0108G-09 N17080 Filler Cap Float Reservoir Tank z Grommet Clip Slotted Spring Pin : Specified torque z Non-reusable part Cylinder Piston Push Rod Washer Snap Ring Boot z Gasket Lock Nut Clevis Pin Clevis N·m (kgf·cm, ft·lbf) 12 (120, 9) 15 (155, 11) - INTRODUCTION HOW TO USE THIS MANUAL 01-1 1 Author: Date: 2005 SIENNA REPAIR MANUAL (RM1163U) HOW TO USE THIS MANUAL GENERAL INFORMATION 1. GENERAL DESCRIPTION (a) This manual is made in accordance with SAE J2008. (b) Generally, repair operations can be separated in the following 3 main processes: 1. Diagnosis 2. Removing/Installing, Replacing, Disassembling/Reassembling, Checking and Adjusting 3. Final Inspection (c) This manual explains the 1st process of ”Diagnosis” (found in the ”Diagnostics” section), the 2nd pro- cess of ”Removing and Installing, Replacing, Disassembling, Installing and Checking, and Adjusting”, but the 3rd process of ”Final Inspection” is omitted. (d) The following essential operations are not written in this manual. However, these operations must be performed in actual situations. (1) Operations with a jack or lift (2) Cleaning of a removed part when necessary (3) Visual check 2. INDEX (a) An alphabetical INDEX section is provided at the end of the book as a reference to help you find the item to be repaired. 3. PREPARATION (a) Use of special service tools (SST) and special service materials (SSM) may be required, depending on the repair situation. Be sure to use SST and SSM when they are required and follow the working procedure properly. A list of SST and SSM is in the Preparation section of this manual. 4. REPAIR PROCEDURES (a) Component drawing is placed under the title where necessary. (b) Non-reusable parts, grease application area, precoated parts and tightening torque are specified in the component drawings. Example:
Illustration: what to do and where Component part No. Detailed text: how to perform task Task heading: what to do Set part No D31009 01-2 - INTRODUCTION HOW TO USE THIS MANUAL 2 Author: Date: 2005 SIENNA REPAIR MANUAL (RM1163U) (c) Tightening torque, grease application area, and non-reusable parts are described as important points in the procedures. NOTICE: There are cases where such information can only be explained by using an illustration. In these cases, all the information such as torque, oil, etc. are described in the illustration. (d) Installing procedures are performed in the reverse order of the removal and only the important points are described. (e) Only items with points are described in the procedure, and the operational portion and content are placed using an illustration. In the explanations, details of the operational method, standard value and notices are placed. (f) There may be a case where the illustrations of similar models are used. In that case, specific details may be different from the actual vehicle. (g) The procedures are presented in a step-by-step format: (1) The illustration shows what to do and where to do it. (2) The task heading tells what to do. (3) The explanation text tells how to perform the task and gives other information such as specifica- tions and warnings. Example: HINT: This format provides an experienced technician with a FAST TRACK to the necessary information. The task heading can be read at a glance when necessary and the text below provides detailed information. Important specifications and warnings are always written in bold type to stand out from the rest of the text. 5. SERVICE SPECIFICATIONS (a) Specifications are presented in bold type throughout the manual. You never have to leave the proce- dure to look up your specifications. The specifications are also found in the Service Specifications sec- tion for quick reference. 6. TERMS DEFINITION CAUTION Indicates the possibility of injury to you or other people. NOTICE Indicates the possibility of damage to the components being repaired. HINT Provides additional information to help you to perform the repair efficiently.
- INTRODUCTION HOW TO USE THIS MANUAL 01-3 3 Author: Date: 2005 SIENNA REPAIR MANUAL (RM1163U) 7. SI UNIT (a) The units given in this manual are primarily expressed according to the SI UNIT (International System of Units), and alternately expressed in the metric system and in the English System. Example: Torque: 30 N⋅m (310 kgf⋅cm, 22 ft⋅lbf)
The 2004 Toyota Sienna Service & Repair Manual is a comprehensive guide tailored for owners of the 2004 Toyota Sienna model. It offers detailed instructions and step-by-step procedures for servicing and repairing various vehicle components. This manual is valuable for both professional mechanics and DIY enthusiasts.
Owners can easily access essential information for maintaining their vehicle in top condition, including routine maintenance, troubleshooting, and major repairs. The manual covers detailed instructions for all maintenance procedures, step-by-step repair procedures for various components, wiring diagrams, electrical schematics, troubleshooting guides for common issues, and diagnostic codes with solutions.
Using this manual, owners can save time and money by conducting repairs and maintenance themselves, providing a cost-effective alternative to expensive dealership visits. It empowers owners to have full control over the care and maintenance of their vehicle, ensuring smooth and efficient operation.
Whether you are a seasoned mechanic or a DIY enthusiast, the 2004 Toyota Sienna Service & Repair Manual is an essential tool for keeping your Toyota Sienna in optimal condition.
Printable: Yes Language: English Compatibility: Pretty much any electronic device, incl. PC & Mac computers, Android and Apple smartphones & tablet, etc. Requirements: Adobe Reader (free)
Lifetime Access
