C-SERIES SKID STEER LOADERS Rated Operating Capacity (ROC): 1,350-3,000 lbs (612-1 360 kg) 48-74 hp (36-55 kW) Tier 4f VOLVO CONSTRUCTION EQUIPMENT

2 A passion for performance. At Volvo Construction Equipment, we’re not just coming along for the ride. Developing products and services that raise productivity – we are confident we can lower costs and increase profits for industry experts. Part of the Volvo Group, we are passionate about innovative solutions to help you work smarter – not harder. Helping you to do more Doing more with less is a trademark of Volvo Construction Equipment. High productivity has long been married to low energy consumption, ease of use and durability. When it comes to lowering life-cycle costs, Volvo is in a class of its own. Designed to fit your needs There is a lot riding on creating solutions that are suited to the particular needs of different industry applications. Innovation often involves high technology – but it doesn’t always have to. Some of our best ideas have been simple, based on a clear and deep understanding of our customers’ working lives. You learn a lot in 180 years Over the years, Volvo has advanced solutions that have revolutionized the use of construction equipment. No other name speaks Safety louder than Volvo. Protecting operators, those around them and minimizing our environmental impact are traditional values that continue to shape our product design philosophy. We’re on your side We back the Volvo brand with the best people. Volvo is truly a global enterprise, one that is on standby to support customers quickly and efficiently – wherever they are. We have a passion for performance. Volvo Trucks Renault Trucks Mack Trucks

3 UD Trucks Volvo Buses Volvo Construction Equipment Volvo Penta Volvo Financial Services

4 Work comfortably. It’s proven that less fatigue means more productivity. The Volvo cab has it all. It features comfortable operation, both at the controls and in regard to its low noise level. It also has plenty of personal space to make operators feel more at ease. Comfort cab The new skid steer loader cab is spacious and safe. It meets the ROPS/ FOPS safety standards and offers operators 27% more space over previous models. Increased comfort means extended operator productivity. Ample storage Storage space is conveniently located under the left hand armrest. This easily accessible area gives the operator a secure place to store personal items such as keys. There is also a 12V power outlet here. Interior noise All models – both canopy and enclosed cab – are designed to limit noise in and around the operator environment. Less noise reduces operator fatigue and creates a more comfortable working environment. Instrument consoles Two consoles, positioned in the upper front cab corners, provide easy to read gauges. Simply presented instruments, situated for operator comfort, ensure easy viewing.

5 Cab access Large side door allows operators to safely enter and exit the machine without climbing over an attachment. This minimizes the risk of slipping and the need to turn to sit down. Operators access the cab via a non-slip step. In a raised loader arm service position operators do not need to walk under the loader arm to engage the support strut.

Designed for performance. Loader design The unique single loader arm design delivers the loading performance and durability of a traditional machine but with the advantages of side entry and a single tower for improved visibility and safety.

7 Our unique, single loader arm design affords operators many performance advantages. It’s durable, it’s safe and it provides excellent visibility. With high capacity and built in efficiency, you can perform at a higher level. Vertical lift Excellent vertical lift that is perfect for truck loading and material handling applications due to the increase in height and reach. Also delivers greater lift capacity for efficiency in repeated load and carry operations. Radial lift Radial lift path is the ideal design for ground engaging applications. It’s strong, durable and easy to maintain. Radial lift offers increased levels of stability and remains the ideal choice for heavy-duty attachment applications. Weight distribution Weight is evenly distributed across the machine providing stability when handling both heavy and light loads. The offset cab and engine compartment counterbalance the unique single loader arm ensuring ultimate stability and balance from side to side.

8 Easier service. Longer life. Access greater uptime with user-friendly serviceability. Perform routine daily checks or access major components – it’s all within easy access. This means you spend less time maintaining your machine and more time earning money. O-ring face seals Hydraulic connections use o-ring face seal (ORFS) fittings to eliminate hydraulic leaks. ORFS connectors reduce downtime and service costs by providing a 100% leak free joint. Loader pivot pins Our loader arm pivot pins are larger and therefore stronger than those used by competitors. They effectively distribute the load over the single arm design for longevity and durability. Cab tilt The entire cab can easily be tilted forward by one person with the removal of two bolts from the inside. Gas struts lock into place for simple, safe and quick access to key internal components.

9 Service access Easy service access due to single loader arm, forward- tilting cab and large rear door. Simple access to service and maintenance items helps provide a longer operating life.

See it all. Do it all. Visibility The single tower loader arm – with no horizontal cross member on the vertical lift model – provides superior visibility. The machine has a large top window and narrow ROPS cab pillars. The unique features help the operator maneuver the machine in tight areas to maximize productivity.
