CLG835 轮式装载机
CLG835 WHEEL LOADER
（东康动力/柳工桥提速箱）
零 件 图 册
PARTS CATALOGUE
62F0025XXXXXXXX
62F0029XXXXXXXX
62F0036XXXXXXXX
CLG835 whell loader parks catalog 200904005
2
零件图册使用说明
柳工根据用户的不同需求，在现有的基础配置上增加了各种选配系统，形成了不同的 15 位代码机型，每
一个 15 位代码表示一个机型。比如“64F01390001B000”中的前七位代码“64F0139”代表基础配置，表明了
机器的发动机、桥、箱、工作系统等信息，后八位代码则代表了机器的各种选装配置，包括空调、冷启动、
铭牌、空滤的预滤、尾气净化、集中润滑、保险杠、警示灯、蜂鸣器、称重系统、音响系统、各类斗、岩
石斗、抱叉、侧卸等。
请您向柳工经销商咨询购买本机器的 15 位代码，或者从机器提货单上获得机器的 15 位代码和机器配置信
息，例如 15 位代码：64F01430001B001，机器配置 ：CLG855 装/潍柴/柳工桥箱/空调/3 方斗。
另外，在本页“关于选配件的说明”章节中将与您机器 15 位代码相同的信息项使用水笔特别注明出来，或打
勾注明。您使用的零件图册，集合现有基础配置下的该机型所有选装配置，因此该图册可能包含多个不同
的 15 位代码机型，正确认识您购买机器的 15 位代码，今后对您机器的维修保养工作带来方便。
关于选配件的说明
本图册为 CLG835 轮式装载机配置东康柴油机的综合零件图册，其中注有（选配）字样的系统图为标准配
置以外的系统图。如果用户购买了标准配置以外的机型，则选择选配的系统取代标准配置的相应系统。
请仔细阅读本章节的说明，以下信息项每一条代表一种机型。如果您购买了标准配置的机型，则只需参阅
第一条信息项；如果您购买了标准配置以外的机型，则需参阅第一条及与您选配的机器有关的信息项。
1、 本图册零件号不加注“选配”字样的配置为标准配置，适用于本手册的标准配置 CLG835 装/东康/柳
工桥提速箱/空调/E 牌/1.7 方斗(62F00250001B001) 。
2、 整机配置为 CLG835 装/东康/柳工桥提速箱/空调/E 牌/警示灯/1.7 方斗(62F00250004B001) 的装载
机，
新增“46C1767 旋转警示灯总成”;
系统下挂的零部件同时取代相应系统下挂零部件。其余系统同标准配置。
3、 整机配置为 CLG835 装/东康/柳工桥提速箱/无氟/E 牌/派克阀/1.7 方斗(62F00250005B001) 的装载
机，
使用“11E0340 工作液压系统”取代“11E0097 工作液压系统 ”，
使用“20E0196 行车制动系统”取代“20E0143 行车制动系统”，
使用“30E0289 前车架总成”取代“30E0253 前车架总成”。
系统下挂的零部件同时取代相应系统下挂零部件。其余系统同标准配置。
4、 整机配置为 CLG835 装/东康/柳工桥提速箱/空调/E 牌/三联阀/货叉/1.7 快换斗(62F00290001B001)
的装载机，
使用“11E0308 工作液压系统”取代“11E0097 工作液压系统”，
使用“30E0274 前车架总成”取代““30E0253 前车架总成”,
使用“32E0346 工作装置限位系统”取代“32E0418 工作装置限位系统”,
新增“32E0343 快换装置”,
新增“43C0388 快换平叉”。
系统下挂的零部件同时取代相应系统下挂零部件。其余系统同标准配置。
CLG835 whell loader parks catalog 200904005
3
5、 整机配置为 CLG835 装 / 东康 / 柳工桥提速箱 / 空调 /E 牌 / 派克三联阀 /φ600 叉 /1.7 方斗
(62F00360001B001) 的装载机，
使用“11E0384 工作液压系统”取代“11E0097 工作液压系统 ”，
使用“ 30E0334 前车架总成”取代“30E0253 前车架总成”,
新增“32E0189 装卸叉系统（φ600）”，
新增“00C0883 抱叉管路”。
系统下挂的零部件同时取代相应系统下挂零部件。其余系统同标准配置.
关于零件号后的扩展号
每个 7 位零件号后面的 3 位扩展号代表了机器零部件持续改进的过程。柳工销售文件在 2007 年 9 月份之
后对产品零件图册中的零件号增加了 3 位扩展号， 例如“00E0236 002”中“00E0236”代表该零部件的零件号，
“002”代表改进版本。 扩展号不同而零件号相同的零部件可能会存在微小的改进，这些改进可能会对你的装
配带来一些影响。在对零部件进行定货过程中向柳工经销商报零件号+扩展号，会对你的零部件装配有帮助。
注意
柳工保留对零部件持续改进过程中的解释。对于机器设计过后的持续改进有可能会在该手册中无法一一体
现。但是会在将来对其进行更新和修订再印刷。
任何时候，如果您对该手册或柳工的机器有任何疑问，都可以咨询柳工的经销商，向他们获取最新的信息。
CLG835 whell loader parks catalog 200904005
4
How to use the part catalog
All kiNds of optioNal attachmeNts based oN curreNt staNdard coNfiguratioN are added aNd form
differeNt 15 codes model accordiNg to the customers’ requiremeNts, every 15 codes is a machiNe model.
For example, the first seveN codes of “64F01390001B000”is staNdard coNfiguratioN, show the eNgiNe、
axle、traNsmissioN、operatiNg system ect，after eight code of it show various optioNal attachmeNts
iNcludiNg of the air coNditioNer, startiNg aids, Nameplate, pre-filter, exhaust gas purifyiNg, ceNtralized
lubricatioN, bumper, beacoN, buzzer, couNterweight system, souNd system, various buckets, rock
bucket, loggiNg fork, side dump ect.
CoNsult with your LiugoNg dealers for the machiNe 15 codes what you will buy or get 15 codes aNd
coNfiguratioN iNformatioN from machiNe bill. For example, 64F01430001B001， coNfiguratioN： CLG855
Wheel loader/Weichai power/LiugoNg axle & traNsmissioN/air coNditioNer/3m
3
bucket.
IN additioN，sigN the special marks of machiNe 15 codes iNformatioN iN the sectioN of optioNal
coNfiguratioN iN this page by the dealers. The part catalog what you use aggregates all optioNal
coNfiguratioNs based oN curreNt staNdard coNfiguratioN， so this part catalog coNsists of maNy differeNt
15 codes machiNe models. KNow correctly 15 codes of machiNe what you buy to be coNveNieNt at
maiNteNaNce aNd service.
Optional configuration instruction
This part catalog is aN iNtegrate part catalog which coNfigures CLG835 wheel loader DongFeng
Cummins power. the system chart sigNed optioNal is except of staNdard coNfiguratioN。the customers
should choose the optioNal iNstead of correspoNdiNg staNdard coNfiguratioN if they buy other
coNfiguratioN machiNes.
Read this sectioN，the followiNg iNformatioN each item shows a machiNe model. read the item 1 if you
buy staNdard coNfiguratioN machiNe；read relative iNformatioN of your machiNe except for item1 if you
buy other coNfiguratioNs machiNes.
1、 The part Number Not marked OPTIONAL is staNdard coNfiguratioN， this part catalog’s staNdard
coNfiguratioN is CLG835 Wheel loader/ DongFeng Cummins power/LIUGONG axle &
transmissioN/R134a air conditioNer /E PLATE/1.7m
3
bucket（62F00250001B001） 。
2、 CoNfiguratioN as CLG835 Wheel loader/ DongFeng Cummins power/ LIUGONG axle &
transmissioN/R134a air conditioNer/E PLATE/ warning light/1.7m
3
bucket
（62F00250004B001）
“46C1767 ROTATING BEACON ASSEMBLY”are newly add;
The system assembly chaNges, the parts attached this assembly chaNges at the same time.
For example, B assembly replaces A assembly, the parts C attached B assembly replaces the
correspoNdiNg parts D attached A assembly.Other systems see staNdard coNfiguratioN.
3、 CoNfiguratioN as CLG835 Wheel loader/ DongFeng Cummins power/ LIUGONG axle &
transmissioN/no FREON air conditioNer/E plate/ Parket valve/1.7m
3
bucket
（62F00250005B001） .
uses“11E0340 HYDRAULIC SYSTEM” instead of “11E0097 HYDRAULIC SYSTEM ”，
uses“20E0196 BRAKE SYSTEM” instead of “20E0143 BRAKE SYSTEM ”，
uses “30E0289 FRONT FRAME ASSEMBLY” instead of “30E0253 FRONT FRAME
ASSEMBLY”
The system assembly chaNges, the parts attached this assembly chaNges at the same time.
For example, B assembly replaces A assembly, the parts C attached B assembly replaces the
correspoNdiNg parts D attached A assembly.Other systems see staNdard configuration.
CLG835 whell loader parks catalog 200904005
5
4、 CoNfiguratioN as CLG835 Wheel loader/ DongFeng Cummins power/ LIUGONG axle &
transmissioN/R134a air conditioNer/E PLATE/ parket valve/FORK/1.7m
3
bucket
（62F00290001B001）
uses“11E0308 HYDRAULIC SYSTEM” instead of “11E0097 HYDRAULIC SYSTEM ”，
uses“30E0274 FRONT FRAME ASSEMBLY” instead of ““30E0253 FRONT FRAME
ASSEMBLY”,
uses “32E0346 WORKING IMPLEMENT LIMIT SYSTEM” instead of “32E0418 WORKING
IMPLEMENT LIMIT SYSTEM”,
“32E0343 QUICK COUPLER” are newly added .
“43C0388 QUICK PALLET FORK” are newly added
The system assembly chaNges, the parts attached this assembly chaNges at the same time.
For example, B assembly replaces A assembly, the parts C attached B assembly replaces the
correspoNdiNg parts D attached A assembly.Other systems see staNdard coNfiguratioN.
5、 CoNfiguratioN as CLG835 Wheel loader/ DongFeng CummiNs power/ LIUGONG axle &
transmissioN/R134a air conditioNer/E PLATE/ parket valve/FORK φ600/1.7m
3
bucket
（62F00360001B001） .
uses“11E0384 YDRAULIC SYSTEM” instead of “11E0097 HYDRAULIC SYSTEM ”，
uses“ 30E0334 FRONT FRAME ASSEMBLY” instead of “30E0253 FRONT FRAME
ASSEMBLY”,
“32E0189（φ600） FORK SYETEM” are newly added .
“00C0883 LOGGING FORK CLAMP LINES” are newly added .
The system assembly chaNges, the parts attached this assembly chaNges at the same time.
For example, B assembly replaces A assembly, the parts C attached B assembly replaces the
correspoNdiNg parts D attached A assembly.Other systems see staNdard coNfiguratioN.
Extend Number of part Number
The three exteNd Numbers behiNd each seveN part Number show coNtiNuous improviNg progress of
the parts. The three exteNd Numbers are added to the part catalog after Sep 2007，for example
“00E0236”amoNg“00E0236 002”shows part Number of this part， “002”is improviNg editioN. The differeNt
exteNd Number but the same part Number of parts may Need improve slightly，these improviNg may
affect your coNfiguratioNs. It is helpful to your parts wheN you report the part Number+ exteNd Number
to LiugoNg dealers duriNg orderiNg the part.
Attention!
LiugoNg has reserved rights to explaiN parts improviNg progress. The coNtiNuous improviNg progress
caNNot be iNvolved fully iN this part catalog after desigN. We will reNew, modify aNd republish iN further.
CoNsult with your LiugoNg dealers for New iNformatioN if you have aNy questioNs at aNytime.
CLG835 whell loader parks catalog 200904005
6
目 录
CONTENTS
安全及指示标贴 SAFETY AND INDICATIVE LABEL ....................................... 1
45E0262 002 标贴组件 .................................................................................................................... 1
DECAL SET...................................................................................................................................... 1
动力系统POWER SYSTEM ............................................................................. 4
00E0259 010 柴油机系统 ................................................................................................................ 4
ENGINE SYSTEM ............................................................................................................................ 4
23C0091 001 油门操纵总成............................................................................................................. 6
ACCELERATOR SYSTEM ............................................................................................................... 6
40C0406 000 柴油预滤装置............................................................................................................. 7
FIL TER ASSEM ............................................................................................................................... 7
00E0264 001 散热系统 .................................................................................................................... 8
COOLING SYSTEM ......................................................................................................................... 8
40C0486 001 导风罩总成 .............................................................................................................. 10
FAN HOOD..................................................................................................................................... 10
21C0111 002 柴油箱 .......................................................................................................................11
DIESEL OIL TANK ........................................................................................................................... 11
16C0004 000 透气盖 ..................................................................................................................... 12
VENT CAP...................................................................................................................................... 12
传动系统POWER TRAIN ............................................................................... 14
01E0057 002 前桥总成 .................................................................................................................. 14
FRONT AXLE ASSEMBLY ............................................................................................................. 14
45C0004 001 夹钳总成.................................................................................................................. 16
TORQUE PLATE ASSEMBLY ........................................................................................................ 16
41C0086 007 主传动总成 .............................................................................................................. 18
PRIMARY REDUCTION ................................................................................................................. 18
41C0087 000 差速器 ..................................................................................................................... 20
DIFFERENTIAL .............................................................................................................................. 20
01E0080 008 后桥总成 .................................................................................................................. 22
REAR AXLE ASSEMBLY................................................................................................................ 22
41C0088 007 主传动总成 .............................................................................................................. 26
PRIMARY REDUCTION ................................................................................................................. 26
03E0038 001 传动轴系统 .............................................................................................................. 28
DRIVE SHAFT ASSEMBLY ............................................................................................................ 28
51C0072 000 中间传动轴 .............................................................................................................. 30
PROPELLER SHAFT ..................................................................................................................... 30
01E0081 000 桥上管路 .................................................................................................................. 31
BRAKE TUBE ON THE AXLES ...................................................................................................... 31
01E0059 000 轮胎轮辋总成 ........................................................................................................... 32
TIRE RIM ASSEMBLY .................................................................................................................... 32
01E0053 002 润滑脂管路 .............................................................................................................. 33
LUBRICIATION LINE...................................................................................................................... 33
05E0016 003 变速箱安装总成 ....................................................................................................... 34
TRANSMISSION GEARING ASSEMBLY ....................................................................................... 34
11C0001 001 变速泵(BB70A) ........................................................................................................ 36
PUMP ............................................................................................................................................. 36
42C0035 010 变速箱 ..................................................................................................................... 38
TRANSMISSION CASE ................................................................................................................. 38
42C0102 000 直接档组件 .............................................................................................................. 44
DIRECT DRIVE CLUTCH PISTON ASSEMBLY............................................................................. 44
52C0071 000 超越离合器 .............................................................................................................. 46
CLG835 whell loader parks catalog 200904005
7
CLUTCH ......................................................................................................................................... 46
42C0094 001 倒档行星架总成 ....................................................................................................... 47
REVERSE RANGE PLANETARY CARRIER ASSEMBLY .............................................................. 47
42C0092 001 一档行星架组件 ....................................................................................................... 48
LOW RANGE PLANETARY CARRIER ASSEMBLY ....................................................................... 48
42C0014 000 透气盖总成 .............................................................................................................. 49
BLEEDING COVER ASSEMBLY .................................................................................................... 49
12C0103 001 变速操纵阀 .............................................................................................................. 50
TRANSMISSION CONTROL VALVE .............................................................................................. 50
05E0063 002 变矩器系统 .............................................................................................................. 52
TORQUE COVERTER SYSTEM.................................................................................................... 52
52C0076 004 变矩器总成 .............................................................................................................. 54
CONVERTER ASSEMBLY ............................................................................................................. 54
00C0002 000 变速泵进油管........................................................................................................... 56
TUBE .............................................................................................................................................. 56
53C0085 001 滤油器 ..................................................................................................................... 57
FILTER ........................................................................................................................................... 57
24C0283 000 变速操纵总成........................................................................................................... 58
POWER SHIFT CONTROL ASSEMBLY......................................................................................... 58
液压系统HYDRAULIC SYSTEM .................................................................... 60
11E0097 002 工作液压系统 ........................................................................................................... 60
HYDRAULIC SYSTEM ................................................................................................................... 60
10C0203 000 动臂油缸.................................................................................................................. 64
LIFT CYLINDER ............................................................................................................................. 64
10C0071 001 转斗油缸.................................................................................................................. 66
BUCKET TILTING CYLINDER........................................................................................................ 66
11E0043 002 先导操纵系统 ........................................................................................................... 68
CONTROL GP-PILOT OPERATED HYDRAULIC .......................................................................... 68
44C0046 003 自动复位系统........................................................................................................... 70
AUTO RESET SYSTEM ................................................................................................................. 70
21C0046 000 液压油箱.................................................................................................................. 72
TANK .............................................................................................................................................. 72
12C0037 003 组合阀 ..................................................................................................................... 74
VALVE ............................................................................................................................................ 74
12C0057 000 单向阀 ..................................................................................................................... 76
VALVE ............................................................................................................................................ 76
00C0400 000 先导油滤管路........................................................................................................... 77
PILOT OIL FILTER LINES .............................................................................................................. 77
12C0098 000 分配阀 ..................................................................................................................... 78
VALVE ............................................................................................................................................ 78
10E0046 005 转向液压系统 ........................................................................................................... 80
HYDRAULIC STEERING SYSTEM................................................................................................ 80
10C0360 001 转向油缸.................................................................................................................. 84
CYLINDER GUOUP ....................................................................................................................... 84
44C0047 001 方向机总成 .............................................................................................................. 86
STEERING GEAR .......................................................................................................................... 86
11E0308 000 工作液压系统(选配) ................................................................................................ 88
HYDRAULIC SYSTEM(OPTIONAL)............................................................................................... 88
00C0676 002 泵阀管路（选配）.................................................................................................... 90
PUPM VALVE LINES(OPTIONAL) ................................................................................................. 90
00C0675 000 多功能管路（选配） ................................................................................................ 94
MULTIPURPOSE LINES(OPTIONAL) ............................................................................................ 94
00C0674 000 快换管路（选配）.................................................................................................... 96
QUICK COUPLER LINES(OPTIONAL) .......................................................................................... 96
10C0410 000 快换油缸（选配）.................................................................................................... 98
CLG835 whell loader parks catalog 200904005
8
QUICKER COUPLE CYLINDER(OPTIONAL) ................................................................................ 98
12C0994 001 快换阀安装总成(选配) ............................................................................................ 99
QUICKER COUPLE VALVE MOUNTING ASSEMBLY(OPTIONAL) ............................................... 99
12C0685 008 快换阀（选配） ..................................................................................................... 100
QUICKER COUPLE VALVE(OPTIONAL) ..................................................................................... 100
12C0995 001 分配阀安装管路（选配）....................................................................................... 102
CONTROL VALVE MOUNTING LINES(OPTIONAL) .................................................................... 102
12C0985 000 先导阀安装总成（选配）....................................................................................... 104
PILOT VALVE MOUNTING ASSEMBLY(OPTIONAL) .................................................................. 104
00C0670 000 先导系统管路（选配） .......................................................................................... 106
PILOT SYSTEM LINES(OPTIONAL) ............................................................................................ 106
44C0071 002 先导切换开关（选配） .......................................................................................... 108
PILOT SWITCH(OPTIONAL)........................................................................................................ 108
11E0340 003 工作液压系统(选配) ...............................................................................................110
HYDRAULIC SYSTEM（OPTIONAL）.........................................................................................110
00C0777 000 先导油滤管路(选配) ...............................................................................................114
PILOT OIL FILTER LINES(OPTIONAL) .........................................................................................114
12C1196 001 组合阀（选配） ......................................................................................................116
COMBINATION VALVE(OPTIONAL) .............................................................................................116
12C1200 000 先导阀安装总成(选配) ...........................................................................................118
PILOT VALVE ASSEMBLY(OPTIONAL) ........................................................................................118
12C1247 001 分配阀安装总成（选配）........................................................................................119
CONTROL VALVE(OPTIONAL).....................................................................................................119
00C0776 002 分配阀管路（选配） .............................................................................................. 120
CONTROL LINES(OPTIONAL) .................................................................................................... 120
11E0384 001 工作液压系统(选配) .............................................................................................. 122
YDRAULIC SYSTEM(OPTIONAL) ............................................................................................... 122
12C1521 000 先导阀安装总成(选配) .......................................................................................... 126
PILOT VALVE ASSEMBLY（OPTIONAL） .................................................................................. 126
12C0414 000 先导阀(选配)......................................................................................................... 128
PILOT VALVE(OPTIONAL) ........................................................................................................... 128
12C0414(A) 000 先导阀(A)（选配） ........................................................................................... 130
PILOT VALVE(A)(OPTIONAL) ...................................................................................................... 130
12C0414(B) 000 先导阀(B)（选配） ........................................................................................... 132
PILOT VALVE(B)(OPTIONAL) ...................................................................................................... 132
00C0882 000 多功能管路（选配） .............................................................................................. 134
LINES(OPTIONAL)....................................................................................................................... 134
12C1399 000 分配阀安装总成(选配) .......................................................................................... 136
CONTROL VALVE ASSEMBLY(OPTIONAL) ................................................................................ 136
00C0883 000 抱叉管路(选配) ..................................................................................................... 138
LOGGING FORK CLAMP LINES(OPTIONAL) ............................................................................. 138
10C0199 000 装卸叉油缸（选配） .............................................................................................. 140
FORK CYLINDER(OPTIONAL) .................................................................................................... 140
制动系统BRAKE SYSTEM ........................................................................... 142
20E0143 003 行车制动系统 ......................................................................................................... 142
SERVICE BRAKE SYSTEM ......................................................................................................... 142
13C0201 002 空气干燥器安装总成 .............................................................................................. 144
AIR DRYER ASSEMBLY .............................................................................................................. 144
13C0054 000 空气罐总成 ............................................................................................................ 145
RESERVOIR ASSEM ................................................................................................................... 145
21E0020 003 紧急和停车制动系统 .............................................................................................. 146
PARKING BRAKE SYSTEM......................................................................................................... 146
13C0009 003 制动气室................................................................................................................ 148
CHAMBER ................................................................................................................................... 148
13C0008 000 制动器 ................................................................................................................... 150
CLG835 whell loader parks catalog 200904005
9
ARRESTER .................................................................................................................................. 150
24C0032 000 拉杆轴总成 ............................................................................................................ 152
LEVER ASSEMBLY ...................................................................................................................... 152
20E0196 000 行车制动系统(选配) .............................................................................................. 154
SERVICE BRAKE SYSTEM(OPTIONAL)..................................................................................... 154
车架和工作装置SHEET METAL SYSTEM .................................................... 156
30E0253 000 前车架总成 ............................................................................................................ 156
FRONT FRAME ASSEMBLY ........................................................................................................ 156
30E0257 000 后车架总成 ............................................................................................................ 158
REAR FRAME ASSEMBLY .......................................................................................................... 158
43C0285 000 铰接总成................................................................................................................ 160
ARTICULATION JOINT ASSEMBLY ............................................................................................ 160
32E0316 000 工作装置 ................................................................................................................ 162
WORKING IMPLEMENT .............................................................................................................. 162
32E0418 001 工作装置限位系统.................................................................................................. 163
WORKING IMPLEMENT LIMIT SYSTEM .................................................................................... 163
30E0274 000 前车架总成(选配) .................................................................................................. 164
FRONT FRAME ASSEMBLY(OPTIONAL) ................................................................................... 164
32E0369 000 铲斗总成(1.7 立方) ............................................................................................... 166
BUCKET ASSEMBLY ................................................................................................................... 166
22D0054 002 铲斗 ....................................................................................................................... 168
BUCKET ....................................................................................................................................... 168
30E0289 000 前车架总成（选配） .............................................................................................. 170
FRONT FRAME ASSEMBLY(OPTIONAL) ................................................................................... 170
30E0334 000 前车架总成(选配) .................................................................................................. 172
FRONT FRAME ASSEMBLY(OPTIONAL) ................................................................................... 172
32E0346 000 工作装置限位系统(选配) ....................................................................................... 174
WORKING IMPLEMENT LIMIT SYSTEM(OPTIONAL) ................................................................ 174
32E0189 000 装卸叉系统（φ600）（选配） ................................................................................. 175
FORK SYETEM(OPTIONAL) ....................................................................................................... 175
43C0194 000 装卸叉(选配)......................................................................................................... 176
FORK(OPTIONAL) ....................................................................................................................... 176
32E0343 001 快换装置（选配）.................................................................................................. 178
QUICK COUPLER(OPTIONAL) ................................................................................................... 178
22D0404 000 快换斗(选配)......................................................................................................... 180
BUCKET(OPTIONAL) .................................................................................................................. 180
32D0304 001 快换架(选配)......................................................................................................... 182
BRACKET(OPTIONAL) ................................................................................................................ 182
43C0388 000 快换平叉（选配）.................................................................................................. 184
QUICK PALLET FORK(OPTIONAL) ............................................................................................. 184
驾驶室和覆盖件CAB AND ACCESSORIE .................................................... 186
41E0165 003 驾驶室总成 ............................................................................................................ 186
CAB ASSEMBLY .......................................................................................................................... 186
47C0239 000 灭火器总成 ............................................................................................................ 190
FIRE EXTINGUISHER ASSEMBLY.............................................................................................. 190
47C0108 000 控制箱总成 ............................................................................................................ 191
CONTROL BOX ........................................................................................................................... 191
47C0543 002 左门 ....................................................................................................................... 192
DOOR GROUP............................................................................................................................. 192
47C0544 002 右门 ....................................................................................................................... 194
DOOR GROUP............................................................................................................................. 194
43E0005 000 右扶梯总成 ............................................................................................................ 196
LADDER ASSEMBLY ................................................................................................................... 196
43E0008 000 脚蹬总成 ................................................................................................................ 197
CLG835 whell loader parks catalog 200904005
10
FOOT STEP ASSEMBLY ............................................................................................................. 197
43E0061 001 前挡泥板总成 ......................................................................................................... 198
FENDER ASSEMBLY ................................................................................................................... 198
43E0102 000 扶梯 ....................................................................................................................... 199
LADDER ASSEMBLY ................................................................................................................... 199
44E0062 003 发动机罩总成 ......................................................................................................... 200
ENGINE HOOD ASSEMBLY ........................................................................................................ 200
24C0034 升降机构 ..................................................................................................................... 202
LIFT MECHANISM ....................................................................................................................... 202
41E0084 000 30G围板总成 .......................................................................................................... 204
PLATFORM ASSEMBLY .............................................................................................................. 204
41E0157 000 后视镜总成 ............................................................................................................ 205
MIRROR ASSEMBLY ................................................................................................................... 205
41E0159 000 驾驶室护盖 ............................................................................................................ 206
CAB COVER ................................................................................................................................ 206
46E0032 000 司机椅总成 ............................................................................................................ 207
SEAT ASSEMBLY......................................................................................................................... 207
48C0314 000 后右挡泥板 ............................................................................................................ 208
FENDER ASSEMBLY ................................................................................................................... 208
48C0316 000 后左挡泥板 ............................................................................................................ 209
FENDER ASSEMBLY ................................................................................................................... 209
空调系统AIR CONDITIONER ARRANGEMENT（R134A）........................ 210
23E0113 003 空调系统（无氟） .................................................................................................. 210
AIR CONDITIONER ARRANGEMENT（R134A）....................................................................... 210
46C1342 001 空压机支架总成 ..................................................................................................... 212
COMPRESSOR BRACKET ASSEMBLY ...................................................................................... 212
46C0645 001 蒸发器总成 ............................................................................................................ 214
EVAPORATOR ASSEMBLY ......................................................................................................... 214
电器系统ELECTRICAL SYSTEM ................................................................. 216
22E0292 002 前车架线路 ............................................................................................................ 216
FRONT FRAME CIRCUITRY ....................................................................................................... 216
22E0446 001 后车架线路 ............................................................................................................ 218
REAR FRAME WIRING................................................................................................................ 218
22E0290 001 电瓶线路 ................................................................................................................ 220
BATTERY WIRING ....................................................................................................................... 220
46C2948 000 驾驶室线路 ............................................................................................................ 222
CAB WIRING................................................................................................................................ 222
46C2949 000 控制箱总成 ............................................................................................................ 224
CONTROL CASE AS.................................................................................................................... 224
22E0288 001 倒车警报系统 ......................................................................................................... 226
BACKUP ALARM SYSTEM .......................................................................................................... 226
22E0289 001 灯组件.................................................................................................................... 227
LIGHTING GROUP ...................................................................................................................... 227
46C0704 000 右前灯总成 ............................................................................................................ 228
FRONT LIGHTING-R.H. ............................................................................................................... 228
46C0705 000 左前灯总成 ............................................................................................................ 229
FRONT LIGHTING-L.H. ............................................................................................................... 229
46C1741 000 刮水器与清洗器系统 .............................................................................................. 230
WIPER AND WASHER SYSTEM ................................................................................................. 230
46C1742 002 顶灯线路................................................................................................................ 232
DOME LIGHT WIRES .................................................................................................................. 232
46C1746 000 仪表板总成 ............................................................................................................ 234
INSTRUMENT PANEL.................................................................................................................. 234
46C0264 000 支座总成................................................................................................................ 236
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$46.99
Viewed 32 Times Today
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$46.99
Get access to the comprehensive parts catalogue manual for the LiuGong CLG835 Wheel Loader. This manual includes detailed part listings for the 62F0025XXXXXXXX, 62F0029XXXXXXXX, and 62F0036XXXXXXXX components. Whether you're a professional mechanic or a DIY enthusiast, this manual is an invaluable resource for all your repair and maintenance needs.
