Volvo ECR145D/ECR235D Excavator OEM Service & Repair Manual

ecR145d, ecR235d 14.4-27.7 t / 31,640-60,980 lb, 114-173 hp VOLVO EXCAVATORS

The strength of our dealer network is enhanced with extensive individualized product and product support training at our state- of-the-art Technical Training Center in Asheville and through hands-on training. At our nearby 80-acre Product Demonstration Center, visitors operate equipment from our entire product line under a variety of simulated working conditions. Both facilities are in year-round use by our dealers and customers – more than 2,000 visit each year. Building the best starts right here. The products designed and manufactured by Volvo Construction Equipment have their beginnings at the most advanced Research & Design centers in the industry. Volvo CE machines are designed in 11 R&D centers and produced in 15 manufacturing facilities across the world. The major R&D center and manufacturing plant in the Americas is located in Shippensburg, Pennsylvania. This facility has been in operation for over 30 years and – with its recently added 200,000 sq. ft. expansion – now covers 570,000 sq. ft. on an 80 acre campus. Dedicated work teams and highly advanced technologies and techniques using the Volvo Production System ensure continuous quality improvements, labor savings and cost control to reach the high quality that our customers have come to expect from Volvo. At Volvo Construction Equipment, we’re not just coming along for the ride. Developing products and services that raise productivity – we are confident we can lower costs and increase profits for industry experts. Part of the Volvo Group, we are passionate about innovative solutions to help you work smarter – not harder. Helping you to do more Doing more with less is a trademark of Volvo Construction Equipment. High productivity has long been married to low energy consumption, ease of use and durability. When it comes to lowering life-cycle costs, Volvo is in a class of its own. Designed to fit your needs There is a lot riding on creating solutions that are suited to the particular needs of different industry applications. Innovation often involves high technology – but it doesn’t always have to. Some of our best ideas have been simple, based on a clear and deep understanding of our customers’ working lives. You learn a lot in 175 years Over the years, Volvo has advanced solutions that have revolutionized the use of construction equipment. No other name speaks Safety louder than Volvo. Protecting operators, those around them and minimizing our environmental impact are traditional values that continue to shape our product design philosophy. We’re on your side We back the Volvo brand with the best people. Volvo is truly a global enterprise, one that is on standby to support customers quickly and efficiently – wherever they are. We have a passion for performance. A strong, dedicated, capable dealer network. Our dealers are strategically located throughout North America to provide the equipment you need and the parts and service support you demand for a productive and profitable operation. A passion for performance. 2

UD Trucks Volvo Buses Volvo Aero Volvo Financial Services Volvo Trucks Renault Trucks Mack Trucks Volvo Construction Equipment Volvo Penta 3

Engineered for efficiency. Fuel efficiency is at the heart of Volvo’s ECR145D and ECR235D. Featuring the Tier 4 Interim engine, ECO mode and improved hydraulics, these machines deliver reduced fuel consumption and cycle times, as well as increased digging performance. Save time and money with Volvo. Regeneration Soot collected by the Diesel Particulate Filter is oxidized every eight hours, depending on application. Volvo’s unique, operator controlled, 25 minute system does not interrupt operation, performance or productivity. For increased safety, regeneration can be postponed. Auto idling system Reduces rpm to idle when the controls are inactive for a specified time – between 3-20 seconds. The length of time is set up via the I-ECU monitor. This system delivers reduced fuel consumption and running costs. Efficient engine Volvo’s fuel efficient Tier 4 Interim diesel engine gives you more power, while consuming less fuel. Benefit from reduced operating costs as well as low emission levels for ultimate efficiency and environmental care. Work modes For added versatility operators can select the best work mode for the task at hand to ensure optimum performance and fuel efficiency. Easily choose the correct mode, within the throttle control, according to your working conditions. ECO mode Volvo’s unique ECO mode features sophisticated electronic pump control technology for increased fuel efficiency. It can be used in-conjunction with any working mode. There is no loss of performance in the majority of operating conditions. 4

Get productive with these short swing radius machines – perfect for maneuvering in and out of confined areas with ease. Featuring class-leading digging depth with a 2,4 m (8 ft) flat level and superior stability, you can achieve more with Volvo. Narrow design These machines feature a narrow design compared to the classic crawler excavators but still maintain the stability, balance and performance that you would expect from a conventional model. The boom is positioned in the center of the machine. Get the job done. Compact swing radius Short front and rear radius ensures safe and easy operation within a confined space – reducing the risk of damage to the rear compartments in urban construction. 620 mm 1 980 mm 1 494 mm 725 mm 2' 0" 6' 6" 4' 11" 2' 5" 1 640 mm 2 000 mm 1 720 mm 1 170 mm 5' 5" 6' 7" 5' 8" 3' 10" 5

More power. More speed. Volvo understands that machines need to perform day in, day out. With strong digging power and various work modes the ECR145D and ECR235D are ideally suited to extracting hard and compact materials. Additional pump flow provides faster cycle times. Trust Volvo to increase your productivity. Idle (I) Mode For reduced fuel consumption and more environmental care, the higher I-stage of the Idle Mode is used for auto idling – which is highly recommended when truck loading. The second stage (lower I-stage) is typically used for warm up and cool down. Fine (F) Mode The Fine control mode provides high hydraulic pressure setting same as power boost function for maximum lifting capability. It is also used for precise grading operation. General (G) Mode The General Mode features three different stages of speed. The highest G setting is recommended for maximum fuel saving and good productivity in digging and truck loading. The middle and low G settings can be used for ditching, levelling, slope finishing and spreading where moderate speed is needed. Heavy (H) Mode H Mode is used for high productivity in intensive and bulk earthmoving applications. It is used for hard digging, trenching and truck loading from deep trenches. 6

Space matters – especially in the cab. That’s why Volvo has designed a premier operator environment with built in safety, comfort and all-round visibility. Featuring ample leg room and easy to access controls for increased productivity. See everything from all angles in the Volvo’s spacious cab. Work in comfort. I-ECU monitor Large color monitor provides excellent clarity in all lighting conditions. Using a control panel, the operator and service technician can make quick visual and diagnostic checks, increasing uptime and productivity. The monitor also displays camera images – up to four at a time. Seat Featuring nine different adjustments for superb operator comfort and reduced vibration, Volvo’s superior seat provides comfort to all operators – resulting in more productivity. Control panel Optimally positioned control panel ensures there is no need for operators to move or lean forward to change settings or navigate through the I-ECU monitor. This increases operator comfort and safety. Visibility Slim cab pillars and large expanses of glass ensure excellent all-round visibility. Enhanced vision delivers improved safety and also allows operators to increase their productivity. Industry-leading cab Volvo’s spacious convex cab design is Roll Over Protective Structure (ROPS) certified for increased peace of mind in the unlikely event of machine roll over. The cab features a sliding door and a tilting type left-hand console for easy entry and exit to the machine.

More uptime. Service points Large, wide compartment doors provide ground level access (wherever possible) to grouped filters and greasing points, reducing maintenance downtime. Excellent centralized access for quick servicing and increased uptime. Anti-slip plates Added operator and service mechanic safety from punched anti-slip plate on the superstructure. This provides superb grip, especially in wet or icy conditions. 8

Air filters Conveniently located air filter elements offer easy access for more machine uptime. The primary air filter removes all major particles and may be cleaned up to five times or used for one year. A secondary protective filter is in place in case of malfunction. Main control valve Access to the main control valve is available at ground level, minimizing the amount of service downtime. Service access Conveniently located boom and arm greasing points are grouped for simplicity and ease of access. In general applications greasing is needed at 50 hour intervals but this can be extended to 500 hours with long life bushings. Slew ring greasing is at 250 hours. 9

Profiling your new excavator. CareTrack Volvo’s telematics system guides machine owners towards optimized productivity and their next service – remotely. ECO mode Volvo’s unique ECO mode improves fuel efficiency without sacrificing performance. Boom and arm Available with a mono or two piece boom, and with different arm configurations, for increased flexibility and versatility. Power and speed Perform at a higher level with increased digging power and faster cycle times for greater productivity. Swing radius Short front and rear radius ensures safe and easy operation within a confined space. Undercarriage Three-piece, high tensile steel undercarriage is designed and built to withstand the toughest conditions. 10
