Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. Maintenance Alhambra 2011 ➤ Alhambra 2016 ➤ Edition 10.2022 Service Service Department. Technical Information

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. Maintenance Heading 1. Technical data of the engines 2. Longlife service and time or mileage dependent service 3. Service tables 4. General information 5. Description of work 6. 00 PTI - Periodic Technical Inspection 7. Glossary 8. ---Change history--- Technical information should always be available to the foremen and mechanics, because their careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a matter of course, be observed. Service All rights reserved. No reproduction without prior agreement from publisher. Copyright © 2022 Seat S.A D3E80458080

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. Contents 1 Technical data of the engines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 Longlife service and time or mileage dependent service . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2.1 Service identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2.2 Extended service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 2.3 Time or distance dependent service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 3 Service tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 3.1 Service work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 3.2 Countries with high dust content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 3.3 Countries with petrol fuels not compliant with EN 228 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 3.4 Countries with diesel fuels not compliant with EN 590/EN 15940 . . . . . . . . . . . . . . . . . . . . 25 3.5 Countries with hot climate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 3.6 Difficult operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 3.7 Multi-purpose additive for diesel fuel: adding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 3.8 Multi-purpose additive for petrol fuels: add . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 3.9 Shortened intervals for spark plug replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 4 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 4.1 Raising vehicle with lifting platform or trolley jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 4.2 Stickers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 4.3 Connecting vehicle diagnostic tester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 4.4 Vehicle identification number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 4.5 Vehicle data sticker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 4.6 Engine code and engine number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 4.7 Type plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 5 Description of work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 5.1 Swivel joints, axle mountings, coupling rod bearings and anti-roll bar rubber mounting: inspecting for damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 5.2 Driving light assist and cornering light: checking function . . . . . . . . . . . . . . . . . . . . . . . . . . 46 5.3 Battery: checking battery terminal clamps for secure seating . . . . . . . . . . . . . . . . . . . . . . 48 5.4 Check battery with the battery tester VAS 6161 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 5.5 Battery status: Read off and send the diagnosis protocol online. . . . . . . . . . . . . . . . . . . . . 51 5.6 Charging battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 5.7 Tyres: checking condition, wear pattern, tyre pressure, tread depth and age of tyres . . . . 51 5.8 Front passenger front airbag: checking key switch and “On/Off function” . . . . . . . . . . . . . . 59 5.9 Brake system and shock absorbers: Perform visual check for leaks and damage . . . . . . 61 5.10 Brake and clutch system: change brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 5.11 Checking brake fluid level (dependent upon brake pad/lining wear) . . . . . . . . . . . . . . . . . . 68 5.12 Brakes, front and rear: checking thickness of brake pads and condition of brake discs . . 69 5.13 Diesel particulate filter: checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 5.14 Window regulators: Check positioning (open and close functions) . . . . . . . . . . . . . . . . . . 72 5.15 Read event memories of all systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 5.16 Bonnet catch hook: grease. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73 5.17 Gearbox, final drive and drive shaft boots: inspect for leaks and damage. . . . . . . . . . . . . 73 5.18 Body inside and outside: checking while doors, bonnet and boot/tailgate are open . . . . . . 74 5.19 Ribbed belt: check condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 5.20 Renewing diesel fuel filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 5.21 Cooling system: Checking frost protection and coolant level . . . . . . . . . . . . . . . . . . . . . . . . 78 5.22 Air filter: Clean air filter housing and renew filter element . . . . . . . . . . . . . . . . . . . . . . . . . . 81 5.23 Checking engine oil level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 5.24 Engine oil: draining or extracting, renewing oil filter and replenishing engine oil . . . . . . . . 87 5.25 Engine oil: capacities and specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99 5.26 Removing and installing engine cover and design panel . . . . . . . . . . . . . . . . . . . . . . . . . . 102 5.27 Removing and installing lower insulation tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 Contents i

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. 5.28 Engine and components in engine compartment: inspecting for leaks and damage (from above and below) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 5.29 Panoramic sliding sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106 5.30 Sliding sunroof drains at front: check for blockage, clean if necessary . . . . . . . . . . . . . . . . 112 5.31 Water drain valves at rear: check for blockage, clean if necessary . . . . . . . . . . . . . . . . . . 113 5.32 Road test: performing (driving behaviour, noises, air conditioner etc.) . . . . . . . . . . . . . . . . 114 5.33 Wheel securing bolts: tighten to specified torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114 5.34 Replenish the reducing agent (AdBlue®) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117 5.35 Replace the reducing agent (AdBlue®) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121 5.36 Assign the station buttons of the radio or radio navigation system with the local radio stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121 5.37 Tyre pressure monitoring: performing basic setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122 5.38 Checking tyre repair set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123 5.39 Headlight adjustment: checking halogen headlights and fog lights, adjusting if necessary . . 124 5.40 Headlight adjustment: Checking gas discharge headlights without DLA, adjusting if necessary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129 5.41 Headlight adjustment: checking gas discharge headlights with DLA, adjusting if necessary . . 134 5.42 Sliding sunroof drains: checking for blockage, cleaning if necessary . . . . . . . . . . . . . . . . 138 5.43 Window wash/wipe system and headlight washer system: Checking function and for damage, if necessary replenishing fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139 5.44 Resetting service interval display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143 5.45 Recoding service interval display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147 5.46 Track rods, steering system: checking clearance, attachment and boots . . . . . . . . . . . . . . 149 5.47 Auxiliary heater: setting weekday in menu of dash panel insert . . . . . . . . . . . . . . . . . . . . . . 149 5.48 Dust and pollen filter: Cleaning housing and renewing filter element . . . . . . . . . . . . . . . . . . 151 5.49 Transport mode: deactivate using vehicle diagnostic tester . . . . . . . . . . . . . . . . . . . . . . . . 152 5.50 Transportation devices: remove blocking pieces from front axle springs . . . . . . . . . . . . . . 152 5.51 Transportation devices: removing tie-down rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153 5.52 Door arrester: grease . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155 5.53 Setting clock and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156 5.54 Underbody: inspecting for damage to underbody sealant, underbody panels, routing of lines, plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158 5.55 Camshaft drive toothed belt: renewing (diesel engines) . . . . . . . . . . . . . . . . . . . . . . . . . . 158 5.56 Renewing spark plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158 5.57 6-speed dual clutch gearbox 02E: changing the gear oil and filter . . . . . . . . . . . . . . . . . . . . 169 5.58 7-speed dual clutch gearbox 0BH: changing gear oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170 5.59 All-wheel drive coupling: changing oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170 5.60 Warning triangle: checking availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175 5.61 First aid kit: check and make a note of the expiry date . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175 5.62 Seat belts: Check the completeness of the rivets and locking device of the automatic belt retractors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175 5.63 Vehicle tool kit: Check the completeness of the components relevant in the event of a breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176 5.64 Full Link connection process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176 5.65 All switches, electrical consumers, sockets, gauges and other control elements: Check function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177 5.66 Air conditioning: Set temperature to 22 °C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177 5.67 Assign the station buttons of the radio or radio navigation system with the local radio stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178 5.68 Tasks to be completed on the vehicle interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178 5.69 Tasks to be completed on the vehicle exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179 5.70 Vehicle keys: checking function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 5.71 Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184 5.72 Set the language of the driver information in vehicles with multi-function display . . . . . . . . 185 5.73 Configure and check the Bluetooth connection between the customer's mobile telephone and the vehicle's hand-free system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185 5.74 Battery - connect stationary battery charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185 5.75 Exhaust emissions test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187 Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 ii Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. 6 00 PTI - Periodic Technical Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193 7 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197 8 ---Change history--- . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 Contents iii

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 iv Contents

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. 1 Technical data of the engines (EIGG000592; Edition 10.2022) This chapter contains information about the following topics: ♦ Petrol engines ⇒ page 1 ♦ Diesel engines ⇒ page 2 Note To ease the search for an engine, the engine codes are listed in alphabetical order. Petrol engines Engines ⇒ Petrol engine Petrol engine Petrol engine Petrol engine Petrol engine Dis‐ place‐ ment I 1.4 2.0 1.8 2.0 1.4 Engine code CAVA CCZA CDAA CHHB CNWB No. of cylinders / valves per cylinder 4/4 4/4 4/4 4/4 4/4 Power kW at rpm 110/5800 147/5100-6000 118/4500 to 6200 162/4500 to 6200 110/5800 Torque Nm at rpm 240/1500 to 4000 280/1700 to 5000 250/1500-4500 350/1500 to 4400 240/1500 to 4000 Cylinder bore ∅ mm 76.5 82.5 82.5 82.5 76.5 Stroke mm 75.6 92.8 84.2 92.8 75.6 Compression 10.0 9.8 9.6 9.6 10.0 Injection/ignition Motronic MED 17.05.10 TSI twincharger Motronic MED 17.5 TSI turbocharg‐ er Motronic MED 17.5 TSI turbocharg‐ er Motronic SI‐ MOS TSI turbo‐ charger Motronic MED 17.05.10 TSI twincharg‐ er ROZ unlea‐ ded, min 95 95 95 95 95 Petrol engine par‐ ticulate filter no no no no no Belt-driven starter- alternator no no no no no Camshaft drive Chain Chain Chain Chain Chain En‐ gines ⇒ Petrol engine Petrol engine Petrol engine Petrol engine Dis‐ place‐ ment I 1.4 1.4 2.0 1.4 Engine code CTHA CZDA DEDA DJKA No. of cylinders / valves per cylinder 4/4 4/4 4/4 4/4 Power kW at rpm 110/5800 110/5000-6000 162/4500 to 6200 110/5000 Torque Nm at rpm 240/1750 to 4000 250/1500-3500 350/1500 to 4400 250/1500 to 4000 Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 1. Technical data of the engines 1

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. En‐ gines ⇒ Petrol engine Petrol engine Petrol engine Petrol engine Dis‐ place‐ ment I 1.4 1.4 2.0 1.4 Engine code CTHA CZDA DEDA DJKA Cylin‐ der bore ∅ mm 76.5 74.5 82.5 74.5 Stroke mm 75.6 80.0 92.8 80.0 Compression 9.7 10.0 9.6 10.5 Injection/ignition Motronic MED 17.05 TSI twincharger Motronic MED 17.05.10 TSI twincharger Motronic SIMOS TSI turbocharger Motronic MED 17.1.27 TSI turbocharger ROZ unleaded, min 95 95 (in exceptional cir‐ cumstances at least 91 RON, but with re‐ duced output) 95 95 (in exceptional cir‐ cumstances at least 91 RON, but with reduced out‐ put) Petrol engine par‐ ticulate filter no no no yes Belt-driven starter- alternator no no no no Camshaft drive Chain Notched belt Chain Notched belt Diesel engines Engines ⇒ Diesel engine Diesel engine Diesel engine Diesel engine Diesel engine Displace‐ ment I 2.0 2.0 2.0 2.0 2.0 Engine code CFFA CFFB CFFE CFGB CFGC No. of cylinders / valves per cylinder 4/4 4/4 4/4 4/4 4/4 Power kW at rpm 100/4200 103/4000 85/4200 125/4200 130/4200 Torque Nm at rpm 320/1750 to 2500 320/1750 to 2500 280/1750 to 2500 350/1750 to 2500 380/1750 to 2500 Cylinder bore ∅ mm 81.0 81.0 81.0 81.0 81.0 Stroke mm 95.5 95.5 95.5 95.5 95.5 Compression 16.0 16.5 16.0 16.0 16.0 Injection/ignition TDI common rail TDI common rail TDI common rail TDI common rail TDI common rail Diesel particulate filter (DPF) yes yes yes yes yes Belt-driven starter- alternator no no no no no Camshaft drive Notched belt Notched belt Notched belt Notched belt Notched belt Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 2 1. Technical data of the engines

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. Engines ⇒ Diesel engine Diesel engine Diesel engine Diesel engine Diesel engine Displace‐ ment I 2.0 2.0 2.0 2.0 2.0 Engine code CUVA CUVC CUWA DFLA DFLD No. of cylinders / valves per cylinder 4/4 4/4 4/4 4/4 4/4 Power kW at rpm 85/3500 110/3500 135/3500 to 4000 110/3500 to 4000 85/3500 to 4000 Torque Nm at rpm 280/1750-3000 340/1750-3000 380/1750-3000 340/1750-3000 280/1750-3000 Cylinder bore ∅ mm 81.0 81.0 81.0 81.0 81.0 Stroke mm 95.5 95.5 95.5 95.5 95.5 Compression 16.2 16.2 15.8 16.2 16.2 Injection/ignition TDI common rail TDI common rail TDI common rail TDI common rail TDI common rail Diesel particulate filter (DPF) yes yes yes yes yes Belt-driven starter- alternator no no no no no Camshaft drive Notched belt Notched belt Notched belt Notched belt Notched belt Engines ⇒ Diesel engine Diesel engine Diesel engine Diesel engine Displace‐ ment I 2.0 2.0 2.0 2.0 Engine code DFMA DLTA DLTC DLUB No. of cylinders / valves per cylinder 4/4 4/4 4/4 4/4 Power kW at rpm 135/3500 to 4000 110/3500 85/3500 130/3500 to 4000 Torque Nm at rpm 380/1750-3000 340/1750-3000 280/1750-3000 380/1750 to 2500 Cylinder bore ∅ mm 81.0 81.0 81.0 81.0 Stroke mm 95.5 95.5 95.5 95.5 Compression 15.8 16.2 16.2 15.8 Injection/ignition TDI common rail TDI common rail TDI common rail TDI common rail Diesel particulate filter (DPF) yes yes yes yes Belt-driven starter- alternator no no no no Camshaft drive Notched belt Notched belt Notched belt Notched belt Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 1. Technical data of the engines 3

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A. 2 Longlife service and time or mileage dependent service ⇒ i2.1 dentification”, page 4 ⇒ s2.2 ervice”, page 4 . ⇒ o2.3 r distance dependent service”, page 5 . 2.1 Service identification Service identification for all vehicles using the PR number: – The service intervals depend on the following PR numbers: Model year Fixed service inter‐ vals Flexible service in‐ tervals Up to MY 12 (week 21.2012) PR QG0 / QG2 / QG3 PR QG1 From MY 13 (KW 22.2012) PR QI1 / QI2 / QI3 / QI4 / QI7 PR QI6 – Check the vehicle PR no. on the vehicle data sticker ⇒ page 40 . Up to MY 12 (week 21.2012) Note ♦ Vehicles with PR number “QG1” are equipped with activated Longlife Service (flexible service intervals) ex-factory, it is however possible, to modify the programming to time or dis‐ tance dependent service (fixed service interval). ♦ Vehicles with PR numbers “QG0”, “QG2” or “QG3” are equipped with time or distance dependent intervals (fixed service intervals) ex-factory. It is not possible to modify the programming with these vehicles. From MY 13 (KW 22.2012) Note ♦ Vehicles with PR number “QI6” are equipped with activated Longlife Service (flexible service intervals) ex-factory, it is however possible, to modify the programming to time or dis‐ tance dependent service (fixed service interval). ♦ Vehicles with PR numbers “QI1”, “QI2”, “QI3”, “QI4” or “QI7” are equipped with time or distance dependent intervals (fixed service intervals) ex-factory. It is not possible to modi‐ fy the programming with these vehicles. 2.2 Extended service The LongLife service enables long service intervals, depending on individual driving style and the conditions under which the vehicle is used. Alhambra 2011 ➤, Alhambra 2016 ➤ Maintenance - Edition 10.2022 4 2. Longlife service and time or mileage dependent service
