2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6 DIAGNOSTIC INFORMATION AND PROCEDURES DIAGNOSTIC STARTING POINT - VEHICLE Begin the system diagnosis with Diagnostic System Check - Vehicle . The Diagnostic System Check - Vehicle will provide the following information:  The identification of the control modules which are not communicating through the serial data circuit.  The identification of any stored diagnostic trouble codes (DTCs) and their status. The use of the Diagnostic System Check - Vehicle will identify the correct procedures to begin vehicle diagnosis. These must be performed before system DTC or symptom diagnosis. DIAGNOSTIC SYSTEM CHECK - VEHICLE Test Description The numbers below refer to the step numbers on the diagnostic table. 1: This step ensures that the battery and the vehicle primary power and ground systems are functioning correctly. 3: Lack of communication may be due to a particular malfunction of a serial data circuit. The information in Scan Tool does not Communicate with Class 2 Device will provide a list of modules and the associated data network no communication diagnostic link. 4: A module that is operating in the incorrect power mode based on key position may cause other vehicle symptoms and/or DTCs to set. The information in Power Mode Mismatch will correct the condition before checking for module DTCs or symptoms. 8: This step ensures that all data link communication DTCs are diagnosed before system level DTCs. 9: This step ensures that all electronic control unit (ECU) internal DTCs are diagnosed before other system level DTCs. 10: This step ensures that all device voltage DTCs are diagnosed before other system level DTCs. Diagnostic System Check - Vehicle Step Action Yes No Perform the following preliminary inspections:  Ensure that the battery is fully charged. Refer to Battery Inspection/Test .  Ensure that the battery cables are clean and tight. 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

1  Inspect for any open fuses.  Inspect the easily accessible systems or the visible system components for obvious damage or conditions that could cause the symptom.  Ensure that the grounds are clean, tight and in the correct location.  Inspect for aftermarket devices that could affect the operation of the system. Refer to Checking Aftermarket Accessories .  Search for applicable service bulletins. Did you find and correct the condition? System OK Go to Step 2 2 Install a scan tool. Does the scan tool power up? Go to Step 3 Go to Scan Tool Does Not Power Up 3 1. Turn ON the ignition, with the engine OFF. 2. Attempt to establish communication with all of the control modules on the vehicle. Refer to Scan Tool Does Not Communicate with Class 2 Device for the modules you should expect to observe. Does the scan tool communicate with all of the expected vehicle control modules? Go to Step 4 Go to Scan Tool Does Not Communicate with Class 2 Device 4 1. Access the Power Mode parameter on the scan tool. 2. Rotate the ignition switch, operate the ignition mode switch, through all positions while observing the Power Mode parameter. Refer to Body Control System Description and Operation for a list of the power mode states that correspond with each switch position. IMPORTANT:  To ensure that retained accessory power (RAP) mode is inactive, if equipped, open the drivers door during the following step.  The engine may start during the following step. Turn OFF the engine as soon as you have observed the crank power mode. 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

Does the Power Mode parameter reading on the scan tool match the ignition switch position for all switch positions? Go to Step 5 Go to Power Mode Mismatch 5 Attempt to start the engine. Does the engine crank? Go to Step 6 Go to Symptoms - Engine Electrical 6 Attempt to start the engine. Does the engine start and idle? Go to Step 7 Go to Engine Cranks but Does Not Run for the 3.5L (LX9) engine or Engine Cranks but Does Not Run for the 3.9L engine 7 Use the appropriate scan tool selections to obtain DTCs for each of the control modules.Does the scan tool display any DTCs? IMPORTANT: Do not clear any DTCs unless instructed by a diagnostic procedure. Go to Step 8 Go to Step 12 8 Does the scan tool display any DTCs that begin with a "U"? Go to Diagnostic Trouble Code (DTC) List - Vehicle Go to Step 9 9 Does the scan tool display DTC B1000, B1001, B1004, B1007, B1009, B1013, C0550, P0601, P0602, P0603, P0604, P0606, P062F, P2107, P2108, P2610? IMPORTANT: If any of these DTCs are displayed, diagnose them before diagnosing any other DTCs or symptoms. Go to Diagnostic Trouble Code (DTC) List - Vehicle Go to Step 10 10 Does the scan tool display DTC B1327, B1328, B1370, B1390, B1420, C0899, C0900, P0562, P0563? IMPORTANT: If any of these DTCs are displayed, diagnose them before diagnosing any other DTCs or symptoms. Go to Diagnostic Trouble Code (DTC) List - Vehicle Go to Step 11 IMPORTANT: If any of the remaining DTCs are powertrain DTCs, select Capture Info in order to store the powertrain DTC information with a scan tool. 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

DIAGNOSTIC TROUBLE CODE (DTC) LIST - VEHICLE This master DTC list includes all applicable DTCs in alphanumeric order with descriptors. Diagnostic Trouble Code (DTC) List - Vehicle 11 If multiple DTCs are stored, diagnose the DTCs in the following order: 1. Component level DTCs, such as sensor DTCs, solenoid DTCs and relay DTCs. 2. System level DTCs, such as misfire DTCs, evaporative emission (EVAP) system DTCs and fuel trim DTCs. Diagnose the remaining DTCs. Go to Diagnostic Trouble Code (DTC) List - Vehicle - 12 Is the customers concern with inspection/maintenance (I/M) testing? Go to Inspection/Maintenance (I/M) System Check for the 3.5L (LX9) engine or Inspection/Maintenance (I/M) System Check for the 3.9L engine Go to Symptoms - Vehicle DTC DTC Descriptor Module that Sets the DTC Diagnostic Procedure B0005 In Park Switch/Signal Circuit BCM DTC B0005 B0012 Passenger Frontal Deployment Loop Stage 2 Resistance Low SDM DTC B0012, B0013, B0014, B0016, B0017 or B0018 B0013 Passenger Frontal Deployment Loop Stage 2 Open SDM DTC B0012, B0013, B0014, B0016, B0017 or B0018 B0014 Passenger Frontal Deployment Loop Stage 2 Voltage Out of Range SDM DTC B0012, B0013, B0014, B0016, B0017 or B0018 B0016 Passenger Frontal Deployment Loop Stage 1 Resistance Low SDM DTC B0012, B0013, B0014, B0016, B0017 or B0018 B0017 Passenger Frontal Deployment Loop Stage 1 Open SDM DTC B0012, B0013, B0014, B0016, B0017 or B0018 B0018 Passenger Frontal Deployment Loop Stage 1 Voltage Out of Range SDM DTC B0012, B0013, B0014, B0016, B0017 or B0018 B0022 Driver Frontal Deployment Loop Stage 1 Resistance Low SDM DTC B0022, B0024, B0026, B0042, B0043 or B0044 B0024 Driver Frontal Deployment Loop Stage 1 Voltage Out of Range SDM DTC B0022, B0024, B0026, B0042, B0043 or B0044 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

B0026 Driver Frontal Deployment Loop Stage 1 Open SDM DTC B0022, B0024, B0026, B0042, B0043 or B0044 B0028 Right Front Side Deployment Loop Resistance Low SDM DTC B0028, B0029 or B0030 B0029 Right Front Side Deployment Loop Open SDM DTC B0028, B0029 or B0030 B0030 Right Front Side Deployment Loop Voltage Out of Range SDM DTC B0028, B0029 or B0030 B0040 Left Front Side Deployment Loop Resistance Low SDM DTC B0040, B0041 or B0045 B0041 Left Front Side Deployment Loop Open SDM DTC B0040, B0041 or B0045 B0042 Driver Frontal Deployment Loop Stage 2 Resistance Low SDM DTC B0022, B0024, B0026, B0042, B0043 or B0044 B0043 Driver Frontal Deployment Loop Stage 2 Voltage Out of Range SDM DTC B0022, B0024, B0026, B0042, B0043 or B0044 B0044 Driver Frontal Deployment Loop Stage 2 Open SDM DTC B0022, B0024, B0026, B0042, B0043 or B0044 B0045 Left Front Side Deployment Loop Voltage Out of Range SDM DTC B0040, B0041 or B0045 B0051 Deployment Commanded SDM DTC B0051 B0053 Deployment Commanded with Loop DTCs Present SDM DTC B0053 B0057 Right Front Pretensioner Deployment Loop Resistance Low SDM DTC B0057, B0058 or B0059 B0058 Right Front Pretensioner Deployment Loop Open SDM DTC B0057, B0058 or B0059 B0059 Right Front Pretensioner Deployment Loop Voltage Out of Range SDM DTC B0057, B0058 or B0059 B0064 Left Front Pretensioner Deployment Loop Resistance Low SDM DTC B0064, B0065 or B0066 B0065 Left Front Pretensioner Deployment Loop Open SDM DTC B0064, B0065 or B0066 B0066 Left Front Pretensioner Deployment Loop Voltage Out of Range SDM DTC B0064, B0065 or B0066 B0077 Driver Side Impact Sensor (SIS) Performance SDM DTC B0077, B0078, B0079, B0080, B0081 or B0082 B0078 Passenger Side Impact Sensor (SIS) Performance SDM DTC B0077, B0078, B0079, B0080, B0081 or B0082 B0079 Incorrect Driver Side Impact Sensor (SIS) Installed SDM DTC B0077, B0078, B0079, B0080, B0081 or B0082 Discard Driver Side Impact Sensor DTC B0077, B0078, B0079, B0080, 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

B0080 (SIS) SDM B0081 or B0082 B0081 Incorrect Passenger Side Impact Sensor (SIS) Installed SDM DTC B0077, B0078, B0079, B0080, B0081 or B0082 B0082 Discard Passenger Side Impact Sensor (SIS) SDM DTC B0077, B0078, B0079, B0080, B0081 or B0082 B0092 Passenger Presence System Performance SDM DTC B0092 B0098 Passenger Presence System Configuration Error SDM DTC B0098 B0100 Front End Sensor 1 Performance SDM DTC B0100, B0101, B0102, B0103, B0104 or B0105 B0101 Discard Front End Sensor 1 SDM DTC B0100, B0101, B0102, B0103, B0104 or B0105 B0102 Incorrect Front End Sensor 1 Installed SDM DTC B0100, B0101, B0102, B0103, B0104 or B0105 B0103 Front End Sensor 2 Performance SDM DTC B0100, B0101, B0102, B0103, B0104 or B0105 B0104 Discard Front End Sensor 2 SDM DTC B0100, B0101, B0102, B0103, B0104 or B0105 B0105 Incorrect Front End Sensor 2 Installed SDM DTC B0100, B0101, B0102, B0103, B0104 or B0105 B0109 Left Rear Side Deployment Loop Resistance Low SDM DTC B0109, B0110 or B0111 B0110 Left Rear Side Deployment Loop Ope SDM DTC B0109, B0110 or B0111 B0111 Left Rear Side Deployment Loop Voltage Out of Range SDM DTC B0109, B0110 or B0111 B0112 Right Rear Side Deployment Loop Resistance Low SDM DTC B0109, B0110 or B0111 B0113 Right Rear Side Deployment Loop Open SDM DTC B0109, B0110 or B0111 B0114 Right Rear Side Deployment Loop Voltage Out of Range SDM DTC B0109, B0110 or B0111 B0160 Outside Air Temperature Sensor Circuit Low IPC DTC B0160 B0161 Outside Air Temperature Sensor Circuit High IPC DTC B0161 B0238 Air Flow Control 1 Circuit HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 Air Flow Control 1 Circuit HVAC Control DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

B0239 Performance Module B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0248 Air Flow Control 3 Circuit HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0249 Air Flow Control 3 Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0251 Air Flow Control 3 Circuit Feedback Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0268 Air Flow Control 7 Circuit HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0269 Air Flow Control 7 Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0283 Electric Rear Defrost Circuit BCM DTC B0283 B0408 Temperature Control Circuit HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0409 Temperature Control Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0414 Temperature Control Feedback Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

B0418 Temperature Control 2 Circuit HVAC Control Module B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0419 Temperature Control 2 Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0424 Temperature Control 2 Feedback Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0428 Temperature Control 3 Circuit HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0429 Temperature Control 3 Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0434 Temperature Control 3 Feedback Circuit Performance HVAC Control Module DTC B0238, B0239, B0248, B0249, B0251, B0268, B0269, B0408, B0409, B0414, B0418, B0419, B0424, B0428, B0429, B0434, B3531, B3532, B3747, B3749 or B3782 B0931 Compass Sensor Circuit IPC DTC B0931 B0935 Compass Sensor Circuit Open IPC DTC B0935 B1000 Electronic Control Unit (ECU) Performance BCM, DRR, DVD, IPC, LHPSDM, MSM, PCM, Radio, RHPSDM, SDM, VCIM DTC B1000 IPC DTC B1000 B1001 Option Configuration Error PCM DTC B1001 DRR, Radio DTC B1001 SDM DTC B1001 VCIM DTC B1001 B1004 Electronic Control Unit Identification Circuit Radio, VCIM DTC B1004 B1007 EEPROM Read/Write Error PCM, Radio DTC B1007 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

B1009 EEPROM Checksum Mismatch PK3 DTC B1009 B1011 System Disabled Information Stored LHPSDM, RHPSDM DTC B1011 B1013 Calibration Read Only Memory (ROM) Checksum Error HVAC, PCM DTC B1013 B1259 Antenna Ground Circuit DRR DTC B1259 B1271 Theft Locked Radio, DRR DTC B1271 B1292 Power Sliding Door Motor Control Circuit LHPSDM, RHPSDM DTC B1292 B1293 Power Sliding Door Clutch Control Circuit LHPSDM, RHPSDM DTC B1293 B1294 Power Sliding Door Detent Switch Circuit LHPSDM, RHPSDM DTC B1294 B1327 Device Power Circuit Low BCM DTC B1327 IPC DTC B1327 B1328 Device Power Circuit High BCM DTC B1328 IPC DTC B1328 B1370 Device Ignition 1 (ON and START) Circuit BCM DTC B1370 B1380 Device Ignition ACCESSORY Circuit BCM DTC B1380 B1385 Device Ignition START Circuit BCM DTC B1385 B1390 Device Voltage Reference Input Circuit BCM DTC B1390 B1395 Device Voltage Reference Output Circuit LHPSDM, RHPSDM DTC B1395 B1420 Device Voltage BCM DTC B1420 PSDM DTC B1420 B1428 Ignition-Switched Power Relay 1 Circuit BCM DTC B1428 B1433 Ignition-Switched Power Relay 2 Circuit BCM DTC B1433 B1475 Retained Accessory Power Circuit BCM DTC B1475 B1516 Battery Current Sensor Performance BCM DTC B1516 B1530 Discard Passenger Presence System 1 SDM DTC B1530 B1735 Seat Front Up Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 B1740 Seat Front Down Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 B1745 Seat Rear Up Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6

B1750 Seat Rear Down Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 B1755 Seat Assembly Forward Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 B1760 Seat Assembly Rearward Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 B1770 Seat Motor 2 (assembly horizontal) Circuit MSM DTC B1770, B1775, B1780, B1785, B1790, B1805 or B2415 B1775 Seat Motor 3 (front vertical) Circuit MSM DTC B1770, B1775, B1780, B1785, B1790, B1805 or B2415 B1780 Seat Motor 4 (rear vertical) Circuit MSM DTC B1770, B1775, B1780, B1785, B1790, B1805 or B2415 B1785 Seat Motor 5 (recline) Circuit MSM DTC B1770, B1775, B1780, B1785, B1790, B1805 or B2415 B1815 Seat Recline Forward Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 B1820 Seat Recline Rearward Switch Circuit MSM DTC B1735, B1740, B1745, B1750, B1755, B1760, B1815 or B1820 B1825 Seat Recline Position Sensor Circuit MSM DTC B1825, B1850, B2355, B2365 or B2375 B1920 Seat Heater Timer Circuit BCM DTC B1920 or B2165 B1925 Seat Heater Sensor Circuit BCM DTC B1925 or B2170 B2165 Seat Heater Timer Circuit BCM DTC B1920 or B2165 B2170 Seat Heater Sensor BCM DTC B1925 or B2170 B2355 Seat Front Vertical Position Sensor Circuit MSM DTC B1825, B1850, B2355, B2365 or B2375 B2365 Seat Rear Vertical Position Sensor Circuit MSM DTC B1825, B1850, B2355, B2365 or B2375 B2375 Seat Assembly Horizontal Position Sensor Circuit MSM DTC B1825, B1850, B2355, B2365 or B2375 B2455 Cellular Phone Microphone Circuit Malfunction VCIM DTC B2455 B2470 Cellular Phone Antenna Circuit Malfunction VCIM DTC B2470 B2476 Cellular Phone Select Service Switch Malfunction (3-button assembly) VCIM DTC B2476 B2482 Cellular Phone Select Switch Range/Performance VCIM DTC B2482 B2483 GPS Sensor Circuit Low VCIM DTC B2483 or B2484 B2484 GPS Sensor Circuit Open VCIM DTC B2483 or B2484 B2508 Left Front Seat Heater Relay Circuit BCM DTC B2508 or B2509 2006 Chevrolet Uplander 2006 ACCESSORIES & EQUIPMENT Vehicle DTC Information - Terraza, Uplander & Montana SV6
