INTRODUCTION IN-01 ADDITIONAL REFERENCES Please refer to the materials listed below in addition to this manual. The Operators Manual The Parts Catalog Operation Manual of the Engine Parts Catalog of the Engine Hitachi Training Material MANUAL COMPOSITION This manual consists of three portions: the Techni- cal Manual (Operational Principle), the Technical Manual (Troubleshooting) and the Workshop Man- ual. Information included in the Technical Manual (Operational Principle): technical information needed for redelivery and delivery, operation and activation of all devices and systems. Information included in the Technical Manual (Troubleshooting): technical information needed for operational per- formance tests, and troubleshooting procedures. Information included in the Workshop Manual: technical information needed for maintenance and repair of the machine, tools and devices needed for maintenance and repair, maintenance standards, and removal/installation and assem- ble/disassemble procedures.
INTRODUCTION IN-02 PAGE NUMBER Each page has a number, located on the center lower part of the page, and each number contains the following information: Example : T 1 -3 -5 SAFETY ALERT SYMBOL AND HEADLINE NOTATIONS In this manual, the following safety alert symbol and signal words are used to alert the reader to the potential for personal injury of machine damage. This is the safety alert symbol. When you see this symbol, be alert to the potential for personal injury. Never fail to follow the safety instructions prescribed along with the safety alert symbol. The safety alert symbol is also used to draw attention to component/part weights. To avoid injury and damage, be sure to use appropri- ate lifting techniques and equipment when lifting heavy parts. CAUTION: Indicated potentially hazardous situation which could, if not avoided, result in personal injury or death. IMPORTANT: Indicates a situation which, if not conformed to the instructions, could result in damage to the machine. NOTE: Indicates supplementary technical information or know-how. Consecutive Page Number for Each Group Group Number Section Number T: Technical Manual W: Workshop Manual
INTRODUCTION IN-03 UNITS USED SI Units (International System of Units) are used in this manual. MKSA system units and English units are also indicated in parenthheses just behind SI units. Example : 24.5 MPa (250 kgf/cm 2 , 3560 psi) A table for conversion from SI units to other system units is shown below for reference purposees. Quantity To Convert From Into Multiply By MPa kgf/cm 2 10.197 Pressure MPa psi 145.0 kW PS 1.360 Power kW HP 1.341 Temperature C F C1.8+32 km/h mph 0.6214 Velocity min -1 rpm 1.0 Flow rate L/min US gpm 0.2642 mL/rev cc/rev 1.0 Quantity To Convert From Into Multiply By mm in 0.03937 Length mm ft 0.003281 L US gal 0.2642 L US qt 1.057 Volume m 3 yd 3 1.308 Weight kg lb 2.205 N kgf 0.10197 Force N lbf 0.2248 N m kgf m 1.0197 Torque N m lbf ft 0.7375
INTRODUCTION IN-04 (Blank)
SECTION AND GROUP CONTENTS TECHNICAL MANUAL (Operational Principle) SECTION 1 GENERAL Group 1 Specifications Group 2 Component Layout Group 3 Component Specifications SECTION 2 SYSTEM Group 1 Control System Group 2 Hydraulic System Group 3 Electrical System SECTION 3 COMPONENT OPERATION Group 1 Pump Device Group 2 Swing Device Group 3 Control Valve Group 4 Pilot Valve Group 5 Travel Device Group 6 Others(Upperstructure) Group 7 Others(Undercarriage) TECHNICAL MANUAL (Troubleshooting) SECTION 4 OPERATIONAL PER- FORMANCE TEST Group 1 Introduction Group 2 Standard Group 3 Engine Test Group 4 Excavator Test Group 5 Component Test Group 6 Adjustment SECTION 5 TROUBLESHOOTING Group 1 Diagnosing Procedure Group 2 Component Layout Group 3 Troubleshooting A Group 4 Troubleshooting B Group 5 Troubleshooting C Group 6 Electrical System Inspection Group 7 ICX WORKSHOP MANUAL SECTION 1 GENERAL INFORMA- TION Group 1 Precautions for Disassem- bling and Assembling Group 2 Tightening Torque Group 3 Painting SECTION 2 UPPERSTRUCTURE Group 1 Cab Group 2 Counterweight Group 3 Main Frame Group 4 Pump Device Group 5 Control Valve Group 6 Swing Device Group 7 Pilot Valve Group 8 Pilot Shut-Off Valve Group 9 Shockless Valve Group 10 Solenoid Valve Unit SECTION 3 UNDERCARRIAGE Group 1 Swing Bearing Group 2 Travel Device Group 3 Center Joint Group 4 Track Adjuster Group 5 Front Idler Group 6 Upper and Lower Roller Group 7 Track SECTION 4 FRONT ATTACHMENT Group 1 Front Attachment Group 2 Cylinder
1HHT-1-1 SECTION 1 GENERAL CONTENTS Group 1 Specifications Specifications ............................................ T1-1-1 Working Ranges ....................................... T1-1-5 Group 2 Component Layout Main Component Layout ........................... T1-2-1 Electrical Component Layout (Over view) ............................................... T1-2-2 Electrical System(Relays) ......................... T1-2-3 Electrical System (Monitors and Switches) ........................... T1-2-4 Engine ...................................................... T1-2-5 Pump Device ............................................ T1-2-5 Swing Device ............................................ T1-2-5 Control Valve ............................................ T1-2-6 Travel Device ............................................ T1-2-6 Solenoid Valve Unit ................................... T1-2-7 Shockless Valve ........................................ T1-2-7 Positioning Control Valve ........................ T1-2-7 Group 3 Component Specifications Engine ...................................................... T1-3-1 Engine Accessories .................................. T1-3-4 Hydraulic Component ............................... T1-3-5 Electrical Component ................................ T1-3-8
This service manual set for the HITACHI ZAXIS 330 330LC 350LC 350LCH 350LCN 350H 370MTH EXCAVATOR consists of three main portions:
Technical Manual (Operation Principle)
Technical Manual (Troubleshooting)
Workshop Manual
The Technical Manual (Operation Principle) includes technical information required for redelivery, delivery, operation, and activation of all devices and systems. The Technical Manual (Troubleshooting) contains technical information needed for operational performance tests and troubleshooting procedures. The Workshop Manual provides technical information for maintenance and repair of the machine, tools and devices needed for maintenance and repair, maintenance standards, and removal/installation and assemble/disassemble procedures.
The Workshop Manual includes the following sections:
INTRODUCTION
SAFETY
GENERAL INFORMATION
UPPERSTRUCTURE
UNDERCARRIAGE
FRONT ATTACHMENT
ENGINE AND ACCESSORY
The Troubleshooting Manual contains the following sections:
INTRODUCTION
SAFETY
OPERATION PERFORMANCE TEST
TROUBLESHOOTING
SCHEMATIC
The Operation Principle Manual includes the following sections:
INTRODUCTION
GENERAL
SYSTEM
COMPONENT OPERATION
The service manual (Manual #KM1HHE02) consists of the following three separate volumes:
Additionally, it includes the circuit diagram TT1HHE02CIR.
File Format: .PDF
Total pages: 1272
Size: 68Mb
Manual Language: English
This manual contains comprehensive information, specs, diagrams, actual real photo illustrations, and schemes for the specified model. It is a valuable resource for diagnosing, repairing, and maintaining Hitachi machinery. The digital format allows for space savings and enables the use of the Search feature in Acrobat to find specific information and print out exact pages as needed.
If you are interested in other guides, click on the "Recipes / Manuals" section in the upper right corner. Feel free to contact me if you have any questions or if you are looking for a specific manual. Have a great day!
