Workshop Manual
Alhambra 2011 ➤ , Altea 2004 ➤ ,
Altea 2009 ➤ , Altea XL 2007 ➤ ,
Altea XL 2009 ➤ ,
Altea XL Freetrack 2008 ➤ ,
Altea XL Freetrack 2009 ➤ ,
Córdoba 2003 ➤ , Exeo 2009 ➤ ,
Exeo ST 2009 ➤ , Ibiza 2002 ➤ ,
Ibiza 2008 ➤ , Ibiza ST 2010 ➤ ,
León 2006 ➤ , León 2009 ➤ ,
Toledo 2005 ➤ , Toledo 2009 ➤
Wheel rims and tyres
Edition 07.2010
Service
Service Department. Technical Information
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
List of Workshop Manual Repair Groups
Repair Group
44 - Wheels, tyres, vehicle geometry
Technical information should always be available to the foremen and mechanics, because their
careful and constant adherence to the instructions is essential to ensure vehicle road-worthiness and
safety. In addition, the normal basic safety precautions for working on motor vehicles must, as a
matter of course, be observed.
Service
All rights reserved.
No reproduction without prior agreement from publisher.
Copyright © 2015 Seat S.A D3E8028CCEB
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Contents
44 - Wheels, tyres, vehicle geometry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1 General information about wheel rims and tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Legal and technical conditions for modifying wheel rim and tyre combinations . . . . . . . . . . 2
2.1 Legal conditions for modifying wheel rim and tyre combinations . . . . . . . . . . . . . . . . . . . . 2
2.2 Technical conditions for modifying wheel rim and tyre combinations . . . . . . . . . . . . . . . . . . 3
2.3 Legal regulations for disposal of old tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Vehicle documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 TÜV certificate and vehicle registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2 COC-Document (EC certificate of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3 Determining the version code of the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.4 Official classification of the model types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Facts about tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1 Markings on tyre sidewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.2 Explanation of tyre markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3 Percent of speed-dependent loading capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.4 Code letter for speed category on the tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.5 Tyres with speed code letter V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.6 V-tyres with extra load (XL) specification/reinforced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.7 Ripples in sidewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.8 Tyre storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.9 Ageing of tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.10 Tyres with different tread . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.11 Tyres with special bead for starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.12 Winter tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.13 All-season tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.14 Snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Wear/performance characteristics of tyres (passenger cars) . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 Tyre properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3 Wear on high-speed tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.4 Factors influencing the useful life of tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.5 Driving style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.6 Tyre maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.7 Uniformly worn tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.8 Measuring tread depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.9 Lateral wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.10 Wear of the outer shoulder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.11 Centre wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.12 Diagonal wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6 Tyre rolling noises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2 Saw-tooth tread wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.3 Locking points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
7 Imbalance when driving due to the wheels / tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.1 Causes of imbalance when driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.2 Balancing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.3 Test drive prior to balancing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7.4 Balancing on a static wheel balancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.5 Vibration control system VAS 6230 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.6 Balancing with a Finish Balancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.7 Wheel (rim and tyre) radial and axial runout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.8 Radial and axial rim eccentricity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Alhambra 2011 ➤ , Altea 2004 ➤ , Altea 2009 ➤ , Altea XL 2007 ➤ , Alte ...
Wheel rims and tyres - Edition 07.2010
Contents i
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
7.9 Match balancing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.10 Flat spot on tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8 Vehicle pulls to one side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.2 Conicity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.3 Remedy for pulling to one side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
8.4 Specific replacement of wheels for tyres without prescribed direction of rotation . . . . . . . . 40
8.5 Specific replacement of wheels for tyres with prescribed direction of rotation and/or
asymmetric tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
9 Tyre damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.2 Construction of a radial ply tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.3 Impact damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
9.4 Cuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.5 Damage from foreign bodies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
9.6 Damage due to age . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.7 Scraping: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.8 Loss in tyre pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9.9 Tyre pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
9.10 Damage to tyres as a result of insufficient inflation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.11 Increase in temperature of an underinflated tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
9.12 Tyre damage resulting from mounting errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
10 Run flat tyres (tyres with emergency running characteristics) . . . . . . . . . . . . . . . . . . . . . . 53
10.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
10.2 Tyres with emergency running characteristics SST/runflat (self-supporting tyre) . . . . . . . . 54
10.3 Retrofitting/prerequisites for use of tyres with emergency running characteristics . . . . . . 56
10.4 Tyre pressure monitor (TPM+) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
10.5 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
11 Self-sealing tyre „ContiSeal“ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
11.1 Explanation of the ContiSeal tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
11.2 Handling the ContiSeal tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
12 Important information on rims . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
12.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
12.2 Layout of a wheel rim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
12.3 Specifications on disk wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
12.4 Care and maintenance of light alloy wheel rims . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
12.5 Repair of light alloy rims . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
12.6 The valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
13 Alternative systems for spare tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
13.1 Instructions for the use of emergency wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
13.2 Instructions for the use of breakdown repair kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
14 Mounting wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
14.1 Interchanging wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
14.2 Instructions for changing and fitting wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
15 Technical data on wheels for SEAT vehicle models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
16 Technical data on wheels for Altea 2004 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
17 Technical data on wheels for Altea 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
18 Technical data on wheels for Altea XL 2007 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
19 Technical data on wheels for Altea XL 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
20 Technical data on wheels for Altea XL Freetrack 2008 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
21 Technical data on wheels for Altea XL Freetrack 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
22 Technical data on wheels for Leon 2006 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
23 Technical data on wheels for Leon 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Alhambra 2011 ➤ , Altea 2004 ➤ , Altea 2009 ➤ , Altea XL 2007 ➤ , Alte ...
Wheel rims and tyres - Edition 07.2010
ii Contents
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
24 Technical data on wheels for Toledo 2005 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
25 Technical data on wheels for Toledo 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
26 Technical data on wheels for Ibiza 2002 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
27 Technical data on wheels for Cordoba 2003 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
28 Technical data on wheels for Ibiza 2008, Ibiza ST 2010 . . . . . . . . . . . . . . . . . . . . . . . . . . 93
29 Technical data on wheels for Exeo 2009, Exeo ST 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . 95
30 Technical wheel data for Alhambra 2011 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
31 Emergency tyres and rim for SEAT vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
32 Recommended conventional tyres or summer tyres for SEAT vehicle . . . . . . . . . . . . . . . . 100
32.1 Conventional tyres or summer tyres for Altea 2004 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
32.2 Conventional tyres or summer tyres for Altea 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
32.3 Conventional tyres or summer tyres for Altea XL 2007 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
32.4 Conventional tyres or summer tyres for Altea XL 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
32.5 Conventional tyres or summer tyres for Altea XL Freetrack 2008 . . . . . . . . . . . . . . . . . . . . 102
32.6 Conventional tyres or summer tyres for Altea XL Freetrack 2009 . . . . . . . . . . . . . . . . . . . . 103
32.7 Conventional tyres or summer tyres for Leon 2006 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
32.8 Conventional tyres or summer tyres for Leon 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
32.9 Conventional tyres or summer tyres for Toledo 2005 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
32.10 Conventional tyres or summer tyres for Toledo 2009 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
32.11 Conventional tyres or summer tyres for Ibiza 2002 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
32.12 Conventional tyres or summer tyres for Cordoba 2003 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
32.13 Conventional tyres or summer tyres for Ibiza 2008, Ibiza 2010 . . . . . . . . . . . . . . . . . . . . . . 107
32.14 Conventional tyres or summer tyres for Exeo 2009, Exeo ST 2009 . . . . . . . . . . . . . . . . . . 108
32.15 Conventional tyres or summer tyres for Alhambra 2011 . . . . . . . . . . . . . . . . . . . . . . . . . . 108
33 Recommended all-season tyre) for SEAT vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Alhambra 2011 ➤ , Altea 2004 ➤ , Altea 2009 ➤ , Altea XL 2007 ➤ , Alte ...
Wheel rims and tyres - Edition 07.2010
Contents iii
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
Alhambra 2011 ➤ , Altea 2004 ➤ , Altea 2009 ➤ , Altea XL 2007 ➤ , Alte ...
Wheel rims and tyres - Edition 07.2010
iv Contents
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
44 – Wheels, tyres, vehicle geometry
1 General information about wheel
rims and tyres
This instruction includes updated information above tyres and
wheel rims for passenger cars. Subjects such as troubleshooting
for tyres, alternative spare tyre systems and special tyres with
emergency running features are also listed.
This information is intended to supplement knowledge and expe‐
rience to make you capable of precise and reliable diagnosis in
the event of complaints and on questions regarding tyres and
rims. This will allow you to give your customers a clear and precise
explanation.
Tyres are high-tech products which have been adapted perfectly
to the conditions of use on modern vehicles based on new pro‐
duction processes and continuous quality control.
All tyres used on SEAT vehicles are checked by our technical
development department and matched to the specific vehicle
model. When changing tyres we recommend using only brands
approved by SEAT.
For maximum traffic safety it is necessary to ensure tyres have
balanced characteristics. For this purpose various conditions of
use such as speed ranges and maximum speed are matched to
the usual ambient conditions and road conditions.
Tyre care is of great importance for guaranteeing traffic safety,
driving comfort and performance as well as minimising numerous
types of stress to which the tyres are objected during their service
life.
Note
The causes for complaints and irregularities on tyres can vary
highly. For this purpose it is necessary to determine primarily
whether the causes for the specific complaint are the tyres them‐
selves or other vehicle components in the specific vehicle.
It is necessary to take into consideration that the driving charac‐
teristics of the tyres change as a result of normal tyre wear. This
wear can result in wheel noise or imbalance when driving which
cannot be eliminated in certain cases.
Wheel alignment
Adjustment of the wheel alignment is a very important factor for
achieving maximum tyre performance. See information concern‐
ing alignment in ⇒ Running gear, axles, steering; Rep. gr. 44 .
Mounting and removing tyres
Further information on mounting and removing tyres is given in
the guidelines ⇒ Running gear, axles, steering; Rep. gr. 44 .
Mounting and removing tyres with emergency running properties
Further information on mounting and removing tyres with emer‐
gency running properties is given in the guidelines ⇒ Running
gear, axles, steering; Rep. gr. 44 .
Alhambra 2011 ➤ , Altea 2004 ➤ , Altea 2009 ➤ , Altea XL 2007 ➤ , Alte ...
Wheel rims and tyres - Edition 07.2010
1. General information about wheel rims and tyres 1
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
2 Legal and technical conditions for
modifying wheel rim and tyre combi‐
nations
2.1 Legal conditions for modifying wheel rim
and tyre combinations
The rim/tyre combinations used on SEAT vehicles have been
matched for the specific models.
Caution
♦ We recommend using only these rim/tyre combinations.
Otherwise this poses a hazard for the vehicle safety and
traffic safety with corresponding danger of an accident.
♦ Any unauthorised modifications of the rim/tyre combina‐
tions or to the vehicle invalidate the guarantee. This also
applies for all damage caused by such action including
damage to other vehicles resulting from such modifica‐
tions.
The manufacturer receives a general model approval (TÜV cer‐
tificate) for the complete vehicle as well as for certain equipment
conversion possibilities.
The rims and tyres may only be changed under certain circum‐
stances. The following points must be taken into consideration:
♦ When the specific rim / tyre combination is listed in the TÜV
certificate together with the load index ⇒ page 7 and the
speed code letter ⇒ page 7 this rim/tyre combination can
be mounted on the vehicle without exception.
It is possible that all approved combinations are not listed in the
TÜV certificate according to the „homologation“.
♦ When the specific rim/tyre combination is not listed in the TÜV
certificate, request a certification of „significant retrofit“ from
the manufacturer. If the specific combination is already inclu‐
ded in the „homologation“ for the vehicle, the manufacturer
issues a certificate.
♦ When the specific rim/tyre combination is not listed in either
the TÜV certificate or the „homologation“ it is necessary to re‐
quest an approval study from the manufacturer. If the manu‐
facturer this combination, it is necessary for this new rim/tyre
combination to be included in the TÜV certificate for the vehi‐
cle.
These points relate to legal regulations applicable in the Europe‐
an Union and are not necessarily complete. Outside the European
Union other legal regulations may apply.
The rim/tyre combination recommended by SEAT and approved
by the Ministry for Industry Tourism and Commerce for the SEAT
vehicles (TÜV certificate) take into consideration the prerequi‐
sites which must be observed in this context. The use of Genuine
wheel rims on a vehicle to which they have not been assigned is
not permitted.
In the event of possible changes to the equipment given in the
corresponding lists, the combinations satisfy the requirements of
SEAT S.A. in regard to the driving characteristics and driving
Alhambra 2011 ➤ , Altea 2004 ➤ , Altea 2009 ➤ , Altea XL 2007 ➤ , Alte ...
Wheel rims and tyres - Edition 07.2010
2 Rep. gr.44 - Wheels, tyres, vehicle geometry
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A.
safety. They are the result of practical tests performed on the ba‐
sis of SEAT S.A. recommendations.
2.2 Technical conditions for modifying
wheel rim and tyre combinations
• It is not possible to authorise rim and tyre combinations or even
the exchange of rim equipment resulting from the trade of ac‐
cessories.
• The wheel rim/tyre combinations or alternative equipment
specified in the charts with the technical data for the wheels
on each vehicle ⇒ page 68 refer exclusively to Genuine
SEAT wheel rims.
• Tyres with the emergency running properties (for example run-
flat system) may be used only on rims with „extended hump“
⇒ page 55 and in combination with a tyre inflation pressure
indicator.
• When using the specified wheel/tyre combinations, the tyre
pressures shown should be maintained. The tyre inflation
pressure for conventional tyres or summer tyres is indicated
on the data sticker on the inside of the fuel tank flap on the
vehicle ⇒ Body Repairs; Rep. gr. 00 .
• When the information and conditions on the TÜV certificate
are observed, sufficient freedom of motion is guaranteed for
the tyres and rims relation to the wheel wells and other parts
of the vehicles and brakes under all operating conditions.
• If not otherwise specified, snow chains may only be fitted to
the drive wheels. On vehicles with all-wheel-drive it is only
permissible to install snow chains on the front wheels.
2.3 Legal regulations for disposal of old
tyres
Regulations for disposal of old tyres
The purpose of this regulation is to prevent improper disposal of
old tyres, provide legal guidelines for production and handling and
promote reduction, recycling and other types of utilisation in order
to protect the environment.
Producers and owners of old tyres are obligated to return old tyres
to the tyre manufacturer for recycling or to an approved disposal
point unless they are in a position to properly dispose of them
themselves In this case, the legal regulations for old tyre disposal
facilities apply.
Storage of old tyres in the facilities of the tyre manufacturer or tyre
owner may not exceed a period of one year or a quantity of over
30 tons.
