COMPONENT MODEL NAME
MHC-MC3AV
US Model
Canadian Model
Australian Model
SERVICE MANUAL
SPECIFICATIONS
General
Power requirements
North American model: 120 V AC, 60Hz
Australian model: 220 - 240 V AC, 50/60Hz
Power consumption
U.S.A models: 250 watts
Canadian models: 250 VA
Australian model: 250 watts
Dimensions (w/h/d)
Approx. 280 x 373 x 437 mm (11 1/8 x 14 3/4 x 17 1/4 in)
Mass Approx. 12 Kg (26 lbs. 7 oz)
Supplied accessories:
AM loop antenna (1)
Remote RM-SF250AV (1)
Batteries (2)
FM lead antenna (1)
Speaker cords (5)
Front speaker pads (8)
Center speaker pads(4)
Design and specifications are subject to change without notice.
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-638-21 COMMANDER, STANDARD (RM-SF250AV)
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM)
1-769-317-11 CORD, SPEAKER (2.5m) (SS-MC3AV)
1-769-433-11 CORD, SPEAKER (10m) (SS-SR50)
1-769-433-21 CORD, SPEAKER (2.5m) (SS-CN50)
3-866-408-11 MANUAL, INSTRUCTION (ENGLISH)
3-866-408-21 MANUAL, INSTRUCTION (FRENCH) (Canadian)
4-210-254-01 CUSHION (FOOT) (SS-MC3AV, SS-CN50)
4-981-643-21 BATTERY COVER (FOR RM-SF250AV)
PARTS LIST
MINI Hi-Fi COMPONENT SYSTEM
• MHC-MC3AV is composed of following models.
As for the service manual, it is issued for each component
model, then, please refer to them.
Ref. No. Part No. Description Remark
COMPACT DISC DECK RECEIVER SYSTEM
SPEAKER SYSTEM
FRON SPEAKER
CENTER SPEAKER
REAR SPEAKER
SS-MC3AV
SS-CN50
SS-SR50
HCD-MC3AV
