VECTRA VECTRA Operation, Safety and Maintenance Owner’s Manual

VAUXHALL Vectra Operation, Safety, Maintenance

Data specific to your vehicle Please enter your vehicle’s data here to keep it easily accessible. This information is available under the section "Technical data" as well as on the identification plate and in the Service Booklet. Fuel Designation Engine oil Grade Viscosity Tyre pressure Tyre size with up to 3 people with full load Summer tyres Front Rear Front Rear Winter tyres Front Rear Front Rear Weights Permissible Gross Vehicle Weight – EC kerbweight = Loading

Your Vectra is an intelligent combination of forward- looking technology, impressive safety, environmental friendliness and economy. It now lies with you to drive your vehicle safely and ensure that it performs perfectly. This Owner’s Manual provides you with all the necessary information to that end. Make sure your passengers are aware of the possible risk of accident and injury which may result from improper use of the ve hic le . You must always comply with the specific laws of the country that you are travelling through. These laws may differ from the information in this Owner’s Manual. When instructed to consult a workshop, we recommend that you consult your Vauxhall Authorised Repairer. All Vauxhall Authorised Repairers provide first-class service at reasonable prices. You will receive quick, reliable and individual service. Experienced mechanics, trained by Vauxhall, work according to specific Vauxhall instructions. The Owner’s Manual should always be kept in the vehicle: Ready to hand in the glove compartment. Make use of the Owner’s Manual: z The "In brief" section will give you an initial overview. z The table of contents at the beginning of the Owner’s Manual and within the individual chapters will show you where everything is. z Its index will help you find what you want. z It will familiarise you with the sophisticated technology. z It will increase your pleasure in your vehicle. z It will help you to handle your vehicle expertly. The Owner’s Manual is designed to be clearly laid-out and easily understood. This symbol signifies: 6 Continue reading on next page. 3 The asterisk signifies equipment not fitted to all vehicles (model variants, engine options, models specific to one country, optional equipment, Genuine Vauxhall Parts and Accessories). Yellow arrows in the illustrations serve as points of reference or indicate some action to be performed. Black arrows in the illustrations indicate a reaction or a second action to be performed. Directional data, e.g. left or right, or front or back, in the descriptions always relate to the direction of travel. Thank you for choosing a Vauxhall. We wish you many hours of pleasurable driving. Your Vauxhall Team 9 Wa rn ing Text marked 9 Warning provides information on risk of accident or injury. Disregard of the instructions may lead to injuries or endanger life. Inform your passengers accordingly.

Contents Commitment to customer satisfaction: Our ai m: to keep you happy with your vehicle. All Vauxhall Authorised Repairers offer first-class service at competitive prices. Experienced, factory-trained technicians work according to factory instructions. Your Authorised Repairer can supply you with GENUINE VAUXHALL- APPROVED PARTS, which have undergone stringent quality and precision checks, and of course useful and attractive VAUXHALL-APPROVED ACCESSORIES. Our name is your guarantee! For d eta ils of the Vauxhall Authorised Repairer Network, please ring this number; 0845 090 2044 In brief .. ..... .... ..... .... .... ..... .... ..... .... ..... .... .... . 2 Keys, doors, windows, sunroof ... ..... .... .. 26 Seats, interior ..... .... .... ..... .... ..... .... ..... .... .. 50 Instruments, controls . ..... .... ..... .... ..... .... .. 98 Lighting ..... .... ..... .... .... ..... .... ..... .... ..... .... 128 Infotainment system . ..... .... ..... .... ..... .... 137 Climate control .. .... .... ..... .... ..... .... ..... .... 140 Driving and operation ... .... ..... .... ..... .... 168 Self-help, vehicle care .... .... ..... .... ..... .... 228 Service, maintenance ..... .... ..... .... ..... .... 268 Technical data .. .... .... ..... .... ..... .... ..... .... 282 Index . .... ..... .... ..... .... .... ..... .... ..... .... ..... .... 314

2 In brief In brief To unlock and open vehicle: Press button q, pull door handle 6 Door locks, child safety locks – see page 41, keys – see page 26, electronic immobiliser – see page 27, remote control – see page 28, central locking – see p age 30, mechanical anti-theft locking system 3 – see p age 30, Vauxhall alarm system 3 – see page 38. To unlock and open the luggage compartment: Press button q on remote control, press button on boot lid/tailgate and for Estate, pull catch under handle 6 Remote control – see page 28, central locking – see page 30, Vauxhall alarm system 3 – see page 38, electrically operated tailgate 3 – see page 35.

3 In brief To adjust front seats: Pull handle, slide seat, release handle 6 Seats – see page 50, seat position – see page 52, electrically adjustable front seats – see page 52. To adjust front seat backrests: Turn handwheel Move seat backrest to suit seating position. Do not lean on seat backrest whilst adjusting it. 6 Seats – see page 50, seat position – see page 52, folding down front passenger’s seat backrest – see page 66, electrically adjustable front seats – see p age 52. To adjust front seat height 3 : Operate lever on outboard side of seat Pump action of lever 6 Seats – see page 50, seat position –see page 52, electrically adjustable front seats – see page 52. 9 Warning Important: Do not sit nearer than 10 inches (25 cm) from the steering wheel, to permit safe airbag deployment. Upwards: Seat higher Downwards: Seat lower

4 In brief Adjusting front seat inclination 3: Operate front lever on outboard side of seat Pump action of lever 6 Seats – see page 50, seat position – see page 52, electrically adjustable front seats – see page 52. Electric seat adjustment 3 : Operate switch on outboard side of seat 6 Seats – see page 52, seat position – see page 52, electrically adjustable front seats – see p age 52. To adjust head restraint height 3 of front and outboard rear seats: Press button to release, adjust height, engage in position 6 Head restraints – see page 55, head restraint position – see page 56, rear head restraints – see page 55. Upwards: Seat steeper Downwards: Seat flatter 1 Adjusting the longitudinal position 2 Adjusting the inclination 3 Height adjustment 4 Seat backrest adjustment 5 Lumbar support 3

5 In brief To adjust head restraint angle 3 of front and outboard rear seats: Swivel bottom edge of head restraint forwards or backwards 6 Head restraints – see page 55, head restraint position – see page 56, rear head restraints – see page 55. To apply seat belt: Pull out seat belt smoothly from inertia reel, guide it over the shoulder and engage in the belt buckle The seat belt must not be twisted at any point. The lap belt must lie snugly against the body. The backrests must not be tilted back too far (recommended maximum tilting angle approx. 25°). To release belt, press red button on belt buckle. 6 Three-point seat belts – see page 72, airbag systems 3 – see page 81, seat position – see page 52. Adjusting interior mirror: Swivel mirror housing Swivel lever on underside of mirror housing to reduce dazzle at night. 6 Mirror – see page 44, automatic anti-dazzle interior mirror 3 – see page 44.
