TOYOTA MODEL YEAR(S) CAMRY 1999 -2001 KEY T- HARNESS IMMOBILIZER TOY KEY-1 TOY-1 TOYOTA'S TRANSPONDER ANTI-THEFT SYSTEM, Requires 791 Bypass Module and extra Ignition Key PART COLOR LOCATION DIAGRAM 12 VOLT CONSTANT WHITE (+) and WHITE/RED (+) IGNITION SWITCH HARNESS STARTER RED (+) IGNITION SWITCH HARNESS STARTER 2 N/A IGNITION 1 BLACK/YELLOW (+) IGNITION SWITCH HARNESS IGNITION 2 BLACK/RED (+) 1of 2 use either IGNITION SWITCH HARNESS IGNITION 3 N/A ACCESSORY/HEATER BLOWER 1 BLUE/RED (+) IGNITION SWITCH HARNESS ACCESSORY/HEATER BLOWER 2 N/A KEYSENSE BLUE/BLACK (-) IGNITION SWITCH HARNESS PARKING LIGHTS ( - ) GREEN (-) @ STEERING COLUMN HARNESS PARKING LIGHTS ( + ) GREEN (+) @ BOTTOM OF FUSE BOX See NOTE *1 POWER LOCK DARK BLUE/WHITE (TYPE B) See NOTE *5 @ ORANGE PLUG BOTTOM OF FUSEBOX POWER UNLOCK DARK BLUE (TYPE B) SEE NOTE *5 @ ORANGE PLUG BOTTOM OF FUSEBOX LOCK MOTOR WIRE BLUE/RED (+) @ ORANGE PLUG, BOTTOM OF FUSEBOX DOOR TRIGGER RED/WHITE (-) @ TOP OF FUSEBOX See NOTE *2

DOMELIGHT SUPERVISION USE DOOR TRIGGER,Requires Part #775 Relay TRUNK RELEASE N/A SLIDING POWER DOOR N/A HORN GREEN/BLACK (-) @ STEERING COLUMN HARNESS TACH BLACK (-) or GRAY (-) See NOTE *3 WAIT TO START LIGHT N/A BRAKE GREEN/WHITE (+) @ BOTTOM of FUSE BOX See NOTE *4 FACTORY ALARM DISARM DISARMS with KEYSENSE wire ANTI-THEFT TRANSPONDER ANTI- THEFT SYSTEM, REQUIRES 791 BYPASS MODULE AND EXTRA IGNITION KEY TRANSPONDER @ IGNITION SWITCH TUMBLER NOTES NOTE *1 the GREEN (+) Parking Light wire is located in a WHITE plug just below the fuses. NOTE *2 this wire is located in a 7-Pin plug on the TOP RIGHT side of the FUSE BOX NOTE *3 on the 4-Cylinder engine the BLACK wire is in a GRAY CONNECTOR located on the COIL, drivers side of the engine, on the V-6 use the GRAY wire located at the IGNITOR, located just in FRONT of the STRUT TOWER. NOTE *4 the BRAKE wire is located in a WHITE plug just below the fuses. NOTE *5 the LOCK and UNLOCK wires are 18 gauge and WILL ONLY METER while turning the Key in the PASSENGER DOOR KEY CYLINDER, they will not meter when using the power door lock switch.
