2000-2003 Toyota Corolla Service & Repair Manual

2002 DTC INDEX Corolla AIR BAG RESTRAINT DTCS (A00150677) AIR BAG RESTRAINT DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION NOTE: Retrieval of some diagnostic codes may require the use of special OEM tester or flash method using instrument cluster indicator. For procedures/testing of codes not shown below, refer to appropriate system article. DTC Description DTC B0100 SHORT IN DRIVER-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0101 OPEN IN DRIVER-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0102 DRIVER-SIDE AIR BAG SQUIB CIRCUIT SHORT TO GROUND DTC B0103 DRIVER-SIDE AIR BAG SQUIB CIRCUIT SHORT TO BATTERY DTC B0105 SHORT IN PASSENGER-SIDE AIR BAG SQUIB CIRCUIT DTC B0106 OPEN IN PASSENGER-SIDE AIR BAG SQUIB CIRCUIT DTC B0107 SHORT TO GROUND IN PASSENGER-SIDE AIR BAG SQUIB CIRCUIT DTC B0108 SHORT TO BATTERY IN PASSENGER-SIDE AIR BAG SQUIB CIRCUIT DTC B0110 SHORT IN RIGHT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0111 OPEN IN RIGHT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0112 SHORT TO GROUND IN RIGHT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0113 SHORT TO BATTERY IN RIGHT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0115 SHORT IN LEFT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0116 OPEN IN LEFT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0117 SHORT TO GROUND IN LEFT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0118 SHORT TO BATTERY IN LEFT-SIDE AIR BAG MODULE SQUIB CIRCUIT DTC B0130 SHORT IN PASSENGER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT 2002 DTC INDEX Corolla Bunker

AUTOMATIC TRANSMISSION DTCS (A00140973) AUTOMATIC TRANSMISSION DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION ENGINE PERFORMANCE DTCS (A00133205) DTC B0131 OPEN IN PASSENGER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT DTC B0132 SHORT TO GROUND IN PASSENGER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT DTC B0133 SHORT TO BATTERY IN PASSENGER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT DTC B0135 SHORT IN DRIVER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT DTC B0136 OPEN IN DRIVER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT DTC B0137 SHORT TO GROUND IN DRIVER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT DTC B0138 SHORT TO BATTERY IN DRIVER-SIDE SEAT BELT PRETENSIONER SQUIB CIRCUIT DTC B1100 AIR BAG SENSOR ASSEMBLY MALFUNCTION DTC B1140 RIGHT-SIDE AIR BAG SENSOR ASSEMBLY MALFUNCTION DTC B1141 LEFT-SIDE AIR BAG SENSOR ASSEMBLY MALFUNCTION DTC B1156 & B1157 RIGHT FRONT AIR BAG SENSOR MALFUNCTION DTC B1158 & B1159 LEFT FRONT AIR BAG SENSOR MALFUNCTION DTC Description P0500 Vehicle Speed Sensor P0750 No. 1 Solenoid (Perform appropriate solenoid test under COMPONENT TESTS) P0753 No. 1 Solenoid Circuit Malfunction P0755 No. 2 Solenoid (Perform appropriate solenoid test under COMPONENT TESTS) P0758 No. 2 Solenoid Circuit Malfunction P0770 Lock-Up Solenoid (Perform appropriate solenoid test under COMPONENT TESTS) P0773 Lock-Up Solenoid Circuit Malfunction P1520 Brakelight Switch Signal P1780 Park/Neutral Position Switch Malfunction 2002 DTC INDEX Corolla Bunker

ENGINE PERFORMANCE DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION DTC Description P0100 Mass Airflow Meter Circuit P0101 Mass Airflow Meter Circuit Range/Performance P0110 Intake Air Temperature Sensor Circuit P0115 Engine Coolant Temperature Sensor Circuit P0116 Engine Coolant Temperature Sensor Circuit Range/Performance P0120 Throttle Position (TP) Sensor Circuit P0121 Throttle Position (TP) Sensor Circuit Range/Performance P0125 Insufficient Coolant Temperature For Closed Loop Fuel Control P0128 Thermostat Malfunction P0130 Heated Oxygen Sensor No. 1 Circuit P0133 Heated Oxygen Sensor No. 1 Circuit Slow Response P0135 Heated Oxygen Sensor No. 1 Heater Circuit P0136 Heated Oxygen Sensor No. 2 Circuit P0141 Heated Oxygen Sensor No. 2 Heater Circuit P0171 System Too Lean P0172 System Too Rich P0300 Random Misfire Detected P0301 Cylinder No. 1 Misfire Detected P0302 Cylinder No. 2 Misfire Detected P0303 Cylinder No. 3 Misfire Detected P0304 Cylinder No. 4 Misfire Detected P0325 Knock Sensor Circuit P0335 Crankshaft Position Sensor Circuit P0340 Camshaft Position Sensor Circuit P0420 Catalyst System Efficiency Below Threshold P0440 Evaporative Emission Control System P0441 Incorrect EVAP Purge Flow P0442 Evaporative Emission Control System Leak Detected P0446 EVAP Vent Control Circuit P0450 EVAP Pressure Sensor Circuit P0451 EVAP Pressure Sensor Range/Performance P0500 Vehicle Speed Sensor Circuit P0505 Idle Air Control (IAC) System Circuit P1300 Ignitor No. 1 Circuit P1305 Ignitor No. 2 Circuit P1310 Ignitor No. 3 Circuit P1315 Ignitor No. 4 Circuit P1335 Crankshaft Position Sensor Circuit P1346 Variable Valve Timing Circuit Range/Performance P1349 Variable Valve Timing System Malfunction P1520 Stoplight Switch Signal Circuit (A/T Only) P1600 ECM BATT Circuit 2002 DTC INDEX Corolla Bunker

P1656 Oil Control Valve Malfunction P1780 Park/Neutral Position Switch Circuit (A/T Only) 2002 DTC INDEX Corolla Bunker

2002 SPECIFICATIONS INDEX Corolla SPECIFICATIONS INDEX COROLLA SPECIFICATIONS INDEX System Specification/Procedure Air Conditioning Service SPECIFICATIONS Torque TORQUE SPECIFICATIONS Axle Shaft/Bearing Lock Nut/Drive Axle Nut (Front) 166 ft.lbs (225 N.m) Axle Hub-To-Axle Carrier Bolts (Rear) 59 ft.lbs (80 N.m) Battery NA Brakes Bleeding Sequence BLEEDING BRAKE SYSTEM Disc & Drum Brakes DISC & DRUM BRAKE SPECIFICATIONS Torque TORQUE SPECIFICATIONS Charging Generator ON - VEHICLE INSPECTION Torque TORQUE SPECIFICATIONS Drive Belts Adjustment BELT ADJUSTMENT Belt Routing DRIVE BELT ROUTING Engine Cooling General Service Specifications COOLING SYSTEM SPECIFICATIONS Radiator Cap Pressure 10.7-14.9 psi (.75-1.05 kg/cm 2 ) Minimum opening pressure is 8.5 psi (.59 kg/cm 2 ) Thermostat R & I THERMOSTAT Water Pump R & I WATER PUMP Engine Mechanical Compression ENGINE COMPRESSION Oil Pressure At Idle Speed 4.3 psi (0.3 kg/cm 2 ) or more At 3,000 RPM 43-78 psi (3.0-5.5 kg/cm 2 ) Overhaul ENGINE SPECIFICATIONS Torque TORQUE SPECIFICATIONS Fluid Specifications See FLUIDS under MAINTENANCE tab. Flywheel/Flex Plate (Drive Plate) Torque A/T 61 ft.lbs (83 N.m) M/T Step 1) 36 ft.lbs (49 N.m) 2002 SPECIFICATIONS INDEX Corolla Bunker

Step 2) additional 90 degree turn Fuel System Pressure Specification 44-50 psi (3.1-3.5 kg/cm 2 ) Fuel Pressure Test Procedure CELICA, COROLLA, ECHO & MR2 Fuel Filter Location FUEL FILTER Ignition Firing Order & Cylinder Identification FIRING ORDER & CYLINDER IDENTIFICATION Ignition Wires (Resistance) HIGH TENSION WIRE RESISTANCE Ignition Wires (Routing) NA Spark Plug Type NGK No. IFR5A11 DENSO No. SK16R11 Gap .043 In. (1.10 mm) Torque 13 ft.lbs (18 N.m) Starting Starter STARTER SPECIFICATIONS Torque TORQUE SPECIFICATIONS Wheel Alignment Adjustment Specifications SPECIFICATIONS Torque Refer to applicable components under PROCEDURES . Wheel & Tire Wheel Lug Nut Torque 76 ft.lbs (103 N.m) 2002 SPECIFICATIONS INDEX Corolla Bunker

2002 ACCESSORIES & EQUIPMENT Body Electrical/Troubleshooting - Corolla BODY ELECTRICAL SYSTEM PRECAUTION 1. HEADLIGHT SYSTEM Halogen bulbs have pressurized gas inside and require special handling. They can burst if scratched or dropped. Hold a bulb only by its plastic or metal case. Don't touch the glass part of a bulb with bare hands. 2. SRS (SUPPLEMENTAL RESTRAINT SYSTEM) The COROLLA is equipped with an SRS (Supplemental Restraint System) such as the driver airbag and front passenger airbag. Failure to carry out service operation in the correct sequence could cause the SRS to unexpectedly deploy during servicing, possibly leading to a serious accident. Before servicing (including removal or installation of parts, inspection or replacement), be sure to read the precautionary notices in the RS section. 3. AUDIO SYSTEM If the negative (-) terminal cable is disconnected from the battery, the preset AM, FM 1 and FM 2 stations stored in memory are erased, so be sure to note the stations and reset them after the negative (-) terminal cable is reconnected to the battery. 4. MOBILE COMMUNICATION SYSTEM If the vehicle is equipped with a mobile communication system, refer to PRECAUTIONS . TROUBLESHOOTING PROBLEM SYMPTOMS Ignition Switch And Key Unlock Warning Switch IGNITION SWITCH & KEY UNLOCK WARNING SWITCH NOTE: Take care to observe the following precautions when performing inspections or removal and replacement of body electrical related parts. Symptom/Suspect Area See Ignition Switch Is Not Set To Each Position Ignition Switch (1) "Key Unlock Warning System" Does Not Operate GAUGE Fuse (2) Key Unlock Warning Switch (1) 2002 ACCESSORIES & EQUIPMENT Body Electrical/Troubleshooting - Corolla Bunker

Headlight System (Except Taiwan) HEADLIGHT SYSTEM (EXCEPT TAIWAN) Door Courtesy Switch (3) Integration Relay (I/P J/B) (1) Wire Harness ..... (1) INSPECTION (2) FUSES & CIRCUIT BREAKERS (3) INSPECTION Symptom/Suspect Area See Headlight Does Not Light. (Taillight Is Normal) Wire Harness ..... Headlight Does Not Light (Taillight Does Not Light Up) Wire Harness ..... Only One Side Light Does Not Light Headlight Bulb ..... Head (LH-LWR, RH-LWR) Fuse (E/G Room No. 5 J/B) (1) Wire Harness ..... "Lo-Beam" Does Not Light Headlight Bulb ..... Head (LH-1NR, RH-LWR) Fuse (E/G Room No. 5 J/B) (1) Headlight Control Relay (E/G Room No. 2 J/B) (2) Integration Relay (I/P J/B) (2) Light Control Switch (2) Wire Harness ..... "Hi-Beam" Does Not Light Headlight Bulb ..... Head (LH) Or Head (LH-UPR) Fuse (E/G Room No. 2 J/B) (1) Head (RH) Or Head (RH-UPR) Fuse (E/G Room No. 2 J/B) (1) DRL Fuse (E/G Room No. 5 R/B) (1) Headlight Dimmer Relay (E/G Room No. 5 J/B) (2) Daytime Running Light Relay (E/G Room No. 6 R/B) (2) Daytime Running Light Relay (Main) (2) Headlight Dimmer Switch (2) Wire Harness ..... "Flash" Does Not Light Headlight Bulb ..... Head (LH) Or Head (LH-UPR) Fuse (E/G Room No. 2 J/B) (1) Head (RH) Or Head (RH-UPR) Fuse (E/G Room No. 2 J/B) (1) 2002 ACCESSORIES & EQUIPMENT Body Electrical/Troubleshooting - Corolla Bunker

Headlight System (Taiwan) HEADLIGHT SYSTEM (TAIWAN) DRL Fuse (E/G Room No. 5 R/B) (1) Headlight Dimmer Relay (E/G Room No. 5 J/B) (2) Daytime Running Light Relay (E/G Room No. 6 R/B) (2) Daytime Running Light Relay (Main) (2) Headlight Dimmer Switch (2) Wire Harness ..... "Light-On Warning System" Does Not Operate GAUGE Fuse (I/P J/B) (1) DOME Fuse (E/G Room No. 2 JB) (1) Integration Relay (I/P J/B) (2) Door Courtesy Switch (Driver's) (3) Ignition Switch (4) Wire Harness ..... Headlight Does Not Light With Engine Running And Light Control SW In OFF Headlight Bulb ..... GAUGE Fuse (I/P J/B) (1) HEAD (LH) Or HEAD (LH-UPR) Fuse (E/G Room No. 2 J/B) (1) HEAD (RH) Or HEAD (RH-UPR) Fuse (E/G Room No. 2 J/B) (1) Daytime Running Light Relay (Main) (2) Wire Harness ..... Other Parts (5) (1) FUSES & CIRCUIT BREAKERS (2) INSPECTION (3) INSPECTION (4) INSPECTION (5) Terminal L of generator and parking brake switch. Symptom/Suspect Area See Headlight Does Not Light (Taillight Is Normal) Wire Harness ..... Headlight Does Not Light. (Taillight Does Not Light Up) Wire Harness ..... Only One Side Light Does Not Light Headlight Bulb ..... HEAD (LH) Or HEAD (LH-UPR) Fuse (E/G Room No. 2 JIB) (1) HEAD (RH) Or HEAD (RH-UPR) Fuse (E/G Room No. 2 J/B) (1) 2002 ACCESSORIES & EQUIPMENT Body Electrical/Troubleshooting - Corolla Bunker

Wire Harness ..... "Lo-Beam" Does Not Light Headlight Bulb ..... HEAD (LH) Or HEAD (LH-UPR) Fuse (E/G Room No. 2 JIB) (1) HEAD (RH) Or HEAD (RH-UPR) Fuse (E/G Room No. 2 JIB) (1) Headlight Control Relay (E/G Room No. 2 JIB) (2) Light Control Switch (2) Wire Harness ..... "Hi-Beam" Does Not Light Headlight Bulb ..... HEAD (LH) Or HEAD (LH-UPR) Fuse (E/G Room No. 2 JIB) (1) HEAD (RH) Or HEAD (RH-UPR) Fuse (E/G Room No. 2 JIB) () Headlight Control Relay (E/G Room No. 5 JIB) (2) Headlight Dimmer Switch (2) Wire Harness ..... "Flash" Does Not Light Headlight Bulb ..... HEAD (LH) Or HEAD (LH-UPR) Fuse (E/G Room No. 2 JIB) (1) HEAD (RH) Or HEAD (RH-UPR) Fuse (E/G Room No. 2JB) (1) Headlight Control Relay (E/G Room No. 5 JIB) (2) Headlight Dimmer Switch (2) Wire Harness ..... "Light-On Warning System" Does Not Operate GAUGE Fuse (I/P J/B) (1) DOME Fuse (E/G Room No. 2 JB) (1) HEAD (LH) Or HEAD (LH-UPR) Fuse (E/G Room No. 2 J/B) (1) HEAD (RH) Or HEAD (RH-UPR) Fuse (E/G Room No. 2 J/B) (1) Integration Relay (IIP J/B) (3) Door Courtesy Switch (Driver's) (4) Ignition Switch (4) Wire Harness ..... Headlight Does Not Light With Engine Running And Light Control SW In OFF Headlight Bulb ..... GAUGE Fuse (I/P J/B) (1) Wire Harness ..... Other Parts ..... (5) (1) FUSES & CIRCUIT BREAKERS (2) INSPECTION (3) INSPECTION 2002 ACCESSORIES & EQUIPMENT Body Electrical/Troubleshooting - Corolla Bunker
