 - 20
FC8-7271-000 313 - 17
FC8-7273-000 313 - 19
FC8-7274-000 312 - 8
FC8-7275-000 312 - 9
FC8-7276-000 332 - 1
FC8-7277-000 332 - 2
FC8-7283-000 332 - 3
FC8-7284-000 332 - 4
FC8-7286-010 332 - 15
FC8-7290-000 113 - 3
FC8-7291-000 113 - 4
FC8-7293-000 113 - 15
FC8-7295-000 333 - 1
FC8-7297-000 331 - 8
FC8-7309-000 331 - 9
FC8-7321-000 331 - 47
FC8-7322-000 331 - 48
FC8-7323-000 331 - 49
FC8-7324-000 331 - 10
FC8-7327-000 330 - 11
FC8-7328-000 330 - 12
FC8-7332-000 336 - 2
FC8-7333-000 331 - 50
FC8-7334-000 331 - 11
FC8-7343-000 331 - 12
FC8-7347-000 114 - 4
FC8-7348-000 114 - 5
FC8-7349-000 114 - 8
FC8-7352-000 101 - 32
FC8-7353-000 304 - 14
FC8-7354-000 305 - 14
FC8-7356-000 304 - 15
FC8-7356-000 305 - 15
FC8-7358-000 304 - 16
FC8-7358-000 305 - 16
FC8-7378-000 350 - 1
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$27.99
Canon imageRUNNER ADVANCE 8205/8295/8285 Series Parts CATALOG
Viewed 72 Times Today
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$27.99
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
Description
This is a parts catalog for the Canon imageRUNNER ADVANCE 8205/8295/8285 Series. It covers the following:
- A1 Assembly Location Diagram
- A2 Option Parts Catalog List
- 001 Accessories
- 100 External Covers, Panels, etc.
- 101-108 Internal Components
- 109-114 Machine Plates and Assemblies
- 130-136 Control Panel Assemblies
- 140 Power Cord Terminal Assembly
- 250-336 Various Drive and Paper Handling Assemblies
- 350-810 Various Delivery, Imaging, and Fixing Assemblies
- 900-980 Controller and Power Supply Assemblies
- T40-ZZE Mechanical Standard Parts
Model Specification: Canon imageRUNNER ADVANCE 8205/8295/8285 Series
Total Pages: 206
File Format: PDF
Requirements: Adobe Reader
Language: English
Compatibility: All Versions of Windows & Mac, APP ISO, iPhone, iPad, Android, etc.
This manual is in PDF format, fully indexed and bookmarked by topic for easy navigation. It is an original Adobe document, ensuring high quality and perfect printing. The PDF is searchable, allowing quick access to information in every chapter. Users can print the entire manual or select specific pages. Additionally, diagrams and pictures can be zoomed in for detailed viewing.
This manual facilitates easy and cost-effective repairs with step-by-step instructions and detailed images for all repair areas.
All manuals are available for instant download, eliminating shipping costs and delivery wait times. Secure payment options include major credit/debit cards and PayPal.
