2005
VOLVO
V70/V70R/XC70/XC90
TP 3977201
Frame contained PDF file, click here to view
TP3977201 V70/XC70/V70R/XC90 2005 144
1/1 Battery
2/14 Relay, glow plug unit
2/22 Relay, climate control system
2/32 Engine management system main relay
2/33 Relay, fuel system
2/35 Starter motor relay
2/64 Auxiliary light (accessory) relay
2/90 Relay, windshield wiper, low/high speed
2/91 Relay, intermittent windshield wiper
2/138 Deadlock relay, left-hand rear door
2/139 Deadlock relay, right-hand rear door
2/182 Relay, headlight washer motor
2/191 Relay, remote parking heater start, radio signal
2/192 Relay (230V), engine heater
3/1 Ignition switch
3/4 Cruise control switch (SWS)
3/6 Hazard warning flasher switch
3/8 Heated rear window/door mirror switch
3/9 Brake light contact
3/10 Reversing light contact
3/25 Power sunroof switch
3/26 Power driver’s seat module
3/27 Power passenger seat module
3/37 Horn contact
3/47 Parking brake contact
3/59 Control, beam adjustment
3/60 Auxiliary light switch
3/62 Hood alarm contact
3/71 Gear position contacts
3/73 Power Child Lock (PCL) switch
3/74 Left-hand front door lock unit
3/75 Right-hand front door lock unit
3/76 Left-hand rear door lock unit
3/77 Right-hand rear door lock unit
3/78 Trunk lid lock unit
3/80 Switch, left-hand central lock
3/82 Switch, right-hand central lock
3/85 Rear left door power window switch
3/86 Rear right door power window switch
3/91 Switch, left-hand heated seat
3/92 Switch, right-hand heated seat
3/93 Left seatbelt latch switch
3/94 Right seatbelt latch switch
3/95 Spin control switch
3/111 Light Switch Module (LSM)
3/112 Climate Control Module (CCM)
3/117 Dome light control module
3/126 Driver/Passenger Door Module (DDM)/(PDM)
3/127 Passenger/Driver Door Module (PDM)/(DDM)
3/131 Switch, audio/cellular phone
3/135 RTI switch
3/155 Automatic transmission program selector
3/156 Gear Selector Module (GSM)
3/157 Passenger Airbag Cut Off Switch
(PACOS)
3/171 Switch, retractable door mirrors
3/173 Switch, trunk lid private lock
3/174 Switch, reduced alarm
3/225 Control unit, continuous damping control (CDC)
3/254 Steering Wheel Module (SWM)
4/7 Combustion Preheater Module (CPM)
4/9 Control module, Supplemental Restraint System
(SRS)
4/16 Brake Control Module (BCM)
4/28 Transmission Control Module (TCM)
4/31 Fan control module
4/33 Sunroof Control Module (SRM)
4/46 Engine Control Module (ECM)
4/50 Electronic Throttle Module (ETM)
4/52 Power driver seat module (PSM)
4/56 Central Electronic Module (CEM)
4/58 Rear Electronic Module (REM)
4/68 Steering Angle Sensor module (SAS)
4/70 Upper Electronic Module (UEM)
4/71 Cooling fan control module
4/76 Remote control unit for garage door opener
4/78 Accessory Electronic Module (AEM)
4X/78 Connector, original car interface
4/82 Differential Electronic Module (DEM)
4/83 Fuel pump control module
4/84 Suspension Module (SUM)
4/86 Parking Assistance Module (PAM)
4/99 Electronic power steering control module
4/106 Control module, remote parking heater start
4/107 Control module, parking heater, Call start
4/110 Trailer Module
5/1 Driver Information Module (DIM)
6/1 Windshield wiper motor
6/3 Right-hand headlight wiper motor
6/4 Left-hand headlight wiper motor
6/15 Sunroof motor
6/16 Driver seat motor, backrest angle
6/17 Driver seat motor, up/down front edge
6/18 Driver seat motor, up/down rear edge
6/19 Driver seat motor, forward/backward
6/20 Passenger seat motor, forward/backward
6/25 Starter motor
6/26 Alternator Control Module (ACM)
6/28 Motor, passenger compartment fan
6/29 Motor, cooling fan
6/31 Feed pump, ejectors
6/32 Rear window wiper motor
6/33 Fuel pump
6/35 Fuel pump, auxiliary heater
6/37 Lock motor, fuel filler flap
6/38 Left-hand headlight level adjustment motor
6/39 Right-hand headlight adjustment motor
6/44 Cooling fan, electrics box, engine compartment
6/48 Damper Motor Module (DMM), recirculation
6/58 Motor, front left power window
6/60 Motor, front right power window
6/62 Left-hand power door mirror
6/63 Right-hand power door mirror
6/64 Passenger seat motor, backrest angle
6/65 Passenger seat motor, up/down front edge
6/66 Passenger seat motor, up/down rear edge
6/67 Pump, fuel leakage control
6/69 Damper Motor Module (DMM), ventila-
tion/floor/defroster
6/71 Valve, speed-dependent power steering
6/73 Coolant pump, auxiliary heater
6/76 Climate control system, rear
6/92 Motor, rear left power window
6/93 Motor, rear right power window
6/95 Damper Motor Module (DMM), temperature,
left-hand side
6/96 Damper Motor Module (DMM), temperature,
right-hand side
6/102 Damper Motor Module (DMM), defroster
6/103 Damper Motor Module (DMM), floor/ventilation
6/104 Headlight washer motor
6/105 Fuel distributor, gas
6/114 Vacuum pump
List of components 1:4
TP3977201 V70/XC70/V70R/XC90 2005 145
6/120 Engine throttle body
6/127 Washer motor
7/4 Brake fluid level sensor
7/5 Washer fluid level sensor
7/6 Oil pressure sensor
7/8 Pressure sensor, climate control system
7/10 Interior temperature sensor
7/11 Outside temperature sensor
7/12 Solar sensor, twilight sensor and indicator alarm
7/15 Heated oxygen sensor
7/16 Coolant temperature sensor
7/17 Mass airflow sensor MAF
7/23 Rear knock sensor
7/24 Front knock sensor
7/25 Impulse sensor
7/31 Left-hand front ABS sensor
7/32 Right-hand front ABS sensor
7/35 Oil level sensor
7/41 Temperature sensor, evaporator
7/51 Accelerator pedal sensor
7/56 Left-hand rear ABS sensor
7/57 Right-hand rear ABS sensor
7/61 Input speed sensor
7/62 Output speed sensor
7/73 Coolant level sensor
7/74 Oil temperature sensor, automatic transmission
7/81 Pressure sensor, intake manifold
7/82 Heated oxygen sensor, diagnosis 1
7/87 Acceleration sensor, Four-C, front left
7/88 Acceleration sensor, Four-C, front right
7/89 Acceleration sensor, Four-C, rear left
7/91 Steering angle sensor
7/93 Occupant Weight Sensor (OWS)
7/100 Inclination Sensor Module (ISM)
7/103 Heated oxygen sensor 3
7/105 Outside temperature sensor, engine control
module
7/108 Left-hand rear side impact sensor
7/109 Right-hand rear side impact sensor
7/110 Left-hand seat temperature sensor
7/111 Right-hand seat temperature sensor
7/115 Left-hand front side impact sensor
7/116 Right-hand front side impact sensor
7/118 Acceleration sensor, shock absorber, Four-C,
front left
7/119 Acceleration sensor, shock absorber, Four-C,
front right
7/120 Rear left angle sensor
7/121 Shock absorber, Four-C, rear left
7/122 Mass Movement Sensor (MMS), front
7/123 Clutch pedal sensor
7/124 Brake pedal sensor
7/129 Brake pressure sensor 2
7/130 Fuel level sensor, injector side
7/131 Parking assistance sensor 1
7/132 Parking assistance sensor 2
7/133 Parking assistance sensor 3
7/134 Parking assistance sensor 4
7/135 Glass breakage sensor, left-hand
7/136 Glass breakage sensor, right-hand
7/137 Glass breakage sensor, tailgate
7/139 Brake pressure sensor 1
7/143 Fuel level sensor, pump side
7/149 Rain Sensor Module (RSM)
7/153 Sensor, fuel level LPG
7/156 Pressure and temperature sensor CNG
7/156 Fuel pressure and temperature sensor, gasoline
7/158 Mass Movement Sensor (MMS), rear
7/159 Air Quality Sensor (AQS)
7/162 Pressure sensor, fuel line
7/164 Sensor module DSTC
7/165 Pressure and temperature sensor, intake mani-
fold
7/172 Position sensor, camshaft, intake side
7/173 Position sensor, camshaft, exhaust side
7/175 Passenger seat weight sensor
7/178 RH front impact sensor
7/179 LH front impact sensor
7/192 Temperature sensor, evaporator
7/201 Pressure and temperature sensor, gas
7/204 Parking assistance sensor 5
7/205 Parking assistance sensor 6
7/206 Parking assistance sensor 7
7/207 Parking assistance sensor 8
8/3 Electromagnetic clutch, climate control system
8/6-11 Injectors
8/17 EGR valve
8/18 EVAP valve
8/19 Solenoid, variable valve time, inlet
8/20 Shock absorber, Four-C, front left
8/21 Shock absorber, Four-C, front right
8/22 Shock absorber, Four-C, rear left
8/23 Shock absorber, Four-C, rear right
8/28 Turbocharger control valve
8/30 Driver side airbag igniter
8/31 Passenger side airbag igniter
8/32 Igniter, passenger side airbag stage 2
8/33 Front left belt tensioner igniter
8/34 Front right seat belt tensioner igniter
8/36 Shift lock solenoid
8/37 Automatic transmission
8/38 Shift solenoid 1
8/39 Shift solenoid 2
8/40 Lock-up solenoid
8/41 Pressure solenoid
8/46 DSTC activation module
8/51 Front left side airbag igniter
8/52 Front right side airbag igniter
8/55 Rear left belt tensioner igniter
8/56 Rear right belt tensioner igniter
8/61 Driver side airbag igniter step 2
8/62 Belt tensioner igniter, center rear seat
8/64 Solenoid valve, engine mounting
8/66 Igniter, left-hand inflatable curtain
8/67 Right-hand inflatable curtain igniter
8/71 Throttle solenoid
8/72 Shift solenoid 3
8/73 Shift solenoid 4
8/74 Shift solenoid 5
8/75 Valve, fuel cut-off DFCO
8/76 Gas tank valve
8/78 Oil pressure sensor
8/79 Valve LPG
8/81 Solenoid, variable valve timing outlet
8/82 Solenoid, variable turbo geometry
8/84 Switch, vacuum pump
8/85 Thermostatic switch and fuel filter heating
8/88 Solenoid, gas tank CNG rear
8/89 Solenoid, fuel tank CNG front left
8/90 Solenoid, fuel tank CNG front right
8/94 Left-hand belt tensioner igniter, third row of seats
8/95 Right-hand belt tensioner igniter, third row of seats
8/96 Left-hand inflatable curtain igniter, third row of
seats
8/97 Right-hand inflatable curtain igniter, third row of
seats
List of components 2:4
TP3977201 V70/XC70/V70R/XC90 2005 146
8/99 Igniter, steering column
8/111 Solenoid valve, high-pressure diesel
8/123 Igniter, airbag, ventilation, driver’s side
8/124 Igniter, airbag, ventilation, passenger side
8/134 Solenoid, reverse interlock, manual
9/1 Front 12V outlet
9/2 Heated rear window
9/12 Seat Heater Module (SHM) left-hand
9/13 Seat Heater Module (SHM) right-hand
9/16 Left-hand backrest heating element
9/17 Right-hand backrest heating element
9/18 Left-hand seat heating element
9/19 Right-hand seat heating element
9/25 Rear 12V outlet
9/30 Auxiliary heater
9/32 PTC resistor - air preheating
9/33 Left-hand heated door mirror
9/34 Right-hand heated door mirror
10/1 Left-hand front lamp housing
10/2 Right-hand front lamp housing
10/3 License plate lighting
10/5 Front left fog light
10/6 Front right fog light
10/11 Front left parking light
10/12 Front right parking light
10/13 Front left direction indicator
10/14 Front right direction indicator
10/15 Front left fender direction indicator, V70/XC70
10/15 Direction indicator, left front door, XC90
10/16 Front right fender direction indicator, V70/XC70
10/16 Direction indicator, right front door, XC90
10/17 Lamp housing, right-hand tail light
10/18 Lamp housing, left-hand tail light
10/19 Auxiliary brake light
10/25 Ceiling light, cargo compartment
10/29 Glove compartment lighting
10/43 Right-hand brake light
10/44 Right-hand tail light lamp
10/45 Right-hand tail light lamp 2
10/46 Fog light, right rear
10/47 Rear right direction indicator
10/48 Right-hand reversing light
10/50 Left-hand brake light
10/51 Left-hand tail light lamp
10/52 Left-hand tail light lamp 2
10/53 Fog light, left rear
10/54 Rear left direction indicator
10/55 Left-hand reversing light
10/64 Right-hand high beam
10/65 Front right auxiliary light
10/66 Right-hand low beam
10/68 Left-hand high beam
10/69 Front left auxiliary light
10/70 Left-hand low beam
10/71 Front left side marker light
10/72 Front ashtray lighting
10/73 Front right side marker light
10/114 Left-hand vanity mirror lighting
10/115 Right-hand vanity mirror lighting
10/125 Left-hand front courtesy lighting
10/126 Right-hand front courtesy lighting
10/148 Left-hand rearview mirror lighting
10/149 Right-hand rearview mirror lighting
10/150 Rear reading light
10/151 Left-hand rear door switch lighting
10/152 Right-hand rear door switch lighting
10/172 Reading light, third row of seats
10/173 Cargo compartment lighting, tailgate
10/218 Remote start indicator light
11A/no. Main fuses in engine compartment fuse box
11B/no. Fuses in engine compartment fuse box
11C/no. Fuses in passenger compartment fuse box
11E/no. Main fuses at battery
15/30 Connecting rail to 15/31
15/31 Engine compartment distribution box
16/1 Audio Module (AUM)
16X/1 Connector, original car interface
16/2 Amplifier
16/3 Right-hand front door speaker
16/4 Left-hand front door speaker
16/5 Right-hand rear door speaker
16/6 Left-hand rear door speaker
16/10 Horn 1
16/11 Horn 2
16/15 CD changer
16/16 LH window antenna amplifier 1
16/26 Central dashboard speaker
16/35 Alarm siren (SCM)
16/36 TV receiver
16/45 Road Traffic Information (RTI)
16X/45 Connector, original car interface
16/46 RTI display, V70/XC70
16/46 Multimedia display, XC90
16/47 GPS antenna RTI
16/50 Left-hand rear window antenna
16/54 Right-hand rear window antenna
16/55 Left-hand front tweeter
16/56 Right-hand front tweeter
16/57 Speaker, left-hand D-pillar
16/58 Speaker, right-hand D-pillar
16/59 Antenna, remote control
16/60 Phone Module (PHM)
16/62 Hand unit, cellular phone
16/63 GPS antenna, Telephone
16/64 Antenna, cellular telephone
16/65 Antenna ring/ignition switch lighting
16/67 Amplifier antenna, bumper
16/68 Antenna, bumper
16/71 Window antenna amplifier 1 right
16/73 Window antenna amplifier 2 left
16/74 Window antenna amplifier 2 right
16/77 Microphone, cellular telephone
16/78 Speaker, cellular telephone
16/79 Subwoofer, V70/XC70
16/79 Bass speaker system SUB, XC90
16/81 LCD screen
16/82 DVD player, rear
16/93 Control module, cellular telephone handsfree
16/94 Infotainment Control Module (ICM)
16/105 Audio module (AUD)
16X/105 Connector, original car interface
16/106 Control module, CD player (MP2)
16/107 Control module, MD player (MP1)
16/108 Multimedia module (MMM)
16/110 Antenna control module (ATM)
16/111 Socket, rear left headphones
16/112 Socket, rear right headphones
16/126 Holder, cellular telephone handsfree
16/127 Microphone, cellular telephone handsfree
17/13 Data link connector
17/17 Jump start connection
17/19 12V outlet, cargo compartment
List of components 3:4
TP3977201 V70/XC70/V70R/XC90 2005 147
17/38 7-pin outlet, towbar cable harness
17/39 13-pin outlet, towbar cable harness
18/4 Contact reel
20/3-8 Spark plug and ignition coil
20/16 Capacitor
20/22-26 Glow plug
27/3 Left-hand Camera Module (LCM)
27/4 Right-hand Camera Module (RCM)
31/no. Ground connection
53/no. Junction point
54/no. Connector
54X/no. Connector, original car interface
A1 Connecting rail to 15/31
C1-6 Connecting rails to 15/31
List of components 4:4
© Volvo Car Corporation
Vehicles with SRS (Airbag)/SIPS bag/
IC (Inflatable Curtain)
Warning!
Vehicles equipped with SRS/SIPS bag/IC must be handled with extra care when making
repairs. This avoids:
1. Personal injuries when performing repair work.
2. Damage or malfunction of the SRS/SIPS bag/IC system.
Work involving the SRS/SIPS bag/IC systems or other components in the vehicle that may
affect the SRS/SIPS bag/IC systems must always be performed by an authorized Volvo
workshop.
In case of doubt, consult the SRS and SIPS bag/IC service manual.
Is the vehicle equipped with SRS/SIPS bag/IC ?
Vehicles with SRS are most easily recognized by the letters SRS in the center of the steering
wheel. If the vehicle also has a passenger side airbag, the letters SRS are stamped on the
dashboard above the glove compartment. SRS vehicles from 1993 and onward also have
explosive seatbelt tensioners. SIPS bags are only installed on SRS vehicles from 1995 and
onward. SIPS bag decals are located on the windshield and seat compartment. Vehicles with
IC can be recognized by the letters IC on the C/D panel (4 door) or the B panel (5 door).
General recommendations
• Be especially careful when working on or around SRS, SIPS, and IC components.
• Make sure that no wires are pinched, frayed, or pierced.
• Never install accessories by the sensors.
• Where applicable, work on the steering wheel, steering shaft, or steering gear must be done
in accordance with the methods in the SRS section of VADIS.
• Certain components of the aforementioned systems must be grounded while working. Read
the appropriate sections in VADIS.
• Install no accessories in the areas between the A and B posts, the B and C posts, and the C
and D posts.
Test terminal
Data link connector in the passenger compartment.
Modifications introduced up to February 2004
Any changes made to the vehicles after this date are not included in the
manual. If necessary refer to service bulletins.
Volvo models are sold in versions adapted for different markets. These
adaptations depend on factors such as legal requirements, taxation, and
market demands.
This manual may therefore include illustrations and text that do not apply to
the vehicles in your country.
TP3977201 V70/V70R/XC70/XC90 2005
Vehicles with SRS (Airbag)/SIPS bag/
IC (Inflatable Curtain)..................................................... 2
Abbreviations ................................................................. 5
How to use the wiring diagrams 1:2............................... 6
Electrical distribution 1:2................................................ 8
Fuses
Engine compartment 11A/1-8 ....................................... 12
Engine compartment 11B/1-6 ....................................... 13
Engine compartment 11B/8-23 ..................................... 14
Passenger compartment 11C/1-4................................. 15
Passenger compartment 11C/5-8................................. 16
Passenger compartment 11C/9-14 ............................... 17
Cargo compartment 11E/1-7 ........................................ 18
Central Electronic Module (CEM) F1-F16..................... 19
Central Electronic Module (CEM) F17-F34................... 20
Rear Electronic Module (REM) F1-F19 ........................ 21
Rear Electronic Module (REM) F20-F38 ...................... 22
Relays
Ignition switch and relays............................................. 23
Engine compartment FMA2 - FST3 ............................. 24
Other relays ................................................................. 25
Ground connections
31/1 - 31/46 ................................................................. 26
31/47 - 31/70 ............................................................... 27
31/72 - 31/83 ............................................................... 28
31/84 - 31/91 ............................................................... 29
31/93 - 31/95 ............................................................... 30
31/96 - 31/120 ............................................................. 31
Control modules
Overview of locations V70/XC70 ................................. 32
Overview of designations V70/XC70 ........................... 33
Overview of locations XC90......................................... 34
Overview of designations XC90................................... 35
Central Electronic Module (CEM) 1:2 .......................... 36
Rear Electronic Module (REM) 1:2 .............................. 38
High speed CAN data communication ......................... 40
Low speed CAN data communication V70/XC70 ........ 41
Low speed CAN data communication XC90................ 42
LIN data communication 1:2 ........................................ 43
Data communication MOST, XC90.............................. 45
Accessory Electronic Module (AEM) ........................... 46
Group 23 Fuel system
Engine management system, 5-cyl 1:2 ...................... 47
Engine management system, 5-cyl Turbo 1:2 ............. 49
Engine management system, 6-cyl 1:2........................ 51
Engine management system, Bi-fuel 1:2 .................... 53
Engine management system, Diesel 1:2 ..................... 55
Emission control, 5-cyl ................................................. 57
Emission control, 5-cyl Turbo & 6-cyl Turbo ................ 58
Group 26 Cooling system
Cooling fan .................................................................. 59
Group 27 Engine control
Cruise control ............................................................... 60
Group 32 Generator and voltage regulator
Power supply .............................................................. 61
Group 33 Starting system
Starting system ............................................................ 62
Group 35 Lighting
High and low beam/Bi-Xenon & Daytime running
lights V70/XC70 ....................................................... 63
High and low beam/Bi-Xenon & Daytime running
lights XC90 ................................................................ 64
Fog lights ..................................................................... 65
Brake lights .................................................................. 66
Reversing lights ........................................................... 67
Home safe lighting ....................................................... 68
Position/parking lights, tail lights & license plate
lighting V70/XC70 .................................................... 69
Position/parking lights, tail lights & license plate
lighting XC90 ............................................................. 70
Interior lighting V70/XC70 ........................................... 71
Interior lighting XC90 ................................................... 72
Beam length adjustment V70/XC70............................. 73
Beam length adjustment XC90 .................................... 74
Auxiliary light ................................................................ 75
Group 36 Additional electrical equipment
Rain sensor ................................................................. 76
Direction indicators and hazard warning flashers
V70/XC70 .................................................................. 77
Direction indicators and hazard warning flashers
XC90 ........................................................................ 78
Wipers/washers, windshield......................................... 79
Wipers/washers, headlights V70/XC70........................ 80
High pressure headlight washer .................................. 81
Wiper/washer, rear window.......................................... 82
Horn ........................................................................ 83
Electronic immobilizer .................................................. 84
Anti-theft alarm V70/XC70 .......................................... 85
Anti-theft alarm XC90 .................................................. 86
Accessory Electronic Module (AEM)............................ 87
Parking assistance....................................................... 88
Group 37 Wiring and fuses
Diagnostics system ...................................................... 89
12V outlet ..................................................................... 90
Towbar cable harness, 7-pin........................................ 91
Towbar cable harness, 13-pin .................................... 92
Group 38 Instruments
Seat belt reminder ....................................................... 93
Driver information module............................................ 94
Driver information module Bi-fuel................................. 95
Group 39 Other
Audio V70/XC70 ....................................................... 96
Audio XC90 ................................................................ 97
Audio with auxiliary amplifier V70/XC70 1:2 ................ 98
Cellular telephone V70/XC70 .................................... 100
Road Traffic Information (RTI) V70/XC70.................. 101
Road Traffic Information (RTI) XC90 ........................ 102
Handsfree V70/XC70 ................................................. 103
Handsfree XC90 ........................................................ 104
CD changer V70/XC70 .............................................. 105
CD/MD player XC90 .................................................. 106
Subwoofer XC90........................................................ 107
Infotainment XC90 .................................................. 108
Rear seat entertainment, XC90 ................................. 109
Table of Contents 1:2
TP3977201 V70/V70R/XC70/XC90 2005
Group 43 Transmission
Automatic transmission AW55-50SN/AW50AWD ..... 110
Automatic transmission, 4T65AWD ........................... 111
Geartronic .................................................................. 112
Shift lock .................................................................... 113
Differential Electronic Module (DEM)......................... 114
Group 59 Brake system
Brake control system ................................................ 115
Group 64 Steering
Electronic power steering .......................................... 116
Group 76 Shock absorbers
Four-C V70R.............................................................. 117
Group 83 Doors and openings
Central locking system V70/XC70 ............................ 118
Central locking system XC90 .................................... 119
Power windows.......................................................... 120
Power sunroof ........................................................... 121
Group 84 Exterior decorative elements etc.
Power door mirrors .................................................... 122
Heated door mirrors ................................................... 123
Heated rear window................................................... 124
Power door mirrors with camera function ................. 125
Group 85 Interior equipment
Power driver’s seat, LHD .......................................... 126
Power driver’s seat, RHD........................................... 127
Power passenger seat, LHD ...................................... 128
Power passenger seat, RHD ..................................... 129
Heated seats ............................................................. 130
Group 87 Climate controls
Parking heater, auxiliary heater .............................. 131
Climate control system 1:2 ........................................ 132
Relay, electric engine heater ..................................... 134
Parking heater, remote start ...................................... 135
Parking heater, Call start ........................................... 136
Short stop heater ....................................................... 137
Climate control system, rear XC90 ............................ 138
Group 88 Internal equipment
Supplemental Restraint System (SRS) V70/XC70 ... 139
Supplemental Restraint System (SRS) XC90 ........... 140
Remote garage door opener ...................................... 141
Index ......................................................... 142
List of components 1:4
Table of Contents 2:2
TP3977201 V70/V70R/XC70/XC90 2005 5
Explanations
Abbreviations
Groups
Group 23 = Fuel system
Group 26 = Cooling system
Group 27 = Engine controls
Group 32 = Generator and voltage regulator
Group 33 = Starting system
Group 35 = Lighting
Group 36 = Additional electrical equipment
Group 37 = Wiring and fuses
Group 38 = Instruments
Group 39 = Other
Group 43 = Transmission
Group 59 = Brake system
Group 64 = Steering
Group 76 = Shock absorbers
Group 83 = Doors and openings
Group 84 = Exterior decorative elements etc.
Group 85 = Interior equipment
Group 87 = Climate controls
Group 88 = Internal equipment
Ignition switch symbols
X = Accessories (audio position)
S = Powered upon insertion of key
15 = The switch remains connected during
start
15l = Contact is broken while starting
30 = Constant power from the battery
50 = Start
Countries/Markets
A = Austria
AUS = Australia
B = Belgium
CDN = Canada
CH = Switzerland
D = Germany
DK = Denmark
E = Spain
EU/OS = Markets outside USA and Canada
FIN = Finland
GB = Great Britain
ISR = Israel
J = Japan
KOR = Korea
N = Norway
NL = Netherlands
S = Sweden
USA = United States of America
WEU = Western Europe
Other
ACC = Accessory
AMP = Amplifier
AUDIO = Audio system
AUTO = Automatic transmission
Bi-X = Bi-Xenon
BLIS = Blindspot Indication System
CDCH = CD Changer Under Shelf
CEM = Central Electronic Module
DRL = Daytime Running Lights
DSTC = Dynamic Stability Traction Control
ECC = Electronic climate control system
ECPS = Electronic power steering
EXC = Exclusive
EXT. D = Extended electrical distribution
HISPEED = High speed data bus
LH = Left-hand side
LHD = Left-hand drive
LOSPEED = Low speed data bus
MAN = Manual transmission
OPN = Option (factory-installed)
PCL = Power Child Lock
PETROL = Gasoline
REM = Rear Electronic Module
RH = Right-hand side
RHD = Right-hand drive
RTI = Road Traffic Information
SRS = Airbag
SUBWOOF = Bass speaker
SULEV = Super Ultra Low Emission Vehicle
T = Turbo engine
ULEV = Ultra Low Emission Vehicle
W/O = Without
5CYL = 5-cylinder engine
6CYL = 6-cylinder engine
Colors
BL = Blue
BN = Brown
GN = Green
GR = Gray
LBL = Light Blue
LGN = Light Green
OR = Orange
P = Pink
R = Red
SB = Black
VO = Violet
W = White
Y = Yellow
You're Reading a Preview
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$31.99
2011-2012 Volvo S60 Electrical Wiring Diagram Manual
Viewed 14 Times Today
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
$31.99
Secure transaction
What's Included?
Lifetime Access
Fast Download Speeds
Online & Offline Access
Access PDF Contents & Bookmarks
Full Search Facility
Print one or all pages of your manual
Description
The VOLVO V70 V70R XC70 and XC90 Wiring Diagram 2005 is a comprehensive diagram that provides detailed information on the electrical systems of these Volvo models. This diagram is an essential tool for mechanics and car enthusiasts who need to diagnose and repair electrical issues in these vehicles.
The diagram includes a complete breakdown of the electrical circuits, wiring connections, components, and their locations. It covers all vital electrical systems such as the engine, transmission, fuel system, lighting, heating, air conditioning, and more. With this diagram, users can easily trace and identify any electrical faults, short circuits, or malfunctioning components.
The VOLVO V70 V70R XC70 and XC90 Wiring Diagram 2005 is a comprehensive and user-friendly resource, providing a clear and organized representation of the vehicle's electrical network. It ensures accurate and efficient troubleshooting, saving time and effort in finding and fixing electrical problems.
Compatible with the following models:
- VOLVO V70
- VOLVO V70R
- VOLVO XC70
- VOLVO XC90
