JCB Parts LIST 2 200 410 415 418 435 520 700 2B 2D 3C 3CX

ENGINE INFORMATION 2.8T 3 CYL STD BORE: 3.934" DESCRIPTION PART NO. MAJOR OH KIT N/A A-OK2.8T IN FRAME OH KIT N/A A-IK2.8T For Models: 2, 2B ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON LESS RINGS 1 A-37D426 3 PISTON LESS RINGS A-37D3106 3 PISTON RING SET 2 A-AHM9023 3 PISTON RING SET 3 A-AHM9025 3 PISTON LINER 3 A-37D1837 3 PISTON LINER 4 A-37D425 3 LINER SEAL 3 A-AMK102 3 LINER SEALING RING 4 A-AMK61 3 PISTON LINER SHIM (.005") A-AMK1971 3 DESCRIPTION PART NO. SIZE QTY KIT MAIN BEARING SET (STD) A-8G2366 1 MAIN BEARING SET (.030) A-8G236630 1 ROD BEARING SET, STD A-8G2369 1 DESCRIPTION PART NO. SIZE QTY KIT CONN ROD BUSHING A-37D3037 3 THRUST WASHER SET A-37D155 1 TIMING COVER SEAL A-BMK991 1 DESCRIPTION PART NO. SIZE QTY KIT INTAKE VALVE A-AMK1567 3 EXHAUST VALVE A-AMK48 3 INNER VALVE SPRING A-AMK82 6 OUTER VALVE SPRING A-AMK81 6 INTAKE VALVE GUIDE A-86K144 3 EXHAUST VALVE GUIDE A-86K145 3 DESCRIPTION PART NO. SIZE QTY KIT UPPER GASKET SET A-78G1300 1 GASKET SET, BOTTOM A-78G1198 1 HEAD GASKET A-37D1845 1 DESCRIPTION PART NO. SIZE QTY KIT FUEL LIFT PUMP A-13H3375 1 A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 2.8T ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN (1) 2, 2B, 3/45, <4041 (2) 2, E3055> (3) 2, 3, 2B, 3/42, 3/45, 10/42, E3055 > (4) 2, 3, 2B, 3/42, 3/45, 10/42, < E3054

ENGINE INFORMATION 2.8TD 3 CYL STD BORE: 3.934" DESCRIPTION PART NO. MAJOR OH KIT N/A A-OK2.8TD IN FRAME OH KIT N/A A-IK2.8TD For Models: 2, 2B ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON LESS RINGS 1 A-37D426 3 PISTON LESS RINGS A-37D3106 3 PISTON RING SET 2 A-AHM9025 3 PISTON LINER 3 A-37D1837 3 PISTON LINER 4 A-37D425 3 LINER SEAL 3 A-AMK102 3 LINER SEALING RING 4 A-AMK61 3 PISTON LINER SHIM (.005") A-AMK1971 3 DESCRIPTION PART NO. SIZE QTY KIT MAIN BEARING SET (STD) 5 A-8G2366 1 MAIN BEARING SET (.030) 5 A-8G236630 1 DESCRIPTION PART NO. SIZE QTY KIT CON ROD BRG SET (STD) A-8G2484 1 CON ROD BRG SET (.015) A-8G248415 1 CON ROD BUSHING A-37D3037 3 THRUST WASHER SET A-ABU9634 1 DESCRIPTION PART NO. SIZE QTY KIT FRONT OIL SEAL A-AAU6234 1 REAR OIL SEAL A-NKJ3472 1 DESCRIPTION PART NO. SIZE QTY KIT INTAKE VALVE A-AMK1567 3 EXHAUST VALVE A-AMK48 3 INNER VALVE SPRING A-AMK82 6 OUTER VALVE SPRING A-AMK81 6 INTAKE VALVE GUIDE A-86K144 3 EXHAUST VALVE GUIDE A-86K145 3 DESCRIPTION PART NO. SIZE QTY KIT UPPER GASKET SET A-78G1300 1 GASKET SET, BOTTOM 6 A-78G1198 1 HEAD GASKET A-37D1845 1 DESCRIPTION PART NO. SIZE QTY KIT FUEL LIFT PUMP A-13H3375 1 2.8TD (1) 2, 2B, <4041 (2) 2, 2B, < 4041 (3) 2, 3, 2B E3055> (4) 2, 3, 2B, <E3054 (5) 3C, 4C, 3D ONLY (6) 2B, ONLY A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION 3.8T 4 CYL STD BORE: 3.934" DESCRIPTION PART NO. MAJOR OH KIT N/A A-OK3.8T IN FRAME OH KIT N/A A-IK3.8T For Models: 3C, 3D, 4C ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON LESS RINGS A-37D426 4 PISTON RING SET A-AHM9025 4 PISTON LINER 1 A-37D1837 4 PISTON LINER 2 A-37D425 4 LINER SEAL 3 A-AMK102 4 LINER SEAL 4 A-AMK61 4 PSTN LINR SHIM (.005") 2 A-AMK1971 4 DESCRIPTION PART NO. SIZE QTY KIT MAIN BRG SET (STD) 6 A-8G2366 1 MAIN BRG SET (-.015") 7 A-8G248315 1 MAIN BRG SET (.015) 6 A-8G236615 1 MAIN BRG SET (.030) 6 A-8G236630 1 DESCRIPTION PART NO. SIZE QTY KIT CON ROD BRG SET (STD) A-8G2370 1 CON ROD BRG SET (015) A-8G237015 1 CON ROD BRG SET (030) A-8G237030 1 CON ROD BUSHING A-37D3037 4 DESCRIPTION PART NO. SIZE QTY KIT THRUST WASHR SET 8 A-37D155 1 TIMING COVER SEAL 8 A-BMK991 1 DESCRIPTION PART NO. SIZE QTY KIT INTAKE VALVE A-AMK1567 4 EXHAUST VALVE A-AMK48 4 INNER VALVE SPRING A-AMK82 8 OUTER VALVE SPRING A-AMK81 8 INTAKE VALVE GUIDE A-86K144 4 EXHAUST VALVE GUIDE A-86K145 4 DESCRIPTION PART NO. SIZE QTY KIT UPPER GASKET SET 9 A-78G1330 1 LOWER GASKET SET A-78G1258 1 CYLINDER HEAD GASKET 9 A-86K625 1 ROCKER COVER GSKT 10 A-CMK1315 1 ROCKER COVER GSKT 11 A-CMK1343 1 SUMP GASKET A-96K614 1 DESCRIPTION PART NO. SIZE QTY KIT FUEL LIFT PUMP A-13H3375 1 (1) 3C, 4C, 3D, E48185> (2) 3C, 4C, 3D, < E49184 (3) 2, 3, 2B, E3055 > (4) 3C, 4C, 3D, < 49184 (6) 3C, 4C, 3D, ONLY (7) 4/65 ONLY (8) 3C, 4C, 3D, ONLY (9) 3MK11, 3MK111, 3CMK11, 3MK111, 2D, 3D, 3DMK111, 4D, 700 <E44286 (10) 3C, 4C, 3D, <80180 (11) 3C, 4C, 3D, 80181 > A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 3.8T ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION 4.98NT 4 CYL STD BORE: 3.858" DESCRIPTION PART NO. MAJOR OH KIT N/A A-OK4.98NT IN FRAME OH KIT N/A A-IK4.98NT For Models: 2D, 3C, 3CMK111, 3CX, 3D, 3MK111, 3DMK111, 700 ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON L/ RINGS 1 A-96K471 4 PISTON L/ RINGS 2 A-96K570 4 RING SET 2 A-AHM9014 4 RING SET 1 A-AHM9072 4 LINER 2 A-86K937 4 LINER 3 A-96K432 4 LINER 4 A-NKJ149 4 LINER SEAL 5 A-CAL8963 4 LINER SEAL 6 A-CAL8964 4 LINER SHIM (.003) 7 A-89J88 4 LINER SHIM (.004) A-89J89 4 LINER SHIM (.005) A-89J90 4 DESCRIPTION PART NO. SIZE QTY KIT MAIN BRG SET (STD) A-8G2483 1 MAIN BRG SET (.015) A-8G248315 1 MAIN BRG SET (.030) A-8G248330 1 DESCRIPTION PART NO. SIZE QTY KIT CON ROD BRG SET (STD) A-8G2484 1 CON ROD BRG SET (.015) A-8G248415 1 CON ROD BUSHING 2 A-37D3037 4 CON ROD BUSHING 1 A-AHM9042 4 THRUST WASHER SET A-ABU9634 1 DESCRIPTION PART NO. SIZE QTY KIT FRONT OIL SEAL A-AAU6234 1 REAR OIL SEAL A-NKJ3472 1 DESCRIPTION PART NO. SIZE QTY KIT INTAKE VALVE 11 A-86K943 4 INTAKE VALVE 9 A-NKJ32 4 EXHAUST VALVE 10 A-86K944 4 INNER VALVE SPRING 11 A-AMK82 8 OUTER VALVE SPRING 11 A-AMK81 8 INTAKE VALVE GUIDE 11 A-86K144 4 EXHAUST VALVE GUIDE 11 A-86K145 4 DESCRIPTION PART NO. SIZE QTY KIT UPPER GASKET SET A-78G1395 1 LOWER GASKET SET A-78G1258 1 CYLINDER HEAD GSKT 12 A-NKJ202 1 ROCKER COVER GSKT 13 A-CMK1343 1 SUMP GASKET 7 A-96K614 1 DESCRIPTION PART NO. SIZE QTY KIT FUEL LIFT PUMP A-13H3375 1 4.98NT (1) 270, 272, 472, 72632 > (2) 270, 272, 472, < 72631 (3) 3C, 3D, 3CX, 525, < E2066/81595; 520, 520HL, 520M, < E81565; 530, 530H, E2066/81596 > (4) 3C, 3D, 3CX, E2066/81596 >; 270, 272, 472, 702, 704, 81596 > (5) 3C, 3D, 3CX, 270, 272, 472, 702, 704 (ALL TOP) (6) 3C, 3D, 3CX, 270, 272, 472, 702, 704, (ALL BOTTOM) (7) 270, 272, 472, 702, 704, ONLY (9) 3C, 3D, 3CX, E504/1404 >; 270, 272, 472, 702, 704, 83028 > (10) 530, 530HL, < E504/1404 (11) 3C, 3CX, 3D, 520, 520HL, 520M, 525, 530, 530HL, < E504/1404; 270, 272, 472, 702, 704, < 83027 (12) 3C, 3D, 3CX, 520, 520HL, 520M, E504/1404 > (13) 3C, 3D, 3CX, 525, 530, 530HL < E2066/82339; 270, 272, 472, 702, 704, < 81595 A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION 4.98TT 4 CYL STD BORE: 3.857" DESCRIPTION PART NO. MAJOR OH KIT N/A A-OK4.98TT IN FRAME OH KIT N/A A-IK4.98TT For Models: 4C ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON L/ RINGS A-96K471 4 RING SET A-AHM9072 4 LINER A-96K432 4 LINER A-NKJ149 4 LINER SEAL 3 A-CAL8963 4 LINER SEAL 4 A-CAL8964 4 LINER SHIM (.003) A-89J88 4 LINER SHIM (.004) A-89J89 4 LINER SHIM (.005) A-89J90 4 DESCRIPTION PART NO. SIZE QTY KIT MAIN BRG SET (STD) A-8G2483 1 MAIN BRG SET (.015) A-8G248315 1 MAIN BRG SET (.030) A-8G248330 1 DESCRIPTION PART NO. SIZE QTY KIT CON ROD BRG SET (STD) A-8G2484 1 CON ROD BRG SET (.015) A-8G248415 1 CON ROD BUSHING A-AHM9042 4 THRUST WASHER SET A-ABU9634 1 DESCRIPTION PART NO. SIZE QTY KIT FRONT OIL SEAL A-AAU6234 1 REAR OIL SEAL A-NKJ3472 1 DESCRIPTION PART NO. SIZE QTY KIT INTAKE VALVE A-NKJ32 4 EXHAUST VALVE A-86K944 4 DESCRIPTION PART NO. SIZE QTY KIT UPPER GASKET SET A-78G1395 1 LOWER GASKET SET A-78G1258 1 CYLINDER HEAD GASKET A-NKJ202 1 ROCKER COVER GASKET 6 A-CMK1343 1 SUMP GASKET A-96K614 1 DESCRIPTION PART NO. SIZE QTY KIT FUEL LIFT PUMP A-13H3375 1 (3) 4C TOP (4) 4C BOTTOM (6) 3C, 4C, 3D 80181> A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 4.98TT ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION 3.8 TD DESCRIPTION PART NO. MAJOR OH KIT N/A A-OK3.8TD-A IN FRAME OH KIT N/A A-IK3.8TD-A For Models: 2D, 3CMK11, 3CMK111, 3D, 3DMK11, 3MK11, 3MK111, 4D, 700 ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT LINER 1 A-86K1190 4 LINER SHIM (.004") 2 A-89J89 4 LINER SHIM (.005") 2 A-89J90 4 DESCRIPTION PART NO. SIZE QTY KIT MAIN BRG SET (STD) A-8G2483 1 MAIN BRG SET (-.015") A-8G248315 1 MAIN BRG SET (-.030") A-8G248330 1 DESCRIPTION PART NO. SIZE QTY KIT THRUST WASHER SET A-ABU9634 1 3.8 TD (1) 3MK11, 3MK111, 3CMK11, 3CMK111, 2D, 3D, 3DMK11, 4D, 700, E21242 >; 384, 21241 > (2) 3MK11, 3MK111, 3CMK11, 3CMK111, 2D, 3D, 3DMK11, 4D, 700, < E21241 A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION 4.236 4 CYL, LIP SEAL BORE: 3.8770" 98.476MM DESCRIPTION PART NO. ENG O/H KIT, MAJOR A-OK507 ENG O/H KIT, BASIC 4.236 A-IK507 For Models: (BACKHOE: 3CX E-SN UA103064L-U106654N), (LOADER: 410 E-SN UA103064L-U106654N), (HANDLER: 520 E-SN UA103064L- U106654N) ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON LINER KIT A-U5MK0123 4 MI PISTON A-68301 4 PISTON RINGS A-41158041 4 PISTON LINER A-31358394 4 DESCRIPTION PART NO. SIZE QTY KIT BRG SET, MAIN A-81558 STD 1 M BRG SET, MAIN A-81558A .010 1 M BRG SET, MAIN A-81558B .020 1 M BRG SET, MAIN A-81558C .030 1 M (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT BRG, CONN ROD SET A-85042 STD 1 MI BRG, CONN ROD SET A-85042A .010 1 MI BRG, CONN ROD SET A-85042B .020 1 MI BRG, CONN ROD SET A-85042C .030 1 MI (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT THRUST WASHER SET A-31137551/61 1 M DESCRIPTION PART NO. SIZE QTY KIT FRONT CRANK SEAL A-2418F436 1 M REAR CRANK SEAL A-303158411 1 M CRANKSHAFT 1 A-3637401M91 1 DESCRIPTION PART NO. SIZE QTY KIT VALVE TRAIN KIT A-VTK406 1 M INTAKE VALVE A-31431641 4 EXHAUST VALVE A-31431881 4 GUIDE, IN VALVE A-3343F002 4 GUIDE, EX VALVE A-3343J002 4 INNER, VALVE SPRING A-31744131 8 OUTER, VALVE SPRING A-31745121 8 SEAL VALVE A-33817117 8 LOCK, VALVE A-33173108 8 DESCRIPTION PART NO. SIZE QTY KIT BUSHING, CON ROD A-31134123 4 M BOLT, CONNECTOR ROD A-32762144 8 MI NUT, CON ROD A-33221328 8 MI CONNECTING ROD A-ZZ90009 4 DESCRIPTION PART NO. SIZE QTY KIT TOP GASKET SET A-U5LT0015 1 MI BOTTOM GASKET SET A-U5LB0045 1 MI HEAD GASKET A-36812349 1 OIL PAN SET A-U5MK0600 1 TIMING COVER GSKT A-3681P045 1 DESCRIPTION PART NO. SIZE QTY KIT CAM BUSHING SET A-31134132 1 M CAMSHAFT A-31415321 1 TAPPET A-31434163 8 PUSHROD A-31434307 8 ROCKER SHAFT A-ZZ90032 1 LH ROCKER ARM A-41151483 4 RH ROCKER ARM A-41151484 4 ROCKR SHAFT BUSHNG A-2511425 8 DESCRIPTION PART NO. SIZE QTY KIT CRANK GEAR A-31171681 1 CAMSHAFT GEAR A-31161353 1 IDLER GEAR A-41115023 1 DESCRIPTION PART NO. SIZE QTY KIT OIL PUMP 2 A-41314182 1 FUEL TRANS PUMP A-2641728 1 ENGINE RELATED INFORMATION For Alternators & Starters, see A&I ALTERNATOR STARTER CATALOG (1) SPLINED NOSE- SINGLE BOLT, LIP SEAL (2) FOR NON AGRICULTURAL USE A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 4.236 ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION C4.236 COMPENSATED, 4 CYL, LIP SEAL BORE: 3.8770" 98.476MM DESCRIPTION PART NO. O/H KIT A-OK452 BASIC KIT A-IK452 For Models: (BACKHOE: 200 E-SN U106655N-U418405U) ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON LINER KIT A-CK416 4 MI PISTON A-U5LP0011 1 LINER A-3135X032 1 PISTON RINGS A-41158147 1 DESCRIPTION PART NO. SIZE QTY KIT MAIN BEARING SET A-81558 STD 1 M MAIN BEARING SET A-81558A .010 1 M MAIN BEARING SET A-81558B .020 1 M MAIN BEARING SET A-81558C .030 1 M (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT CONN ROD BEARING SET A-85042 STD 1 MI CONN ROD BEARING SET A-85042A .010 1 MI CONN ROD BEARING SET A-85042B .020 1 MI CONN ROD BEARING SET A-85042C .030 1 MI (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT THRUST WASHER SET A-31137551/61 1 M DESCRIPTION PART NO. SIZE QTY KIT FRONT CRANK SEAL A-2418F436 1 M REAR CRANK SEAL A-303158411 1 M CRANKSHAFT A-ZZ90082 1 DESCRIPTION PART NO. SIZE QTY KIT VALVE TRAIN KIT A-VTK419 1 M INTAKE VALVE A-31431315 4 GUIDE, INT VALVE A-3343F002 4 GUIDE, EXH VALVE A-3343J002 4 INNER, VALVE SPRING A-31744133 8 OUTER, VALVE SPRING A-31745122 8 LOCK, VALVE A-33173108 8 VALVE SEAL A-33817117 8 DESCRIPTION PART NO. SIZE QTY KIT BUSHING, CON ROD A-31134123 4 M BOLT, CONNECTOR ROD A-32762144 8 MI CON ROD NUT A-33221328 8 MI DESCRIPTION PART NO. SIZE QTY KIT HEAD GASKET SET A-3638983M91 1 MI BOTTOM GASKET SET A-U5LB0045 1 MI HEAD GASKET A-3681E036 1 OIL PAN SET A-U5MK0600 1 TIMING COVER GSKT A-3681P045 1 DESCRIPTION PART NO. SIZE QTY KIT CAM BUSHING SET A-31134132 1 M TAPPET A-31434163 8 PUSHROD A-31434307 8 ROCKER SHAFT A-ZZ90032 1 LH ROCKER ARM A-41151483 4 RH ROCKER ARM A-41151484 4 ROCKR SHAFT BUSHNG A-2511425 8 DESCRIPTION PART NO. SIZE QTY KIT CRANK GEAR 1 A-31171681 1 IDLER GEAR A-41115023 1 DESCRIPTION PART NO. SIZE QTY KIT OIL PUMP A-41314182 1 ENGINE RELATED INFORMATION For Belts, Hoses, Radiators, & Water Pumps, see A&I COOLING SYSTEM CATALOG or TRACTOR PARTS CATALOG C4.236 (1) DO NOT USE ON BUILD NO: LE70089/LE22376/LE80173 A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION C4.236 COMPENSATED, 4 CYL, LIP SEAL BORE: 3.8770" 98.476MM DESCRIPTION PART NO. MAJOR OH KIT A-OK455 IN FRAME OH KIT A-IK455 For Models: (BACKHOE: (3CX, 200 ALL E-SN U418405U>)) ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON LINER KIT A-CK416 4 MI PISTON A-U5LP0011 4 LINER A-3135X032 4 PISTON RINGS A-41158147 4 DESCRIPTION PART NO. SIZE QTY KIT MAIN BRG SET A-81558 STD. 1 M MAIN BRG SET A-81558A .010 1 M MAIN BRG SET A-81558B .020 1 M MAIN BRG SET A-81558C .030 1 M (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT CONN ROD BRG SET A-85042 STD. 1 MI CONN ROD BRG SET A-85042A .010 1 MI CONN ROD BRG SET A-85042B .020 1 MI CONN ROD BRG SET A-85042C .030 1 MI (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT THRUST WASHER SET(2) A-31137551/61 1 M DESCRIPTION PART NO. SIZE QTY KIT FRONT SEAL A-2418F436 1 M REAR LIP SEAL A-303158411 1 M CRANKSHAFT A-ZZ90082 1 DESCRIPTION PART NO. SIZE QTY KIT VALVE TRAIN KIT A-VTK419 1 M INTAKE VALVE A-31431315 4 GUIDE, INT VALVE A-3343F002 4 GUIDE, EXH VALVE A-3343J002 4 INNER, VALVE SPRING A-31744133 8 OUTER, VALVE SPRING A-31745122 8 LOCK, VALVE A-33173108 8 VALVE SEAL A-33817117 8 DESCRIPTION PART NO. SIZE QTY KIT BUSHING, CONN ROD A-31134123 4 M BOLTS, CONN ROD A-32762144 8 MI CONN ROD NUT A-33221328 8 MI CONNECTING ROD A-ZZ90009 4 DESCRIPTION PART NO. SIZE QTY KIT TOP GSKT SET A-U5LT0046 1 MI BOTTOM GASKETS A-U5LB0045 1 MI HEAD GASKET A-3681E036 1 OIL PAN SET A-U5MK0600 1 TIMING COVER GSKT A-3681P045 1 DESCRIPTION PART NO. SIZE QTY KIT CAM BUSHING SET A-31134132 1 M CAMSHAFT 1 A-31415374 1 TAPPET A-31434163 8 PUSHROD A-31434307 8 ROCKER SHAFT A-ZZ90032 1 LH ROCKER ARM A-41151483 4 RH ROCKER ARM A-41151484 4 ROCKR SHAFT BUSHNG A-2511425 8 DESCRIPTION PART NO. SIZE QTY KIT CRANK GEAR A-31171681 1 IDLER GEAR A-41115023 1 DESCRIPTION PART NO. SIZE QTY KIT OIL PUMP 2 A-41314182 1 FUEL TRANS PUMP 3 A-2641728 1 ENGINE RELATED INFORMATION For Belts, Hoses, Radiators, & Water Pumps, see A&I COOLING SYSTEM CATALOG or TRACTOR PARTS CATALOG (1) ENG SN U106655N> (2) FOR NON AGRICULTURAL USE (3) ENG SN 236UA57135> A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 C4.236 ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN

ENGINE INFORMATION T4.236 TURBOCHARGED, 4 CYL, LIP SEAL BORE: 3.8770" 98.476MM DESCRIPTION PART NO. ENG O/H KIT, MAJOR A-OK451 ENG O/H KIT, BASIC T4.236 A-IK451 For Models: (LOADALL: 520S E-SN U027773M>), (LOADER: 415 E-SN U027773M>), (BACKHOE: 4CX E-SN U027773M>), (FORKLIFT: 410M E-SN U027773M>) ENGINE COMPONENT PARTS NOTICE: Parts included in the overhaul kits are indicated as follows: M parts included in MAJOR OVERHAUL KITS I parts included in IN FRAME OVERHAUL KITS DESCRIPTION PART NO. SIZE QTY KIT PISTON LINER KIT A-CK236T 4 MI PISTON A-U5LP0022 4 RING SET A-41158145 4 LINER A-3135X032 4 DESCRIPTION PART NO. SIZE QTY KIT MAIN BEARING SET A-81558 STD 1 M MAIN BEARING SET A-81558A .010 1 M MAIN BEARING SET A-81558B .020 1 M MAIN BEARING SET A-81558C .030 1 M (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT BRG, CONN ROD SET-STD A-85042 STD 1 MI BRG, CONN ROD SET-STD A-85042A .010 1 MI BRG, CONN ROD SET-STD A-85042B .020 1 MI BRG, CONN ROD SET-STD A-85042C .030 1 MI (For Overhaul Kits, specify size desired from above list) DESCRIPTION PART NO. SIZE QTY KIT THRUST WASHER SET A-31137551/61 STD 1 M DESCRIPTION PART NO. SIZE QTY KIT SEAL, FRNT CRANK, 4.236 A-2418F436 1 M REAR CRANK SEAL, VITON A-303158411 1 M CRANKSHAFT A-ZZ90082 1 DESCRIPTION PART NO. SIZE QTY KIT KIT, VALVE TRAIN, T4.236 A-VTK414 1 M INTAKE VALVE A-3142H002 4 EXHAUST VALVE A-33A83 4 GUIDE, INT VALVE A-3343F002 4 GUIDE, EXH VALVE A-3343J002 4 INNER, VALVE SPRING A-31744131 8 OUTER, VALVE SPRING A-31745121 8 LOCK, VALVE A-33173108 8 VALVE SEAL A-33817117 8 DESCRIPTION PART NO. SIZE QTY KIT BUSHING, CON ROD A-31134131 4 M BOLT, CONNECTOR ROD A-32762144 8 MI NUT, CON ROD A-33221328 8 MI CONROD TURBO A-ZZ90013 4 DESCRIPTION PART NO. SIZE QTY KIT GASKET SET, TOP A-U5LT0046 1 MI PAN GSKT SET W/O SEALS A-U5LB0045 1 MI HEAD GASKET A-3681E016 1 OIL PAN SET A-U5MK0600 1 TIMING COVER GSKT A-3681P045 1 DESCRIPTION PART NO. SIZE QTY KIT CAM BUSHING SET A-31134132 1 M TAPPET A-31434163 8 PUSHROD A-31434307 8 ROCKER SHAFT A-ZZ90032 1 LH ROCKER ARM A-41151483 4 RH ROCKER ARM A-41151484 4 ROCKR SHAFT BUSHNG A-2511425 8 DESCRIPTION PART NO. SIZE QTY KIT CRANK GEAR A-31171681 1 DESCRIPTION PART NO. SIZE QTY KIT OIL PUMP A-4132F012 1 OIL PUMP 1 A-4132F041 1 FUEL TRANS PUMP A-2641728 1 ENGINE RELATED INFORMATION For Alternators & Starters, see A&I ALTERNATOR STARTER CATALOG T4.236 (1) FOR USE ON AGRICULTURAL APPLICATIONS A&I PRODUCTS website: www.aiproducts.com email: sales@aiproducts.com 1-800-657-4343 fax: 1-800-511-0516 ALLIS CHALMERS DEUTZ MASSY FERGUSON WHITE/ OLIVER CASE-IH ZETOR NEW HOLLAND CATERPILLAR OWATONNA PERKINS RENAULT SULLAIR CORP. VERMEER CLARK FIAT FORD GEHL HYSTER IMT INGERSOLL RAND JCB JOHN DEERE JACOBSEN LEYLAND LANDINI LINCOLN ELECTRIC MELROE MICHIGAN
