2002 VOLVO S60 Service and Repair Manual

GENERAL INFORMATION DTC Index - S60 ACCESSORY ELECTRONIC MODULE (AEM) DTCS ACCESSORY ELECTRONIC MODULE (AEM) DTC INDEX Volvo Code Description AEM - 1A01 Power supply. Signal too low. Intermittent fault AEM - 1A01 Power supply. Signal too low. Permanent fault AEM - 1D01 Control module. Internal fault. Intermittent fault AEM - 1D01 Control module. Internal fault. Permanent fault AEM - 1D02 Control module, software. Internal fault. Intermittent fault AEM - 1D02 Control module, software. Internal fault. Permanent fault AEM - 1D03 Control module not fully programmed. Internal fault. Intermittent fault AEM - 1D03 Control module not fully programmed. Internal fault. Permanent fault AEM - 1D07 Control module. Internal fault. Intermittent fault AEM - 1D07 Control module. Internal fault. Permanent fault AEM - 1D08 Control module. Internal fault. Intermittent fault AEM - 1D08 Control module. Internal fault. Permanent fault AEM - 1D0A Control module. Internal fault. Intermittent fault AEM - 1D0A Control module. Internal fault. Permanent fault AEM - 5F10 Relay, engine block heater. Signal too low. Intermittent fault AEM - 5F10 Relay, engine block heater. Signal too low. Permanent fault AEM - 5F11 Relay, engine block heater. Signal too high or Signal missing. Intermittent fault AEM - 5F11 Relay, engine block heater. Signal too high or Signal missing. Permanent fault AEM - 5F20 Remote start. Signal too low. Intermittent fault AEM - 5F20 Remote start. Signal too low. Permanent fault AEM - 5F22 Remote start. Signal too low. Intermittent fault AEM - 5F22 Remote start. Signal too low. Permanent fault AEM - 5F23 Remote start. Signal too high. Intermittent fault AEM - 5F23 Remote start. Signal too high. Permanent fault AEM - 6C50 Alarm output P0. Signal too low or signal missing. Intermittent fault AEM - 6C50 Alarm output P0. Signal too low or signal missing. Permanent fault AEM - 6C51 Alarm output P0. Signal too high. Intermittent fault AEM - 6C51 Alarm output P0. Signal too high. Permanent fault AEM - 6C52 Alarm output P1. Signal too low or signal missing. Intermittent fault AEM - 6C52 Alarm output P1. Signal too low or signal missing. Permanent fault AEM - 6C53 Alarm output P1. Signal too high. Intermittent fault AEM - 6C53 Alarm output P1. Signal too high. Permanent fault AEM - 6C54 Alarm output S0. Signal too low or signal missing. Intermittent fault AEM - 6C54 Alarm output S0. Signal too low or signal missing. Permanent fault Volvo S60

AUDIO MODULE (AUM) DTCS AUDIO MODULE (AUM) DTC INDEX AEM - 6C55 Alarm output S0. Signal too high. Intermittent fault AEM - 6C55 Alarm output S0. Signal too high. Permanent fault AEM - 6C56 Alarm output S1. Signal too low. Intermittent fault AEM - 6C56 Alarm output S1. Signal too low. Permanent fault AEM - 6C57 Alarm output S1. Signal too high or Signal missing. Intermittent fault AEM - 6C57 Alarm output S1. Signal too high or Signal missing. Permanent fault AEM - 7A10 Carphone mute signal. Signal too low. Intermittent fault AEM - 7A10 Carphone mute signal. Signal too low. Permanent fault AEM - 7A11 Carphone mute signal. Signal too high or Signal missing. Intermittent fault AEM - 7A11 Carphone mute signal. Signal too high or Signal missing. Permanent fault AEM - 7A12 Rheostat signal. Signal too low / high or signal missing. Intermittent fault AEM - 7A12 Rheostat signal. Signal too low / high or signal missing. Permanent fault AEM - 7A14 Speed signal. Signal too low / high or signal missing. Intermittent fault AEM - 7A14 Speed signal. Signal too low / high or signal missing. Permanent fault AEM - 7A16 Antenna amplifier. Signal too low. Intermittent fault AEM - 7A16 Antenna amplifier. Signal too low. Permanent fault AEM - 7A17 Antenna amplifier. Signal too high or Signal missing. Intermittent fault AEM - 7A17 Antenna amplifier. Signal too high or Signal missing. Permanent fault AEM - E001 Control module communication. Faulty communication AEM - E003 Configuration fault. Faulty configuration AEM - XXXX Unknown diagnostic trouble code (DTC) for the current control module version Volvo Code Description AUM - 36E1 Antenna, satellite radio. Signal too low AUM - 36EF Antenna, satellite radio. Signal missing AUM - 4001 Antenna amplifier 1. Signal too low. Intermittent fault AUM - 4001 Antenna amplifier 1. Signal too low. Permanent fault AUM - 4002 Amplifier, main antenna. Signal too high. Intermittent fault AUM - 4002 Amplifier, main antenna. Signal too high. Permanent fault AUM - 40FF Amplifier, main antenna. Signal missing. Intermittent fault AUM - 40FF Amplifier, main antenna. Signal missing. Permanent fault AUM - 41FF Amplifier, sub-antenna. Signal missing. Intermittent fault AUM - 41FF Amplifier, sub-antenna. Signal missing. Permanent fault AUM - 42FF Single CD player. Not connected or communication problems. Intermittent fault AUM - 42FF Single CD player. Not connected or communication problems. Permanent fault AUM - 43FF MiniDisc player. Not connected or communication problems. Intermittent fault AUM - 43FF MiniDisc player. Not connected or communication problems. Permanent fault AUM - 44FF 4 disc CD changer. Not connected or communication problems. Intermittent fault

BRAKE CONTROL MODULE (BCM) DTCS BRAKE CONTROL MODULE (BCM) DTC INDEX AUM - 44FF 4 disc CD changer. Not connected or communication problems. Permanent fault AUM - 45FF Cassette deck. Not connected or communication problems. Intermittent fault AUM - 45FF Cassette deck. Not connected or communication problems. Permanent fault AUM - 46FE 10 disc CD changer. Faulty installation. Intermittent fault AUM - 46FE 10 disc CD changer. Faulty installation. Permanent fault AUM - 46FF 10 disc CD changer. Not connected or communication problems. Intermittent fault AUM - 46FF 10 disc CD changer. Not connected or communication problems. Permanent fault AUM - 47FE Amplifier. Faulty installation. Intermittent fault AUM - 47FE Amplifier. Faulty installation. Permanent fault AUM - 47FF Amplifier. Not connected or communication problems. Intermittent fault AUM - 47FF Amplifier. Not connected or communication problems. Permanent fault AUM - 48FD Control module. Faulty frequency setting. Intermittent fault AUM - 48FD Control module. Faulty frequency setting. Permanent fault AUM - 49FD Control module. Faulty installation. Intermittent fault AUM - 49FD Control module. Faulty installation. Permanent fault AUM - 4BFF Control module. Internal program fault. Intermittent fault AUM - 4BFF Control module. Internal program fault. Permanent fault AUM - E001 Control module communication. Faulty communication AUM - E003 Configuration fault. Faulty configuration Volvo Code Description BCM - 0010 Left front wheel sensor. Signal missing BCM - 0011 Left front wheel sensor. Faulty signal BCM - 0012 Left front wheel sensor. Faulty signal BCM - 0020 Right front wheel sensor. Signal missing BCM - 0021 Right front wheel sensor. Faulty signal BCM - 0022 Right front wheel sensor. Faulty signal BCM - 0030 Left rear wheel sensor. Signal missing BCM - 0031 Left rear wheel sensor. Faulty signal BCM - 0032 Left rear wheel sensor. Faulty signal BCM - 0040 Right rear wheel sensor. Signal missing BCM - 0041 Right rear wheel sensor. Faulty signal BCM - 0042 Right rear wheel sensor. Faulty signal BCM - 0050 Control module. Faulty signal BCM - 0052 Control module. Internal fault BCM - 0057 Power supply. Voltage too low BCM - 0058 Power supply. Voltage too high BCM - 0061 Brake discs. Temperature too high

BCM - 0065 Stop lamp switch. Faulty signal BCM - 0068 Sensor power supply. Faulty signal BCM - 0070 Power supply for the pump motor. Faulty signal BCM - 0071 Pump motor. Signal missing BCM - 0072 Pump motor. Mechanical fault BCM - 0074 Hydraulic valves. Faulty signal BCM - 0076 Control module. Faulty configuration BCM - 0080 Lateral accelerometer. Incorrect offset value BCM - 0081 Accelerometer. Incorrect offset value BCM - 0082 Yaw rate sensor. Incorrect offset value BCM - 0083 Angle of lean sensor. Incorrect offset value BCM - 0090 Lateral accelerometer. Faulty signal BCM - 0091 Accelerometer. Faulty signal BCM - 0092 Yaw rate sensor. Faulty signal BCM - 0093 Angle of lean sensor. Faulty signal BCM - 0094 Communication between control units Communication problems with DEM BCM - 0095 Communication between control units Communication problems with DEM BCM - 0097 Communication between control modules. Communication problems with the central electronic module (CEM) BCM - 0100 Communication between control modules. Communication problems with the engine control module (ECM) BCM - 0101 Communication between control modules. Communication problems with the engine control module (ECM) BCM - 0103 Pedal position sensor. Faulty signal BCM - 0106 Steering wheel or wheel alignment. Incorrect steering wheel or wheel alignment BCM - 0108 Communication between control modules. Communication with the steering angle sensor. Control module not initiated BCM - 0109 Communication between control modules. Communication with the steering angle sensor. Internal fault BCM - 0111 Communication between control modules. Check of the steering angle sensor tolerances has not been run BCM - 0112 Active yaw control sensor. Sensor not calibrated BCM - 0113 Back-up (reversing) signal. Signal missing BCM - 0114 Communication with the active yaw control sensor. Signal missing BCM - 0115 Communication between control modules. Communication with the steering angle sensor. Signal missing BCM - 0116 Communication with the active yaw control sensor. Communication problems BCM - 0117 Communication with the active yaw control sensor. An incorrect active yaw control sensor had been installed BCM - 0118 Power supply for the active yaw control sensor. Voltage too high BCM - 0119 Power supply for the active yaw control sensor. Voltage too low BCM - 0121 Yaw rate sensor. Signal outside its permitted range

CLIMATE CONTROL MODULE (CCM) DTCS CLIMATE CONTROL MODULE (CCM) DTC INDEX BCM - 0123 Active yaw control sensor. Internal fault BCM - 0125 Lateral accelerometer. Signal outside its permitted range BCM - 0127 Angle of lean sensor. Signal outside its permitted range BCM - 0129 Accelerometer. Signal outside its permitted range BCM - 0130 Brake pressure sensor 1. Signal too low BCM - 0133 Brake pressure sensor 2. Signal too low BCM - 0136 Brake pressure sensor 1 and 2. Signal outside its permitted range BCM - 0138 Power supply for the active yaw control sensor. Faulty voltage BCM - 0139 Pressure build-up valve, power brake booster. Signal outside its permitted range BCM - 0140 Pedal pressure sensor. Signal outside its permitted range BCM - 0145 Stability control. Too long stability control BCM - 0146 Factory test, dynamic stability and traction control (DSTC). Test cycle not approved BCM - 0147 Pedal position sensor. Signal outside its permitted range BCM - 0148 Communication between control modules. Faulty configuration ID BCM - 0150 Stop lamp switch. Signal outside its permitted range BCM - 0151 Control module. Internal memory fault BCM - A030 Communication between control modules. Steering angle sensor. Initialization check not run BCM - A031 Communication between control modules. Steering angle sensor. Tolerance check not run BCM - A032 Stability function. Too long stability control BCM - E000 Control module communication. Faulty communication BCM - E003 Configuration fault. Faulty configuration BCM - XXXX Unknown diagnostic trouble code (DTC) for the current control module version Volvo Code Description CCM - 0001 Configuration fault. Non-approved value CCM - 0002 Evaporator temperature sensor. Signal too high / Signal missing CCM - 0003 Evaporator temperature sensor. Signal too low CCM - 0004 Passenger compartment temperature sensor. Signal too high / Signal missing CCM - 0005 Passenger compartment temperature sensor. Signal too high / Signal missing CCM - 0006 Blower fan motor passenger compartment temperature sensor. Signal too high / Signal missing CCM - 0011 Control module. Internal fault CCM - 0020 Function button. Activated too long CCM - 0030 Left heater pad. Faulty signal CCM - 0031 Sensor left-hand seat heater. Faulty signal CCM - 0032 Left-hand seat heater. Internal fault CCM - 0033 Left-hand seat heater. Internal fault

CCM - 0034 Right heater pad. Faulty signal CCM - 0035 Sensor right-hand seat heater. Faulty signal CCM - 0036 Right-hand seat heater. Internal fault CCM - 0037 Right-hand seat heater. Internal fault CCM - 0040 Air quality sensor. Internal fault CCM - 0050 Blower fan knob. Faulty signal CCM - 0051 Temperature control left. Faulty signal CCM - 0052 Temperature control right. Faulty signal CCM - 0053 Air distribution control. Faulty signal CCM - 0060 Damper motor defroster. Internal fault CCM - 0061 Recirculation damper motor. Internal fault CCM - 0062 Left temperature damper motor. Internal fault CCM - 0063 Right temperature damper motor. Internal fault CCM - 0064 Air distribution damper motor. Internal fault CCM - 0070 Configuration fault. Faulty identification CCM - 0071 Damper motor. Faulty position CCM - 0072 Damper motor. Initiation fault CCM - 0073 Configuration fault. Calibration not done CCM - 0074 Damper motor, defroster Internal fault CCM - 0074 Damper motor, defroster Internal fault (L.H.D) CCM - 0075 Damper motor Internal fault CCM - 0075 Damper motor Internal fault (L.H.D) CCM - 0076 Damper motor, temperature left Internal fault CCM - 0076 Damper motor, temperature left Internal fault (L.H.D) CCM - 0077 Damper motor, temperature right Internal fault CCM - 0077 Damper motor, temperature right Internal fault (L.H.D) CCM - 0078 Damper motor distribution Internal fault CCM - 0078 Damper motor distribution Internal fault (L.H.D) CCM - 0090 Lower switch. Faulty ID CCM - 0091 Lower switch. ID missing CCM - 00A0 Blower fan motor. Signal too low CCM - 00A1 Blower fan motor. Signal too high CCM - DD00 LIN bus1. Incorrect data CCM - DD01 LIN bus1. Signal too high / Signal too low CCM - DD02 LIN bus1. Faulty check sum CCM - DD10 Air quality sensor (AQS). No communication CCM - DD12 Left-hand seat heater. No communication CCM - DD14 Recirculation damper motor. No communication CCM - DD15 Left temperature damper motor. No communication CCM - DD16 Damper motor air distribution. No communication CCM - DD20 LIN bus 2. Incorrect data CCM DD21

CENTRAL ELECTRONIC MODULE (CEM) DTCS CENTRAL ELECTRONIC MODULE (CEM) DTC INDEX LIN bus 2. Signal too high/Signal too low CCM - DD22 LIN bus 2. Incorrect check sum CCM - DD30 Right-hand seat heater. No communication CCM - DD31 Recirculation damper motor. No communication CCM - DD32 Right temperature damper motor. No communication CCM - DD33 Damper motor defroster. No communication CCM - DD34 Air quality sensor (AQS). No communication CCM - E001 Control module communication CCM - E003 Configuration fault CCM - E010 Power supply CCM - XXXX Unknown diagnostic trouble code (DTC) for the current control module version Volvo Code Description CEM - 1A03 S-Power supply Signal too low CEM - 1A04 X-Power supply. Signal too low CEM - 1A05 X-Power supply Signal too high CEM - 1A06 15-Power supply. Signal too low CEM - 1A07 15-Power supply. Signal too high CEM - 1A08 50-Power supply. Signal missing CEM - 1A09 50-Power supply. Signal too high CEM - 1A51 Communication with the supplemental restraint system module (SRS). Signal missing CEM - 1A52 Communication with the driver door module (DDM). Signal missing CEM - 1A53 Communication with the passenger door module (PDM). Signal missing CEM - 1A54 Communication with the power seat module (PSM). Signal missing CEM - 1A55 Communication with the climate control module (CCM). Signal missing CEM - 1A56 Communication with the driver information module (DIM). Signal missing CEM - 1A57 Communication with the RTI module. Signal missing CEM - 1A58 Communication with the phone module (PHM). Signal missing CEM - 1A59 Communication with the audio module (AUM). Signal missing CEM-1A5A Communication with the rear electronic module (REM). Signal missing CEM-1A5C Communication with the upper electronic module (UEM). Signal missing CEM-1A5E Communication with the steering wheel angle sensor module (SAS). Signal missing CEM-1A5F Communication with the brake control module (BCM). Signal missing CEM-1A61 Communication with the transmission control module (TCM). Signal missing (AW50/51 AWD; AW55-50/51SN) CEM-1A62 Communication with the engine control module (ECM). Signal missing CEM-1A62 Communication with the engine control module (ECM). Signal missing (B5204T5; B5254T4)

CEM-1A62 Communication with the engine control module (ECM). Signal missing (B5244S; B5244S6) CEM-1A62 Communication with the engine control module (ECM). Signal missing (B5244T5; B5254T2) CEM-1A63 Communication with the accessory electronic module (AEM). Signal missing CEM-1A64 Communication with the differential electronic module (DEM). Signal missing CEM-1A65 Communication with the suspension module (SUM). Signal missing CEM-1C05 30-Power supply. Signal too low CEM - 1C06 Alternator control module (ACM). Electrical fault (B5204T5; B5254T4) CEM - 1C06 Alternator control module (ACM). Electrical fault (B5244S) CEM - 1C06 Alternator control module (ACM). Electrical fault (B5244T5; B5254T2) CEM - 1C07 Alternator control module (ACM). Over heated (B5204T5; B5254T4) CEM - 1C07 Alternator control module (ACM). Over heated (B5244S) CEM - 1C07 Alternator control module (ACM). Over heated (B5244T5; B5254T2) CEM - 1C08 Alternator control module (ACM). Mechanical fault (B5204T5; B5254T4) CEM - 1C08 Alternator control module (ACM). Mechanical fault (B5244S) CEM - 1C08 Alternator control module (ACM). Mechanical fault (B5244T5; B5254T2) CEM - 1C0A Alternator control module (ACM). Voltage too high (B5204T5; B5254T4) CEM - 1C0A Alternator control module (ACM). Voltage too high (B5244S) CEM - 1C0A Alternator control module (ACM). Voltage too high (B5244T5; B5254T2) CEM - 1D01 Control module. Internal fault CEM - 1D02 Control module. Internal fault CEM - 1D03 Control module not fully programmed. Internal fault CEM - 1D06 Control module. Configuration fault CEM - 1D07 Control module. Internal fault CEM - 1D08 Control module. Internal fault CEM - 1D09 Control module. Internal fault CEM - 1D0A Control module. Internal fault CEM - 1D0B Control module. Internal fault CEM - 1F00 ECM, software. Faulty signal CEM - 1F01 TCM, software. Faulty signal CEM - 3F02 Shift lock signal. Signal too high CEM - 3F03 Shift lock signal. Signal too low CEM - 3F81 Immobilizer signal. Signal too high CEM - 3F82 Immobilizer signal. Signal too low CEM - 3F83 Immobilizer signal. Signal too low CEM - 3F84 Immobilizer signal. Faulty signal CEM - 3F90 Fuel pump relay. Open-circuit or short-circuit to ground CEM - 3F91 Fuel pump relay. Short-circuit to supply voltage CEM - 4A31 Ejector sensor. Faulty signal CEM - 4A33 Fuel level sensor. Short-circuit to supply voltage or open-circuit

CEM - 4A34 Fuel level sensor. Short-circuit to ground CEM - 4A35 Fuel level sensor. Faulty signal CEM - 4A37 Fuel level sensor. Short-circuit to supply voltage or open-circuit CEM - 4A38 Fuel level sensor. Short-circuit to ground CEM - 4F00 Reset button. Activated too long CEM - 4F01 Read button. Activated too long CEM - 4F41 Light emitting diode, left camera module. Signal too low CEM - 4F42 Light emitting diode, right camera module. Signal too low CEM - 4F43 Light emitting diode, left camera module. Signal too high CEM - 4F44 Light emitting diode, right camera module. Signal too high CEM - 4F45 Light emitting diode, left camera module. No signal CEM - 4F46 Light emitting diode, right camera module. No signal CEM - 4F47 Left camera module. Internal fault CEM - 4F48 Right camera module (RCM). Internal fault CEM - 4F90 Seat belt reminder. Signal too high CEM - 4F91 Seat belt reminder. Signal too low CEM-4F92 Seat belt reminder. Signal missing CEM-4F93 Seat belt reminder. Faulty signal CEM-5A00 Sun sensor. Signal too high CEM-5A01 Sun sensor. Signal too low CEM-5F31 Coolant temperature sensor Open circuit or short circuit to supply CEM-5F32 Coolant temperature sensor Short circuit to ground CEM-5F36 Flame sensor Short circuit to ground CEM-5F37 Factory set diagnostic trouble code (DTC). Faulty code CEM-5F39 Flame sensor Flame interuption CEM-5F3A Water pump. Signal too high CEM-5F3B Water pump. Signal too low CEM-5F3C Combustion fan. Signal too high CEM-5F3D Combustion fan. Signal too low CEM-5F3E Combustion fan. Faulty signal CEM-5F3F Fuel pump (FP). Signal too high CEM-5F40 Fuel pump (FP). Signal too low CEM-5F41 Overheat protection thermostat. Signal too low CEM-5F42 Power supply. Faulty CEM-5F43 Power supply. Missing CEM-5F46 Glow plugs. Faulty signal CEM-5F47 Control module power supply. Signal too high CEM-5F4C Power supply. Signal too low CEM-5F4D On-board diagnostic (OBD) system. Too long time CEM-5F4F Start attempt. Too many unsuccessful attempts CEM-5F50 Overheat protection thermostat. Signal too high CEM 6C41
