Date:
2013/12/15
Image id:
1013369
Catalogue:
20044
Model:
ECR88
Brand:
Volvo
Serial:
10001-14010
Group/Section:
210/100
Title:
Engine
Section option Kit Option description
VOE8279041 Engine without Epa label INT AND KOREAN MARKET
VOE8279042 Engine with Epa label EMISSION CERTIFICATED FROM EPA
Q1-Q5 Option Option description
Q1 8279041 VOE8279041 Engine without Epa label INT AND KOREAN MARKET
Q2 8279042 VOE8279042 Engine with Epa label EMISSION CERTIFICATED FROM EPA
Pos Part Q1 Q2 Q3 Q4 Q5 PS Kit Description Option(s) Remark
1 VOE14530218 1 SS Engine Without labels SER NO
10001-10087
VOE14540752 1 Engine (VOE14533408)
Without labels SER NO
10088-10749
VOE14540752 1 Engine Without labels SER NO
10750-11623
VOE14575309 1 Engine Without labels SER NO
11624-
VOE14530219 1 Engine With EU and EPA label
SER NO 10001-10072
VOE14533409 1 SS Engine With EU and EPA label
SER NO 10073-10749
VOE14540753 1 Engine With EU and EPA label
SER NO 10750-11623
VOE14575308 1 Engine With EU and EPA label
SER NO 11624-
Date:
2013/12/15
Image id:
1013370
Catalogue:
20044
Model:
ECR88
Brand:
Volvo
Serial:
10001-14010
Group/Section:
210/200
Title:
Repair kits for engine
Section option Kit Option description
VOE8279041 Engine without Epa label INT AND KOREAN MARKET
VOE8279042 Engine with Epa label EMISSION CERTIFICATED FROM EPA
Q1-Q5 Option Option description
Q1 8279041
Q2 8279042
Pos Part Q1 Q2 Q3 Q4 Q5 PS Kit Description Option(s) Remark
1 VOE14528170 1 1 Gasket
2 VOE14521606 1 1 •Gasket
3 VOE14528161 1 1 •Gasket
4 VOE14521527 8 8 •Valve seal
5 VOE14521532 4 4 •Protection
6 SA8210-08770 1 1 SS •Seat
7 VOE14521552 1 1 •Gasket
8 VOE14521554 1 1 •Gasket
9 VOE11714737 1 1 •Gasket (SA8210-04570)
10 VOE14520599 2 2 •Gasket
11 VOE14521528 8 8 •Valve seal
12 VOE11714738 2 2 •O-ring (SA8210-04770)
13 VOE11714739 1 1 •O-ring (SA8210-04780)
14 SA8210-04820 1 1 •Gasket
15 SA8210-04840 1 1 •Gasket
16 VOE11714740 1 1 •Gasket (SA8210-02790)
17 VOE11714741 1 1 •Gasket (SA8210-02840)
18 SA8210-02780 1 1 •Gasket
19 VOE11714477 3 3 •Gasket (SA8210-05580)
20 VOE11714478 2 2 •Gasket (SA8210-03370)
21 SA8210-08860 1 1 •O-ring
22 VOE11714386 12 12 •O-ring (SA8210-08870)
23 VOE11714371 3 3 •O-ring (SA8210-08880)
24 VOE11714476 7 7 •Sealing washer (SA8240-01020)
25 VOE14509382 1 1 •O-ring
26 VOE14521512 1 1 •Wrapping
27 VOE14525412 1 1 Brush
28 VOE14543857 1 1 Gasket (SA8240-02760)
Date:
2013/12/15
Image id:
1013371
Catalogue:
20044
Model:
ECR88
Brand:
Volvo
Serial:
10001-14010
Group/Section:
211/100
Title:
Cylinder head
Section option Kit Option description
VOE8279041 Engine without Epa label INT AND KOREAN MARKET
VOE8279042 Engine with Epa label EMISSION CERTIFICATED FROM EPA
Q1-Q5 Option Option description
Q1 8279041
Q2 8279042
Pos Part Q1 Q2 Q3 Q4 Q5 PS Kit Description Option(s) Remark
1 VOE14521519 1 1 Cylinder head
2 VOE14525388 16 16 •Valve guide
3 VOE14521521 8 8 •Guide
4 VOE14521522 1 1 •Plug
5 VOE14521504 4 4 •Plug
6 VOE11714379 1 1 •Plug (SA8210-05840)
7 VOE14521523 8 8 •Inlet valve INLET VALVE
