General Information DTC Index ENGINE CONTROL MODULE (ECM) DTCS - B6304T4 ENGINE CONTROL MODULE (ECM) - DTC INDEX DTC Volvo Code Description B1024 ECM - B102400 Start control unit. General Failure Information. No sub type information B1024 ECM - B102482 Start control unit. Bus Signal/Message Failures. Alive/sequence counter incorrect/not updated B1024 ECM - B102486 Start control unit. Bus Signal/Message Failures. Signal invalid B11D4 ECM - B11D487 Low Speed Collision Mitigation By Braking Disabled. Bus Signal/Message Failures. Missing message C0040 ECM - C004082 Brake Pedal Switch "A". Bus Signal/Message Failures. Alive/sequence counter incorrect/not updated C2003 ECM - C200387 Steering wheel switch left module. Bus Signal/Message Failures. Missing message P0011 ECM - P001100 Intake Camshaft Position Timing - Over- Advanced (Bank 1). General Failure Information. No sub type information P0012 ECM - P001200 Intake Camshaft Position Timing - Over- Retarded (Bank 1). General Failure Information. No sub type information P0016 ECM - P001621 Crankshaft Position - Camshaft Position Correlation - Bank 1 Sensor A. General Signal Failures. Signal too low P0016 ECM - P001692 Crankshaft Position - Camshaft Position Correlation - Bank 1 Sensor A. Component Failures. Performance or incorrect operation P0031 ECM - P003100 HO2S Heater Control Circuit Low (Bank 1, Sensor 1). General Failure Information. No sub type information P0032 ECM - P003200 HO2S Heater Control Circuit High (Bank 1, Sensor 1). General Failure Information. No sub type information P0033 ECM - P003300 Turbo/Super Charger Bypass Valve Control Circuit/Open. General Failure Information. No sub type information P0034 ECM - P003400 Turbo/Super Charger Bypass Valve Control 2012 Volvo S80 General Information DTC Index

Circuit Low. General Failure Information. No sub type information P0035 ECM - P003500 Turbo/Super Charger Bypass Valve Control Circuit High. General Failure Information. No sub type information P0036 ECM - P003600 HO2S Heater Control Circuit (Bank 1, Sensor 2). General Failure Information. No sub type information P0037 ECM - P003700 HO2S Heater Control Circuit Low (Bank 1, Sensor 2). General Failure Information. No sub type information P0038 ECM - P003800 HO2S Heater Control Circuit High (Bank 1, Sensor 2). General Failure Information. No sub type information P0039 ECM - P003900 Turbo/Super Charger Bypass Valve Control Circuit Range/Performance. General Failure Information. No sub type information P0045 ECM - P004500 Turbo/Super Charger Boost Control Solenoid Circuit/Open. General Failure Information. No sub type information P0047 ECM - P004700 Turbo/Super Charger Boost Control Solenoid Circuit Low. General Failure Information. No sub type information P0048 ECM - P004800 Turbo/Super Charger Boost Control Solenoid Circuit High. General Failure Information. No sub type information P006D ECM - P006D00 Barometric Pressure - Turbocharger/Supercharger Inlet Pressure Correlation. General Failure Information. No sub type information P0071 ECM - P007162 Ambient Air Temperature Sensor Range/Performance. Algorithm Based Failures. Signal compare failure P0072 ECM - P007200 Ambient Air Temperature Sensor Circuit. General Failure Information. No sub type information P0075 ECM - P007500 Intake Valve Control Circuit (Bank 1). General Failure Information. No sub type information P0076 ECM - P007600 Intake Valve Control Circuit Low (Bank 1). General Failure Information. No sub type information P0077 ECM - P007700 Intake Valve Control Circuit High (Bank 1). General Failure Information. No sub type information P0087 ECM - P008700 Fuel Rail/System Pressure - Too Low. General 2012 Volvo S80 General Information DTC Index

Failure Information. No sub type information P0088 ECM - P008800 Fuel Rail/System Pressure - Too High. General Failure Information. No sub type information P0096 ECM - P009621 Intake Air Temperature Sensor 2 Circuit Range/Performance (Bank 1). General Signal Failures. Signal too low P0097 ECM - P009700 Intake Air Temperature Sensor 2 Circuit Low Input. General Failure Information. No sub type information P0101 ECM - P010192 Mass or Volume Air Flow A Circuit Range/Performance. Component Failures. Performance or incorrect operation P0102 ECM - P010200 Mass or Volume Air Flow Circuit Low Input. General Failure Information. No sub type information P0106 ECM - P010600 Manifold Absolute Pressure/BARO Sensor Range/Performance. General Failure Information. No sub type information P0107 ECM - P010700 Manifold Absolute Pressure/BARO Sensor Low Input. General Failure Information. No sub type information P0111 ECM - P011123 Intake Air Temperature Sensor 1 Circuit Range/Performance (Bank 1). General Signal Failures. Signal stuck low P0111 ECM - P011126 Intake Air Temperature Sensor 1 Circuit Range/Performance (Bank 1). General Signal Failures. Signal rate of change below threshold P0112 ECM - P011200 Intake Air Temperature Sensor 1 Circuit Low Input. General Failure Information. No sub type information P0116 ECM - P011621 Engine Coolant Temperature Sensor 1 Circuit Range/Performance. General Signal Failures. Signal too low P0116 ECM - P011629 Engine Coolant Temperature Sensor 1 Circuit Range/Performance. General Signal Failures. Signal signal invalid P0117 ECM - P011700 Engine Coolant Temperature Circuit Low Input. General Failure Information. No sub type information P0122 ECM - P012200 Throttle/Pedal Position Sensor A Circuit Low. General Failure Information. No sub type information P0123 ECM - P012300 Throttle/Pedal Position Sensor A Circuit High. General Failure Information. No sub type information 2012 Volvo S80 General Information DTC Index

P0128 ECM - P012800 Coolant Thermostat (Coolant Temp Below Thermostat Regulating Temperature). General Failure Information. No sub type information P0131 ECM - P013100 O2 Circuit Low Voltage (Bank 1, Sensor 1). General Failure Information. No sub type information P0132 ECM - P013200 O2 Circuit High Voltage (Bank 1, Sensor 1). General Failure Information. No sub type information P0133 ECM - P013300 O2 Circuit Slow Response (Bank 1, Sensor 1). General Failure Information. No sub type information P0134 ECM - P013400 O2 Circuit No Activity Detected (Bank 1, Sensor 1). General Failure Information. No sub type information P0137 ECM - P013700 O2 Circuit Low Voltage (Bank 1, Sensor 2). General Failure Information. No sub type information P0138 ECM - P013800 O2 Circuit High Voltage (Bank 1, Sensor 2). General Failure Information. No sub type information P013A ECM - P013A00 O2 Sensor Slow Response - Rich to Lean (Bank 1 and Sensor 2). General Failure Information. No sub type information P0140 ECM - P014000 O2 Circuit No Activity Detected (Bank 1, Sensor 2). General Failure Information. No sub type information P0171 ECM - P017100 System Too Lean (Bank 1). General Failure Information. No sub type information P0172 ECM - P017200 System Too Rich (Bank 1). General Failure Information. No sub type information P0181 ECM - P018121 Fuel Temperature Sensor A Circuit Range/Performance. General Signal Failures. Signal too low P0182 ECM - P018200 Fuel Temperature Sensor A Circuit Low Input. General Failure Information. No sub type information P0191 ECM - P019126 Fuel Rail Pressure Sensor A Circuit Range/Performance. General Signal Failures. Signal rate of change below threshold P0192 ECM - P019200 Fuel Rail Pressure Sensor Low Input. General Failure Information. No sub type information P0201 ECM - P020100 Cylinder 1 Injector Circuit/Open. General Failure Information. No sub type information P0202 ECM - P020200 Cylinder 2 Injector Circuit/Open. General 2012 Volvo S80 General Information DTC Index

Failure Information. No sub type information P0203 ECM - P020300 Cylinder 3 Injector Circuit/Open. General Failure Information. No sub type information P0204 ECM - P020400 Cylinder 4 Injector Circuit/Open. General Failure Information. No sub type information P0205 ECM - P020500 Cylinder 5 Injector Circuit/Open. General Failure Information. No sub type information P0206 ECM - P020600 Cylinder 6 Injector Circuit/Open. General Failure Information. No sub type information P0220 ECM - P022023 Throttle/Pedal Position Switch B Circuit. General Signal Failures. Signal stuck low P0220 ECM - P022024 Throttle/Pedal Position Switch B Circuit. General Signal Failures. Signal stuck high P0234 ECM - P023400 Turbo/Super Charger Overboost Condition. General Failure Information. No sub type information P0236 ECM - P023600 Turbo/Super Charger Boost Sensor A Circuit Range/Performance. General Failure Information. No sub type information P0237 ECM - P023700 Turbo/Super Charger Boost Sensor A Circuit Low. General Failure Information. No sub type information P0299 ECM - P029900 Turbo/Super Charger Underboost. General Failure Information. No sub type information P0300 ECM - P030000 Random Misfire Detected. General Failure Information. No sub type information P0301 ECM - P030100 Cylinder 1 Misfire Detected. General Failure Information. No sub type information P0326 ECM - P032621 Knock Sensor 1 Circuit Range/Performance (Bank 1). General Signal Failures. Signal too low P0327 ECM - P032700 Knock Sensor 1 Circuit Low Input (Bank 1). General Failure Information. No sub type information P0328 ECM - P032800 Knock Sensor 1 Circuit High Input (Bank 1). General Failure Information. No sub type information P0331 ECM - P033121 Knock Sensor 2 Circuit Range/Performance (Bank 2). General Signal Failures. Signal too low P0332 ECM - P033200 Knock Sensor 2 Circuit Low Input (Bank 2). General Failure Information. No sub type information P0333 ECM - P033300 Knock Sensor 2 Circuit High Input (Bank 2). General Failure Information. No sub type 2012 Volvo S80 General Information DTC Index

information P0335 ECM - P033500 Crankshaft Position Sensor A Circuit. General Failure Information. No sub type information P0336 ECM - P033600 Crankshaft Position Sensor A Circuit Range/Performance. General Failure Information. No sub type information P0339 ECM - P033900 Crankshaft Position Sensor A Circuit Intermittent. General Failure Information. No sub type information P0340 ECM - P034000 Camshaft Position Sensor A Circuit (Bank 1 or single sensor). General Failure Information. No sub type information P0341 ECM - P034100 Camshaft Position Sensor A Circuit Range/Performance (Bank 1 or single sensor). General Failure Information. No sub type information P0344 ECM - P034400 Camshaft Position Sensor A Circuit Intermittent (Bank 1 or single sensor). General Failure Information. No sub type information P0351 ECM - P035111 Ignition Coil A Primary/Secondary Circuit. General Electrical Failures. Circuit short to ground P0351 ECM - P035112 Ignition Coil A Primary/Secondary Circuit. General Electrical Failures. Circuit short to battery P0351 ECM - P035113 Ignition Coil A Primary/Secondary Circuit. General Electrical Failures. Circuit open P0352 ECM - P035211 Ignition Coil B Primary/Secondary Circuit. General Electrical Failures. Circuit short to ground P0352 ECM - P035212 Ignition Coil B Primary/Secondary Circuit. General Electrical Failures. Circuit short to battery P0352 ECM - P035213 Ignition Coil B Primary/Secondary Circuit. General Electrical Failures. Circuit open P0353 ECM - P035311 Ignition Coil C Primary/Secondary Circuit. General Electrical Failures. Circuit short to ground P0353 ECM - P035312 Ignition Coil C Primary/Secondary Circuit. General Electrical Failures. Circuit short to battery P0353 ECM - P035313 Ignition Coil C Primary/Secondary Circuit. General Electrical Failures. Circuit open P0354 ECM - P035411 Ignition Coil D Primary/Secondary Circuit. General Electrical Failures. Circuit short to 2012 Volvo S80 General Information DTC Index

ground P0354 ECM - P035412 Ignition Coil D Primary/Secondary Circuit. General Electrical Failures. Circuit short to battery P0354 ECM - P035413 Ignition Coil D Primary/Secondary Circuit. General Electrical Failures. Circuit open P0355 ECM - P035511 Ignition Coil E Primary/Secondary Circuit. General Electrical Failures. Circuit short to ground P0355 ECM - P035512 Ignition Coil E Primary/Secondary Circuit. General Electrical Failures. Circuit short to battery P0355 ECM - P035513 Ignition Coil E Primary/Secondary Circuit. General Electrical Failures. Circuit open P0356 ECM - P035611 Ignition Coil F Primary/Secondary Circuit. General Electrical Failures. Circuit short to ground P0356 ECM - P035612 Ignition Coil F Primary/Secondary Circuit. General Electrical Failures. Circuit short to battery P0356 ECM - P035613 Ignition Coil F Primary/Secondary Circuit. General Electrical Failures. Circuit open P0365 ECM - P036500 Camshaft Position Sensor B Circuit (Bank 1). General Failure Information. No sub type information P0366 ECM - P036600 Camshaft Position Sensor B Circuit Range/Performance (Bank 1). General Failure Information. No sub type information P0369 ECM - P036900 Camshaft Position Sensor B Circuit Intermittent (Bank 1). General Failure Information. No sub type information P0420 ECM - P042000 Catalyst System Efficiency Below Threshold (Bank 1). General Failure Information. No sub type information P043E ECM - P043E00 Evaporative Emission System Leak Detection Reference Orifice Low Flow. General Failure Information. No sub type information P0441 ECM - P044100 Evaporative Emission System Incorrect Purge Flow. General Failure Information. No sub type information P0442 ECM - P044200 Evaporative Emission System Leak Detected (small leak). General Failure Information. No sub type information P0444 ECM - P044400 Evaporative Emission System Purge Control Valve Circuit Open. General Failure 2012 Volvo S80 General Information DTC Index

Information. No sub type information P0455 ECM - P045500 Evaporative Emission System Leak Detected (gross leak/no flow). General Failure Information. No sub type information P0458 ECM - P045800 Evaporative Emission System Purge Control Valve Circuit Low. General Failure Information. No sub type information P0459 ECM - P045900 Evaporative Emission System Purge Control Valve Circuit High. General Failure Information. No sub type information P0460 ECM - P046000 Fuel Level Sensor A Circuit. General Failure Information. No sub type information P0461 ECM - P046100 Fuel Level Sensor A Circuit Range/Performance. General Failure Information. No sub type information P0464 ECM - P046400 Fuel Level Sensor A Circuit Intermittent. General Failure Information. No sub type information P0480 ECM - P048000 Fan 1 Control Circuit. General Failure Information. No sub type information P0481 ECM - P048100 Fan 2 Control Circuit. General Failure Information. No sub type information P0500 ECM - P050082 Vehicle Speed Sensor A. Bus Signal/Message Failures. Alive/sequence counter incorrect/not updated P0500 ECM - P050087 Vehicle Speed Sensor A. Bus Signal/Message Failures. Missing message P0504 ECM - P050429 Brake Switch A/B Correlation. General Signal Failures. Signal signal invalid P0504 ECM - P050462 Brake Switch A/B Correlation. Algorithm Based Failures. Signal compare failure P0504 ECM - P050465 Brake Switch A/B Correlation. Algorithm Based Failures. Signal has too few transitions/events P0506 ECM - P050600 Idle Air Control System RPM Lower Than Expected. General Failure Information. No sub type information P0507 ECM - P050700 Idle Air Control System RPM Higher Than Expected. General Failure Information. No sub type information P050A ECM - P050A00 Cold Start Idle Air Control System Performance. General Failure Information. No sub type information P0525 ECM - P052548 Cruise Control Servo Control Circuit Range/Performance. System Internal Failures. 2012 Volvo S80 General Information DTC Index

Supervision software failure P052A ECM - P052A00 Cold Start Camshaft Position Timing Over- Advanced (Bank 1). General Failure Information. No sub type information P052B ECM - P052B00 Cold Start Camshaft Position Timing Over- Retarded (Bank 1). General Failure Information. No sub type information P0531 ECM - P053100 A/C Refrigerant Pressure Sensor A Circuit Range/Performance. General Failure Information. No sub type information P0532 ECM - P053200 A/C Refrigerant Pressure Sensor A Circuit Low Input. General Failure Information. No sub type information P0533 ECM - P053300 A/C Refrigerant Pressure Sensor A Circuit High Input. General Failure Information. No sub type information P0534 ECM - P053400 A/C Refrigerant Charge Loss. General Failure Information. No sub type information P0562 ECM - P056200 System Voltage Low. General Failure Information. No sub type information P0563 ECM - P056300 System Voltage High. General Failure Information. No sub type information P0575 ECM - P057500 Cruise Control Input Circuit. General Failure Information. No sub type information P0603 ECM - P060300 Internal Control Module Keep Alive Memory (KAM) Error. General Failure Information. No sub type information P0606 ECM - P060661 Control module processor. Algorithm Based Failures. Signal calculation failure P0606 ECM - P060662 Control module processor. Algorithm Based Failures. Signal compare failure P0606 ECM - P060696 Control module processor. Component Failures. Component internal failure P0607 ECM - P060704 Control Module Performance. General Failure Information. System Internal Failures P060C ECM - P060C68 Internal Control Module Main Processor Performance. Algorithm Based Failures. Event information P0615 ECM - P061511 Starter Relay Circuit. General Electrical Failures. Circuit short to ground P0615 ECM - P061512 Starter Relay Circuit. General Electrical Failures. Circuit short to battery P0615 ECM - P061513 Starter Relay Circuit. General Electrical Failures. Circuit open P061A ECM - P061A00 Internal Control Module Torque Performance. 2012 Volvo S80 General Information DTC Index

General Failure Information. No sub type information P061A ECM - P061A68 Internal Control Module Torque Performance. Algorithm Based Failures. Event information P061B ECM - P061B64 Internal Control Module Torque Calculation Performance. Algorithm Based Failures. Signal plausibility failure P061F ECM - P061F00 Internal Control Module Throttle Actuator Controller Performance. General Failure Information. No sub type information P0628 ECM - P062800 Fuel Pump A Control Circuit Low. General Failure Information. No sub type information P0629 ECM - P062900 Fuel Pump A Control Circuit High. General Failure Information. No sub type information P0634 ECM - P063400 PCM/ECM/TCM Internal Temperature Too High. General Failure Information. No sub type information P0634 ECM - P06344B PCM/ECM/TCM Internal Temperature Too High. System Internal Failures. Over temperature P0634 ECM - P063498 PCM/ECM/TCM Internal Temperature Too High. Component Failures. Component or system over temperature P0642 ECM - P064200 Sensor Reference Voltage A Circuit Low. General Failure Information. No sub type information P0645 ECM - P064500 A/C Clutch Relay Control Circuit. General Failure Information. No sub type information P0646 ECM - P064600 A/C Clutch Relay Control Circuit Low. General Failure Information. No sub type information P0647 ECM - P064700 A/C Clutch Relay Control Circuit High. General Failure Information. No sub type information P065A ECM - P065A00 Generator System Performance. General Failure Information. No sub type information P065C ECM - P065C00 Generator mechanical performance. General Failure Information. No sub type information P0668 ECM - P066800 PCM/ECM/TCM Internal Temperature Sensor Circuit Low. General Failure Information. No sub type information P0669 ECM - P066900 PCM/ECM/TCM Internal Temperature Sensor Circuit High. General Failure Information. No sub type information P068B ECM - P068B00 Control module internal power +5 V. General 2012 Volvo S80 General Information DTC Index
