2 0 0 7 VOLVO S80 VOLVO OWNER'S MANUAL S80 1 THANK YOU FOR CHOOSING VOLVO Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts at all times in this (or any other) automobile. And, of course, please do not operate a vehicle if you may be affected by alcohol, medication or any impairment that could hinder your ability to drive. Your Volvo is designed to meet all applicable safety and emission standards, as evidenced by the certification labels attached to the driver's door opening and on the left wheel housing in the engine compartment. For further information please contact your retailer, or: In the USA : Volvo Cars of North America, LLC Customer Care Center P.O. Box 914 Rockleigh, New Jersey 07647-0914

1-800-458-1552 www.volvocars.us In Canada: Volvo Cars of Canada Corp. National Customer Service 175 Gordon Baker Road North York, Ontario M2H 2N7 1-800-663-8255 www.volvocanada.com 2006 © Volvo Car Corporation. All rights reserved. 2 Contents 00 Introduction Important information 6 Important warnings 7 Environment 9 01 Safety Occupant safety 12 Reporting safety defects 13 Safety in the passenger compartment 14 Crash mode 28 Child safety 29 Child restraint systems 32 Infant seats 34 Convertible seats 36 Booster cushions 39 ISOFIX lower anchors 40 Top tether anchors 41 Integrated booster cushion 42 Child safety locks 45 02 Locks and alarm Remote key and key blade 48 Keyless drive 56 Locks 59 Alarm 62 3 Contents

03 Your driving environment Instruments and controls 68 Ignition modes 75 Seats 77 Steering wheel 82 Lighting 84 Wipers and washers 90 Power windows 92 Mirrors 94 Power moonroof 96 HomeLink® Universal Transceiver (option) 98 Starting the engine 102 Transmission 105 Brakes 107 Parking brake 110 04 Comfort and driving pleasure Menus and messages 114 Climate system 118 Audio system 125 Trip computer 136 Compass 137 Stability system 139 Active chassis system-Four C 141 Cruise control 142 Adaptive Cruise Control-ACC 144 Collision warning system (option) 150 Park assist (option) 153 Blind Spot Information System (option) 155 Passenger compartment convenience 158 Bluetooth hands-free (option) 162 05 During your trip Driving recommendations 170 Refueling 174 Loading 179 Towing a trailer 182 Emergency towing 185 4 Contents 06 Maintenance and specifications Volvo maintenance 190 Maintaining your car 191 Hood and engine compartment 193 Engine oil 194 Fluids 196 Replacing bulbs 198 Wiper blades and washer fluid 205 Battery 207 Fuses 210 Wheels and tires 216 Vehicle care 236 Label information 241 Specifications 243 Volvo programs 250 07 Index Index 252 5 Contents This page left intentionally blank.

6 Introduction Important information Points to keep in mind Before you operate your vehicle for the first time, please familiarize yourself with the information in chapter 3. Information contained in the balance of the manual is extremely useful and should be read after operating the vehicle for the first time. The manual is structured so that it can be used for reference. For this reason, it should be kept in the vehicle for ready access. Do not export your Volvo to another country before investigating that country's applicable safety and emission control requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries. All information, illustrations and specifications contained in this manual are based on the latest product information available at the time of publication. This information is subject to change without prior notice. Please note that some vehicles may be equipped differently, depending on special legal requirements. Optional equipment described in this manual may not be available in all markets. Volvo reserves the right to make model changes at any time, or to change specifications or design without notice and without incurring obligation WARNING If your vehicle is involved in an accident, unseen damage may affect its drivability and safety. Vehicle event data (Black box) Your vehicle's driving and safety systems employ computers that monitor, and share with each other, information about your vehicle's operation. One or more of these computers may store what they monitor, either during normal vehicle operation or in a crash or near-crash event. Stored information may be read and used by: Volvo Car Corporation service and repair facilities law enforcement or government agencies others who may assert a legal right to know, or who obtain your consent to know such information. 7 Introduction Important warnings Driver distraction A driver has a responsibility to do everything possible to ensure his or her own safety and the safety of passengers in the vehicle and others sharing the roadway. Avoiding distractions is part of that responsibility. Driver distraction results from driver activities that are not directly related to controlling the vehicle in the driving environment. Your new Volvo is, or can be, equipped with many feature-rich entertainment and communication systems. These include hands-free cellular telephones, navigation systems, and multipurpose audio systems. You may also own other portable electronic devices for your own convenience. When used properly and safely, they enrich the

driving experience. Improperly used, any of these could cause a distraction. For all of these systems, we want to provide the following warning that reflects the strong Volvo concern for your safety: Never use these devices or any feature of your vehicle in a way that distracts you from the task of driving safely. Distraction can lead to a serious accident. In addition to this general warning, we offer the following guidance regarding specific newer features that may be found in your vehicle: Never use a hand-held cellular telephone while driving. Some jurisdictions prohibit cellular telephone use by a driver while the vehicle is moving. If your vehicle is equipped with a navigation system, set and make changes to your travel itinerary only with the vehicle parked. Never program your audio system while the vehicle is moving. Program radio presets with the vehicle parked, and use your programmed presets to make radio use quicker and simpler. Never use portable computers or personal digital assistants while the vehicle is moving. Accessory installation We strongly recommend that Volvo owners install only genuine, Volvo-approved accessories, and that accessory installations be performed only by the factory-trained technicians at your authorized Volvo retailer. Genuine Volvo accessories are tested to ensure compatibility with the performance, safety, and emission systems in your vehicle. Additionally, your authorized Volvo retailer knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult your authorized Volvo retailer before installing any accessory in or on your vehicle. Accessories that have not been approved by Volvo may or may not be specifically tested for compatibility with your vehicle. Additionally, an inexperienced installer may not be familiar with some of your car's systems. Any of your car's performance and safety systems could be adversely affected if you install accessories that Volvo has not tested, or if you allow accessories to be installed by someone unfamiliar with your vehicle. Damage caused by unapproved or improperly installed accessories may not be covered by your new vehicle warranty. 8 Introduction Important warnings See your Warranty and Service Records Information booklet for more warranty information. Volvo assumes no responsibility for death, injury, or expenses that may result from the installation of non-genuine accessories. 9 Introduction Environment Volvo and the environment Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact. Volvo's environmental activities are based on a holistic view, which means we consider the overall environmental impact of a product throughout its complete life cycle. In this context, design, production, product use, and recycling are all important considerations. In production, Volvo has partly or completely phased out several chemicals including CFCs, lead chromates, asbestos, and cadmium; and reduced the number of chemicals used in our plants 50% since 1991. Volvo was the first in the world to introduce into production a three-way catalytic converter with a Lambda sond, now called the heated oxygen sensor, in 1976. The current version of this highly efficient system reduces emissions of

harmful substances (CO, HC, NOx) from the exhaust pipe by approximately 95-99% and the search to eliminate the remaining emissions continues. Volvo is the only automobile manufacturer to offer CFC-free retrofit kits for the air conditioning system of all models as far back as the 1975 model 240. Advanced electronic engine controls and cleaner fuels are bringing us closer to our goal. After Volvo vehicles and parts have fulfilled their use, recycling is the next critical step in completing the life cycle. The metal content is about 75% of the total weight of a vehicle, which makes the vehicle among the most recycled industrial products. In order to have efficient and well controlled recycling, all Volvo variants have printed dismantling manuals, indicating the weight and material of individual components. For Volvo, all homogeneous plastic parts weighing more than 3.4 oz. (100 grams) are marked with international symbols that indicate how the component is to be sorted for recycling. In addition to continuous environmental refinement of conventional gasoline-powered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles. When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment. To reduce your vehicle's environmental impact, you can: Maintain proper air pressure in your tires. Tests have shown decreased fuel economy with improperly inflated tires. Follow the recommended maintenance schedule in your Warranty and Service Records Information booklet. Drive at a constant speed whenever possible. See a trained and qualified Volvo service technician as soon as possible for inspection if the check engine (malfunction indicator) light illuminates, or stays on after the vehicle has started. Properly dispose of any vehicle-related waste such as used motor oil, used batteries, brake pads, etc. When cleaning your vehicle, please use genuine Volvo car care products. All Volvo car care products are formulated to be environmentally friendly. WARNING PROPOSITION 65 WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the state of California to cause cancer, and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. Contents | Top of Page

2 0 0 7 VOLVO S80 10 01 Safety Occupant safety 12 Reporting safety defects 13 Safety in the passenger compartment 14 Crash mode 28 Child safety 29 Child restraint systems 32 Infant seats 34 Convertible seats 36 Booster cushions 39 ISOFIX lower anchors 40 Top tether anchors 41 Integrated booster cushion 42 Child safety locks 45 11 01 Safety 12 01 Safety Occupant safety Volvo's concern for safety Safety is Volvo's cornerstone. Our concern dates back to 1927 when the first Volvo rolled off the production line. Three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo vehicles long before it was fashionable or required by government regulation. We will not compromise our commitment to safety. We continue to seek out new safety features and to refine those already in our vehicles. You can help. We would appreciate hearing your suggestions about improving automobile safety. We also want to know if you ever have a safety concern with your vehicle. Call us in the U.S. at: 1-800-458-

1552 or in Canada at: 1-800-663-8255. Occupant safety reminders How safely you drive doesn't depend on how old you are but rather on: How well you see. Your ability to concentrate. How quickly you make decisions under stress to avoid an accident. The following suggestions are intended to help you cope with the ever changing traffic environment. Never drink and drive. If you are taking any medication, consult your physician about its potential effects on your driving abilities. Take a driver-retraining course. Have your eyes checked regularly. Keep your windshield and headlights clean. Replace wiper blades when they start to leave streaks. Take into account the traffic, road, and weather conditions, particularly with regard to stopping distance. 13 01 Safety Reporting safety defects Reporting safety defects in the U.S. If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Volvo Cars of North America, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America, LLC. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153) or write to: NHTSA, U.S. Department of Transportation, Washington D.C. 20590. You can also obtain other information about motor vehicle safety from: http://www.safecar.gov Volvo strongly recommends that if your vehicle is covered under a service campaign, safety or emission recall or similar action, it should be completed as soon as possible. Please check with your local retailer or Volvo Cars of North America, LLC if your vehicle is covered under these conditions. NHTSA can be reached at: Internet: http://www.nhtsa.gov Telephone:1-888-DASH-2-DOT (1-888-327-4236). Reporting safety defects in Canada If you believe your vehicle has a defect that could cause a crash or could cause injury or death, you should

immediately inform Transport Canada in addition to notifying Volvo Cars of Canada Corp. To contact Transport Canada, call (800) 333- 0510, or (613) 993-9851 if you are calling from the Ottawa region. 14 01 Safety Safety in the passenger compartment Seat belts Using seat belts Volvo, the inventor of the three-point seat belt, urges you and all occupants of your vehicle to wear seat belts and ensure that children are properly restrained, using an infant, convertible, or booster seat determined by age, weight and height. Volvo also believes no child should sit in the front seat of a vehicle. Most states and provinces make it mandatory for occupants of a vehicle to use seat belts. Seat belt tensioners All seat belts are equipped with tensioners that reduce slack in the belts. These tensioners are triggered in situations where the front airbags deploy. The front seat belts also include a tension reducing device which, in the event of a collision, limits the peak forces exerted by the seat belt on the occupant. Buckling a seat belt Pull the belt out far enough to insert the latch plate into the receptacle until a distinct click is heard. The seat belt retractor is normally "unlocked" and you can move freely, provided that the shoulder belt is not pulled out too far. The retractor will lock up as follows: if the belt is pulled out rapidly during braking and acceleration if the vehicle is leaning excessively when driving in turns. To make child seat installation easier, each seat belt (except for the driver's belt) is equipped with a locking mechanism to help keep the seat belt taut. See page 31 for more information regarding the Automatic Locking Retractor (ALR). When wearing the seat belt remember: The belt should not be twisted or turned. The lap section of the belt must be positioned low on the hips (not pressing against the abdomen).

Make sure that the shoulder belt is rolled up into its retractor and that the shoulder and lap belts are taut. 15 01 Safety Safety in the passenger compartment Seat belt reminder The seat belt reminder consists of an audible signal, an indicator light above the rearview mirror, and a symbol in the instrument panel that alert the driver if his/her seat belt is not fastened. Unbuckling the seat belt To remove the seat belt, press the red section on the seat belt receptacle. Before exiting the vehicle, check that the seat belt retracts fully after being unbuckled. If necessary, guide the belt back into the retractor slot. Seat belt maintenance Check periodically that the seat belts are in good condition. Use water and a mild detergent for cleaning. Check seat belt mechanism function as follows: attach the seat belt and pull rapidly on the strap. WARNING Never use a seat belt for more than one occupant. Never wear the shoulder portion of the belt under the arm, behind the back or otherwise out of position. Such use could cause injury in the event of an accident. As seat belts lose much of their strength when exposed to violent stretching, they should be replaced after any collision, even if they appear to be undamaged. WARNING Never repair the belt yourself; have this work done by a trained and qualified Volvo service technician only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision. The seat back should not be tilted too far back. The shoulder belt must be taut in order to function properly. Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that children who have outgrown these devices sit in the rear seat with the seat belt properly fastened. 16 01 Safety Safety in the passenger compartment Seat belt use during pregnancy
