21 To open the panoramic glass roof sheeting move forward from any position behind. In its most forward position lining locks (Figure 1.33). NOTE You move the ceiling sheathing fold sun visors up. Sunroof Fig. 1.34. Keys hatch on the roof Luc control keys on the console on the roof (Figure 1.34). For the gradual movement of the hatch, press the button briefly. To automatically open or close hold them pressed. Lifting the hatch. In the closed hatch, press , Hatch rear its rear. Opening the hatch. In the raised position to re-press , The hatch is fully open. Closing the hatch. Press . Because of the open hatch closed, for security reasons do not reach 20 cm to the end. to completely close it, hold the key pressed. Sun blinds Sun blinds designed to ensure that the sun's rays do not penetrate into the salon with a closed sliding hatch. When you open the hatch opens and sun blinds. Opening curtains. Press , Shutter is fully open. Closing the curtain. Press , Shutter is fully closed. From the open position shutter is closed for security reasons, do not reach 20 cm to the end. For a complete closing of the shutter, press and hold . NOTE With the luggage on the roof, to avoid damage, make sure you have enough space to move the sliding hatch. If a sliding sunroof and sun blinds do not work, you must activate the electronic system. To do this, turn on the ignition, close the sliding hatch and hold down at least 10 seconds. Close the sun blinds and hold down at least 10 seconds.

22 1.2. Controls and combination devices Combination of devices and light detectors Failure tell-tale oil level Failure tell-tale oil pressure in the engine. This alarm warns the driver of low pressure in the lubricating system of engine. Indicator lights up when you turn the ignition switch in position «ON» ( «Ignition included) and goes out after starting the engine. NOTICE Do not work the engine when the oil pressure drop detectors. This can lead to engine failure. Need to check serviceability of sensors, pressure drop of oil in the engine every time you turn the ignition. In case of sensors fail, you will not receive a timely message about the fall of oil pressure and engine may be damaged. If the indicator does not light up when you turn the ignition, do not run the engine. Refer to the service station official Opel dealer for inspection and repair signaling. If the indicator light up on the run the car, follow these steps. 1. Observing precautions immediately turn over to the side or to the edge of the roadway and stop on a horizontal platform. 2. Stop the engine and wait 5 minutes, to glass in motor oil sump. 3. Check the oil level in the engine. If the oil level is below normal, top up the oil and bring its level back to normal. Control lamp sensors malfunction of the braking system / indicator applying the parking brake Indicator lights up when the parking brake, if the ignition switch is in position «START» ( «starter) or« ON »(« Ignition inclusive). Indicator goes out with complete exclusion of the parking brake. Fig. 1.37. Control lamp sensors malfunction of the braking system / indicator applying the parking brake Failure tell-tale levels of brake fluid If the alarm continues to burn after a full off the parking brake, a possible cause of a malfunction of the braking system. Observing precautions immediately turn over to the side or to the edge of the roadway and stop. You may notice that the brake pedal or turn increased (pedal dropped to the floor). In both cases, the vehicle braking distance increases. Check the brake fluid. If necessary, top up the brake fluid and bringing its level to normal. After topping up the brake fluid, check whether the burn continues to alarm. If the alarm continues to burn or there are signs of malfunction of the braking system, further movement of the car is prohibited.

23 NOTE The need for topping up the brake fluid can sometimes be a consequence of its leakage. Therefore, immediately refer to the service station official Opel dealer to check the functioning of the braking system, even if the indicator is not lit. NOTICE It is dangerous to operate the vehicle, if the fire alarm malfunction of the braking system. This indicates that the braking system of your car can not work or refuse at any time. If the alarm continues to burn, then after checking off the parking brake should immediately check the status of the braking system. NOTE On vehicles with Easytronic transmission in nezatyanutom parking brake indicator light flashes for a few seconds after the ignition is turned off. Alarm stoppers locks belt / cignalizator airbag system Stoppers locks of safety belts, along with systems airbags are controlled by electronic system, and indication of their operation is carried out by an indicator on the dashboard. When you turn the ignition indicator lights up for about 4 seconds. If it does not burn, does not go out at 4 with lights or in traffic, so there was fault in the system of locks stoppers belts or airbags systems. Stoppers locks belts or air-bags may fail during an accident. Airbag systems, together with a system of identification of employment and lockable seat belt locks are controlled by electronic system, which is an indicator of the alarm on the dashboard. When you turn the ignition indicator light is about 4 seconds. If he does not light up or do not go out after 4 s, or burns on the road, so there was fault in the systems of airbags, seat recognition system of employment or pinning system locks of safety belts. The systems can fail in a traffic accident. Fig. 1.38. Alarm stoppers locks belt / cignalizator airbag system NOTICE It is strictly forbidden to interfere in the construction of their own system of airbags or seatbelt pretensioners. All work on the maintenance and repair of these systems must be carried out at the service station official dealer Opel. Self-repair, maintenance or intervention in the design of a danger. Bag or seat belt retractors may accidentally trigger or lead to failure. This can lead to serious injuries of people. Electronic alarm system dynamic stability ESR system if necessary, improves the stability of the vehicle and prevents stalling of the driving wheels regardless of the condition of pavement and tire in any road conditions. If you notice the danger of skidding vehicle (insufficient or too dramatic impact on the government) engine power is reduced (changing the engine noise) and individual wheels purposefully disinhibited. Thus significantly improving the stability of the car, especially in the snow and ice, as well as on wet or slippery road.

24 Indicator is lit after ignition for a few seconds. After that the system is ready to work. Blinking during movement indicates actuation system. Engine power is somewhat reduced (changing the engine noise), and the car automatically slows down. If the indicator is lit during motion - means the system is off or malfunctioning. You can continue to travel, but the sustainability of progress may deteriorate depending on the condition of the road. Turn the ESR system or fix the problem. Fig. 1.39. Electronic alarm system dynamic stability Interactive Dynamic Driving System (IDS + - Interactive Driving System) IDS + system combines sensors and control devices of electronic stabilization program (ESR), Antilock braking system (ABS) and electronic dynamic control shock absorbers (CDC). This achieves a pronounced dynamics of the movement while improving safety. (CDC – Continuous Damping Control) Electronic dynamic control shock absorbers (CDC - Continuous Damping Control) CDC coordinates the system stiffness of the suspension of the car with traffic conditions and characteristics of road surface. The system continuously monitors the movement of the wheels and the car and immediately change the rigidity of each shock absorber. This ensures optimum alignment of the chassis with traffic conditions and the properties of road surface. When the sport mode suspension control system adjusts for a more sporty driving style (more "stiff" suspension). Light and sound detectors-belt safety Safety belt reminder alarm fire if ignition switch is turned to position «ON» ( «Ignition inclusive) and the driver's belt is not fastened. Alarm car door closure Indicator lights up when one of the doors (including rear luggage compartment door) is open or not closed tightly. Battery discharge indicator Indicator lights up when you turn the ignition switch in position «ON» ( «Ignition included) and goes out after starting the engine. If the indicator light up on the run the car - this is a malfunction of the electric generator or the power system. Observing precautions immediately turn over to the side or to the edge of the roadway and stop. NOTICE If the light is the battery level indicator, then further movement of the car is prohibited, because in this case, the engine can suddenly die out.

25 Failure tell-tale levels of coolant If the indicator light up when the engine is running, stop and turn off the engine. Too high temperature of the coolant is hazardous and can cause damage to the powertrain. Check the coolant and top up if necessary. Detector electronics of the vehicle (engine and gearbox) Indicator lights for a few seconds after ignition. Illuminated sensors with the engine running indicates a malfunction in the electronic system of the engine or gearbox. Electronic switches to emergency mode. This can increase fuel consumption and can deteriorate driving characteristics. In some cases the problem can be eliminated by turning off and restart the engine. If the indicator lights when the engine is running, you should seek help at the service station. Short-term single lamp ignition signaling does not matter. Illuminated sensors can also indicate the presence of water in diesel fuel filter, while at the service of information indicating the display the corresponding text message. In this case, check the fuel filter on the presence of residual water. Flashing signaling device when the ignition is a malfunction in the system start the engine block. In this case, start the engine is impossible. Under these conditions, the system checks whether you can crank the engine used by the key. Start the engine is possible, if the key is recognized by the system as "permitted". Verification is carried out using the built-in key transponder. Electronic lock engine start automatically after extracting the key from the ignition. Try again to turn off and turn on the ignition. If the indicator continues to flash, try to start the engine, spare keys, or ask for help at service stations. NOTE Detector can also be illuminated in case of failure of transmission Easytronic. For serious faults on the transmission indicator extra icon appears . Continue the movement is possible, if only the indicator lights . This is not to switch to manual mode. If the indicator gear icon appears in addition , Continued travel is impossible. Eliminate the problem or ask for help at service stations. Fig. 1.40. Detector electronics of the vehicle (engine and gearbox) Interruption of power Alarm will also burn if there are problems with power supply. NOTICE When a discharged battery and included the transfer clutch is not dropped. Driving a car is impossible. In the case of discharge of the battery, follow the procedure support the launch.
