ECR58D, ECR88D 5.7-9.5 t (12,550 - 20,950 lbs) 49-58 hp VOLVO EXCAVATORS

The strength of our dealer network is enhanced with extensive individualized product and product support training at our state- of-the-art Technical Training Center in Asheville and through hands-on training. At our nearby 80-acre Product Demonstration Center, visitors operate equipment from our entire product line under a variety of simulated working conditions. Both facilities are in year-round use by our dealers and customers – more than 2,000 visit each year. Building the best starts right here. The products designed and manufactured by Volvo Construction Equipment have their beginnings at the most advanced Research & Design centers in the industry. Volvo CE machines are designed in 11 R&D centers and produced in 15 manufacturing facilities across the world. The major R&D center and manufacturing plant in the Americas is located in Shippensburg, Pennsylvania. This facility has been in operation for over 30 years and – with its recently added 200,000 sq. ft. expansion – now covers 570,000 sq. ft. on an 80 acre campus. Dedicated work teams and highly advanced technologies and techniques using the Volvo Production System ensure continuous quality improvements, labor savings and cost control to reach the high quality that our customers have come to expect from Volvo. At Volvo Construction Equipment, we’re not just coming along for the ride. Developing products and services that raise productivity – we are confident we can lower costs and increase profits for industry experts. Part of the Volvo Group, we are passionate about innovative solutions to help you work smarter – not harder. Helping you to do more Doing more with less is a trademark of Volvo Construction Equipment. High productivity has long been married to low energy consumption, ease of use and durability. When it comes to lowering life-cycle costs, Volvo is in a class of its own. Designed to fit your needs There is a lot riding on creating solutions that are suited to the particular needs of different industry applications. Innovation often involves high technology – but it doesn’t always have to. Some of our best ideas have been simple, based on a clear and deep understanding of our customers’ working lives. You learn a lot in 180 years Over the years, Volvo has advanced solutions that have revolutionized the use of construction equipment. No other name speaks Safety louder than Volvo. Protecting operators, those around them and minimizing our environmental impact are traditional values that continue to shape our product design philosophy. We’re on your side We back the Volvo brand with the best people. Volvo is truly a global enterprise, one that is on standby to support customers quickly and efficiently – wherever they are. We have a passion for performance. A strong, dedicated, capable dealer network. Our dealers are strategically located throughout North America to provide the equipment you need and the parts and service support you demand for a productive and profitable operation. A passion for performance. 2

UD Trucks Volvo Buses Volvo Financial Services Volvo Trucks Renault Trucks Mack Trucks Volvo Construction Equipment Volvo Penta 3

Powered to perform. Enhanced hydraulics Volvo’s state-of-the-art hydraulic system is perfectly matched to the Volvo engine and components – delivering high performance and improved fuel efficiency. The hydraulic system has been designed for fast response and smooth operation.

Volvo proudly introduces the new ECR58D and ECR88D compact short swing radius excavators. Featuring a powerful Volvo engine and perfectly matched hydraulic system, each machine delivers high performance, excellent control and low fuel consumption, whether working in road construction, utilities, landscaping or any other application. Tractive force Change text to: Increased tractive effort through high system pressure delivers impressive performance when dozing or travelling over rough terrain Slew and boom offset Slew and boom offset movements are controlled simultaneously for easy and fast positioning of the machine. Joystick control enables precise, smooth and effortless command of the slew and boom offset. Tier 4f engine Volvo’s premium Tier 4f engine delivers superior performance and low fuel consumption. The engine features an Exhaust After Treatment System (EATS) to lower emissions and a regeneration process that does not interrupt operation, performance or productivity. 5

Single pivot pin Volvo uses a single pivot design that achieves maximum support between main frame and front equipment, This concept increases, stability, durability and lifetime of the components. Service access For safe and easy access, all service check points are located under the wide-opening engine hood and are accessed from ground level. Grouped filters ensure regular maintenance is straightforward and uptime is maximized. MATRIS and VCADS Pro For increased uptime, Volvo’s high-tech, computer-based MATRIS tool allows you to monitor machine usage and analyze machine operation. VCADS Pro analysis and programming software provides fast diagnostics. Stability you can count on. If you’re looking for the performance of a conventional excavator but need to work in confined areas, the Volvo ECR series has the machine for you. With a “new” wraparound counterweight and “re-designed” heavy duty undercarriage these ECRs have an impressive lift capacity, reducing the requirement for an expensive larger model. Volvo offers customers built-in serviceability with safe and convenient maintenance access for maximum uptime. 6

Stability Design improvements including a heavier wraparound counterweight have shifted the center of gravity towards the rear of the machine. Together with a strong undercarriage, this delivers superior stability while lifting bigger loads. 7

Control in comfort. At Volvo we know that when operators are comfortable they experience less fatigue and work more productively. That’s why the premium, Volvo designed cab provides superior visibility, a safe and spacious working environment and easy to access controls. Step inside and see the results for yourself. Volvo Cab All-around visibility from slim cab pillars and large expanses of glass is at the center of Volvo’s cab design. The ROPS certified cab features vibration and noise isolation, ergonomic controls and an adjustable seat for increased comfort, reduced fatigue and increased productivity. 8

Climate control Control your climate with Volvo’s powerful, industry-leading climate control system. With seven well-spaced vents quickly heating or cooling the cab, this air circulation and defrosting system increases comfort and productivity. Proportional joysticks Via the joystick controls, the operator can easily adjust the direction and amount of hydraulic flow sent to the attachment. Benefit from the correct speed and power for optimal attachment operation. Keypad The majority of switches are integrated in one centralized keypad on the right-hand console. The operator can easily control the I-ECU monitor and audio system for increased comfort. Storage The Volvo cab features ample storage locations for personal belongings including a storage box, side pocket, phone storage, cup holder and a pocket behind the seat. 9

Infinite opportunities. Hydraulic breakers Volvo’s durable hydraulic breakers have been designed for ultimate compatibility with Volvo excavators. The range has been built to break the most demanding materials and combines excellent performance with low noise and vibration levels. 10
