Volvo Compact Wheel Loaders 5.5-6.1 t / 12,125-13,448 lb 74 hp L30G,

2 The strength of our dealer network is enhanced with extensive individualized product support training at our best-in-class Customer Center in Shippensburg and through hands-on training. Using a great Product Demonstration Center featuring a dedicated area for most commons applications, visitors operate equipment from our entire product line under a variety of simulated working conditions. This facility is in year-round use by our dealers and customers. Building the best starts right here. The products designed and manufactured by Volvo Construction Equipment have their beginnings at the most advanced Research & Design centers in the industry. Volvo CE machines are designed in 11 R&D centers and produced in 15 manufacturing facilities across the world. The major R&D center and manufacturing plant in the Americas is located in Shippensburg, Pennsylvania. This facility has been in operation for over 30 years and – with its recently added 200,000 sq. ft. expansion – now covers 570,000 sq. ft. on an 80 acre campus. Dedicated work teams and highly advanced technologies and techniques using the Volvo Production System ensure continuous quality improvements, labor savings and cost control to reach the high quality that our customers have come to expect from Volvo. Helping you to do more Doing more with less is a trademark of Volvo Construction Equipment. High productivity has long been married to low energy consumption, ease of use and durability. When it comes to lowering life-cycle costs, Volvo is in a class of its own. Designed to fit your needs There is a lot riding on creating solutions that are suited to the particular needs of different industry applications. Innovation often involves high technology – but it doesn’t always have to. Some of our best ideas have been simple, based on a clear and deep understanding of our customers’ working lives. You learn a lot in 180 years Over the years, Volvo has advanced solutions that have revolutionized the use of construction equipment. No other name speaks Safety louder than Volvo. Protecting operators, those around them and minimizing our environmental impact are traditional values that continue to shape our product design philosophy. We’re on your side We back the Volvo brand with the best people. Volvo is truly a global enterprise, one that is on standby to support customers quickly and efficiently – wherever they are. We have a passion for performance. A strong, dedicated, capable dealer network Our dealers are strategically located throughout North America to provide the equipment you need and the parts and service support you demand for a productive and profitable operation. A passion for performance At Volvo Construction Equipment, we’re not just coming along for the ride. Developing products and services that raise productivity – we are confident we can lower costs and increase profits for customers around the globe. Part of the Volvo Group, we are passionate about innovative solutions to help you work smarter – not harder.

3 Volvo Trucks Renault Trucks Mack Trucks UD Trucks Volvo Buses Volvo Construction Equipment Volvo Penta Volvo Financial Services

4 Efficient performance Built for working in tough conditions, the L30G and compact wheel loaders from Volvo are versatile machines, strong by design and well protected for enhanced durability. These robust, reliable machines are built to deliver superior performance that lasts. Featuring a comfortable cab, excellent hydraulics, easy-to-use controls and outstanding serviceability, these compact wheel loaders are designed to work with power and precision, improving safety and performance in all applications. Versatile by design The compact wheel loaders are suitable for any application, whether you are handling delicate freight, traveling frequently between worksites, or using demanding attachments. The dual hydraulics enable simultaneous lifting and steering, while the optional boom suspension absorbs bumps. Cut your transit time with the smooth hydrostatic drive and high speed option, and boost productivity with the optional auxiliary hydraulic pump, which provides up to 100 liters (26 gallons) per minute. Easy operations Take a seat in the cozy Volvo Care Cab and benefit from optimum visibility with the perfectly designed dashboard and large expanse of glass. The operator can maneuver with ease and confidence thanks to exceptional all- round visibility. Customize your driving experience with the new adjustable steering column, providing more room to ensure a comfortable ride. Safety first The compact wheel loaders are easy to drive, even for less experienced operators, thanks to the single inching braking pedal. Designed with safety in mind, the FOPS / ROPS certified Cab enables safe ingress and egress, reducing the risk of accidents or injury. Promote best safety practices on your jobsite with the optional orange seatbelt and transmission cut-off switch. Enhanced uptime Reduce downtime and tighten costs with Volvo solutions. Maintain high power without the need for regeneration by selecting the newly introduced Diesel Oxidation Catalyst engine, or choose the Diesel Particulate Filter engine if working in sensitive environments. Maximize uptime with 100 hours lift frame greasing interval and excellent access to service the transversally mounted engine. Protect your investment from obstacles with the high ground clearance and sturdy, casted rear counterweight, ensuring high residual value of your compact wheel loader.

5 Boost your performance Expect unbeatable traction and best-in-class ground clearance with the L30G and The compact wheel loaders are equipped with an articulated oscillating joint, 100% differential locks for front and rear wheels, and industry unique portal axles. Maintain excellent parallel movement with forks and ensure fast cycle times with Z-bar or TP linkages, delivering high tilt force throughout the entire lift path. Connect to a wide range of attachments with the universal skid steer coupler.

6 Efficient attachment changes Volvo attachment brackets are the perfect fit for maximizing productivity of your machine. Quickly and easily, connect to a full range of attachments, adding versatility and efficiency to your machine.

7 State-of-the-art support Volvo is committed to providing a complete solution to guarantee the highest performance from your Volvo machine, including high quality attachments and state-of-the-art support through our customer solutions. Take advantage of our unique, global dealer support network to ensure your machine achieves maximum uptime, and generates maximum profit and growth for your business. Robust attachments to match Keep the production running with Volvo attachments, built to last. Trust our high quality attachments and gain peace of mind. Perfectly matched to Volvo compact wheel loader, Volvo buckets, forks, grapple and material handling arms make your machine perform at maximum capacity. Control service costs We can help support the profitability of your operation. The range of Customer Support Agreements offer preventive maintenance, total repairs and a number of uptime services. Volvo uses the latest technology to monitor machine operation and status, giving you advice to increase machine uptime. By having a Customer Support Agreement, you are in control of your service costs. Retain Volvo quality Our leading parts availability ensures maximum uptime of your machine. Volvo parts are extensively tested and approved because every part is vital for performance. Benefit from a cost-effective manufacturing program by selecting the Diesel Particulate Filter engine, providing short part delivery to reduce your maintenance time. Here to support you Volvo is here to support you whenever you need it. As a complete solutions provider, we listen to your requirements to ensure machine uptime and increase your revenue. With our extensive infrastructure of technicians, workshops and dealers, Volvo has a comprehensive network to fully support you using local knowledge and experience.

8 Ultimate performance Achieve unbeatable traction and ground clearance with an articulated oscillating joint, 100% differential locks, and industry unique portal axles. Boost your performance Maximize the versatility and efficiency of your machine with Volvo attachment brackets. Efficient attachment changes Control service costs Control costs with a wide variety of Customer Support Agreements, offering preventative maintenance, total repairs and uptime services. Easy operations Customize your comfort in the Volvo Care Cab, offering optimum visibility and the new adjustable steering column. Robust attachments to match Perform at maximum capacity with Volvo buckets, forks, grapple and material handling arms to keep the production running.

9 Here to support you Gain expert advice and support from Volvo. As a total solutions provider, we are here to increase your profitability. Retain Volvo quality Maximize uptime with Volvo’s high quality components and remanufacturing program designed to suit you and your machine Safety first Secure your safety in the FOPS / ROPS certified Cab, equipped with the single inching braking pedal for maximum drivability. Versatile by design Boost productivity while minimizing transit time with the compact wheel loader, suitable for any application. Enhanced uptime Reduce downtime and control costs with Volvo solutions, offering flexibility and high return on investment.

10 L30G, in detail Engine Volvo 4-cylinder, common rail, diesel engine compliant to EU stage IIIB and EPA Tier 4f environmental regulations. Maximun engine incline is 30 degrees in all directions. Air cleaning: 1. Paper filter with indicator in cab 2. Safety filter Exhaust after treatment system: - D3.3M: Cooled Exhaust Gas Recirculation (EGR), charge air cooler (CAC) and diesel oxidation catalyst (DOC). - D3.3H Cooled Exhaust Gas Recirculation (EGR), diesel oxidation catalyst (DOC) and diesel particulate filter (DPF). L30G Engine Volvo D3.3M or D3.3H D3.3M or D3.3H Max power at r/min (r/s) 2,600 (43.3) 2,600 (43.3) SAE J1995 gross kW (hp) 55.4 (74) 55.4 (74) Max. torque at r/min (r/s) 1,500 (25) 1,500 (25) SAE J1995 gross Nm (ft lbf) 265 (195) 265 (195) Economic working range r/min (r/s) 1,300 - 2,100 (21.7 - 35) 1,300 - 2,100 (21.7 - 35) Displacement l (in³) 3.3 (203) 3.3 (203) Bore mm (in) 98 (3.86) 98 (3.86) Stroke mm (in) 120 (7,323) 120 (7,323) Electrical system Contronic electrical system with central warning light and buzzer, providing clear and easy to read information to the operator. A keypad allows easy navigation on the central LCD display with main and sub information field. Indicators and activation lights are available for various control and monitoring functions. An audible warning alarm will sound and a central warning indicator will flashes if abnormal operating values or error messages arise. Gauges are available for coolant temperature and fuel level. A fuse test port is available in the fuse box, allowing operators to perform initial invstigations, reducing diagnostic time. L30G Voltage V 12 12 Batteries V 1 1 Battery capacity Ah 100 100 Alternator rating W/A 1,260 / 90 1,260 / 90 Starter motor output kW 3 3 Drivetrain The hydrostatic transmission allows for speed range change without any tractive power interruption. Maximum tractive power is available in all speed ranges, regardless of the driving direction. Single “Inch/brake pedal” for variable machine speed control and easy power transfer to the wheels at constant engine rpm. Transmissions forward, neutral, reverse and differential locks buttons are all easy to reach on the multifunctional right joystick. This allows excellent ergonomics and greater efficiency in all applications thanks to the single-handed operation of the machine. Two rigid portal axles provides long durability and best in class ground clearance. The central articulating-oscillating joint and all wheel drive allows excellent mobility in all ground conditions. The 100% differential lock on both axles enable low tire wear on hard ground while maximizing traction force in soft terrain. L30G Angle of oscillation ± ° 10 10 Oscillation at wheel, max. mm (in) 250 (9.8) 270 (10.6) Track mm (in) 1,482 (58.3) 1,532 (60.3) Travel speed, forward/ reverse 1st range km/h (mi/h) 6 (3.7) 6 (3.7) 2nd range km/h (mi/h) 20 (12.4) 20 (12.4) Low-speed version 1st gear km/h (mi/h) 6 (3.7) 6 (3.7) 2nd gear km/h (mi/h) 20 (12.4) 20 (12.4) High-speed version 1st gear km/h (mi/h) 8 (5) 8 (5) 2nd gear km/h (mi/h) 30 (18.6) 30 (18.6) Tires L30G Size 365 / 80 R20 405 / 70 R20 Linkage Z-bar linkage providing high breakout force to the bucket and also parallel movement to the fork frame thanks to Volvo’s specific kinematics. L30G Linkage system Z-bar Z-bar Lift cylinders 2 2 Tilt cylinders 1 1 Lift time (loaded) s 6.5 5.5 Lowering time (empty) s 3.5 3.5 Dump time s 1.5 1.2 Brake System Service brake: an Inching-brake pedal provides hydrostatic wearless braking in the first stage for precise approach; if applied further the central disk brake takes over for final braking and machine immobilization. Parking brake: Mechanically activated central drum brake, located on the rear axle dropbox and acting upon all four wheels. Steering System Central articulating-ocillating joint with Elastical end-stops. Hydrostatic steering powered via a dedicated gear pump allowing precise operation even at low engine revolutions: steering the machine does not influence the working hydraulic speed e.g. when lifting loads. L30G Steering cylinders 1 1 Working pressure MPa (psi) 19 (2,756) 19 (2,756) Maximum flow l/min (gal/min) 33.5 (8.85) 33.5 (8.85) Max articulation ± ° 40 40 Cab The cab is tested and approved according to ROPS (ISO 3471, SAE J1040) and FOPS (ISO 3449). The cab is compliant with ISO 6055 requirements regarding Operator overhead protection - Industrial trucks and SAE J386 regarding Operator Restraint System. The operator’s seat features an adjustable suspension and a retractable seatbelt. Fresh air is filtered through a large elements prior entering, ensuring extremely clean air distribution in the cab. Several air vents enables fast de-misting and defrosting. The contronic monitoring system provides all important information in a central position and all machine controls are located in the operator’s field of vision. Hydraulic system Working hydraulic system with pilot operated control valves. System supply: A gear pump provides flow to the working hydraulic. System control: Double-acting 3-spools main control valve. The lift function has four positions: lift, hold (neutral), lower and float position. The tilt function has three positions: rollback, hold (neutral) and dump. A fourth hydraulic funtions is available as options to power hydraulic implements (Hi-Tip bucket, angle sweeper etc...) Filtration: Full-flow filtration through 10 micron (absolute) filter cartridge in a combined suction-return-filter. Cooling: Thermostatically controlled oil flow to oil cooler (fast warm-up, optimized cooling). L30G Working pressure max MPa (bar) 23 (230) 24 (240) Flow l/min (gal/min) 57 (15) 69 (18.2) at engine speed r/min (r/s) 2,600 (43.3) 2,600 (43.3) Service Refill Ground level access, fuel filler and hydraulic oil filler well protected under the rear engine hood. L30G Fuel tank l (gal) 84 (22.2) 84 (22.2) Engine oil l (gal) 11.2 (3) 11.2 (3) Engine coolant l (gal) 11 (2.9) 11 (2.9) Hydraulic tank l (gal) 54 (14.3) 54 (14.3) Front axle oil l (gal) 12.2 (3.2) 12.2 (3.2) Rear axle oil l (gal) 13.5 (3.6) 13.5 (3.6) Sound Level L30G In-cab sound pressure level according to ISO 6396: LpA dB(A) 75 75 External sound power level around the machine according to ISO 6395: LwA dB(A) 99 99
